Emerson 110V User manual

(07/04)
N Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
S
Si in ng gl le e P Po ol le e 1 11 10 0V V
U
Us se er r M Ma an nu ua al l
HOT
SWAP
Network Power Switch
Liebert NPS

(07/04)
Dear Customer,
Please accept our thanks for giving us the privilege to serve you by choosing a Liebert make
product.
If this is your first Liebert product, we hope it is the beginning of a long relationship which
delivers value to your organisation. If you already own and use a Liebert product, we are
doubly honoured by your decision of continuing this relationship.
It is our constant endeavour to partner you for the growth and success of your business. This
philosophy is reflected in our Mission statement “To deliver value through Air & Power
Quality solutions to achieve customer delight”. Please do give us feedback to help us
realize our Mission.
Emerson Network Power

USER MANUAL
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page i
ENGLISH
This manual describes installation and operation procedures for the
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h.
All relevant parts of the manual should be read prior to commencing installation.
If you encounter any problems with the procedures contained in this manual
you should seek immediate assistance from the Liebert Sales Office
from whom the equipment was purchased.
Liebert Corporation pursues a policy of continual product development and reserves the right to change the
equipment design without notice.
 Copyright 2003 by Liebert Corporation.
Unauthorized reproduction prohibited
All rights reserved.

USER MANUAL
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page i
REGISTERED HEAD OFFICE
EMERSON NETWORK POWER (India) Pvt. Ltd.
Plot no. C-20, Road no. 19
Wagle Industrial Estate
Thane – 400 604 Maharashtra, India
TELEPHONE: [phone]
FAX: [phone]
Z O N A L O F F I C E S
MUMBAI
B 414-424, Bhaveshwar Arcade,
(opp. Shreyas cinema), LBS Road,
Ghatkopar(W), MUMBAI – 400 086
Tel : [phone]
Fax: [phone] Pager : 9623-988 000
Mobile : [phone]
NEW DELHI
18 / 14, WEA, Pusa Lane, Karol Baug;
NEW DELHI 110 005
Tel : [phone],
5744774, 5766438
Fax: [phone]
Pager : 9632-100 300
KOLKOTA
77 A, Raja Basant Roy Road,
KOLKOTA – 700 029
Tel : 033 - 4646387, 4647197
Fax: 033 – 4667172

USER MANUAL
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page ii
Branch Offices:
BARODA
39 / 2, Arunodaya Society,
Alkapuri, BARODA-390 005
Tel : [phone], 330383
Fax: [phone], 330383
JAMSHEDPUR
Kashi kunj, Road no. 2, Gr. Floor
Contractor’s area, Bistupur;
JAMSHEDPUR – 831 001
Tel : [phone]
Fax: [phone]
CHANDIGARH
SCO-198 / 199 / 200,
Sector – 34A, Near Labour Chowk,
CHANDIGARH
Phone: [phone]
Mobile: [phone]
LUCKNOW
206, Sriram Tower, Ashok Marg
LUCKNOW
Phone : [phone]
Pager : 9628-555091
Mobile: [phone]
CHENNAI
No. 22, First Floor, Gopal Krishna Road,
T. Nagar, CHENNAI – 600 017
Tel : 044 - 8231742, 8221063, 8228996
Fax: 044 - 8231742
NAGPUR
203, Ganga Apts,
13, Giripeth
NAGPUR 400 010
Phone / Fax : 0712 – 540423, 548551
COCHIN
Lakshmini No. 36 / 2684,
Veluthamma House, Azad Road,
Kaloor, COCHIN 682017
Tel : 0484 - 341985
Fax: 0484 - 341986
PUNE
B-6, Shri Dwarka co-op. Society,
467/ C1, Hare Krishna Mandir Path,
Model Colony, Off University Road,
PUNE – 411006
Tel : 020 - 5676975, 5670709
Fax: 020 - 4004020
GOA
622 / A, La Citadel Colony
Dona Paula, GOA – 403 004
Tel : c/o. 0832 – 220 723
SECUNDARABAD
Plot no. 4, Sardar Patel Road
SECUNDARABAD – 500 003
Tel : 040 - 7717263, 7719196
Fax: 040 - 7806502
GUWAHATI
South Savania, Ashram Road,
Ulubari, GUWAHATI 781 007
Tel : 0361 - 543848
Fax: 0361 - 543270
Mobile: [phone]

