EMPORIA JOY-LTE User manual

Eveline Pupeter, emporia Telecom
www.emporia.eu
Thank you for purchasing an emporia product!
Please read this user guide before attempting to use your phone.
English
Mobile data
tariff required
JOY- LTE

1Loudspeaker
2 Display (screen)
3 Green key
• Start or accept a call
• In the menu:
Conrm selection
• On standby: Access Chats
4 Arrow keys
• Use these to ick through
your Contacts and
the Menu.
• When the phone is on
standby, press to
call up the Menu.
• When the phone is on
standby, press to
access Contacts.
5 Red key
• When in a call: End
• When in the menu:
One step back
• When entering digits or
letters: Delete
6 Speed-dial keys
7 key (voicemail)
8 On/O key
9 Port for a charging cable or
USB headset
10 Handset volume control
buttons and
11 Torch button
12 Camera button
13 Wrist strap holder
14 Emergency button
(optional)
15 Loudspeaker
16 Battery cover
17 Opening for removing
thebattery cover
18 Camera, LED and
external display
2
1
4
6
8
9
5 11
12
14 15 18
16
9
17
13
9
3
10
7
› YOUR MOBILE PHONE AT A GLANCE

›Symbols on the screen
Network signal
strength
Roaming (abroad)
Mobile data enabled
Battery indicator
Missed call
Call forwarding
New text message
(SMS)
Prole: Silent/Sleep
mode
Prole: Maximum
Prole: Meeting/
Theatre mode
USB headset plugged in
Alarm on
Bluetooth activated
Bluetooth connected
›External display
Symbols are only visible
when the phone is closed
and disappear when it is
opened.
Time
Incoming call
Missed call
New message
Battery low
Battery charging
Alarm
Snooze
If you press the volume
buttons or the camera
button when the phone is
closed, the screen will be
activated for approximately
3 seconds.

ENGLISH–04
1. SETTING UP YOUR PHONE
1.1 Inserting a SIM card and a Micro SD card (optional)
1. Remove the battery cover (opening in the bottom left-hand
corner).
2. Insert the SIM card into the SIM card holder with the gold
contacts facing down.
3. Insert your Micro SD card into the memory card holder with
thegold contacts facing down.
1.2 Inserting the battery
1. Insert the battery, making sure that the battery contacts touch
the phone's gold contacts.
2. Place the battery cover over the battery and click it into place.
1.3 Charging the battery
Before you use the phone for the rst time, charge the battery for
at least 4 hours. If you don't charge the phone for this period of
time, the battery life could be reduced.

ENGLISH–05
Never connect the phone to the charger or a PC if a battery has
not been inserted. Do not attempt to operate the phone without a
battery inserted. Doing this can damage the phone.
›Charging with the charging cable
To avoid contact faults with the USB connector, only use
thecharging cable supplied with the phone for charging.
• Connect the USB cable to the mains plug.
• Plug the charging cable into the USB port on the phone.
• Then plug the mains plug into a wall socket.
›Using the charging cradle
• Connect the USB cable to the mains plug.
• Plug the charging cable into the USB port on the back of
thecharging cradle and then
• place the phone in the charging cradle.
If you intend to use this method to charge your phone every time,
you can leave the charging cable plugged into the charging cradle
permanently.
›Using a computer
Plug the phone into a USB port on your computer. If necessary,
disconnect the USB cable from the mains plug to do this.

ENGLISH–06
1.4 Turning on the phone
• Press and hold the key for at least 2 seconds until
theemporia logo appears. It will take a few seconds for
thehome screen to be displayed.
1.5 Entering a PIN code
Enter the four-digit PIN code for your SIM card when asked to
do so and conrm the entry.
You have a maximum of three attempts to enter the correct
number. If you enter the wrong number three times in a row,
you will only be able to unblock the SIM card with the PUK
code. Youwill nd your original PIN code and PUK code in the
documents supplied with your SIM card by your network operator.
1.6 Setting the language, time and date
1. Use to select a Language and then conrm your selection
by pressing OK.
2. Set the Time and Date and then save these settings.
1.7 Saving battery power
After a few seconds of inactivity, the screen will turn o to save
battery power. In the event of an incoming call or you pressing
any key, the screen will light up again.

