Emerson CF730 User manual

LIMITED WARRANTY
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and
materials. You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for a lifetime of your ceiling fan. All other components and accessories are
covered by this warranty for one year from the date you purchased your ceiling fan. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at no charge to you.
If repair of the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson will refund
the actual purchase price of your fan. WE WILL SHIP THE REPAIRED PRODUCT OR REPLACEMENT TO YOU AT NO CHARGE, BUT YOU ARE
RESPONSIBLE FOR ALL COSTS OR REMOVAL, REINSTALLATION AND SHIPPING OF THE PRODUCT TO EMERSON ELECTRIC CO.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR
OTHER PROOF OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products, Division
of Emerson Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air
Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover any defects, malfunctions
or failures caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties apply, and
no employee, agent, dealer or other person is authorized to give any warranties on behalf of Emerson Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS NOT
RESPONSIBLE FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages include but are
not limited to such damages as loss of time and loss of use. Consequential damages include but are not limited to the cost of repairing or
replacing other property which was damaged if this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply
to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Part No. F40BP73150000 Form No. BP7315
U.L. Model No.: CF730
READ AND SAVE THESE INSTRUCTIONS
FLORISSANT™
Net Weight: 28.8 Lbs.
52” Ceiling Fan
Owner's Manual
CF730AGW00 CF730WB00 CF730BZH00
Model No.
BP7315 Florissant 3/7/06 8:42 AM Page 1

2
WARNING: To avoid fire, shock, and serious personal injury, follow these
instructions. Safety Instructions
1. Read your owner’s manual carefully and keep it for future reference.
2. Before servicing or cleaning unit, switch power off at service panel and lock
service panel disconnecting means to prevent power from being switched on
accidentally. When the service disconnecting means cannot be locked,
securely fasten a warning device, such as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the
fan. Always turn off the power to the ceiling fan before servicing.
4. Do not put anything into the fan blades while they are turning.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off at the fuse box before
wiring, and do not operate fan without blades.
2. The installation is to be in accordance with the National Electrical Code,
ANSI/NFPA 70-1999 and Local Codes. Use the National Electrical Code if Local
Codes do not exist. The ceiling fan must be grounded as a precaution against
possible electrical shock. Electrical installation should be made or approved
by a licensed electrician.
3. The outlet box and joist must be securely mounted and capable of reliably
supporting at least 50 pounds. Use only U.L. outlet boxes listed as
“Acceptable for Fan Support”, and use the mounting screws provided with the
outlet box. Most outlet boxes commonly used for support of light fixtures are
not acceptable for fan support and may need to be replaced. Consult a
qualified electrician if in doubt.
4. The fan must be mounted with the fan blades at least 7 feet from the floor to
prevent accidental contact with the fan blades.
5. Follow the recommended instructions for the proper method of wiring your
ceiling fan. If you do not know enough about electrical wiring, have your fan
installed by a licensed electrician.
WARNING: To reduce the risk of fire or electric shock, this fan should only be
used with fan speed control Model No. UC7067RC, manufactured by Rhine
Electric Co., Ltd.
NOTE: This fan is suitable for use with solid-state speed controls.
WARNING: This product is designed to use only those parts supplied with this
product and/or any accessories designated specifically for use with this product
by Emerson Electric Co. Substitution of parts or accessories not designated for
use with this product by Emerson Electric Co. could result in personal injury or
property damage.
WARNING: To reduce the risk of personal injury, do not bend the blade flange
when installing the blade flanges, balancing the blades or cleaning the fan. Do not
insert foreign objects in between rotating fan blades.
WARNING: To reduce the risk of electrical shock, this fan must be installed with
an isolating wall control/switch.
!WARNING
DATE CODE:
The date code of this fan may be found on the box, stamped in ink on a white label.
You should record this data above and keep it in a safe place for future use.
BP7315 Florissant 3/7/06 8:42 AM Page 2

