Emerson GirlPower GP765 User manual

BATTERY INSTALLATION
1
INSTALLING THE REMOTE CONTROL BATTERIES
The battery compartment is located on the rear of
the remote control.
•Remove the battery compartment door by
pressing down and sliding the door off.
•Insert two (2) AAA size batteries into the battery
compartment as shown below. Use a well
known brand of alkaline batteries for longest life
and best performance. Be sure to observe the
polarity markings which are engraved inside the
battery compartment. If the batteries are
inserted incorrectly, the remote control will not
operate.
•Replace the battery compartment door.
•Do not mix different types of batteries together
(e.g. Alkaline and Carbon Zinc) or old batteries
with fresh ones.
•When the operation of the remote control
becomes intermittent, replace the batteries. A
fresh set of alkaline batteries should operate the
remote for up to one year of normal use.
Thank you for purchasing the 5-in-1 Universal Remote Control. This uniquely
designed product can be easily programmed using the codes found at the back of
this manual, or automatically.
We are sure that this unit will provide you with many years of exceptional
performance with a minimum of care and maintenance. Please review the contents
of this instruction manual completely and carefully before operating your unit, to
make sure that you understand all functions and operations and get the maximum
benefit out of all the great features included in this product.

2
LOCATION OF CONTROLS
!
!
"
$
#
%
&
'



"
#
$
%
&
'
1. TV/AV Function Button
2. Number Buttons (0-9)
3. ENTER Button
4. TV Device Button
5. Fast Forward Button
6. SAT (Satellite)/CBL (Cable) Device
Button
7. Stop Button
8. Channel +/– Buttons
9. Pause Button
10. Record Button
11. Reverse Button
12. Red Indicator
13. Power Button
14. P. CH (Previous Channel) Button
15. SET Button
16. VCR Device Button
17. AUD (Audio)/DVD Device Button
18. Volume +/– Buttons
19. Mute Button

3
SETTING THE REMOTE
DIRECT ENTRY
Directly enter the three digit code found at the end of this manual as follows:
Turn on the power to the desired device you
want to control and press the respective
Device button (i.e. TV). Using the Remote
Codes table found at the end of this manual,
look up the brand and remote code for the
device.
1
Press and hold the SET button ❶, then the
TV button ❷ simultaneously; the Red
indicator will light. Release both buttons.
1
2
2
Using the Key buttons (0-9), enter the
three digit code of the desired device; the
Red indicator will go out. If the red
indicator blinks twice, it was done
incorrectly - repeat steps.
3
Aim the remote at the device and press
the Power button. If the device turns off,
then it is set. It is does not, repeat these
steps with another code. Write the code
down and repeat these steps for your
other devices.
4
DEVICE BUTTON: When this owner’s manual refers to the Device button, it is
referring to the TV, SAT/CABLE,VCR or AUDIO Device button you want to control.

4
SETTING THE REMOTE (CONTINUED)
AUTO SEARCH
Automatically search through the remote codes to find the appropriate code as follows:
Turn on the power to the desired device
you want to control and press the
respective Device button (i.e. TV).
1
While aiming the remote at the device,
press and hold the SET ❶ and Power ❷
buttons simultaneously for four seconds
until the red indicator lights, then release
the buttons. Auto Search will now be
performed.
1
2
2
When the device turns off, the remote is
now programmed properly. Press any
button to exit the Auto search mode and
the red indicator will go off. Make sure all
functions operate (channel, volume, etc.).
If they do not, repeats steps above.
3

5
SETTING THE REMOTE (CONTINUED)
MANUAL SEARCH
Manually search through the remote codes to find the appropriate code as follows:
NOTE: To exit the manual search, simply press any of the Device buttons (TV, VCR,
SAT/CBL, DVD/AUD) once or wait 30 seconds; the red indicator will go out automatically.
Turn on the power to the desired device
you want to control and press the
respective Device button (i.e. TV).
1
While aiming the remote at the device,
press and hold the SET button ❶ and the
desired Device button ❷(i.e. TV)
simultaneously; the red indicator will light,
then release the buttons.
1
2
2
Press the SET button ❶ again; the Red
indicator will blink. Press and release the
Power button ❷ repeatedly until the power
of the device (i.e. TV) turns off. When the
TV turns off, press the TV Device button
❸; the red indicator will go out. Make sure
the Channel, Volume, etc. operates
properly.
1
2
3
3
During Manual Search, press the SET
button to change the code search direction
from forward to backward. Press the SET
button again to change it back to forward
search. Repeat these steps for your other
devices.
4

