WARNING
FAILURE TO COMPLY WITH THE
FOLLOWING WARNINGS COULD RESULT
IN PERSONAL INJURY OR PROPERTY
DAMAGE
SHOCK HAZARD
• Disconnect electrical power supplies before
installation or servicing.
FIRE HAZARD
• Do not exceed specied voltages. Only
power transformers should be connected
to line voltage. All other wires shall only
connect to low voltage (24 VAC). Safely
route and secure all wiring after installation.
• Protect powered devices from direct
contact with water. Replace any device
exposed to water. (Does not apply to
Supply Air Sensors, Return Air Sensors,
Suction Line Sensors, Liquid Line Sensors.)
• Installer must be a qualified technician, familiar
with installation and service of HVAC equipment,
associated wiring, and electrical codes.
• Follow all local and national
codes and ordinances.
• The Sensi Predict power transformers are
designed for connection to 120VAC or 240VAC volt
electric powers within existing HVAC chassis only.
• After installation or replacement, follow the HVAC
manufacturer’s recommended instructions to
ensure proper operation of the HVAC equipment.
• Labeling any HVAC wires that need
to be disconnected during the
installation is recommended.
The Sensi™ Predict kit is designed for conventional, residential HVAC equipment (furnace, AC, & heat
pumps) in homes that have Internet access. The Sensi Predict system acts as a monitor only and does not
provide any HVAC control.
As the installing technician, it is your responsibility to know what requirements, hazards and precautions
exist, and to install the monitoring system in a safe manner.
Do not alter the mounting of parts within the HVAC equipment.
INDOOR KIT INSTALLATION & ACTIVATION GUIDE
0037-7660002
The Sensi Predict Contractor PRO Portal can be accessed at sensipredictpro.com
For login support, contact your office administrator. For support within the PRO Portal, call 1-877-424-1715.
OPERATING CONDITION:
Operating Temp -40°F to 158°F
Storage Temp -40°F to 176°F
ELECTRICAL RATING:
Line Voltage Inputs 90-132VAC / 180-
264VAC
Frequency 60Hz
Control Line Voltage 24VAC at 60Hz
CONTRACTOR SUPPORT:
18774241715
Sensi Predict Data Hub
Transformer Harness
120VAC
Or
Transformer Harness
240VAC
Power Transformer
120VAC/240VAC – 24VAC
Main Cable
(Keyed)
Supply Air Sensor
Black Wire Return Air Sensor
Gray Wire
Suction Line Sensor
Yellow Wire Liquid Line Sensor
Red Wire
Current Sensor
SENSI™PREDICT INSTALL KIT INCLUDES:
INDOOR KIT
CABLE & SENSORS
Cable Ties
(15 pcs.)
Plastic Clips
(8 pcs.) Refrigerant Line Sensor Holder
(2 pc.)
Grommet
(1 pc.)
For Main Cable
Wire Nuts
(2 pcs.) 8x1" Screws
(2 pcs.) 8x¾" Screws
(2 pcs.) 8x½" Screws
(8 pcs.)
PARTS
Powerline Extender KitGatewayCondensate MonitorOutdoor Sensor Kit
Comfort Monitoring
OPTIONAL ACCESSORIES
OUTDOOR KIT
RSDA - 101
E000-0000-00A6-EB87
1. SETUP GATEWAY* CONFIRM WIFI AND NOTE EQUIPMENT DATA
1. POWER THE SENSI PREDICT CONFIGURED GATEWAY
• Connect the Gateway power adapter to an outlet near the existing home router.
• Ensure the Gateway powers up.
2. CONNECT THE GATEWAY TO THE EXISTING HOME ROUTER
• Connect one end of the provided network cable to an open port on the Gateway.
• Connect the other end of the network cable to any open, numbered LAN port on
the existing home router.
NOTE: If homeowner has a cable or DSL modem with only one Network (LAN) port and no router, then a router
must be purchased and installed by the homeowner before install.
3. CHECK FOR WIRELESS SIGNAL AT THE FURNACE/AIR HANDLER
• Though the wireless network may be seen through your mobile phone or
tablet’s available Wi-Fi networks, it is important to check the desired wireless
signal strength using a mobile app showing “Received Signal Strength
Indication” or RSSI.
