Emerson SW350 User manual

Part No. F40BP72530002 Form No. BP7253-2
READ AND SAVE THESE INSTRUCTIONS
SW350, SR330 & SW375
Ceiling Fan/Light
Wall Control, Remote Control &
Receiver Owner's Manual
For use only with Emerson Ceiling Fan Models: F2100 2, F2200 2, F2300 1,
CF1 1, CF2300 1, CF2400 1, CF2454 2, CF2500 1, CF2600 2, CF2650 0,
CF2675 1, CF3500 0, CF3900 1, CF4500 4, CF4600 0 and CF4800 3.
Off On
Up Down
Lights
S
e
l
e
c
t
Fan
Sleep
F
l
o
w
S
e
c
u
r
i
t
y
Model
SW350
Wall Control
Lights
Fan
S
e
l
e
c
t
A
i
r
f
l
o
w
S
l
e
e
p
S
e
c
uri
t
y
W
i
n
t
e
r
Fan Low
Down Light
Fan High
Up Light
Air
DN
Air
UP
Model
SR330
Remote Control
Model
SW375
Receiver
NOTE: The SW350 and SR330 controls
must be used with a SW375 receiver.
BP7253-2 4/28/06 11:58 AM Page 1

2
Safety Instructions
WARNING: To avoid fire, shock, and serious personal injury, follow all instructions
carefully.
1. Read your Owner's Manual carefully before installing the Remote Control, Wall
Control, or Receiver. Retain Owner's Manual for future reference.
2. Before servicing or cleaning the ceiling fan, switch power off at service panel and lock
service panel to prevent power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a warning device such as a
tag, to the service panel.
ADDITIONAL SAFETY INSTRUCTIONS FOR INSTALLATION
1. To avoid possible electrical shock, be sure electricity is turned off at the main fuse or
circuit breaker box before wiring.
2. Make certain no bare wires are exposed outside the wire connectors.
3. All wiring must conform to National and Local Electrical Codes.
4. Follow the recommended instructions for the proper method of wiring your new
Remote Control, Wall Control, or Receiver. If you feel you do not have enough
electrical wiring knowledge or experience, have your Remote Control, Wall Control, or
Receiver installed by a licensed electrician. Any electrical work not described in this
manual should be performed by a licensed electrician.
WARNING
!
DATE CODE:
The date code of this fan may be found on the box, stamped in ink on a white label.
You should record this data above and keep it in a safe place for future use.
INSTRUCTION TO THE USER (if device contains a digital device)
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This equipment has been certified to comply with the limits for a class B computing device,
pursuant to FCC Rules. In order to maintain compliance with FCC regulations, shielded cables
must be used with this equipment. Operation with non-approved equipment or unshielded
cables is likely to result in interference to radio and TV reception. The user is cautioned that
changes and modifications made to the equipment without the approval of manufacturer could
void the user’s authority to operate this equipment.
This Class B digital apparatus meets all requirements of the Canadian
Interference-Causing Equipment Regulations.
BP7253-2 4/28/06 11:58 AM Page 2

3
General
Installation to Operate the
Ceiling Fan, Downlight
and Uplight
Your Emerson Ceiling Fan/Light Control
consists of either a hand-held transmitter
with wall caddy and/or a wall control as
well as a receiver which is mounted under
the fan ceiling cover. The wall control and
remote control are designed to control
your ceiling fan speed, airflow direction,
and light intensity.
IMPORTANT
It is important that you also follow the
instructions found in the Owner's
Manual supplied with your Ceiling Fan.
Pay particular attention to the Safety
Instructions and WARNING notes.
NOTE 1: On the CF4600 Series Ceiling
Fan, install the fan blades and switch
cup assembly in accordance with the
instructions in the ceiling fan owner’s
manual, then proceed with steps 1
through 10 below.
1. Remove the wire connectors from the
red and brown wires. Cut the white,
blue and black wires about 3" above
the motor coupling (Figure 1). Strip
insulation 1/2" from end of white, blue,
red and brown wires. Install a wire
connector on the black wire; this wire
will not be used.
