To avoid possible fire hazard, do not
exceed the wattage indicated on the
light fixture.
WARNING
!
Installation of Glass Shades
1. To install the shade (1), back the
knurled screws (2) out until the shade
neck slips into the holder (3) (Figure 6).
Then tighten the screws (2) until the
three screws touch the neck with
approximate equal projection on the
outside. Never use a screwdriver or
pliers to tighten screws against the
shade, or a broken or damaged shade
will most surely result.
NOTE: It is advisable to periodically
check the tightness of the knurled
screws. Fan operation may loosen
these screw.
2. CFSLK1 & CFSLKPF: Install a 100-
watt (maximum) medium base bulb into
the fixture socket.
3. All Other Models: Install a 60-watt
(maximum) medium base bulb into each
fixture socket.
Ceiling Fan Light Fixture
Owner's Manual
LIMITED WARRANTY
What The Warranty Covers:
All products covered by this Owner’s Manual are warranted against all defects in workmanship and materials. You must be the original purchaser or user of the
product to be covered.
What The Period Of Coverage Is:
All components are covered by this warranty for one year from the date you purchased your light fixture. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Light Fixture at no charge to you. WE WILL SHIP THE REPAIRED PRODUCT OR REPLACEMENT TO YOU AT
NO CHARGE, BUT YOU ARE RESPONSIBLE FOR ALL COSTS OF REMOVAL, REINSTALLATION AND SHIPPING OF THE PRODUCT TO EMERSON.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE LIGHT FIXTURE TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR OTHER PROOF
OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products, Division of Emerson
Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Light Fixture should
be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
This warranty also does not cover any defects, malfunctions or failures caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your light fixture while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The ceiling fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties apply, and no employee,
agent, dealer or other person is authorized to give any warranties on behalf of Emerson Electric Co..
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS NOT RESPONSIBLE FOR
DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages include but are not limited to such damages as loss
of time and loss of use. Consequential damages include but are not limited to the cost of repairing or replacing other property which was damaged if this
product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Part No. BP7130-8
Form No. F40BP71300008 Form No. F40BP71300008 Part No. BP7130-8
U.L. Model No.: CFMLK4, LK36, CFSLK1, CFSLKPF, CFFC4, F440, F460, F465, F330
Printed in China 03/09
READ AND SAVE THESE INSTRUCTIONS
USE THESE FIXTURES ONLY WITH
EMERSON CF AND F SERIES CEILING FANS.
THIS OWNER’S MANUAL
COVERS THE CF AND LK SERIES
LIGHT FIXTURES AND THE
CF AND F SERIES LIGHT FITTERS
4. Insert the black and white wires through
the lockwasher (8) and hex nut (7)
supplied. Firmly tighten the hex nut to
secure the light kit fixture to the switch
housing cover (5).
5. Carefully locate the white and blue
wires (labeled either “L” or “LIGHT”) in
the switch housing and remove the wire
connectors (3) from the wires.
6. Connect the white wire from the ceiling
fan to the white wire of the light fixture.
Connect the blue wire from the ceiling
fan to the black wire of the light fixture.
Use listed wire connectors (3) provided
to make connections. (Figures 4 and 5.)
7. Carefully tuck all wires and splices into
the switch housing (1). (Figure 4.)
(1) GLASS
SHADE
(2) KNURLED SCREW
(3 PER SHADE)
(3) HOLDER
LIGHT BULB
(1 PER
SOCKET
Figure 6
NOTE: ANY LIGHT KIT OR FITTER AND GLASS
COMBINATION COVERED BY THIS MANUAL
WEIGHS 7.5 LBS. OR LESS.
4. Installation is complete. Turn on power
at main fuse or circuit breaker box.
To avoid possible electrical shock,
be careful not to pinch the wires
between the switch housing (1) and
the cover (5).
WARNING
!
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant • St. Louis, MO 63136
For repair parts, phone:
1-800-654-3545
Figure 5
To avoid possible fire or electrical
shock, make certain no bare wire
strands are exposed outside wire
connectors.
WARNING
!
8. Attach the cover/light fixture (5)(6) to the
housing (1) using the two screws (2) that
were removed in step 2. (Figure 4.)
9. Proceed to “Installation of Glass
Shades” section.
Figure 3
To avoid possible fire or electrical
shock, make certain no bare wire
strands are exposed outside wire
connectors.
WARNING
!
11. Position the cup/light fixture (1)(7) on
the cover plate (2) and install the
three screws (3) that were previously
removed in step 2 and tighten
securely.
12. Proceed to “Installation of Glass
Shades/Globes” section.
Installation on Emerson
Fans Having Two-Piece
Die-Cast Switch Housings
1. Remove all parts and parts packages
from carton.
2. Remove the cover (5) from the fan
switch housing (1) by removing the two
outer screws (2). (See Figure 4.)
3. Remove the center screw (4) in the
switch housing cover (5). Insert the
black and white wires from the light
fixture (6) thru the hole and thread the
switch housing cover tightly onto the
light fixture. (See Figure 4.)