6
SETTING THE REMOTE (CONTINUED)
PREPROGRAMMED REMOTE CODE DISPLAY
This feature will allow you to check which remote code is being used for each device.
Press the Device button of the unit you
want to check the remote code for (i.e.
TV).
1
Press and hold the SET button, then press
the 1 Key button if you want the first digit
of the remote code, 2 Key button if you
want the second digit or 3 Key button if
you want the third digit.
2
Release the SET button and the red
indicator will blink a set number of times to
indicate the digit. For example, if the code
was 345 and the 1 key button was
pressed in step 2, the red indicator will
blink three times.
3
PUNCH THROUGH
The remote will allow the Volume and Mute feature to operate the TV, even if another
device is selected. For example, while operating the VCR, simply press the Volume +/–
button to raise or lower the volume without having to press the TV Device button.

7
REMOTE CONTROL OPERATION
This universal remote control is compatible with most brands (infrared remote
control components made after 1990). Please refer to the Remote Code Tables.
When programmed, this remote control will operate the basic features of the
original device’s remote control. Simply press the desired Device button (TV,
VCR, SAT/CBL, DVD/AUD) of the unit you want to operate, to use the buttons
that correspond to that device.
TV/AV Function button controls AV input mode, such as TV/VCR button on VCR.
IF THE REMOTE CONTROL DOES NOT WORK:
•Make sure the remote is pointed at the remote sensor of the device you want
to operate.
•Make sure you pressed the correct Device button first (TV, VCR, SAT/CBL,
DVD/AUD).
•Make sure nothing is between the remote and the remote sensor on the device
you want to operate.
•Make sure the batteries are correctly installed and that they are not weak or
dead.
•Make sure the remote code is set properly.

8
REMOTE CODES TABLE
A-Mark 002
Abex 012
Admiral 024
Adventura 014
Aiko 023
Akai 011
Alaron 039
Allegro 057,058
Ambassador 037
Anam 019,040
AO C 002,006,011,041
Archer 002
Audiovox 002,023,040,050,055
Aumark 021
Baysonic 040
Belcor 006
Beuamark 004,011,039
Bradford 040
Broksonic 002,044,051
Brokwood 006
Candle 011,014,020,042
Carnivale 011
Carver 018
Celebrity 061
Cineral 023,050
Citizen 011,013,014,020,021,023,042,046
Clairtone 041
Concerto 020
Contec 032,040,041,067
Contec/cony 072
Craig 040
Crosley 018
Crown 013,040
CXC 040
Curtis Mathes 011,013,018,020,021,024,027,035,
050,052,059,060,067
Daewoo 006,013,023,050,055,056
Daytron 006,013
Denon 027
Dumont 004,006
Dwin 057,058
Electroband 041,061
Electrohome 048,067
Emerson 006,013,037,038,039,040,041,044,
046,047,051,055,056,062,067,075,
076
Envision 011
Fisher 030,033,070
Fujitsu 039
Funai 036,039,040
Futuretech 040
GE 008,010,024,047,050,059,060,066
Gibtralter 004,006
Goldstar 001,006,011,013,020,064,067
Go Video 021
Gradiente 017,020
Grunpy 039,040
Harman 018
Harman/Kardon 018
Harley Davidson 039
Harvard 040
Hitachi 012,020,027,062,063,067,072,077
Infinity 018
Inteq 004
J aneil 014
JBL 018
JC P enny 072
JCB 061
JVC 017,067,072
KEC 040
Kenwood 006
Kloss 009,014
KTV 013,040,041,046,067
LG 020
Luxman 020
LXI 004,018,030,031,060,070,071
Magnavox 007,009,011,018,025,036,039,042,
043,049,065,067
Marantz 011,018
MEI 041
Majustic 003
Matsushita 045
Megatron 002,027
Memorex 003,020,021,028,030,045
MGA 006,011,029
MGA/Mitsubishi 073
Midland 004,012,013
Minutz 008
Mitsubishi 006,024,028,038
Motorola 019,024
MTC 006,011,020,021,041
Multitech 040
NAD 031,035,038,071
National 019
NEC 006,011,020,053
Nikko 004,011,015,023,030,031,038,060
Noshi 005
NTC 023
Onwa 040
Optimus 030,035,045
Optonica 024,034
Orion 039,044,051
Panasonic 001,015,016,017,018,019,021,024,
027,028,030,031,034,038,045,060,
074
Penney 002,005,006,008,010,011,012,013,
015,016,020,021,031,038,060,067
Philco 006,007,009,011,018,024,027,042,
043,051,065,067
Philips 004,005,006,007,008,009,013,018,
036,061,065,082,067
Pilot 006,011,013
Pioneer 035,062
Portland 006,013,023,067
Prism 016
Proscan 011,015
Proton 002,038,052,067
Pulsar 004,006
Quasar 016,019,034,045
Radio Shac k 006,012,013,015,020,030,034,038,
040,067,070
RCA 005,006,015,016,022,024,059,060,
062,078
TV