YELLOW WIRE FROM MOTOR
COUPLING (See NOTE 3)
BROWN
WIRE
RED WIRE YELLOW WIRE
FROM UPLIGHT
(See NOTE 3)
REMOVE WIRE
CONNECTORS
FROM RED AND
BROWN WIRES
(See NOTE 1) 3" BLUE WIRE
BLACK WIRE
WHITE WIRE
CAP BLACK WIRE
USING A WIRE
CONNECTOR
REMOVE
WIRE
CONNECTOR
MOTOR COUPLING
Figure 1
NOTE 2: On Model CF1, CF2400, and
CF2800 Series Ceiling Fans, the red
and brown wires from the motor are
connected to red and brown wires from
the reversing switch. Remove the wire
connectors and separate these wires.
Using wire connectors, cap the red and
brown wires from the reversing switch;
these wires will not be used.
NOTE 3: If your ceiling fan does not
have a built-in uplight, these yellow
wires will not be present.
2. Remove the wire connector (Figure 1)
from the yellow wires (See NOTE 3).
Separate the yellow wires, and cap the
yellow wire coming from the motor
coupling.
NOTE 4: On early Model CF2400 Series
Ceiling Fans, cut the orange wire
midway between the motor coupling
and the housing (Figure 2). Cap the
orange wire from the motor coupling
using a wire connector. The orange
wire from the housing will get
connected to the uplight yellow wire in
Step 6.
3. Loosen the setscrew in the hanger ball,
slide the ball down the hanger pipe,
and remove the clevis pin. Then slide
the hanger ball off the hanger pipe
(Figure 3). Retain all parts.
DOWNROD
CLEVIS PIN
SETSCREW
HANGER
BALL
Figure 3
ORANGE WIRE
(See NOTE 3)
Figure 2
BP7253-2 4/28/06 11:58 AM Page 3

7. Fold the wires of the wiring harnesses
into the slot in the motor coupling, slide
the hanger pipe down the wires and
seat the hanger pipe in the motor
coupling.
8. Align the clevis pin holes in the hanger
pipe with the holes in the motor
coupling. Install the clevis pin and
secure with the hairpin clip. The clevis
pin must go through the holes in the
motor coupling and the holes in the
hanger pipe (Figure 6). Push the
straight leg of the hairpin clip through
the hole near the end of the clevis pin
until the curved portion of the hairpin
clip snaps around the clevis pin. The
hairpin clip must be properly installed to
prevent the clevis pin from working
loose.
9. Install the setscrew (supplied in loose
parts bag supplied with ceiling fan) in
the motor coupling and tighten using
the 5/32" setscrew wrench (supplied
with ceiling fan) (Figure 6). A loose
setscrew could cause the fan to
wobble.
10. Screw the two threaded studs (select
the proper length stud as described in
the Ceiling Fan Owner’s Manual) into
the threaded holes in top of the motor.
(Figure 7). (Early motors have two
threaded brackets.) Coil the wires and
4
4. Push the wiring harness connector
(supplied with the SW375 receiver) and
the connectors on the blue wire
(supplied with the control) and yellow
wire (supplied with fans containing
built-in Uplights) through the hanger
pipe until they extend about 4" out of
the pipe (Figure 4).
5. Cut the harness wires approximately 3"
from the end of the pipe. Strip
insulation 1/2" from end of wires.
6. Using wiring connectors supplied,
connect the white, red, yellow, blue, and
brown wires of the wiring harness to the
white, red, yellow (orange wire for early
CF2400 Models), blue, and brown wires
of the ceiling fan (Figure 5). Wires must
be connected color-to-color.
It is critical that the clevis pin in the
motor coupling is properly installed and
the setscrew securely tightened. Failure
to verify that the pin is properly installed
could result in the fan falling.
WARNING
!