–For Android devices, use an app called Wifi Analyzer.
–For iOS (Apple) devices, use an app called Airport Utility and enable
the Wi-Fi scanner function through the settings app.
• Confirm the Gateway’s RSSI level stays in a range of -70 to 0 dBm at proposed
Data Hub mounting location.
• If the wireless signal level at desired Data Hub mounting location is too low,
you may need to consider alternate Data Hub mounting locations or Powerline
Extenders and Gateway to relocate a wireless network closer to Data Hub.
For more information on using these free apps or Powerline Extenders, visit
the Support section of the Sensi Predict Pro Portal, or call 1-877-424-1715.
4. WRITE DOWN THE ID FROM THE DATA HUB; YOU WILL NEED THIS
DURING ACTIVATION
The Data Hub ID (located on the back side, just above the barcode) has 16 alpha-
numeric characters.
You may also take a photo to reference later in the install.
INDOOR EQUIPMENT DETAILS
System Type
Brand Year of Install
Model Number
Serial Number
Output KBTU KW
Filter Type
Filter Size H= W= T=
OUTDOOR EQUIPMENT DETAILS
System Type
Brand Year of Install
Model Number
Serial Number
Refrigerant Type
SEER Rating
Tonnage
*Gateway is an optional accessory–if not used jump to step 3
3. INSTALL OPTIONAL OUTDOOR SENSOR KIT
4. PAIRING
1. WPS PAIRING (all steps must be completed within 2 minutes)
• Press the WPS button located on the gateway or have the homeowner start
the WPS push-button pairing process for their wireless network (if supported
otherwise go to step 2.)
• Press and hold for 5 seconds the pairing button on the Sensi Predict Data Hub
– The Data Hub is ready when the green and red LEDs remain solid, while the
amber LED blinks
– If the Data Hub LEDs don’t indicate you are in the correct mode, re-try
depressing for 5 seconds the pairing button on the Data Hub
2. DIRECT PAIRING
• If WPS Pairing fails or is not available, use the Sensi Predict Pairing app to
directly pair to desired wireless network.
•  Instructions are contained within the app.
NOTE: Once Data Hub is placed into direct pairing mode, it will stay in that mode for up to 5 minutes
or until it receives wireless network credentials through the pairing app.
3. CONFIRM CONNECTION ON DATA HUB
• Pairing may take a couple minutes to complete.
• Once a connection has been established, only the amber and green LEDs will be lit.
• The amber LED may flicker slightly to indicate data is being sent to the Sensi
Predict servers.
NOTE: If there is any other light configuration you may need to repeat the process, or an Internet
service problem may exist. If after three attempts you are unable to correctly pair the Data Hub,
call 1-877-424-1715 for assistance.
BLINKING
PAIRING
BUTTON
PAIRING
For more in-depth troubleshooting,
visit the Support section of the
Sensi Predict Pro Portal or call
1-877-424-1715.
BLINKING
BLINKING
BLINKING
BLINKING
SUCCESSFULLY
CONNECTED DATA HUB
Green and amber lights on.
• Amber light may flicker.
POWERED ON /
UNPAIRED
This display appears when:
• Data Hub is first
powered on.
• After the Data Hub
has been reset.
• There is no Wi-Fi
connection.
• Wi-Fi signal too weak.
DIRECT PAIRING /
NOT CONNECTED
This display appears when:
• Data Hub is in “Soft AP”
mode for direct pairing
to homeowner’s Wi-Fi.
• Mobile device being
used to pair needs
to stay within range
until pairing process
completed.
WI-FI CONNECTED /
NO SERVER
This display appears when:
• Wi-Fi is connected, but
data is not being
communicated with the
Sensi Predict servers.
• Call for assistance to
determine best next step.
1-877-424-1715
5. TROUBLESHOOTING
6. ACTIVATION
• Complete the system activation process through the Contractor Portal– sensipredictpro.com
7. RUN A PERFORMANCE CHECK REPORT
• Verify proper equipment operation and sensor installation, system must run for 10 minutes.
• View recent data or run an additional Performance Check through the Contractor Portal
by pulling up the homeowner’s account and manually running reports
• Leave behind installation sheets/guides.
PAIRED
PAIRING
BUTTON BLINKING
(instructions included with kit)
