ENBAO A Series Technical manual

Wireless
Your Sound
A3
POWER
MENU/SELECT
   
SET
POW ER
/ A3B
PROFESSIONAL LARGE-SCALE WIRELESS MICROPHONE SYSTEM
Large-scale Performance Flagship A Series
Operation Instruction

1
CATALOGUE
Safe Information..................................................
Product Introduction...........................................
System................................................................
Receiver diagram................................................
Transmitter diagram............................................
Bodypack installation instruction........................
Receiver display..................................................
Receiveroperationinstruction...........................
Handheld microphoneoperationinstruction.......
Bodypack microphoneoperationinstruction......
Suggestion and Tips............................................
Frequency group using method............................
Rack mount.........................................................
Antenna distributor
(optional) connection diagram.............................
Simple fault process............................................
Specification.......................................................
2
3
5
6
7
8
9
10
15
17
18
19
20
21
23
24

2
SAFEINFORMATION
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean with dry cloth only.
7.Do no block any ventilation openings. lnstallin accordance with the manufacturer's
instructions.
8.Do not install near any hear sources such as: radiators, stoves or other apparatus
(including amplifier)that produces heat.
9.Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
10.0nly use attachments/accessories specified by the manufacturer.
11.Unplug the apparatus during lightening storms , or when unused for long periods of time.
12.Refer all servicing to qualified personnel. Service is required when the apparatus has
been damaged in any way ,such as power supply cord or plug is damaged , liquid has
been spilled or objects have fallen into the apparatus has been exposed to rain or moisture,
does not operated normally, or has been dropped.
13.This appliance shall not be exposed to dripping or splashing water and that no subject
filed with liquid such as vases shall be placed on the apparatus.
14.Caution-to prevent electrical shock, match wide blade plug wide slot fully insert.
15.Please keep a good ventilation environment around the entire unit.
16.Batteries(battery pack or batteries installed)shall not be exposed to excessive heat such
as sunshine, fired or the like.

3
PRODUCT INTRODUCTION
Thanks for using professional large-scale performance A series wireless system with stable
performance and solid structure , which adopt world class high end RF&AF chip . Industrial
OLED display screen ensure operation in all weather . Bodypack transmitter support bass
20Hz and large dynamic instrument with many patents and special design.
Large-scale performance flagship A series wireless microphone system
Features:
1.Design for large-scale show , lecture and art and sport activities.
2.Front-panel adopt full-color TFT display screen.
3.Rotary button control.
4.Pilot frequency squelch technology delete wireless RF interference when transmitter closed.
5.Receiver display battery of transmitter.
6.Lock function avoid wrong operation.
7.Anti-interference frequency can be set and changed , up to 20 sets can be used in the same
frequency range without interference.
8.Receive signal automatically , eliminate break signal , increased receive distance and stability.
9.UHF frequency range , PLL technology.
10.Automatically infrared sync technology , connecting transmitter quickly.
11.Auto Scan function scan available frequency.
12.level receive sensitivity , adjust SQ for different environment.
13.Handheld microphone and bodypack use OLED display screen.
14.Metal case , elegant design.
15.Transmitter use a pair of AA battery.

4
This devise have same frequency range for selection and have same pre-set frequency
channel system.
Frequency pre-set advantage:
Transmit channel can be stand by quickly
Several transmit channel have no interference (can no adjust each other)
Frequency System
400 500 700 800600
Superfrequencyhave5differentfrequencyrangeforAFtransmission , eachonehave1200to
2400flexiblefrequency, receivercanselectthefrequencyfromaboverang:
Eachfrequencyrange(A-J)have10frequencygroup , eachgrouphave14channel:
GroupA~J
Channel1~14
GroupApre-setgroup
GroupBpre-setgroup
GroupJpre-setgroup
Channel1pre-set channel
Channel2pre-set channel
Channel14pre-set channel
RangeA:
470~500
RangeB:
518~548
RangeC:
606~668
RangeEF:
740~790
RangeG:
795~825