MOTOR
COUPLING
HANGER PIPE
HAIRPIN
CLIP
CLEVIS
PIN SETSCREW
Figure 6
4"
DOWNROD
CUT HERE
3"
YELLOW LEAD (Built-in Up Light Only)
(See NOTE 3)
WIRING
HARNESS
BLUE WIRE
Figure 4
BLUE WIRE TO
BLUE WIRE
Off On
Up Down
Lights
Fan
Sleep
FAN BLADES REMOVED
FOR CLARITY
HANGER
PIPE
WHITE WIRE
BLACK WIRE
WIRING HARNESS
CONNECTOR
YELLOW WIRE
TO YELLOW
WIRE (Built-in
Up Light Only)
BLUE WIRE TO
BLUE WIRE
SW375 RECEIVER
TO
120V SUPPLY
BROWN WIRE
TO BROWN
WIRE
YELLOW WIRE
TO YELLOW WIRE*
(Built-in Up Light Only)
SW350
WALL CONTROL
OR
ON/OFF WALL
SWITCH
RECEIVER
CONNECTOR
BLACK WIRE
(NOT USED)
RED WIRE TO
RED WIRE WHITE WIRE TO
WHITE WIRE
LIGHT
FIXTURE
FAN
HOUSING
* ON SOME CF2400 MODELS,
THE WIRE FROM MOTOR
MAY BE ORANGE
Figure 5
BP7253-2 4/28/06 11:58 AM Page 4

Pull the hanger ball up tight against
the pin and securely tighten the
setscrew in the hanger ball. A loose
setscrew could create the fan to
wobble.
13. Install the hanger bracket, then hang
the fan in accordance with the
instructions in the ceiling fan Owner's
Manual.
14. Screw two 1-1/4" threaded studs
(supplied with the ceiling fan) into the
tapped holes in the hanger bracket
(Figure 9).
15. Position the receiver by passing the
opening in the receiver over the
hanger pipe (Figure 9).
5
NOTE 5: On Model CF2600, CF2650 and
CF2675 Series Ceiling Fans, if you have
installed the 18” downrod (supplied)
and are planning to install the
decorative support rods, proceed to
“Installation of Decorative Support
Rods Assembly” section in the ceiling
fan owner’s manual. After you have
installed the support rods assembly,
continue with the following installation
procedures.
NOTE 6: On Model CF4600 Series
Ceiling Fans, assemble the upper
housing, the upper glass and the
housing trim and slide the assembly
over the downrod in accordance with
the instructions in the ceiling fan
owner’s manual. Then proceed with
steps 11 through 19 below.
11. Position the ceiling cover over the
hanger pipe (Figure 8). Be sure the
cover is oriented correctly, with the
large opening at the top.
12. Install the hanger ball on the hanger
pipe as follows. Route the wiring
harness connectors through the
hanger ball and slide the hanger ball
over the hanger pipe. Install the pin
through the holes at the top of the
hanger pipe and slide the hanger ball
up the hanger pipe, aligning the ball
so the pin is captured in the groove in
the top of the hanger ball (Figure 8).
HANGER
BRACKET HANGER
BALL
CEILING
COVER
SW375
RECEIVER
OPEN
SIDE
Figure 9
wire connectors around the motor
coupling, then slide the motor cover
over the hanger pipe and rotate the
motor cover until the threaded studs
protrude. Install two knurled knobs
(supplied with ceiling fan) to secure
the motor cover to the fan (Figure 7).
All wires and wire connectors must be
enclosed under the motor cover.
KNURLED KNOB (2)
MOTOR COVER
1" THREADED
STUD (2)
Figure 7
It is critical that the clevis pin in the
hanger ball is properly installed and the
setscrew securely tightened. Failure to
verify that the pin is properly installed
could result in the fan falling.
WARNING
!
DOWNROD
PIN
HANGER BALL
CEILING
COVER
SETSCREW
Figure 8
BP7253-2 4/28/06 11:58 AM Page 5

6
Installation of SW350
Wall Control
SW350
WALL CONTROL
HOT BLACK
NEUTRAL
BLACK
GROUND
LOAD
BLACK
Off On
Up Down
Lights
Fan
Sleep
AMERICA’SFANCOMPANY
FAN RECEIVER LOCATED
WITHIN CEILING CANOPY
Figure 10
SINGLE-POLE INSTALLATION (Figure 10)
1. Disconnect power at circuit breaker or
remove fuse.
