EMPORIA TOUCH smart.2 User manual

English
Eveline Pupeter, emporia Telecom
www.emporia.eu
Thank you for purchasing an emporia product!
Please read this user guide before
attempting to use your phone.
TOUCH
smart.2
Wi-Fi
connection or
mobile data tariff
required

2
1
4
16
7
9
12
11
3
13 14
21
18
20
19
5
10
› YOUR MOBILE PHONE AT A GLANCE
1Loudspeaker
2Home screen
3Navigation ring
4Left function key
5Selection key
6Right function key
7Phone book key
8Camera key
9Green key
10 Chat app key
11 Red key
12
1
key (voicemail)
13 Camera lens and ash
14 Emergency button
(extra battery cover without
an emergency button)
15 Headset port
16 Torch button
17 Volume controls
and
18 Battery cover
19 Loudspeaker
20 Microphone
21 Port for USB charging cable
6
15
17
8
›Symbols on the external
display
Reception indicator
Battery
12:3012:30 Time
21.0821.08 Date
SunSun Day
Incoming call
Missed call
New SMS
New messaging
appmessage
›Other symbols on
the home screen
Vo LTE
Reception indicator
Wi-Fi
Alarm
Silent mode
Bluetooth
12 °C12 °C Temperature

› SYMBOLS AND OPERATING THE PHONE
ENGLISH–03
›How do I return a missed call?
1. Tap on the word Show on the screen below the notication
Missed call.
2. The call function will open and the number or name of
thecaller will be highlighted by a red bar.
›How do I access a new SMS message?
1. Tap on the word Show on the screen below the notication
New message.
2. The text message function will open.
3. The number or name of the sender will be highlighted by a bar.
4. Tap on the new SMS to read it.
›How do I access a new messaging app message?
• Tap on the chat app key to open the app.
›How do I remove indicators for missed calls,
SMS messages and messaging app notifications?
The symbols on the external display and along the top of the
screen will disappear as soon as you've read the SMS, opened
the messagingapp or had a look to see who the missed call
was from.

ENGLISH–04
› CONTENTS
› Your mobile phone at a
glance..................02
› Symbols and operating
thephone ..............03
1. Getting started .........06
1.1 Inserting a SIM card........06
1.2 Inserting and charging
thebattery................06
1.3 Turning on the phone......07
1.4 Entering a PIN code........07
1.5 Saving battery power......07
2. Setting up your phone...08
2.1 Setting up a
messaging app............08
2.2 Personalising the menu ....09
2.3 Updating your system
andapps..................09
3. Using the phone ........10
3.1 Using the home screen ....10
3.2 Dual-function keys ........10
3.3 Using the menu ...........11
3.4 Writing text ...............12
4. Calls ...................13
4.1 Accepting, rejecting or
ending a call ..............13
4.2 Calling someone ..........13
5. Contacts................14
5.1 Searching for a contact
in the phone book.........14
5.2 Adding a contact ..........14
5.3 Transferring contacts ......15
5.4 Opening and editing
acontact record ...........16
5.5 Contact options ...........17
6. Messages (SMS) .........18
6.1 Writing and sending
amessage ................18
6.2 Reading a message ........18
7. Messaging app..........19
7.1 Setting up a messaging app19
7.2 Using the messaging app ..19
7.3 Closing the messaging app 19

ENGLISH–05
8. Info centre .............20
8.1 Receiving a notification ....20
8.2 Opening a notification .....20
8.3 Deleting notifications......20
9. Camera.................21
9.1 Taking a photo or
recording a video..........21
9.2 Changing the camera
settings...................21
10. Photo album............22
10.1 Viewing a photo or video ..22
10.2 Sending or editing a photo 22
11. Settings ................24
11.1 Alarm.....................24
11.2 Silent mode ...............24
11.3 Wi-Fi......................25
11.4 Bluetooth .................25
11.5 Mobile data . . . . . . . . . . . . . . .26
11.6 Flight mode ...............26
11.7 Location (GPS).............26
11.8 Open to answer calls.......26
11.9 Voice assistant ............27
11.10 Wi-Fi hotspot ............27
11.11 Wallpaper ...............27
11.12 Messaging app ..........27
11.13 More settings............28
12. Internet ................29
13. Calendar ...............30
13.1 Entering a new event ......30
13.2 Opening an event
you've entered ............31
13.3 Searching for an event .....31
14. System updates.........32
15. Weather ................33
16. Emporia emergency call
function................34
17. Guarantee and service...36