REMOTE CODES TABLE (CONTINUED)
9
Realistic 011,012,013,020,030,034,038,040,
070,075
Rhapsody 041
Runco 004,011,053,054,080
Sampo 011,012,013
Samsung 011,012,013,020,021,038,067,079
Samsux 013
Sansei 050
Sansui 051
San yo 028,030,033,070
Scotch 038
Scott 006,038,039,040,044,067
Sears 015,018,020,028,030,031,033,036,
038,039,070,071,072
Semivox 040
Semp 031
Shar p 013,024,032,034,049,067,081
Shogun 006
Signature 003
Silvania 007,009,011,025,042
Simpson 042,043
Sony 026,061
Soundesign 038,039,040,042
Spectr icon 002
Squareview 036
SSS 040
Starlite 040
Supre-Macy 014
Supreme 061
Sylvania 018,043,048,065,069
Symphonic 036
Tandy 024
Tatung 002,019,071
Technics 004,015,016,045,060
Technika 003,006,013,018,020,021,023,028,
039,040,042,072
Technol Ace 039
Techwood 002,020
Telefunken 020
Teknika 067
TMK 020,037,038
Toshiba 021,030,031,070,071,072
Tosonic 041
Totevision 013,067
Trical 032
Universal 008,010
Vector Research 011
Victor 017
Vidikron 018
Vidtech 006,038
Viking 014
Wards 007,008,010,011,018,020,025,026,
031,034,038,039,043,065,066
Westinghouse 055,056
Words 003,006
Yamaha 006,011
Zenith 003,004,023,028
Zonda 002
Some models 068
Asha 042
Audiovox 009
Beaumark 042
Bell & Howell 029
Broksonic 001,033,035,038,045,049,071
Calix 009
Canan 007
Capehart 003
Carver 028
CCE 027,044
Cineral 044
Citizen 009,044
Colt 027
Craig 009,018,027,042,043
Curtis Mathes 007,013,034
Daewoo 003,016,044,051
Daytron 003
Denon 014
Dynatech 059
Electrophonic 009
Electrohome 009
Emerex 004
Emerson 001,008,009,015,021,022,026,033,
035,037,038,040,044,045,049,051,
059,071
Fisher 018,020,024,029
Fuji 005,007
Funai 059,070
Garrard 059,070
GE 007,019,036,042
Goldstar 009,010
Go Video 047,050,072,073
Gradiente 002,059
Harley Davidson 059
Harman/Kardon 010,028
Harwood 026,027
Headguarter 017
HI-Q 018
Hitachi 013,014,030,059
Jensen 013
JVC 002,013,025
KEC 009,044
Kenwood 010,013,017,025
KLH 027
Kodak 007,009
Logik 027
Lloyd’s 037,059
LXI 009
Magnasonic 044,052
Magnavox 007,011,028,032,059
Magin 042
Marantz 007,010,028
Marta 009
MEI 007
Matsushita 007,034,048
Memorex 007,009,011,017,018,019,029,042,
046,053,056,057,059
MGA 015,021,022,042
MGNTechnology 042
Minolta 014,030
Mitsubishi 015,019,021,022,025,074,075
Motorola 007,019
MTC 042,059
Multitech 027,059
NAP 005,006,007,009,011,014,024,030
NEC 010,012,013,025,029
American High 007
Admiral 019
Adventura 059
Aiko 044
Aiwa 009,046,059,067,068
Akai 013,021,022,030,069
Amstrad 070
VCR