2. Remove faceplate and screws from
existing wall switch. Pull switch out
from the wall box. Do not attempt to
disconnect any wires not already
connected to existing switch.
3. Connect one black wire of wall control
to the “hot” wire in the wall box.
Securely connect wires with wire
connectors supplied (Figure 11).
4. Connect the other black wire of wall
control to the “load” (black) wire in wall
box. Securely connect wires with wire
connector supplied.
5. Screw wall control into wall box and
install decorator style faceplate
(included). Leave wall control in “OFF”
mode until fan installation is completed.
6. Refer to fan Owner’s Manual to
complete fan installation.
7. Perform Code Learning Procedure
(Page 8).
Do not connect any neutral (white) wire
to this control. Incorrect wiring will
damage this control.
WARNING
!
BLACK
BLACK
HOT
SW350
WALL CONTROL
Off On
Up Down
Lights
Fan
Sleep
NEUTRAL
WALL BOX
T
O
1
2
0
V
A
C
S
O
U
R
C
E
G
R
O
U
N
D
T
O
L
O
A
D
Figure 11
3-WAY INSTALLATION
(One fan controlled by two different
wall controls) (See Figures 12 and 13.)
1. Disconnect power at circuit breaker or
remove fuse.
2. At all wall box locations remove
faceplates and screws from existing
switches. Pull switches out from wall
boxes and determine which wall box
contains the “hot” lead and which wall
box contains the “load” wire. Also,
identify traveler wire(s) which are
common to both wall boxes.
16. Connect the black wire from the
wiring harness to the black (hot)
supply wire (Figure 5). Connect the
white wire from the wiring harness to
the white (neutral) supply wiring.
Connect the green ground wires from
the hanger bracket and the hanger
ball to the supply ground wire. Use
wire connectors supplied with your
ceiling fan.
17. Securely connect the wiring harness
connector to the receiver connector,
and connect the blue and yellow wires
(yellow wire is used only on a fan with
a built in Uplight) to the blue and yellow
wires from the receiver (Figure 5).
18. Fold and position the wires into the
space above the hanger ball and into
the outlet box (Figure 9).
19. Feed the wires and connectors
through the open side of the hanger
bracket, and into the outlet box. Slide
the receiver up and over the hanger
bracket. Press the receiver against
the ceiling holding it in place while
installing the ceiling cover in
accordance with the instructions in
the ceiling fan Owner's Manual.
20. Install the fan blades in accordance
with the instructions in the ceiling fan
Owner’s Manual.
NOTE 7: On Model CF2454, CF2600,
CF2650, and CF2675 Series Ceiling
Fans, install the light fixture assembly
(supplied) in accordance with the
instructions in the ceiling fan owner’s
manual.
21. Install the optional downlight kit in
accordance with the instructions in
the downlight kit Owner’s Manual.
BP7253-2 4/28/06 11:58 AM Page 6

Disconnect wires from existing
switches only. Do not attempt to
disconnect any wires not already
connected to existing switches.
NOTE: Retrofit 3-way installations are
likely to include two traveler wires
between the two wall boxes. In new
construction, only one traveler wire is
required.
3. Before installing wall control, place wall
control in “OFF” mode by pushing
“ON/OFF” switch to the “OFF” position.
4. Install a wall control in the wall box
containing the “hot” wire first. Connect
one black wire of the wall control to the
“hot” wire. Securely connect wires with
wire connectors supplied.
5. Connect the other black wire of the wall
control to the remaining traveler wire(s)
in the wall box and secure with wire
connector supplied.
3-WAY WIRlNG DIAGRAM:
NEW CONSTRUCTION
6. Place wall control into wall box. Screw
in place and install decorator style
faceplate.
7. Next, install the other wall control into
the wall box containing the “load” wire.
Connect one black wire of the wall
control to the traveler wire(s) already
connected to the black wire (in the
other wall box). Secure with wire
connectors supplied.