3
This Manual is Designed to Make it as Easy as Possible for You to
Assemble, Install, Operate and Maintain Your Ceiling Fan
Do not install or use fan if any part is
damaged or missing. Call Toll-Free:
1-800-654-3545
!WARNING
This product is designed to use only
those parts supplied with this product
and/or any accessories designated
specifically for use with this product by
Emerson Electric Co. Substitution of
parts or accessories not designated for
use with this product by Emerson Electric
Co. could result in personal injury or
property damage.
!WARNING
Tools Needed for Assembly
One Phillips head screwdriver
One 1/4” blade screwdriver
One 7/16” box or open end wrench or
ratchet wrench
One wire stripper
One stepladder
Three wire connectors (supplied)
Materials
Wiring, outlet box and box connectors
must be of type required by the local code.
The minimum wire would be a 3-conductor
(2-wire with ground) of the following sizes:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
Before assembling your ceiling fan, refer
to section on proper method of wiring
your fan (page 5). If you feel you do not
have enough wiring knowledge or
experience, have your fan installed by a
licensed electrician.
!WARNING
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each
step is completed, place a check mark in the box. This will insure that all steps
have been completed and will be helpful in finding your place should you be
interrupted.
NOTE: If you are uncertain of part
description, refer to exploded view.
a. Fan housing
b. One mounting plate
c. One motor assembly
d. Five fan blades
e. Five blade flanges with captive
screws
f. One light fitter assembly
g. One lower glass
h. One SW101 Fan/Light Wall Control
(transmitter and receiver)
1. Open styrofoam unit containing fan.
Remove top half of styrofoam unit.
Remove parts and check to see that
you have received the following parts:
1. Sixteen M5 x 6mm washer
head screws
2. Five M5 x 12mm pan head
screws with lockwashers
3. One M6 x 14mm pan head
screw with lockwasher (extra
flange-to-motor hub screw/
lockwasher)
4. Four 1/4-20 hex locknuts
5. Four 1/4” flat washers
6. Three wire connectors
7. One receiver bracket
8. One pull chain pendant
9. One coupling
HI
MED
LOW
FANOFF
LIGHT
ONOFF
EMERSON
H
G
F
B
C
A
E
D
I
i. One loose pars bag containing:
BP7315 Florissant 3/7/06 8:42 AM Page 3

4
Your new ceiling fan will require a
grounded electrical supply line of 120 volts
AC, 60 Hz, 15 amp circuit.
The outlet box must be securely anchored
and capable of withstanding a load of at
least 50 pounds.
To reduce the risk of fire, electric shock,
or personal injury, mount fan to outlet box
marked “Acceptable for Fan Support”,
and use screws supplied with outlet box.
Most outlet boxes commonly used for
support of light fixtures are not
acceptable for fan support and may need
to be replaced. Consult a qualified
electrician if in doubt.
!WARNING
If your fan is to replace an existing ceiling
light fixture, turn electricity off at the main
fuse or circuit breaker box at this time and
remove the existing light fixture.
Electrical Requirements
How to Install Your
Ceiling Fan
Turning off wall switch is not sufficient.
To avoid possible electrical shock, be
sure electricity is turned off at the main
fuse or circuit breaker box before wiring.
All wiring must be in accordance with
National and Local codes and the ceiling
fan must be properly grounded as a
precaution against possible electrical
shock.
!WARNING
IMPORTANT: Your ceiling fan will not
function properly, and may be
damaged, if used with any wall dimmer
switch or control other than the
Emerson Electric Fan/Light Wall
Control supplied with the fan, or an
optional Emerson Electric SR100
Remote Control.
General
Your Emerson ceiling fan comes supplied
with a Fan/Light Wall Control which
consists of a wall control (transmitter) and
a remote control receiver mounted under
the fan housing. This system allows you to
regulate your ceiling fan speed and light
intensity.
NOTE: An optional Emerson Electric
SR100 Remote Control may also be
used to control your ceiling fan.
Ceiling Fan Procedures
NOTE: Place the parts from the loose
parts bags in a small container to keep
them from being lost.
Turning off wall switch is not sufficient.
To avoid possible electrical shock, be
sure electricity is turned off at the main
fuse or circuit breaker box before wiring.
All wiring must be in accordance with
National and Local codes and the ceiling
fan must be properly grounded as a
precaution against possible electrical
shock.
!WARNING
IMPORTANT: Before installing your
ceiling fan, refer to sections “Setting
Operating Frequency of Wall Control
and Receiver” and “Installation of Wall
Control”, page 9. These sections
instruct you how to: a) Set the
operating frequency of the fan/light
wall control and the remote control
receiver; and b) Install the fan/light wall
control in the wall box. You will then be
ready to proceed with the assembly
and installation of your ceiling fan, as
follows:
2. Remove the fan assembly from the
protective plastic bag. Place the fan
assembly into the upper foam pad with
the lead wires up.
1. Remove and retain the pan head screw
with lockwasher from the mounting
plate (Figure 1). Engage the tab on the
end of the receiver bracket (supplied)
with the slot in the mounting plate and
position the receiver on the plate.
IMPORTANT: The flat side of the
receiver must be placed against the
mounting plate, and the receiver wires
must be to the right of the bracket as
shown in Figure 1.
BP7315 Florissant 3/7/06 8:42 AM Page 4