ENGLISH–06
1. GETTING STARTED
1.1 Inserting a SIM card
1. Remove the battery cover (opening in the bottom left-hand corner).
2. Slide the SIM card into the SIM card holder with the gold
contacts facing down.
3. To add more storage, insert a memory card into the memory
card holder with the gold contacts facing down.
1.2 Inserting and charging the battery
1. Insert the battery, making sure that the battery contacts touch
the phone's gold contacts.
2. Place the battery cover over the battery and click it into place.
3. Plug the charging cable into the USB port of the phone and
the power plug into a mains outlet.
Charge the battery for at least four hours before the rst time you
use it. Only use batteries and chargers that are permitted for use
with this specic model.

ENGLISH–07
1.3 Turning on the phone
• Press and hold the key for at least two seconds until
the emporia logo appears. It will take a few seconds for the
homescreen to be displayed.
• To turn the phone o, press and hold the key
for 2seconds again.
1.4 Entering a PIN code
• Enter the four-digit PIN code for your SIM card when asked
todo so and conrm the entry.
• You can change or turn o the PIN code in Menu _Settings
_More settings _SIM card lock.
You have a maximum of three attempts to enter the correct
number. If you enter the wrong number three times in a row, you
will only be able to unblock the SIM card with the PUK code. You
will nd your original PIN code and PUK code in the documents
supplied with your SIM card by your network operator.
1.5 Saving battery power
After a few seconds of inactivity, the display will turn o to
save battery power. In the event of an incoming call or you
pressing any key, the screen will automatically light up again.

ENGLISH–08
2. SETTING UP YOUR PHONE
When you use a new SIM card for the rst time, you need to set
the language, date, time and any data connections. You can also
congure and change these later in Menu _Settings if you wish
(See »11. Settings« on page 24).
If you use the phone's mobile data facility, your network tari
must include mobile data. Ask your retailer or network provider for
more information.
2.1 Setting up a messaging app
1. When on the home screen, press the chat app key and
select YES to conrm your answer to the security question.
2. Select the messaging app you want to install.
You can choose from Signal, Telegram and WhatsApp.
3. Pressing the chat app key again now will open
themessaging app you've selected straight away.
More information on setting up a messaging app is available in
the messaging app manual, which is supplied separately.

ENGLISH–09
2.2 Personalising the menu
• The menu has been preset to display the following functions:
Contacts, Messages, Chat app, Calendar, Camera,
Photo album, Settings and Applications.
• The placement of each of these functions can be altered
individually, apart from that of the unmovable Applications
button.
• To replace a function with another one, tap and hold one of
the buttons for approx. 3seconds and select your chosen
function from the list that appears.
2.3 Updating your system and apps
Updates are not performed automatically on the
emporiaTOUCHsmart. When a system update is available,
youwill receive a notice in the info centre.
Always carry out these updates.
(See »14. System updates« on page 32)
If the notice Update app appears when you're opening your
messaging app, proceed as follows:
4. Tap on Download and grant permission to any requests.
5. Go to the info centre and tap on the downloaded document.
6. Allow Install unknown apps and answer the
securityquestions.
7. The new version of your messaging app will be installed.