ENGLISH–07
2. USING THE PHONE
2.1 Home screen
If your phone is on but not using a
function, it will display the home screen.
You can return to the home screen
anytime by pressing the redkey
several times.
2.2 Menu
The keywill display the menu.
Themenu is a list that enables you to
manage the phone's various functions
and adapt the phone to your needs.
• Use the arrow keys to scroll through
themenu.
• The items available in the menu
are Messages, Photo album, Tools,
Contacts, Call history and Settings.
• Use the green key and red key beneath the screen to
conrm your selection or to return to the home screen.
Call Info
LT E
12:30
Sun, 21.04
OK Back
6
5
4
3
2
1
Messages

ENGLISH–08
2.3 Dual-function keys
Pressing and holding the key: Allows you to listen to your
voicemail
Pressing and holding the key: Turns on Silent/Sleep mode
Pressing the key twice: + for a country code,
such as +49 for Germany
2.4 Writing text
You enter text using the keypad in Manual mode or T9 mode
(software-supported suggested words).
›Use the key to switch between the input methods.
• abc: All letters in lower case
• ABC: All letters in upper case
• Abc: The rst letter is in upper case and all the letters
thatfollow are in lower case.
• 123: Digits
• sEn: T9 English for Abc
• sen: T9 English for abc
• sEN: T9 English for ABC

ENGLISH–09
›Inputting text in T9 mode
• Find the key bearing the letter you require and press it once
only. After a few entries, the software will start to detect word
patterns and suggest appropriate words,
(e.g. 4 2 5 5 6 for Hallo).
• Use the arrow keys and to move between
the suggested words.
• Press the green button to select your required word and
itwill be added to the message you're writing.
›Inputting text in manual mode
Press a number key multiple times
(e.g. 4 4 2 5 5 5 5 5 5 6 6 6 for Hallo).
• Special characters and symbols have been assigned to
thevarious keys, but can dier in some languages:
. ,- ?! 1'@ : ; ( ) *  abc2äàåāâæçáć
 def3đéē€èêë  ghi4îïíìğι
j k l 5 £ m n o 6 ö ñ ô œ ó ò
 pqrs7ß$ş t u v 8 ü ù û ú
 wxyz9ŵýÿ Space 0
 ., ? ! ' " ()@ \ / : _;+- * = % &<> ₤ $ ¥ §€¤[ ] { } ~#

ENGLISH–10
3. CALLS
3.1 Accepting, declining or ending a call
• To answer: Open the phone and
press the green key for Accept.
• To decline or end a call: Press the red button or
close the phone.
• To mute the ringtone temporarily,
press the volume control button.
The open-to-answer-calls function is preset to be o, but can be
enabled in Menu _Settings _Open to answer calls _On.
3.2 Calling someone
›Dialling a number
1. Enter the phone number you want to dial (incl. the area code)
using the keypad.
2. Start the call by pressing the green key .
›Using the redial function
1. When on the home screen, press the green key .
Your Chats will be displayed.
2. Use the arrow keys and to select a number.
3. Start the call by pressing the green key .
To go hands-free during a call, open Options and turn on
thespeaker.

ENGLISH–11
4. MESSAGES SMS
›Menu items: Write message, Chats, SMS settings and
MMS settings
4.1 Writing and sending a message
1. Open Menu _Messages.
2. Select Write message.
3. Enter the text using the keypad.
4. To specify a recipient for the SMS,
open Options and select Send.
5. You can now select a Contact from the phone book or
type in a Phone number using the keypad.
4.2 Reading a message
1. When you receive a new message, a symbol will appear
on the home screen.
2. Press the green key for View and to read the message
immediately.
3. You can nd the text message again later on in Menu
_Messages _Chats.
4. To read a message, tap on it.

ENGLISH–12
5. PHOTO ALBUM AND CAMERA
5.1 Taking photos and recording videos
1. When on the home screen, press the camera button on
theside of the phone or open Menu _Tools _Camera.
2. To Zoom in or out on the camera frame, use the volume
buttons and on the side of the phone.
3. Thearrow key will open Options for the camera:
• Image size: Specify the resolution for your photo or video.
• Memory: Select whether the photo or video you're capturing
should be stored in your phone's internal memory or
on the SD card.
• Night mode: If there is not much light available,
this option will increase the camera's light sensitivity.
4. Pressing the camera button or
the arrow key will Take a photo.
5. The photo you've taken will immediately be stored in
thephoto album.
6. Press the green key to go straight from the camera to
thephoto album.
5.2 Viewing photos
All the photos you take will be sorted and displayed
chronologically.
1. Open Menu _Photo album.
2. Use the arrow keys to scroll through the photos on the
overview screen.

ENGLISH–13
3. Pressing the green key will open Options for
the selected photo:
• View: A complete, full-screen version of the selected photo
will be displayed. You can use the arrow keys to move to other
photos.
• Send: This option allows you to send the selected photo to a
recipient as an MMS message. (Please not that this will incur
additional costs.)
• Wallpaper: You can use the selected photo as your wallpaper
on the home screen.
• Rename: You can give the selected photo or
video a new le name.
• Delete: This option will delete the selected photo or video.
• Delete all: This option will delete the entire photo album.
5.3 Backing up photos on your PC
1. Plug the USB connector end of the USB cable supplied with
thephone into your PC and the other end into your phone.
2. Select Transferles from the list displayed.
3. The PC will now detect your phone and display the phone's
internal memory.
4. You can then select les from the album PHOTOS and copy
them to your PC.