5
POWER
MENU/SELECT
   
/ A3B
SET
POW ER
SYSTEM
(Receiver)
(Handheldtransmitter)
(Audiocable) (Guitarcable)
(Shortrackmount)
(Beltpacktransmitter) (LavalierMic)
(HeadsetMic)
(Power cable)
(Longrackmount) (Connect panel)

6
POWER
MENU/SELECT
   
恩宝电子有限公司
WI RELE SS SY STEM :A3
RECEIVER MODEL: A3 R
Made in china
FREQ:638-668MHz
2016071415789
Receiver Front Panel
2.IR Sync Indicator Light
RECEIVER DIAGRAM
1.Power Switch
Turnon/offreceiver
Stopinputandreturnback
3.Rotary Function Knob
Pressrotaryknob
Rotaterotarybutton
Openthemenuinterface
Selecttheitem
Storesettingandreturntomaininterface
Lock
Select channel setting interface
Switchtolastandnextitem
Changeeachitem
4.FullColorTFTDisplayScreen
Displayspecification
ReceiverBack Panel
1.Antenna
Antenna A/B BNC socket
2.RF Mixed Output
1/4"unbalanced connector
3.RF Balanced Output
XLR balanced connector
4.Power Supply
External direct current 12V-15V/500mA

/ A3B
SET
POWER
MUTE OPEN
7
TRANSMITTER DIAGRAM
Handheld Microphone
1.Metal Microphone Grill
2.OLED Display Screen
Display clearly
3.Power/Return/Mute Switch
Button
Turn on/off power supply
Return main interface
Mute/unmute
4.Up Button
Up to select menu
5.Down Button
Down to select menu
6.Set Button
Confirm selection
7.IR Set
Receive IR signal from receiver
8.Transmitter Antenna
9.Mic Tube
(hold the mic far away from bottom of
mic tube )
Bodypack Transmitter
1.OLED Display Screen
Display clearly
2.Up Button
Up to select menu
3.Power / SET button
4.Down Button
Down to select menu
5.AF Output Connector
6.Mute Switch
Push mute switch to mute or unmute
7.Power Indicator Light
Display battery volume
8.Antenna
9.IR set Indicator Light
Receive IR signal from receiver
10.Lock Switch
9.Battery Compartment
It is used to lock or unlock bodypack
Insert two standard AA batteries here

8
BELTPACK TRANSMITTER MICROPHONE INSTALLATION
1.Slide down the cover then put into the two pieces
1.5V battery if LED lights up, it means install correct
and power on.
2.Lavalier Microphone
Clamping the microphone to tie or collar,
then connecting the microphone plug to
beltpack output socket and finished
installation.
3.Headset Microphone
Connecting the
microphone plug to
beltpack output socket
and finish installation.
4.Guitar Cable Connection
Plug the guitar cable into bodypack ,
plug the other side of cable into pickup
connector.
Be Careful To Damage Hearing And Equipment!
Receiver have a big noise when plug and pull out the the connecting
cable during install bodypack. Turn down volume before installation.
High noise will damage hearing and overload loudspeaker.
SET
POWE R
/ A3B
SET
POWE R
/ A3B
TONE
TONE
VOLUME
SET
POWE R
/ A3B

9
①②③④⑤
⑥
⑦
⑧⑨⑩⑪
   
Display receiver specification and the important information of receiver and transmitter
operation status.
Display RX/TX Explanation
1.Antenna A Receiver
Receiver
Receiver
Antenna input port A is activate
2.Antenna sign
3.Antenna B
Antenna signal sign
Antenna input port A is activate
4.Mute sign Receiver/Transmitter AF signal mute
5.Battery Transmitter
Display transmitter battery volume , display
low battery under low voltage
6.Group Receiver Pre-set group number
7.Frequency Receiver Setting frequency
8.Wireless signal level Receiver Receiving wireless signal strength
9.AF level Receiver/Transmitter Display AF level
10.High Filter switch Receiver Reduce pick up noise
11.Squelch Receiver Display SQ
RECEIVER DISPLAY