7
STANDARD WIRING FOR EXISTING
3-WAY CONTROLS
HOT BLK
TRAVELER WIRES
BLACK
LOAD
EXISTING
WALL CONTROL
SW350
WALL CONTROL
BLK
BLK
BLK
BLACK
LOAD
TRAVELER WIRES
HOT BLK
Off On
Up Down
Lights
Fan
Sleep
Off On
Up Down
Lights
Fan
Sleep
3-WAY WIRING DIAGRAM: RETROFIT
Figure 13
Do not connect any neutral (white) wire
to this control. Incorrect wiring will
damage this control.
WARNING
!
HOT BLK SW350
WALL
CONTROL
BLK
TRAVELER
WIRE
BLK BLK
LOAD
BLACK GROUND
NEUTRAL
Off On
Up Down
Lights
Fan
Sleep
Off On
Up Down
Lights
Fan
Sleep
FAN RECEIVER LOCATED
WITHIN CEILING CANOPY
AMERICA’SFANCOMPANY
Figure 12
8. Connect one black wire of the wall
control to the “load” (black) wire and
secure with wire connector supplied.
9. Place the second wall control into the
wall box. Screw in place and install
decorator style faceplate (included).
Leave switch in “OFF” mode until fan
installation is completed.
10. Refer to fan Owner’s Manual to
complete fan installation.
NOTE: You must perform the Code
Learning Procedure for both wall
controls to be able to operate your fan
from both wall controls.
BP7253-2 4/28/06 11:58 AM Page 7

8
Trouble Shooting
FAN/LIGHT FAILS TO OPERATE
Make sure the Code Learning
Procedure has been performed (Pages
8 through 11).
• Check that the light switch on the light
fixture is on.
• Check that the battery is good (green
indicator light should light when any
button is pressed).
• Check that the receiver is wired
properly.
• Check that the ON/OFF wall switch is in
the on position.
MULTIPLE FAN INSTALLATION USING
THE SR330 REMOTE CONTROL AND
SW350 WALL CONTROL.
When installing two or more fans on the
same electrical circuit with both using
either the SR330 or SW350 controls to
operate the fans separately perform the
following steps:
3. Install the second fan as directed in the
Owner’s Manual and perform the Code
Learning Procedure.
4. If all ceiling fan installations are
complete at this time, turn the power
back on to the first fan or reconnect the
power to the SW375 Receiver and both
fans will now operate independently.
5. If additional fans are to be installed,
continue to complete Step #2 until all
fans are installed.
USE OF SR330 REMOTE CONTROL IN
CONJUNCTION WITH SW350 WALL
CONTROL.
The SR330 Remote uses a LCD display
that shows the status of the fan, uplight,
and downlight. Each time any button is
pressed on the SR330 handheld, the
remote control sends all instructions to the
SW375 Fan Receiver. This means that the
remote control sends the fan, uplight,
downlight, fan speed, and fan direction
readings on the LCD display to the SW375
Receiver.
If any changes have been made to the fan
or light functions using the SW350 Wall
Control, those changes are not indicated
on the remote LCD display. When the
SR330 Remote Control buttons are
pressed, the fan and light functions
change to the LCD display settings.
Off On
Up Down
Lights
Fan
Sleep
YELLOW WIRE
TO YELLOW
WIRE (Built-in
Up Light Only)
BLUE WIRE TO
BLUE WIRE
SW375 RECEIVER
WIRING HARNESS
CONNECTOR
RECEIVER CONNECTOR
TO
120V SUPPLY
SW350
WALL CONTROL OR
ON/OFF WALL SWITCH
DISCONNECT THE
WIRING HARNESS
CONNECTOR AND THE
RECEIVER CONNECTO
R
Figure 15
Installation of
Pull Chain Plug
If you have either a single or dual pull
chain switch cup assembly and you do not
desire to have the pull chain(s) hang from
your ceiling fan, proceed as follows.
Uncouple the chain extensions(s), if
installed. Unscrew the nut(s) on the inside
of the switch cup assembly and remove
the chain bushing(s) (Figure 14). Tuck the
chain(s) into the switch cup assembly and
then plug the hole(s) with the pull chain
plug(s) (supplied). Choose the color of the
plug that best matches your ceiling fan.