5
3. Pass the outlet box supply wires (black,
white and ground) through the center
hole in the mounting plate and securely
attach the mounting plate to the outlet
box using the screws supplied with the
outlet box (Figure 3).
NOTE: In order for the fan housing to fit
flush with the ceiling, the outlet box
must not protrude below the ceiling.
4. Carefully lift the fan motor assembly
and engage the slot in the motor
bracket with the hook on the mounting
plate so that it is securely suspended
(Figure 4).
The fan must be hung with at least 7'
of clearance from floor to blades
(Figure 2).
!WARNING
PAN HEAD SCREW
WITH LOCKWASHER
RECEIVER
RECEIVER
BRACKET
CODE
SWITCH
MOUNTING
PLATE
Figure 1
SCREWS (SUPPLIED
WITH OUTLET BOX)
MOUNTING
PLATE
OUTLET BOX
Figure 3
MOUNTING PLATE
HOOK
MOTOR
BRACKET
FAN MOTOR
ASSEMBLY
Figure 4
The outlet box and joist must be
securely mounted and capable of
supporting at least 50 lbs. Use only a
U.L. outlet box listed as “Acceptable
for Fan Support”.
!WARNING
To reduce the risk of fire, electric
shock, or personal injury, mount fan
to outlet box marked “Acceptable for
Fan Support”, and use screws
supplied with outlet box. Most outlet
boxes commonly used for support of
light fixtures are not acceptable for
fan support and may need to be
replaced. Consult a qualified
electrician if in doubt.
!WARNING If you feel that you do not have enough
electrical wiring knowledge or
experience, have your fan installed by a
licensed electrician.
2. Swing the receiver bracket down over
the receiver (Figure 1). Position the
receiver so that the code switch is not
covered by the bracket, then securely
reinstall the pan head screw with
lockwasher (previously removed).
CEILING
FLOOR
AT LEAST
7'
Figure 2
BP7315 Florissant 3/7/06 8:42 AM Page 5

6
NOTE: Make all wiring connections
using wire connectors (supplied). Make
sure that all connections are tight,
including ground, and that no bare wire
is visible at the wire connectors, except
for the ground wire.
5. Refer to Figures 5 and 6 and connect
the receiver wires to the supply wires
and the fan motor wires as follows:
a. Securely connect the green grounding
wire from the motor bracket to the
supply grounding conductor (this may
be a bare wire or a wire with green
insulation).
Check to see that all connections are
tight, including ground, and that no
bare wire is visible at the wire
connectors, except for the ground
wire. Do not operate fan until blades
are in place. Noise and fan damage
could result.
!WARNING
b. Securely connect the supply white
(neutral) wire to the receiver white
(AC IN N) wire.
c. Securely connect the supply black wire
(hot) wire to the receiver black (AC IN
L) wire.
d. Securely connect the fan motor white
wire to the receiver white (TO MOTOR
N) wire.
e. Securely connect the fan motor black
wire to the receiver red (TO MOTOR L)
wire.
f. Securely connect the fan motor blue
wire to the receiver blue (FOR
LIGHT) wire.
SUPPLY WHITE
(NEUTRAL) AND
RECEIVER WHITE
WIRES
SUPPLY BLACK
(HOT) AND
RECEIVER BLACK
WIRES
GREEN WIRE
FROM MOTOR
BRACKET
RECEIVER AND
MOTOR BLUE
WIRES
RECEIVER AND
MOTOR WHITE
WIRES
RECEIVER
RED WIRE
FAN BLACK
WIRE
GROUND WIRE
TO MOTOR L
TO MOTOR N
FOR LIGHT
AC IN L
AC IN N
RECEIVER
Figure 5
CAUTION: To reduce the risk of
electrical shock, disconnect the
electrical supply circuit before
installing the fan, light kit or receiver.
Turning off wall switch is not sufficient.
To avoid possible electrical shock, be
sure electricity is turned off at the main
fuse or circuit breaker box before wiring.
All wiring must be in accordance with
National and Local codes and the ceiling
fan must be properly grounded as a
precaution against possible electrical
shock.
!WARNING
BP7315 Florissant 3/7/06 8:42 AM Page 6