10
Rotate rotary button to Channel.
Press rotary button to confirm then number flashing.
04
Menu
Group
Channel
Freq
Scan
IR set
Channle
A
Group
Menu
Group
Channel
Freq
Scan
IR set
Group
Menu
Group
Channel
Freq
Scan
IR set
B
Group
Menu
Group
Channel
Freq
Scan
IR set
A
Menu
Group
Channel
Freq
Scan
IR set
Channle
04 06
Menu
Group
Channel
Freq
Scan
IR set
Channle
   
RXOPERATIONINSTRUCTION
Turn on/off receiver
Group setting
Press rotary button into menu interface.
Rotate rotary button to group.
Rotate rotary button, select group A to J.
Press button confirm and store.
POWER
Long press power switch button, receiver display information.
Long press power switch button again, receiver turn off.
Channel setting
Rotate rotary button, select from 01 to 14, press button to
confirm selection.
Press rotary button into menu interface.
Press rotary button to confirm then number flashing.
Press button confirm and store.

Rotate rotary button to Freq.
650.000MHz
Menu
Group
Channel
Freq
Scan
IR set
Frequency
Scan
Menu
Group
Channel
Freq
Scan
IR set
Frequency
90dB 90dB
606.000 MHz
Menu
Group
Channel
Freq
Scan
IR Set
IR Set
11
Menu
Group
Channel
Freq
Scan
IR set
Frequency
650.025MHz 650.050MHz
Menu
Group
Channel
Freq
Scan
IR set
Frequency
Menu
Group
Channel
Freq
Scan
IR Set
IR Set
Rotate rotary button toIR Set.
Press button confirm selection , then signal light is flashing ,
conecting sucessfully when it keep lighting , the light out after
finished sync connection.
Press rotary button into menu interface.
Frequency setting
Press rotary button to confirm then number flashing.
Rotate rotary button to adjust frequency with 25KHz stepping,
press button to confirm selection.
Press button confirm and store.
Scan and select frequency
Scaning frequency Display available frequency after scanning
Press rotary button into menu interface.
Rotate rotary button to Scan.
Press rotary button start to scan (check picture 2) and search the
free frequency automatically, (check picture 3) display available
frequency. Now rotate rotary button to select free frequency.
Press button confirm and store.
IR set
Press rotary button into menu interface.

12
Menu
Squelch
Lock
Low Cut
Squelch
Back
01
Menu
Squelch
Lock
Low Cut
Squelch
Back
01
Menu
Squelch
Lock
Low Cut
Squelch
Back
05
Press rotary button into menu interface.
Rotate rotary button to Squelch.
Press rotary button to confirm then number flashing.
Rotate rotary button select from 01 to 10 with 1dB stepping ,
Press button confirm and store.
When transmitter closed or transmitting power not high enough ,
Squelch can restrain noise . Squelch setting should be ensure
the receiver don’t have a big noise when turn off transmitter .
When receiving environment is bad , higher squelch setting will
be reduce receiving range.
Closed squelch or setting squelch too low will be causing big noise.
High noise will damage hearing and overload loudspeaker.
Be Careful To Damage Hearing And Equipment !
Ensure squelch keep turning on.
Ensure AF output level adjust to be lowest before setting squelch.
Not allow to change squelch during transfer.
Squelch setting

After setting lock function , main interface display lock sign ,
you should have to turn off lock when you use it.
13
Menu
Squelch
Lock
Low Cut
Back
OFF
LOCK
   
Menu
Squelch
Lock
Low Cut
Back
LOCK
OFF
Menu
Squelch
Lock
Low Cut
Back
ON
LOCK
Menu
Squelch
Lock
Low Cut
Back
OFF
Low Cut
Menu
Squelch
Lock
Low Cut
Back
Low Cut
OFF
Menu
Squelch
Lock
Low Cut
Back
ON
Low Cut
Lock setting
Press rotary button into menu interface.
Rotate rotary button to Lock.
Press rotary button to confirm then number flashing.
Rotate rotary button to select on or off.
Press button confirm and store.
Long-press rotary bottom to turn off lock function.
Setting high pass-filter
Press rotary button into menu.
Rotate rotary button to Low Cut.
Press rotary button confirm selection , on/off flashing.
Rotate rotary button to select on or off.
Press rotary button to store it.
High pass filter function is to reduce the low frequency pick
up by transmitter to receiver , which can eliminate stage
rumble .