ENGLISH–10
3. USING THE PHONE
This phone can be controlled both via its touchscreen and via its
numeric keypad and navigation ring. In the following, operating
the phone using the keys has been prioritised.
3.1 Using the home screen
• Left function key : opens the menu
• Right function key :opens the info centre
(can be made visible for present notications)
• Phone book : opens Contacts
• Camera :opens the photo function
• key: opens your call history
• Chat app key: opens the messaging app installed
3.2 Dual-function keys
Some keys have additional functions if they are pressed and
held down for a few seconds:
•
1
key: allows you to listen to your voicemail
Changing your voicemail settings:
Menu _Contacts _Settings _Voicemail _Setup
_Voicemail number
• key: + for country code, e.g. +49 for Germany
• key: turns the torch on continuously

ENGLISH–11
3.3 Using the menu
1. When on the home screen, press the left function key to
open the Menu.
2. Scroll through the menu items with the navigation ring.
Yourcurrent selection will be highlighted by a blue border.
3. Press the selection key to open the selected menu item.
4. Options which you can select with the function keys will be
shown at the bottom of the screen.
The left function key is normally the OK button,
whilethe right function key is normally for BACK.
Note the terms displayed along the bottom of the screen and
match these with the function keys below them.
• To return to the home screen, press the red key .

ENGLISH–12
3.4 Writing text
You enter text using the keypad.
• To input text, press a number key multiple times (e.g. 2x
4ghi
,
1x
2abc
, 3x
5jkl
, 3x
5jkl
and 3x
6mno
for Hallo).
• Special characters and symbols have been assigned to
thevarious keys, but can dier in some languages:
1
. , ! ? 1 ‘ “ @ :
2abc
 abc2äàåāâæ
3def
 def3đéēè€êë
4ghi
 ghi4îïìíğîι
5jkl
j k l 5 £
6mno
m n o 6 ö ñ ô œ ó
7pqrs
 pqrs7ß$ş
8tuv
t u v 8 ü ù û ú
9 wxyz
 wxyz9ŵýÿ
0
Space 0
+ * # - _ = < > % ( ) [ ] : ; / \ & ~ ^
• Use the
aA1
key to switch between the abc, ABC, Abc and 123
input methods.
The virtual keyboard has been preset to be o, but can be enabled
in Menu _Settings _Advanced settings _Language/
input _Virtual keyboard _On.
Once you've done this, the virtual keyboard will be available as a
fth option assigned to the
aA1
key.

ENGLISH–13
4. CALLS
4.1 Accepting, rejecting or ending a call
• To answer: Open the phone and press Accept.
• To reject or end a call: Press the red button or close
thephone.
• To mute the ringtone temporarily, press the volume
control button.
The open-to-answer-calls function is preset to be o, but can be
enabled in Menu _Settings _Open to answer calls _On.
4.2 Calling someone
›Dialling a number
1. Enter the phone number you want to dial (incl. the area code)
using the keypad.
2. Start the call by pressing .
›Using the redial function
1. When on the home screen, press the green key .
Your call history will be displayed.
2. Use the navigation ring to select a number.
3. Start the call by pressing .
To go hands-free during a call, open Options and turn on the
speaker.

ENGLISH–14
5. CONTACTS
5.1 Searching for a contact in the phone book
1. When on the home screen, press the phone book
key or open Menu _Contacts _Phone
book.
2. Use the navigation ring to scroll through the entries or
use the keypad to type the rst letters of the contact you are
looking for in the search bar.
3. Start the call by pressing .
5.2 Adding a contact
1. Open Menu _Contacts _Phone book _Add contacts.
2. Enter the contact's phone number and then conrm it by
pressingNext.
3. Enter the person's name and save it. You have now created a
contact record for this person and can expand it by adding
other details such as a contact photo, their landline number,
their email address and their birthday.
Always save names and numbers with the international
dialling code, e.g.+41 for Switzerland, +43 for Austria and
+49forGermany.

ENGLISH–15
5.3 Transferring contacts
›Importing contacts from your SIM card
1. Save all your contacts onto the SIM card while the SIM card is
in your old phone.
2. As soon as you insert the SIM card into your new device for the
rst time, you will be asked if you want to transfer the contacts
that are stored on the SIM card.
3. Once you've done this, the imported contacts will appear in
the phone book.
4. To import contacts from the SIM card later on, select Menu
_Contacts_Phone book _Import/export contacts
_Import from SIM card. Tap on the contact you want to
import or open Options and select Import all.
›Importing contacts in a VCF file
1. Save all the contacts on your old phone in a VCF le.
2. Transfer the le to your new device on a memory card or via a
Bluetooth connection.
3. Select Import/export contacts _Import from memory
at the end of the list in the phone book. The VCF le will be
detected automatically and the contacts imported.