SWITCH CUP
ASSEMBLY
PULL CHAIN
PULL CHAIN
PLUG CHAIN
EXTENSION
CHAIN
BUSHING
KNURLED
KNOB
Figure 14
1. On the first fan, install as directed in the
Owner’s Manual and perform the Code
Learning Procedure.
2. Turn the power OFF on the first fan by
either flipping the ON/OFF switch on
the SW350 or turning OFF the wall
switch (if using a SR330 Remote
Control). If there is no wall switch and
you are operating the fan with the
SR330 Remote Control only, discon-
nect the wiring harness in the receiver
(See Figure 15).
BP7253-2 4/28/06 11:58 AM Page 8

9
Once you have selected the correct light
(uplight or downlight) to control, use the
Up/Down arrow buttons (See Figure 16) to
increase or decrease the intensity of the
light.
Press the Up/Down arrow buttons to reach
the desired intensity, then release the
button when satisfied.
NOTE: Both uplight and downlight will
return to their pre-set intensity levels
when the lights are turned back on.
B. FAN ( ) Function
Your Emerson fan operates at six different
fan speeds (from low to high). When the
Fan On/Off button (See Figure 16) is
pressed for the first time, the fan will turn
on to high speed. When the Fan On/Off
button is pressed again, the fan will turn
off.
To change the fan speed and airflow
direction, proceed as follows:
Make sure you are in fan operation. Press
the Select button to change to fan
operation. The Fan On/Off button will glow
and the Up/Downlight indicators will both
be off. Once you have selected the fan
operation, use the Up/DownArrow buttons
to increase the fan speed to high or
decrease the fan speed to low. (Each time
the Up arrow button is pushed, the fan
speed will increase by one speed; each
time the Down arrow button is pushed, the
fan speed will decrease by one speed).
Press the Up/Down arrow buttons to reach
the desired speed, then released the
button when satisfied.
The receiver will always remember the last
fan settings when the fan On/Off button is
pressed to turn the fan back on.
C. SLEEP Function
Pressing the Sleep button will decrease
the fan speed by one speed every 60
minutes until the fan speed reaches its
lowest setting. If the fan is already on, then
it will decrease from its current setting. If
the fan is off, it will start from fan setting “3”
(medium) and decrease from there.
Once the Sleep function is activated, the
fan speed can be increased or lowered
using the Up/Down arrow buttons without
disabling the Sleep function. The fan will
continue to decrease by one speed every
60 minutes until the fan is on low speed.
NOTE: The Code Learning Procedure
must be performed before the wall
control will operate the fan or light.
NOTE: An audible tone will be heard
from the receiver whenever any of the
fan/light or any other function buttons
are pressed.
A. LIGHT ( ) Function
When the Light On/Off button is pressed
for the first time, the up and downlight on
the fan will turn on to a full brightness
level. When the Light On/Off button is
pressed again, the downlight and then the
uplight will turn off.
To change the light level of the uplight and
downlight, proceed as follows:
The uplight and downlight can be operated
independently. Press the Select button to
change between downlight/uplight/fan
operation. When the red Uplight indicator
is on, you are controlling the light level on
the uplight. When the green downlight
indicator is on, you are controlling the light
level of the downlight.
NOTE: The Light On/Off button features
a soft on/soft off feature that ramps the
downlight down and the uplight down
slowly. (This allows you to leave the
room before it is completely dark.)
Tap the Light On/Off button twice
quickly to turn off the downlight and
uplight quickly at the same time.
IMPORTANT
The installation of your fan must be
completed, including the installation of
the fan blades, before testing the wall
control.
CODE LEARNING PROCEDURE
Turn the power off at the SW350 wall
control.
After a few seconds, turn the power back
on at the wall switch. The receiver will
beep indicating the power is on.
During the first 2 minutes after power is
turned back on at the wall switch, press
the Code Learn button (See Figure 16)
with a pen or pencil or paper clip until 1
beep is heard from the SW375 Fan
Receiver.