9. Align the two indents on the inside of
the motor housing with the two tabs on
the mounting plate (Figure 8). Turn the
housing clockwise to hold the housing
on the mounting plate. Secure the
housing to the mounting plate by
installing four pointed M5 x 12mm pan
head screws with lockwashers
(supplied).
7
SW101 FAN/LIGHT WALL
CONTROL (SUPPLIED) BLACK BLACK
WHITE
RED
BLACK
WHITE
GREEN WIRE (GROUND)
FROM MOTOR BRACKET
TWO-CONDUCTOR
CABLE (WITH
GROUND)
BLACK
(HOT)
WHITE
GROUND
TO
120-
VOLT
SUPPLY WHITE
BLUE
WHITE
BLUE
EMERSON®
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
Figure 6
6. Carefully push the wires and
connectors up into the outlet box.
7. Pivot the motor assembly on the hook
so that the three threaded studs on the
mounting plate protrude through the
three holes in the motor bracket (Figure
7).
8. Install and securely tighten three 1/4-20
locknuts and flat washers (nuts and
washers supplied) onto the threaded studs
(Figure 7), then try to shake the motor
bracket to ensure that the assembly is
tight.
MOTOR
BRACKET
THREADED
STUDS (3)
FLAT
WASHERS (3)
1/4 x 20
LOCKNUTS (3)
Figure 7
MOTOR
HOUSING
MOUNTING
PLATE
M5 x 12mm PAN HEAD SCREWS
WITH LOCKWASHERS (4)
TAB INDENT
Figure 8
To avoid possible fire or shock, do
not pinch wires between the motor
bracket and mounting plate, and be
sure no wires or wire connectors are
near the top of the motor.
!WARNING
BP7315 Florissant 3/7/06 8:42 AM Page 7

8
M5 x 6mm WASHER
HEAD SCREWS (3)
CAPTIVE SCREWS (2)
BLADE FLANGE
FAN
BLADE
Figure 9
10. Mount one blade flange to a fan blade
using three M5 x 6mm washer head
screws (supplied) (Figure 9). Repeat
this procedure for the four remaining
blades.
CAPTIVE
SCREWS (2)
BLADE
FLANGE
MOTOR
HUB
Figure 10
SWITCH HOUSING
BLUE WIRE
LIGHT
FITTER
BLACK
WIRE
SWITCH
HOUSING
WHITE
WIRE
LIGHT FITTER
LOOSEN THESE
THREE SCREWS
REMOVE AND
RETAIN THIS SCREW
WITH LOCKWASHER
LIGHT
FITTER
WHITE
WIRE
Figure 11
11. Position the blade flange on the motor
hub so that the captive screws in the
blade flange align with two threaded
holes in the motor hub (Figure 10).
Loosely tighten the captive screws at
this time. Repeat this procedure for
the remaining four blade assemblies.
12. Gently snug all captive screws to the
motor hug, working around the hub in
a clockwise sequence. Next, securely
tighten all captive screws, again
working in a clockwise sequence.
Failure to follow this procedure could
result in fan wobble. This completes
the blade installation.
15. Pass the reversing switch pull chain
through the hole in the light fitter
(Figure 12). Position the three
keyhole slots in the light fitter over the
three pan head screws in the switch
housing flange and turn the light fitter
clockwise.
13. Remove and retain the pan head
screw with lockwasher from the
recessed portion of the switch
housing flange (Figure 11). Loosen
the other three pan head screws in
the flange two or three turns.
14. Connect the white wire from the light
fitter to the white wire from the switch
housing (Figure 11). Connect the
black wire from the light fitter to the
blue wire from the switch housing.
Make sure both connectors are
securely engaged.
To avoid possible fire or shock, before
tightening the screws, make sure that the
wires are not pinched between the light
fitter and the switch housing flange.
Pinched wires will also cause the light
fitter to mount crooked on the switch
housing.
!WARNING
16. Tighten the three pan head screws
(Figure 12). Reinstall the pan head
screw with lockwasher (previously
removed) in the remaining hole to
secure the light fitter.
BP7315 Florissant 3/7/06 8:42 AM Page 8