USER MANUAL
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page iii
Safety Precautions
WARNING
Personnel operating on any apparatus referred in this manual must know extensively the product.
The Network Power Switch must be commissioned and serviced by an engineer approved by the manufacturer (or his
agent).
Failure to do so could result in personnel safety risk, equipment malfunction and invalidation of warranty.
CONFORMITY AND STANDARDS
The optional device complies with the requirements of the standards identified at the beginning of the User’s
Manual supplied with the Network Power Switch
Continued compliance requires installation in accordance with these instructions and the use of manufacturer
approved accessories only.
General
The unit must be grounded in accordance with current electrical regulations.
General
As with other types of power equipment, dangerous voltages are present within the Network Power Switch
enclosure. The risk of contact with these voltages is minimized as the live component parts are housed behind a
hinged, lockable door.
No risk exists to any personnel when operating the equipment in the normal manner, following the recommended
operating procedures.
All equipment maintenance and servicing procedures involve internal access and should be carried out only by
trained personnel.
Guide to the Instructions
The warning triangle indicates all the personal safety instructions.
Follow these instructions carefully to avoid injury.

USER MANUAL
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page iv
Table of Contents
1Chapter 1 – General description ............................................................................................................................... 1-1
1.1 Introduction.......................................................................................................................................................... 1-1
1.2 Design Concept.................................................................................................................................................... 1-2
1.3 Mechanical Design Description .......................................................................................................................... 1-3
1.4 Mimic Indications ................................................................................................................................................ 1-4
1.5 Manual Bypass Switch Operation ....................................................................................................................... 1-5
1.6 Potential free contacts.......................................................................................................................................... 1-6
2Chapter 2 – Operating Instructions........................................................................................................................... 2-1
2.1 Introduction.......................................................................................................................................................... 2-1
2.2 General Notes....................................................................................................................................................... 2-1
2.3 Procedure for Switching the Network Power Switch to power the load from a Power Off condition.............. 2-1
2.4 Switching the Load to Manual Bypass condition ............................................................................................... 2-2
2.5 Procedure for switching the Network Power Switch from Manual Bypass condition to Normal Operation.... 2-2
3Chapter 3 – Installation Procedure ........................................................................................................................... 3-1
3.1 Introduction.......................................................................................................................................................... 3-1
3.2 Equipment positioning and environmental considerations................................................................................. 3-1
3.3 Connecting cables to Network Power Switch..................................................................................................... 3-2
3.3.1 Cable entry ....................................................................................................................................................... 3-2
3.3.2 Cable Rating..................................................................................................................................................... 3-2
3.3.3 Cable connections ............................................................................................................................................ 3-3
3.3.4 Safety earth....................................................................................................................................................... 3-3
3.3.5 Protective devices............................................................................................................................................. 3-3
3.3.6 Cabling Procedure............................................................................................................................................ 3-3
4Chapter 4 - Specifications......................................................................................................................................... 4-1
4.1 General Specifications ......................................................................................................................................... 4-1
4.2 Electrical Specifications ...................................................................................................................................... 4-1
4.3 Mechanical specifications.................................................................................................................................... 4-2
4.4 Environmental specifications .............................................................................................................................. 4-2
5Installation Drawings ................................................................................................................................................ 5-1
5.1.1 Power Circuit Diagram .................................................................................................................................... 5-1
5.1.2 External Power cable connections ................................................................................................................... 5-1
5.1.3 Overall general arrangement............................................................................................................................ 5-1
5.1.1 Power Circuit Diagram .................................................................................................................................... 5-2
5.1.2 External Power cable connections ................................................................................................................... 5-3
5.1.3 Overall general arrangement............................................................................................................................ 5-4

USER MANUAL
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page v
This manual describes the following equipment:
EQUIPMENT PART NUMBER
3kVA, 110V, 25A, 1 Pole Network Power Switch (Rev00) 492100399001