Once the beep is heard, the SW375 Fan
Receiver has received the transmitter
code.
Operation of Your SW350 Wall Control (Figure 16)
BP7253-2 4/28/06 11:58 AM Page 9

Off On
Up Down
Lights
S
e
l
e
c
t
Fan
Sleep
F
l
o
w
S
e
c
u
r
i
t
y
LIGHT ON/OFF
BUTTON
ON/OFF
FAN BUTTON
CODE LEARN
BUTTON
ON/OFF SWITCH
UP/DOWNLIGHT
INDICATOR
UP/DOWN ARROW
CONTROL BUTTONS
SELECT BUTTON TOGGLES
BETWEEN FAN/UPLIGHT/
DOWNLIGHT OPERATION
10
Operation of Your SR330 Remote Control (Figure 17)
NOTE: In order to operate your fan with
the hand held remote, you must
complete the code learning procedure.
CODE LEARNING PROCEDURE
Turn the power off at the wall switch
and/or service panel.
After a few seconds, turn the power back.
During the first 2 minutes, after the power
is turned back on, press both the Select
and Sleep buttons at the same time until 1
beep is heard from the SW375 Fan
Receiver.
Once the beep is heard, the SW375 Fan
Receiver has received the transmitter
code.
NOTE: The Code Learning Procedure
must be performed before the remote
control will operate fan or light.
NOTE: An audible tone will be heard
from the receiver whenever any of the
fan/light or any other function buttons
are pressed.
A. LIGHT ( ) Function
When the Light On/Off button is pressed
for the first time the uplight and downlight
on the fan will turn on to a full brightness
level. All bars will be lit on the LCD Panel
for both the uplight and downlight. When
the Light On/Off button is pressed again
the downlight and then the uplight will turn
off.
To change the light level of the uplight and
downlight, proceed as follows:
The uplight and downlight can be operated
independently. Press the Select button to
change between downlight/ uplight/fan
operation. When the downlight symbol
glows on the LCD panel you have control
of the down light. When the uplight symbol
glows on the LCD panel you have control
of the uplight.
NOTE: The Light On/Off button features
a soft on/soft off feature that ramps the
downlight down and the uplight down
slowly. (This allows you to leave the
room before it is completely dark.) Tap
the Light On/Off button twice quickly to
turn off the downlight and up light
quickly at the same time.
Once you have selected the correct light
(up light or down light) to control, use the
Up/Down arrow Buttons (See Figure 17) to
increase or decrease the intensity of the
light. Press the Up/Down arrow buttons to
reach the desired intensity, then release
the button when satisfied. The bars on the
LCD panel will either increase or decrease
based on the Up/Down arrow button
pushed.
The receiver will always remember the last
Light settings when the Light On/Off
button is pressed to turn the light back on.
To cancel the Sleep function, press the
Fan On/Off button to turn the fan off.
D. SECURITY Function
When the Security button is pressed the
lights will flash and then come to full
brightness. The lights will remain on for a
random period between 8 and 63 minutes.
At that time the lights will turn off for a
period between 8 and 63 minutes. This
process will repeat itself indefinitely.
To cancel the Security function, press the
Light On/Off button.
Figure 16
BP7253-2 4/28/06 11:58 AM Page 10

11
B. FAN ( ) Function
Your Emerson fan operates at six different
fan speeds (from low to high). When the
Fan On/Off button (See Figure 17) is
pressed for the first time, the fan will turn
on to high speed and the fan symbol will
light on the LCD panel. When the Fan
On/Off button is pressed again, the fan will
turn off.
To change the fan speed and airflow
direction, proceed as follows:
Press the Select button to change to fan
operation. The Fan symbol will glow on the
LCD panel and both the up and down light
symbols indicators will be off.
Once you have selected fan operation,
use the Up/Down arrow buttons to
increase the fan speed or decrease the
fan speed. (Each time the Up arrow button
is pushed the fan speed will increase by
one speed; each time the Down arrow
button is pushed the fan speed will
decrease by one speed). The bars on the
LCD panel next to the fan symbol will
either increase or decrease based on the
Up/Down arrow button pushed.