9
18. Screw in two 60-watt (maximum)
candelabra bulbs in the light fitter
sockets (Figure 12). Bulbs not
supplied.
19. Place the lower glass into the light
fitter, aligning the three flat areas on
the lower glass flange with the three
tabs on the light fitter (Figure 13).
Then turn the lower glass clockwise
until the glass stops turning.
20. Your ceiling fan is now installed and
wired to be controlled by your SW101
Fan/Light Wall Control.
FLAT AREAS (3)
LOWER
GLASS
TABS (3)
LIGHT FITTER
Figure 13
Setting Operating
Frequency of Wall
Control and Receiver
(Figure 14)
Your wall control and receiver have code
switches which must be set in one of 16
possible code combinations. The four
levers (numbered 1, 2, 3, and 4) on the
switches are factory-set in the ON (up)
position. Change the switch settings as
follows:
1. Slide the four switch levers in the wall
control to your choice of ON (up) or
down positions. Use a ball-point pen or
small screwdriver and slide the levers
firmly up or down.
2. In the receiver, slide the four switch
levers to the same positions as set in
the wall control. Make sure the levers
on both switches are in the same
positions, otherwise the fan will not
operate.
Figure 14
WALL CONTROL
LEVERS
ON
1234
RECEIVER
SWITCH LEVERS
ON
1234
CODE
SWITCH
ANTENNA WIRE
1 2 3 4
ON
RECEIVER
CODE
SWITCH
WALL
CONTROL
LIGHT
FITTER
TIGHTEN
THREE PAN
HEAD
SCREWS
60-WATT
(MAXIMUM)
CANDELABRA
BULBS (2)
INSTALL PAN HEAD SCREW
WITH LOCKWASHER
PENDANT
COUPLING
REVERSING
SWITCH PULL
CHAIN
CLIP CHAIN
HOLE
Figure 12
17. Slip the reversing switch chain
through the pendant (supplied), then
secure the pendant by snapping the
coupling onto the end of the chain
(Figure 12). Hook the chain in the clip
as shown in Figure 12 insert.
NOTE: Make sure that the lockwashers
are positioned between the screw head
and the light fitter.
BP7315 Florissant 3/7/06 8:42 AM Page 9

4. Install a wall control in the wall box
containing the “hot” wire first. Connect
the black wire of the wall control to the
“hot” wire. Securely connect wires with
wire connectors supplied.
5. Connect one black wire of the wall
control to both remaining traveler wires
in the wall box and secure with wire
connector supplied.
4. Connect one black wire of wall control
to the “hot” wire. Securely connect
wires with wire connectors supplied
(Figure 16).
5. Connect one black wire of wall switch
to the “load” (black) wire in wall box.
Securely connect wires with wire
connector supplied.
6. Screw wall control into wall box and
install decorator style faceplate
(included). Leave wall control in “OFF”
mode until fan installation is completed.
7. Refer to page 4 and complete the
ceiling fan installation. 10
Do not connect any neutral (white)
wire to this control. Incorrect wiring
will damage this control.
!WARNING
EMERSON
®
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
BLACK
BLK
HOT
FAN/LIGHT
WALL
CONTROL WALL
BOX
T
O
L
O
A
D
T
O
1
2
0
V
A
C
S
O
U
R
C
E
G
R
O
U
N
D
Figure 16
3-WAY INSTALLATION
(On fan controlled by two different wall
controls) (See Figures 17 and 18.)
1. Disconnect power at circuit breaker or
remove fuse.
2. At all wall box locations remove
faceplates and screws from existing
controls. Pull controls out from wall
boxes and determine which wall box
contains the “hot” lead and which wall
box contains the “load” wire. Also,
identify traveler wires which are
common to both wall boxes.
Disconnect wires from existing controls
only. Do not attempt to disconnect any
wires not already connected to existing
controls.
Installation of Wall
Control
SINGLE-POLE INSTALLATION
(Figure 15)
1. Disconnect power at circuit breaker or
remove fuse.
2. Remove faceplate and screws from
existing wall control. Pull control out
from the wall box. Determine the “hot”
wire and the “load” wire and disconnect
these wires from control. Do not
attempt to disconnect any wires not
already connected to existing control.
3. Before installing wall control, place wall
control in “OFF” mode by pushing
“ON/OFF” switch to the “OFF” position.
EMERSON
®
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
FAN/LIGHT
WALL CONTROL
HOT BLK
NEUTRAL
BLACK
GROUND
LOAD BLACK
REMOTE CONTROL
RECEIVER LOCATED
UNDER THE FAN
HOUSING
Figure 15
3. Before installing wall control, place wall
control in “OFF” mode by pushing
“ON/OFF” switch to the “OFF” position.
Do not connect any neutral (white)
wire to this control. Incorrect wiring
will damage this control.
!WARNING
BP7315 Florissant 3/7/06 8:42 AM Page 10