User Manual Chapter 1 - General Description
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page
1-1
1 Chapter 1 – General description
1.1 Introduction
The Network Power Switch is an automatic static transfer switch designed to provide fast automatic transfers between
two independent, synchronous AC power sources to provide continuity of AC power to critical equipment, such as
information technology equipment.
One of the two AC inputs is designed as the “preferred” source to which the Network Power Switch will connect the
load as long as the designated input source is within the acceptable limits, the Network Power Switch is designed to
transfer the output load to the “alternate “input source, as long as the alternate source is within the acceptable voltage
limits.
The Network Power Switch provides fast, break-before-make transfers to prevent interconnection of the two sources,
even under faulted source conditions.
The maximum sense and transfer times are within the tolerance of IEEE Standard 446 susceptibility curve for
information technology equipment to allow uninterrupted load equipment operation.
In case of overload, Network Power Switch gives the alarm. Under Short-circuit condition a fast acting semi conductor
fuse protects condition of the load.
Manual Bypass Switch
The entire power static switch module is hot swappable. Before removing this module the load is transferred, without
break to any one of the source directly by using the Manual bypass switch. After replacing the static switch module, the
load is restored on static switch module, using the Manual bypass switch.
Block Diagram
Fig 1.1 – Block Diagram of Network Power Switch
L1 BYP.
L2 BYP.
STATIC
SWITCH
L1
L2
MAN. BYP. SW
N1
N2
OUTPUT
NET WOR K POW ER SWIT CH
NEUTRAL
L
N

Chapter 1 - General Description User Manual
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page 1-2
1.2 Design Concept
Fig 1.2 - Power Circuit Diagram for Network Power Switch
Figure 1.2 shows the Power circuit diagram for Network Power Switch. Source 1 & Source 2 are the two
synchronized power sources with fuse switches FS1 & FS2 & pair of SCR’s TA & TB in series with each path.
Logic dictates that at any time only one pair of back-to-back connected SCR’s in the line path should conduct. This
routes the input power to the output load. Should the load feeding source fail due to any reason; the other source takes
over automatically in less than 6 ms.
This ensures that the critical load always receives the power & changeover time is less than the tolerance limit set by
IEEE 446 (CBEMA curve) for information technology equipments. The change over is always with break, which
ensures that in no case two sources get paralleled.
Priority source can be selected through front panel switch. The live mimic on front panel indicates which source is on
priority & which is feeding the load. Figure 1.4 shows the details of live mimic panel.

User Manual Chapter 1 - General Description
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page
1-3
1.3 Mechanical Design Description
Fig 1.3 – Hot swappable and Fixed Unit
The Network Power Switch consists of two modules.
Fixed module consists of the input and output connections and manual bypass transfer control switch.
Second module is hot swappable plug-in type with removable electronics & static switching module.
The bypass / transfer control switch is located on right side of the cabinet with a key lock to restrict access to qualified
or designated operators. The plug in module likewise contains locked latches to prevent unauthorized removal of the
module. The Network Power Switch is designed to allow replacement of the removable electronics switching module
without having to de-energize the load equipment.
Entire power static switch module is hot swappable. Before removing this module the load is transferred without break
to any one of the source directly. After replacing the static switch module, the load is again transferred back to Network
Power Switch without break.
FIXED UNIT
HOT SWAPPABLE UNIT

Chapter 1 - General Description User Manual
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page 1-4
1.4 Mimic Indications
Fig 1.4 – Mimic and LED Indications
LED INDICATION
Mimic indications: Ten LEDs are mounted on the mimic plate;
Glowing LED’s indicate the status of the Network Power Switch.
S1 Healthy: Source –1 is a healthy source and is well above the 10% under voltage setting.
S2 Healthy: Source –2 is a healthy source and is well above the 10% under voltage setting.
S1 Priority: The priority selector switch is on S1 priority position.
S2 Priority: The priority selector switch is on S2 priority position.
S1 Feeding: The load is fed through source –1.
S2 Feeding: The load is fed through source -2.
Overload: Overload has occurred i.e. current level crossed 110% of full load.
Unsynchronized: The sources are out of phase-synchronized window.
Load on S1: Source –1 is feeding the load.
Load on S2: Source –2 is feeding the load.
S1 Healthy S1 Priority S1 Feeding
S2 Healthy S2 Priority S2 Feeding
Priority
Selection
Switch
Load on S1
Load on S2
Load on Super Switch
Unsynchronised transfer