The receiver will always remember the last
speed setting of the fan when the Fan
On/Off button is pressed to turn the fan
back on. It will return to its pre-set level.
Press the Airflow button to reverse the
direction of the fan.
The Air UP or Air DN symbols will be lit on
the LCD panel indicating which direction
the fan is running. When the fan is
spinning counter clockwise the fan is in
“Summer” operation and when the fan is
spinning clockwise the fan is in “Winter”
operation.
C. SLEEP Function
Pressing the Sleep button will decrease
the fan speed by one speed every 60
minutes until the fan reaches its lowest
setting. The Sleep icon will be seen on the
LCD panel indicating Sleep mode. If the
fan is already on then it will decrease from
its current setting. If the fan is off, it will
start from fan setting "3" (medium) and
decrease from there.
Once the Sleep function is activated, the
fan speed can be increased or lowered
using the Up/Down Arrow buttons without
disabling the Sleep function. The fan will
continue to decrease by one speed every
60 minutes until the fan is on low speed.
To cancel the Sleep function, press the
Fan On/Off button to turn the fan off.
D. WINTER Mode
When the Winter button is pressed the fan
will go in the clockwise direction and run at
low speed. The Winter icon will be lit on
the LCD display. Every ten minutes the fan
will turn up to high speed for three
seconds and then return to low speed.
This helps push warm air down from the
ceiling to reduce heating costs.
The lights can be turned on or off or
changed at any time without canceling the
winter function.
To cancel the Winter function, press the
Fan On/Off button
E. SECURITY Function
When the Security button is pressed the
lights will flash once and then come to full
brightness. The Security icon will be
displayed on the LCD panel. The lights will
remain on for a random period between 8
and 63 minutes. At that time the lights will
turn off for a period between 8 and 63
minutes. This process will repeat itself
indefinitely.
To cancel the Security function, press the
Light On/Off button.
Figure 17
Lights
Fan
S
e
l
e
c
A
i
r
f
l
o
w
S
l
e
e
p
S
e
c
ur
i
t
W
i
n
t
e
r
Fan Low
Down Light
Fan High
Up Light
Air
DN
Air
UP
FAN ON/OFF
FUNCTION
LIGHT ON/OFF
FUNCTION
LCD DISPLAY
UP/DOWN ARROW
CONTROL BUTTONS
SELECT BUTTON TOGGLES
BETWEEN
FAN/UPLIGHT/DOWNLIGHT
OPERATION
BP7253-2 4/28/06 11:58 AM Page 11

LIMITED WARRANTY
What The Warranty Covers:
All products covered by this Owner’s Manual are warranted against all defects in workmanship and materials.
You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
All components are covered by this warranty for one year from the date you purchased your Remote Control,
Wall Control, or Receiver ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson will replace a defective Emerson Remote Control, Wall Control, or Receiver at no charge to you.
We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs
or removal, reinstallation and shipping of the product to Emerson.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE REMOTE CONTROL, WALL CONTROL, OR RECEIVER
TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR OTHER PROOF OF PURCHASE. You can
return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to
Air Comfort Products, Division of Emerson Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136.
Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest
authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized
service center. Your Emerson Remote Control, Wall Control, or Receiver should be properly packed to avoid
damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
This warranty also does not cover any defects, malfunctions or failures caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your remote control while in your
possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal
wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are
voided when:
• The original purchaser or user ceases to own the product, or
• The ceiling fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other
written or oral warranties apply, and no employee, agent, dealer or other person is authorized to give any
warranties on behalf of Emerson Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS
WARRANTY AND EMERSON IS NOT RESPONSIBLE FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL
AND CONSEQUENTIAL DAMAGES. Incidental damages include but are not limited to such damages as loss of
time and loss of use. Consequential damages include but are not limited to the cost of repairing or replacing
other property which was damaged if this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above
exclusion or limitation may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
Part No. F40BP72530002 Printed in China 05/06 Form No. BP7253-2
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant ¥ St. Louis, MO 63136
BP7253-2 4/28/06 11:58 AM Page 12