NOTE: Retrofit 3-way installations are
likely to include two traveler wires
between the two wall boxes. In new
construction, only one traveler wire Is
required.
3-WAY WIRlNG DIAGRAM:
NEW CONSTRUCTION
6. Place wall control into wall box. Screw
in place and install decorator style
faceplate (included).
7. Next, install the other wall control into
the wall box containing the load wire.
Connect the black wire of the wall
control to the traveler wire(s) already
connected to the black wire (in the
other wall box). Secure with wire
connectors supplied.
11
HOT
BLACK
FAN/LIGHT
WALL
CONTROL
TRAVELER
WIRE
BLK
BLK
LOAD
BLACK GROUND
NEUTRAL
EMERSON
®
EMERSON
®
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
REMOTE CONTROL
RECEIVER LOCATED
UNDER THE FAN
HOUSING
Figure 17
HOT BLK
FAN/LIGHT
WALL CONTROL
BLK
TRAVELER WIRES
BLK
BLK
BLACK
LOAD
BLACK
LOAD
TRAVELER WIRES
HOT BLK
EXISTING
WALL CONTROL
EMERSON
®
EMERSON
®
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
Figure 18
STANDARD WIRING FOR EXISTING
3-WAY CONTROL
8. Connect one black wire of the wall
control to the “load” (black) wire and
secure with wire connector supplied.
9. Place the second wall control into the
wall box. Screw in place and install
decorator style faceplate (included).
Leave switch in “OFF” mode until fan
installation is completed.
10. Refer to page 4 and complete the
ceiling fan installation.
BP7315 Florissant 3/7/06 8:42 AM Page 11

12
Operating Your
Ceiling Fan
IMPORTANT
Fan installation must be completed,
including the installation of the fan
blades, before testing of the remote
control.
Your Fan/Light Wall Control (Figure 19)
has full control of your fan and light.
However, airflow direction is controlled by
a pull chain on the light fitter switch.
1. Restore electrical power to the outlet
box by turning the electricity on at the
service panel.
NOTE: Make sure that the ON/OFF slide
switch on the Fan/Light Wall Control is
in the ON position.
2. To set the desired fan speed, press the
HI, MED, or LOW buttons to operate
your fan on high, medium, or low speed
(Figure 19).
3. To turn your fan off, press the OFF
button.
4. To set the level of housing light
brightness, press and hold the LIGHT
button. The light brightness will
continue to increase then decrease
while the button is held down. When
the light is at the desired brightness,
release the button.
5. To turn the housing lights on and off,
press and release the LIGHT button.
The light will turn on at the light level
previously set (see step 4).
6. If airflow is desired in the opposite
direction, turn the fan off and wait for
the blades to stop turning. Turn the
lower glass counterclockwise and
remove the glass from the light fitter
(Figure 12). Remove the pull chain
from the clip on the light fitter and pull
on the pendant until the reversing
switch clicks. Replace the pull chain in
the clip, then replace the lower glass on
the light fitter, and turn the glass
clockwise until the glass stops turning.
Turn the fan on again; the blades will
turn in the opposite direction and
reverse the airflow.
EMERSON®
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
Figure 19
BP7315 Florissant 3/7/06 8:42 AM Page 12

13
Do not use water when cleaning your
ceiling fan. It could damage the
motor or the blades and create the
possibility of an electrical shock.
!WARNING
Maintenance
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new ceiling fan is
the only maintenance that is needed.
When cleaning, use only a soft brush or
lint free cloth to avoid scratching the finish.
Abrasive cleaning agents are not required
and should be avoided to prevent damage
to finish.
The use of any other control not
specifically approved for this fan
could result in fire, shock and
personal injury.
!WARNING
This product is designed to use only
those parts supplied with this
product and/or any accessories
designated specifically for use with
this product by Emerson Electric Co.
Substitution of parts or accessories
not designated for use with this
product by Emerson Electric Co.
could result in personal injury or
property damage.
!WARNING
Accessories
1. SR100 Remote Control (see store or
catalog).
INSTRUCTION TO THE USER
(if device contains a digital device)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certified to comply with the limits for a Class B computing device,
pursuant to FCC Rules. In order to maintain compliance with FCC regulations, shielded
cables must be used with this equipment. Operation with non-approved equipment or
unshielded cables is likely to result in interference to radio and TV reception. The user is
cautioned that changes and modifications made to the equipment without the approval of
manufacturer could void the user’s authority to operate this equipment.
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
BP7315 Florissant 3/7/06 8:42 AM Page 13