User Manual Chapter 1 - General Description
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page
1-5
1.5 Manual Bypass Switch Operation
Fig 1.5 – Manual Bypass Switch Operation
Manual Bypass switch is used only when a fault occurs in the Network Power Switch and the control circuitry of the
Network Power Switch is to be checked. For doing this operation the load is connected to the bypass. For Normal
Operation, the position of the switch should be at Network Power Switch output position (i.e. horizontal)
If the load is to be fed through the source 1 Bypass, first it is to be unlocked and the knob should be rotated
upwards. To feed through source 2 bypass the knob is to be rotated downward.
A mechanical interlocking arrangement is provided on this Bypass switch, by which the Hot swappable unit can be
removed only when load is connected to bypass. In normal operation when the load is connected to Network Power
Switch, the Hot swappable unit cannot be removed.
Operating Network Power Switch in Normal Mode (load connected to Network Power Switch output)
• Unlock the Manual Bypass Switch with the key provided.
• Depending upon the available healthy source (i.e. either Source-1 or Source-2 ) select it by changing the
Manual Bypass Switch position.
• Unlock the sliding module
• Pull out the Hot swappable sliding module out of the Network Power Switch, which contains (SCR
assembly, control circuitry).
Operating Network Power Switch in Bypass mode
• Insert the Hot swappable module into the Network Power Switch unit
• Lock the sliding module for preventing its accidental opening.
• Unlock the Manual Bypass Switch with the key provided
• Connect the Load output to Network Power Switch by changing the switch position to Network Power
Switch output.
• Depending on the priority switch, Load will get transferred to source-1, if the priority switch is on source1.
• The Static Switch output position LED will glow
YELLOW LED
(LOAD ON S2)
YELLOW LED
(LOAD ON S1)
BYPASS ON S1 SOURCE
BYPASS ON S2 SOURCE
OUTPUT

Chapter 1 - General Description User Manual
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page 1-6
1.6 Potential free contacts
The Network Power Switch status can be checked with the 37-pin D-type connector, located on the rear end. This is a
potential free contact, and gives following indications as shown in Table 1-1 –
Table 1-1
The pin details for this connector is shown in fig 1.6
Two potential free contacts indicating Source 1 and Source 2 Healthy conditions are taken from this 37 pin D type
connector and terminated at rear terminal connectors, as shown in figure 1.7.
Fig 1.6 – Pin details for 37 pin D-type Connector
Fig 1.7 – Potential free contacts Connectors
191837363517Unsy nc h
193416151433S2 Feed
191332313012S2 Healthy
19291110928S1 Healthy
1982726257S1 Feed
192465423Priority
192132120Overload
CommonNONCCommonNONC
Termination available of 37 pin D-type connectorStatus
191837363517Unsy nc h
193416151433S2 Feed
191332313012S2 Healthy
19291110928S1 Healthy
1982726257S1 Feed
192465423Priority
192132120Overload
CommonNONCCommonNONC
Termination available of 37 pin D-type connectorStatus
1219 3456789101112131415161718
2037 21222324252627282930313233343536
52 50 51
Pin Details
50
–
S2 Healthy
51
–
S1 Healthy
52
-Common
O/p Line Input Fus e 1
Input Fus e 2
Rear View
Neutral - 2 Neutral - 1 I/p Line - 2 I/p Line - 1
Common
S2 Healthy S1 Healthy
Common
S2 Healthy S1 Healthy
52 50 51
POTENTIAL
FREE CONTACTS

User Manual Chapter 2 – Operating Instructions
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page
2-1
2 Chapter 2 – Operating Instructions
2.1 Introduction
The Network Power Switch can be considered to be in one of the three operating conditions:
• Normal Operation - All relevant power switches and fuses closed and the Load is connected to Network
Power Switch output
• Manual Bypass – The load is connected to the input supply directly.
• Shut down - All power switches are off and load is not operational.
2.2 General Notes
NOTE: All users controls and indicators mentioned in these procedures are identified in chapter1
Fig 2.1 - Power Connection details for Network Power Switch
2.3 Procedure for Switching the Network Power Switch to power the load from a Power Off
condition
This procedure should be followed when turning on the Network Power Switch from a fully powered down condition
-i.e. when the load is not being initially supplied at all. It is assumed that the installation is complete; the authorized
personnel have commissioned the system.
1. Select the priority to source1. Close the fuse FS1.
2. Check for the LED S1 healthy, S1 priority, S1 feed and LED load on source1 to glow.
3. Close the fuse FS2.
4. Check for the LED S2 healthy to glow.
5. Using priority switch transfer the load to source2, check this transfer does not affect the load.
6. Transfer the load to source 1 again and check this transfer does not affect the load.
O/p Line Input Fus e 1
Input Fus e 2
Rear View
Neutral - 2 Neutral - 1
Snap-on
Connector
External Cables
I/p Line - 2 I/p Line - 1
Earthing
Comm on
S2 Healthy S1 Healthy
Comm on
S2 Healthy S1 Healthy
Potential
Free Contacts
External Cable