(3) WIRE
CONNECTORS
WHITE WIRES
BLUE WIRE
BLACK WIRE
FAN
SWITCH
CHAIN
(1) SWITCH
HOUSING
ASSEMBLY
(5) COVER
(2) SCREWS
(4) CENTER
SCREW
(8) LOCKWASHER
(7) HEX NUT
(6) LIGHT
FIXTURE
Figure 4
Assembly and Installation
2 3
Installation on Emerson
Fans Having A Modular
Switch Cup with Center
Screw
1. Remove all parts and parts packages
from the carton.
2. Remove the switch cup (1) from the
cover plate (2) by removing the three
screws (3) around the side of the switch
cup (Figure 1).
3. Disconnect the motor connector (4)
from the switch cup connector (5)
(Figure 1).
Safety Instructions
WARNING: To avoid fire, shock, and serious personal injury, follow all instructions
carefully.
1. Read your Owner's Manual carefully before installing the light fixture. Retain Owner's
Manual for future reference.
2. Be careful of the fan and blades when cleaning, painting, or working near the fan.
Before installing or servicing the light fixture or ceiling fan, switch power off at
service panel and lock service panel disconnecting means to prevent power from
being switched on accidentally. When the service disconnecting means cannot be
locked, securely fasten a warning device, such as a tag, to the service panel.
3. Use medium base bulbs of the wattage indicated on the fixture. Do not exceed the
indicated wattage.
4. Do not use as a ceiling fixture.
ADDITIONAL SAFETY INSTRUCTIONS FOR INSTALLATION
1. To avoid possible electrical shock be sure electricity is turned off at the main fuse or
circuit breaker box before wiring.
2. Make certain no bare wires are exposed outside the wire connectors.
3. All wiring must conform to national and local electrical codes.
4. Follow the recommended instructions for the proper method of wiring your new light
fixture. If you feel you do not have enough electrical wiring knowledge or experience,
have your light fixture installed by a licensed electrician. Any electrical work not
described in this manual should be performed by a licensed electrician.
WARNING: To reduce the risk of possible fire and electrical shock, install only on
Emerson “CF” and “F” Series Ceiling Fans. This light kit is not to be used with CF652,
CF653, CF670, and CF742 Model Ceiling Fans installed in damp or wet locations.
4. Remove the center screw (6) from the
switch cup (Figure 1).
5. Carefully locate the white and blue
wires (labeled either "L" or "LIGHT") in
the switch cup and remove the wire
connectors from the wires.
6. Insert the black and white wires from
the light fixture (7) through the center
hole in the switch cup (Figure 2) and
thread the switch cup onto the light
fitter. Hold wires taut while installing
switch cup to prevent the wires from
twisting. Tighten the fitter until the fan
switch chain aligns with the bushing in
side of fitter.
7. Insert the black and white wires through
the lockwasher (8) and the hex nut (9)
supplied. Firmly tighten the hex nut to
secure the light fixture to the switch
cup.
8. Connect the white wire from the switch
cup to the white wire of the light fixture
(Figure 2). Connect the blue wire from
the switch cup to the black wire of the
light fixture. Use listed wire connectors
(previously removed in step 5) to make
connections (Figures 2 and 3).
9. Carefully tuck all wires and splices into
the switch cup (1). (Figure 2.)
10. Connect the motor connector (4) to
the switch cup connector (5).
(3) SCREWS
(6) CENTER SCREW
(1) SWITCH
CUP
(4) MOTOR
CONNECTOR
(2) COVER PLATE
(5) SWITCH CUP
CONNECTOR
FAN SWITCH
CHAIN
Figure 1
(3) SCREWS
(5) SWITCH CUP
CONNECTOR
(2) COVER PLATE
(6) WIRE
CONNECTORS
WHITE WIRES
(1) SWITCH
CUP
BLACK WIRE
FAN SWITCH
CHAIN
(8)
LOCKWASHER
(9) HEX NUT
(7) LIGHT FIXTURE
BLUE WIRE
(4) MOTOR
CONNECTOR
Figure 2
NOTE: YOUR FIXTURE MAY NOT LOOK THE SAME AS THE ONE IN THIS
ILLUSTRATION. HOWEVER, IT INSTALLS IN A SIMILAR MANNER.
NOTE: YOUR FIXTURE MAY NOT LOOK THE SAME
AS THE ONE IN THIS ILLUSTRATION. HOWEVER,
IT INSTALLS IN A SIMILAR MANNER.
Do not install or use the light fixture
if any part is missing or damaged.
Call toll-free:
1-800-654-3545
WARNING
!To avoid possible electrical shock,
be sure electricity is turned off at the
main fuse or circuit breaker box
before wiring.
WARNING
!
To avoid possible electrical shock,
be sure electricity is turned off at the
main fuse or circuit breaker box
before wiring.
WARNING
!
To avoid possible electrical shock,
be careful not to pinch wires
between the switch cup (1) and the
cover plate (2)
WARNING
!
WARNING
!