Repair Parts
8
17
18
9
10
13
12
2
11
4
3
16
14
15 7
5
HI
MED
LOW
FAN OFF
LIGHT
ONOFF
EMERSON
1
6
Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS,ALWAYS GIVE THE FOLLOWING INFORMATION:
• PART NUMBER
• NAME OF ITEM
• PART DESCRIPTION
• MODEL NUMBER
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone [phone].
14
BP7315 Florissant 3/7/06 8:42 AM Page 14

15
Part Numbers
Key Model No. Model No. Model No.
No. Description CF730WB00 CF730BZH00 CF730AGW00
1 Plate, Mounting 763139 763139 763139
2 Housing, Fan 763126-WB 763126-BZH 763126-AGW
3 Flange Set (full set of one fan) 763127-WB 763127-BZH 763127-AGW
4 Blade Set (full set of one fan) 763132 763132-1 763132-1
5 Harness Assembly, Wiring 763134 763134 763134
6 Fitter Assembly, Light 763136-WB 763136-BZH 763136-AGW
7 Glass, Lower 763144 763144-1 763144-1
* Parts Bag, Containing: 763135 763135 763135
8 Bracket Assembly, Receiver — — —
9 Screw, Pan Head with Lockwasher,
M5 x 12mm (5) — — —
10 Connector, Wire (3) — — —
11 Screw, Washer Head, M5 x 6mm (16) — — —
12 Locknut, 1/4-20 (4) — — —
13 Washer, Flat, 1/4” (4) — — —
14 Pendant, Pull Chain — — —
15 Coupling — — —
16 Screw, Pan Head with Lockwasher,
M6 x 14mm (extra flange screw) — — —
17 Wall Control, Fan/Light 762348-1 762348-1 762348-1
18 Receiver, Remote Control 762670 762670 762670
— Owner's Manual BP7315 BP7315 BP7315
Repair Parts Listing
BP7315 Florissant 3/7/06 8:42 AM Page 15

Part No. F40BP73150000
Printed in China 03/06 Form No. BP7315
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant ¥ St. Louis, MO 63136
Trouble Shooting
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
1. Fan will not 1. Fuse or circuit breaker 1. Check main and branch circuit fuses
start. blown. or circuit breakers.
WARNING: Make sure main power
is turned off.
2. Loose power line 2. Check line power connections to fan.
connections to the fan
3. Fan/Light Wall Control is OFF. 3. Turn ON Fan/Light Wall Control.
4. Code switches in remote control 4. Check that both code switches
receiver and Fan/Light Wall Control are set in the same positions.
are not set in the same position
2. Fan sounds 1. Screws securing fan blade 1. Check to make sure the
noisy. flanges to motor hub are screws which attach the
loose. blade flanges to the motor
hub are tight.
2. Screws holding blades to 2. Tighten screws securely.
flanges are loose.
3. Fan wobbles 1. Screws securing fan blade 1. Check to be sure screws
flanges to mounting hub which attach the fan blade
are loose. flanges to the mounting hub
are tight.
2. Fan blade flanges not 2. Check to be sure that the
seated properly. fan blade flanges seat firmly
and uniformly on the motor
hub. If flanges are seated
incorrectly, loosen the flange
screws and retighten.
3. Mounting plate and/or 3. Tighten the mounting plate
ceiling outlet box is not screws to the outlet box,
securely fastened. and/or secure outlet box.
4. Fan blades out of balance. 4. Interchanging an adjacent
(side-by-side) blade pair can
redistribute the weight and
result in smoother operation.
Or use supplied balancing
kit to balance blades.
WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX
OR CIRCUIT BREAKER BEFORE TROUBLE SHOOTING YOUR FAN.
!
!
BP7315 Florissant 3/7/06 8:42 AM Page 16