ENGLISH–16
5.4 Opening and editing a contact record
There are two ways to open a saved contact record.
›Using the physical buttons:
1. Open Menu _Contacts _Phone book.
2. Use the navigation ring to select the contact record.
Your current selection will be highlighted by a blue border.
3. Press the left navigation button for Options.
A menu consisting of Call, Send message
andContact details will appear.
4. Select Contact details. The contact record containing the
contact's Photo, Mobile number, Landline number, Email
address and Birthday will then be displayed.
5. Select Edit using the left function key. You can then change
any of the contact details.
6. Conrm any changes you make by selecting Save.
›Using the touchscreen:
1. Open Menu _Contacts _Phone book.
2. Search for the contact and tap on the contact picture
(photo or head icon) next to the name.
3. A menu button containing icons forCall,
Send messageand Contact information will appear.
4. Tap on and the Contact details will appear.

ENGLISH–17
5.5 Contact options
›Send message
Write the contact currently open a text message.
›Send details
Copy the name and number of the contact currently open into
a text message and send them to a third person.
›Call history for a contact
In the call history, you will see all the calls you've had with this
contact. As well as the date, time and, if applicable, duration of
the call, you can see the type of call beside each entry here:
Outgoing calls (duration)
Incoming calls (duration)
Missed call
›Setting the contact as a favourite
If you set the contact as a favourite, it will be displayed at
thebeginning of the list in the phone book.
It is not possible to use one of the number keys to put a contact on
speed dial.
›Deleting a contact
If you tap on Delete, the contact will be permanently deleted
from your phone.

ENGLISH–18
6. MESSAGES SMS
6.1 Writing and sending a message
1. Open Menu _Messages.
2. Select Write message.
3. Enter the text using the keypad.
4. To specify a recipient for the SMS,
open Options and select Send.
5. You can now select a Contact from the phone book,
type in a Phone number using the keypad,
select a number from your Recent calls list or
select Multiple contacts at the same time.
6.2 Reading a message
• When you receive a new message, a note and
a symbol will appear on the home screen.
• The number of new messages will then be displayed in a red
circle next to the messages icon
1
on the menu screen.
1. Open Menu _Messages.
2. Unread messages will be highlighted by a blue bar.
3. To read a message, tap on it.

ENGLISH–19
7. MESSAGING APP
7.1 Setting up a messaging app
(See »2.1 Setting up a messaging app« on page 08)
7.2 Using the messaging app
• The emporia TouchSMART.2 doesn't have all the functions
of a smartphone. With regard to messaging apps, the device
has been designed in a way that enables messages in chats
including photos, short videos and audio les to be received
and replied to.
• Make sure you regularly delete photos and videos received
or sent via your messaging app to free up storage space.
Recording and sending videos that are too large can prevent
the device from running smoothly.
• This device is not connected to a Google account. It is
therefore also not possible to back up messaging app
communication using Google.
7.3 Closing the messaging app
It is best to close the messaging app installed by pressing
thered key or simply closing the phone.
Pressing the Back key to exit the app can have a negative
eect on notications and indicators for new messaging
appmessages.

ENGLISH–20
8. INFO CENTRE
The Info centre basically collects all the information
your phone wants to share with you. This gives you
a better overview and ensures you don't miss any
notications. It can include missed call notications,
new messages, messaging app message notications and update
notices for new available system updates.
8.1 Receiving a notication
• If you have missed a call or received a new message (SMS or
your messaging app), a notice will appear on the home screen.
• Select Show to see the call or message immediately (See
»Symbols and operating the phone« on page 03).
8.2 Opening a notication
As soon as an unread notication is available, INFO will be
displayed in the bottom right-hand corner of the home screen.
1. To open the Info centre, press the right function key or select
Menu _Info centre.
2. Tap on a notication in the list displayed. You will be taken
straight to the app the notication refers to.
8.3 Deleting notications
A notication will normally disappear as soon as you have
tapped on it. Regardless of this, however, you can also delete
the entire list by tapping on Delete all.