REMOTE CODES TABLE (CONTINUED)
10
Nikko 009
Nikon 006
Noblex 042
Olympus 007
Optimus 009,019,029,034,047,048,052,054,
055,056,057
Optonica 023
Orion 001,035,045,049
Panasonic 007,034,041,048,056
Penney 007,009,010,012,014,020,042
Pentax 014,030
Philco 007,038
Philips 023,028,032
Pilot 009
Pioneer 025
Portland 003
Profitronic 042
Proscan 036
Protec 027
Pulsar 011
Quasar 007,034,048,056
Quarter 017
Quartz 017
Radio Shack 053,059
Randex 009
RCA 007,014,019,030,031,036,042
Realistic 007,009,017,018,019,023,024,029,
059
Ricon 006
Ridix 009
Runco 011
Samsung 016,042
Sanky 011,019
Sansui 013,025,043,049,059
Sanyo 017,018,029,042
Scott 015,016,033,035,039,040
Sears 007,009,014,017,018,020,024,029,
030,059
Semp 016
Sharp 019,023
Shintom 027
Shogun 042
Signature 007
Singer 027
Sony 004,006,007,059
STS 014
Sylvania 007,015,028,032,059
Symphonic 052,059,070
Tatung 013
Teac 013,059
Technics 007,011,034,036
Technika 007,009,059
Thomas 059
TMK 008,037,042
Toshiba 015,016,024,039,040
Totevision 009,042
Unitech 042
Vector 016
Vector Research 010,012
Vediosonic 042
Video Concepts 012,016,021,022
Wards 007,014,016,018,019,023,027,028,
040,042,059
White Westinghouse 044
XR-100 007,027,059
Yamaha 010,013
Zenith 005,006,011,049,059
Some models 060,061,062,063,064,065,066
Aifa 190
Aiko 184
Alfa Gold 177
Alphastar 078,124
Best 148
Channel Master 046,062
Chaparral 049,060,062,063,098,114
Citoh 125
Digital Satellite TV 179,180,181,182
Drake 046,050,065,102,106,108,115,118,
121,169,170
Drake Satellite 139,140,141
Dx Antenn 047
DX Communications 116
Echostar 055,057,066,079,099,111,149,153,
156,157,158,159,160,163,164,165
Equus 110
Eurostar 166
Expressvu 079
Fortec Star 175,176
Fujitsu 095
General Instrument 068,091,092,093,117,126,127
Hitachi 081,261
Homecable 064
HTS 079,112
Hughes Network Sys. 077
Hughes Satellite 261
Instrument 072
Intersat 113
IQ 061
IQ Prism 061
Janeil 056,095
Jerrold 068,072
JVC 079
Kenwood 096
Legend 066,099
Macom 046,089,093,126
Macom Satellite 138
Magnavox 075,076
Memorex 066,076
Micro Formula 171
Mina 167
Mitsubishi 168
Orb 104
Orbit 162
Pace 189
Panasonic 056,074,088
Pansat 101,120,151
Panaset 187
Pbi 171
Philips 059,075,076,174
President 051
Primester 068,072,150
Prosat 145
Proscan 071
Quick Draw 116
Radio Shack 071,091,092
RCA 054,070,071,082,143,183
RCA DSS 263,264,265
RC-AK 152
Realistic 052
Rural Cable 091
Samsung 124,155
Scientific Atlanta 146,183
Signal Super LT 930 154
Skardin 191,192,193
Sony 073
SATELLITE