Chapter 2 – Operating Instructions User Manual
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page 2-2
2.4 Switching the Load to Manual Bypass condition
Fig 2.2 – Switching to Bypass
WARNING
This operation should be performed by Trained personnel only.
SWITCH TO YELLOW LED ‘ON’ POSITION ONLY.
1. By seeing the LED indication check which source is feeding.
2. Unlock the Bypass switch lock by the using the key provided.
3. Rotate the Manual Bypass switch in the direction of the source feeding the load as per the warning given on the
mimic.
4. Relock the Bypass switch, remove the key and keep it in original place.
2.5 Procedure for switching the Network Power Switch from Manual Bypass condition to
Normal Operation
1. Unlock the Bypass switch using the key provided.
2. Rotate the bypass switch knob to the Static switch output position, i.e. horizontal position.
3. Lock the Bypass Switch, remove the key and keep it in original place.
YELLOW LED
(LOAD ON S2)
‘ON’
YELLOW LED
(LOAD ON S1)
BYP ASS ON S1 SOURCE
BYP ASS ON S2 SOURCE
(LOAD CONNECTED TO THIS BYPASS)
OUTPUT
(NOT CONNECTED)

User Manual Chapter 3 – Installation Procedure
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page
3-1
3 Chapter 3 – Installation Procedure
3.1 Introduction
WARNING
Do not apply electrical power to the Network Power Switch equipment before the arrival of the
commissioning engineer.
WARNING
The Network Power Switch equipment should be installed by a qualified engineer in accordance with the
information contained in this chapter and the drawing package shipped inside UPS cabinet.
This chapter contains information regarding the positioning and cabling of the Network Power Switch.
Because every site has its peculiarities, it is not the aim of this chapter to provide step-by-step installation
instructions, but to act as a guide to the general procedures and practices that should be observed by the
installing engineer.
3.2 Equipment positioning and environmental considerations
The Network Power Switch cabinets are designed to fit in standard 19-inch rack. In case of non-availability, it can be
kept on floor or as a tabletop item, with sufficient ground clearance.
The super switch module should be located in a cool, dry, clean environment with adequate ventilation to keep the
ambient temperature within the specified operating range.
WARNING
The Network Power Switch cabinet is connected with live voltages,
hence it should be located at safe place.
Before Installing, the ‘Transit Clamps’ are to be removed as shown in the figure 3.1. Without removing the clamps, the
Hotswap unit cannot be opened.
Fi
g
3.1
–
Removal of Transit Clam
p
s

Chapter 3 – Installation Procedure User Manual
N
Ne et tw wo or rk k P Po ow we er r S Sw wi it tc ch h
Page 3-2
3.3 Connecting cables to Network Power Switch
WARNING
BEFORE CABLING-UP THE NETWORK POWER SWITCH, ENSURE THAT YOU ARE AWARE OF
THE LOCATION AND OPERATION OF THE EXTERNAL ISOLATORS THAT CONNECT THE
NETWORK POWER SWITCH INPUT SUPPLY TO THE MAINS DISTRIBUTION PANEL.
CHECK THAT THESE SUPPLIES ARE ELECTRICALLY ISOLATED, AND POST ANY NECESSARY
WARNING SIGNS TO PREVENT THEIR INADVERTENT OPERATION.
3.3.1 Cable entry
Cable enter the Network Power Switch cabinet, from the rear side as shown in figure 3.2. The cables are terminated on
the connectors and fuses.
3.3.2 Cable Rating
Following are the recommended cable size for 6kVA Network Power Switch –
Table 3-1
Description Max. Current rating (Amp) PVC cable (sq.mm)
Input Cables 25 4
Output Cables 25 4
Earthing - 2.5
Note:
These recommendations are for guideline purposes only and may be superseded by local regulations and codes
of practices.