ENGLISH–14
6. TOOLS
›Menu items:Alarm clock, Birthday reminder, Calendar,
Calculator, Bluetooth, FM radio and Camera
6.1 Alarm clock
1. Open Set time.
2. Enter your desired Alarm time and then Save it.
3. The alarm clock is activated and will now go o at the time you
have set every day.
4. When the alarm is ringing, you can press the red key to turn
it o or the green key to activate the snooze function.
5. Select Off to deactivate the alarm permanently.
If the phone is turned o, the alarm is turned o as well.
The alarm will therefore not sound when the phone is o.
6.2 Bluetooth
1. Turn the Bluetooth function On.
2. Tap on Connect and on Search for new devices.
A list of available devices will be displayed.
3. Select the device you want to pair the phone with from the list.
4. Follow the instructions to pair the devices.
Devices that have been connected before will be recognised and
connected automatically.

ENGLISH–15
6.3 FM radio
• Searching for a station
You can set the station using the arrow keys .
• Adjusting the volume
You can adjust the volume of the radio with and on
theside of the phone.
You cannot change the volume if you are in an Options menu
item. In this case, close the Options menu rst.
• Station list
This list will display all the radio stations that have already
been saved.
• Manual input
If you know the frequency of the station you want, you can
enter it here directly. Use this key for the decimal point.
• Auto search
This function searches for all detectable stations and
savesthem in the station list together with their frequencies.
• Loudspeaker
Turn hands-free mode on to listen to the radio without
aheadset.
• Exit
Turn the radio o.
The FM radio will only work with a headset plugged in.
Theheadset takes on the role of the antenna.

ENGLISH–16
›Menu items: Search for name, Add contact, Edit contact,
Delete, Send contact via SMS, Copy contacts, My number,
Speed-dial keys, Emergency contacts, Contact settings,
SMS's in Contacts and Blocked numbers
7.1 Searching for a contact in the phone book
1. When on the home screen, press the phone book key or
open Menu _Contacts _Search for name.
2. Use the arrow keys and to scroll through the entries or
use the keypad to type the rst letter of the contact you are
looking for.
3. Start the call by pressing the green key .
7. CONTACTS

ENGLISH–17
7.2 Adding a contact
1. Open Menu _Contacts _Add contact.
2. Enter the phone number and the person's name and
thenSave them.
Always save names and numbers with the international dialling
code, e.g. +41 for Switzerland, +43 for Austria and +49 for Germany.
3. Decide whether you want to save a photo for the contact.
This photo will be displayed on the screen when the contact
calls and you open the phone. If the contact is saved on your
phone, the exterior screen will display the name of the caller,
otherwise it will just display the phone number.
4. Select a photo from the photo album and set it as a newphoto.
Contacts with a photo cannot be saved on the SIM card and have
to be saved on the phone only.
7.3 Editing contact
Edit the previously saved entries and save your changes.
7.4 Deleting a contact
• Single: Select a contact you want to delete.
• Delete all: Specify whether you want to delete all the contacts
from the SIM card or from the phone.

ENGLISH–18
7.5 Sending contact via SMS
1. Select the contact you want to send.
2. Enter the recipient's Number or Search for their name in
yourcontacts.
3. You'll then send an SMS that the contact receives as text in
theformat #Name#Number#.
7.6 Copying contacts
You can save one or all the contacts on your SIM card in
thephone's memory or vice versa.
7.7 My number
Save your own phone number so that you never forget it again.
7.8 Speed-dial keys , and
›Saving a speed-dial key
You can assign quick dial keys to numbers you call often.
1. Press one of the speed-dial keys , and .
2. Enter a Name and Number or Search for a contact in
thephone book.
›Changing or deleting a speed-dial key
1. Open Menü _Contacts _Speed-dial keys.
2. Select a speed-dial key from the list.
3. Change or delete its link to a particular contact.

ENGLISH–19
7.9 Contact settings
• Save entries on SIM or Phone
• Memory in use: SIM, Phone or both
• Automatically save in Contacts: On or Off
• Memory status: Up to 300 contacts can be saved on the
SIMcard and up to 500 contacts can be saved on the phone.
7.10 SMS's in Contacts
If you receive a message that contains text in the format
#Name#Number#, the text will be saved in your contacts
automatically. Specify whether this function should be
switched on or o and whether only entries from saved
numbers are permitted in contacts.
7.11 Blocked numbers
Enter selected numbers you don't want to receive calls or
messages from. A maximum of 10 numbers can be blocked.

ENGLISH–20
8. CALL HISTORY
›Menu items: Missed calls, Dialled calls, Received calls,
Call duration and Delete
Each list is sorted chronologically and shows the date and
timeof each call beneath the contact's name or number.
Options: Call, Save in Contacts, Edit number before call,
Write message, and Delete
When on the home screen, you can access your Chats
containing all your calls by pressing the green key .
The symbols indicate the following:
• Missed calls 
• Dialled calls 
• Received calls 
• Call duration
Duration of the last call
Total duration of all outgoing calls
Total duration of all received calls
Total duration of all calls