14
POWER
POWER
POWER
MENU/SELECT
   
Menu
Squelch
Lock
Low Cut Back
Back
   
   
652.000MHz
   
652.100MHz
Low voltage
NO 00
1. IR set function on the A3 receiver
long-press MENU/SELECT button can synchronize the
frequency both the receiver and transmitter quickly
2.No matter in which menu, you can return to the main performance display
quickly when press the power button on the A3 receiver
SHORTCUT OPERATION
Return
Select Back in the menu , and press rotary button to confirm
selection.
Return back the main interface after confirm the selection.
Ps: Return back to main interface automatically when
stop operation after 15 seconds.
Porject debug mode
Press POWER button and rotary button at the same time until it
display logo , then start to adjust it.
Rotate the rotary button to adjust frequency by stepping 25KHz .
If the RF line beating that means this frequency have interference
so that you choose next available clear frequency and confirm
selection .
BE CAREFUL FOR DAMAGE HEARING AND PRODUCT !
When using prject mode , RF interference will make mute function
be useless and cause big noise . Please turn down the volume ,
large noise will damage hearing and overload loudspeaker .
Low voltage
Display screen have low voltage flashing as left picture , it should
replace the battery.

15
638.000
A01
+10dB
NO 01
Group
Channel
Freq
Group
A
Group
D
Group
Channel
Freq
Channel
01
Channel
08
638.000
D01
+10dB
638.000
D08
+10dB
638.000
A01
+10dB
638.000
A01
MUTE
NO 01
MUTE
HANDHELD MICROPHONE OPERATION INSTRUCTION
Turn/off Transmitter
Long press power switch button again,
Transmitter turn off.
Long-press switch button to turn on transmitter
display information interface , (Only display
number after 3 second without operation)
Ps : press switch button in the menu
interface will be turn back to information
interface.
Setting mute
Press switch button in the main interface to start mute.
Press switch button again to cancel mute .
Group setting
Press set button into menu to select group.
Press set button confirm
selection.
Press up and down button to select
group A to J.
Press set button to confirm selection , display group information in
the main interface.
Channel setting
Press set button into menu to select channel.
Press set button confirm
selection.
Press up and down button to select
channel 01 to 14.
Press set button to confirm selection , display group information in
the main interface.

16
638.025
+10dB
Group
Channel
Freq
Freq Freq
638.025
638.025
Gain
Lock
Back
Gain
-10dB
Gain
+10dB
+10dB
Gain
Lock
Back
Lock
OFF
638.000
+10dBA01
Frequency setting
Press set button into menu to select frequency.
Press set button confirm selection.
Press up and down button to select frequency by stepping 25Khz.
Press set button to confirm selection , display group information in
the main interface .
Gain setting
Press set button into menu to select Gain.
Press set button confirm selection.
Press up and down button to select 3 level including -10dB , +00dB
and 10dB.
Press set button to confirm selection , display group information in
the main interface .
Ps: over +10dB will cause signal over adjustment and AF
distortion , it can adjust Gain according to the user sound
pressure.
Lock setting
Press set button into menu to select Lock.
Press set button confirm
selection.
Press up and down button to
select ON.
Press set button to confirm selection, handheld microphone locked ,
Lock sign display in the main interface.
Long-press set button cancel lock , lock sign disappear.

17
NO 01
638.000
[
[
GAIN
+10dB
638.000
[
[
GAIN
+10dB
MUTE OPEN
MUTE OPEN
638.000MHz
FREQ
638.025
[
[
GAIN
+10dB
638.025MHz
FREQ
UP
DOWN
UP
DOWN
638.025
[
[
GAIN
-10dB
UP
DOWN
UP
DOWN
+00dB
GAIN
-10dB
GAIN
BODYPACK MICROPHONE OPERATION INSTRUCTION
Turn/off Transmitter
Long-press switch button to turn on transmitter
display information interface , (Only display
number after 3 second without operation).
Long press power switch button again,
Transmitter turn off.
Mute function
Push press button to mute to cancel mute , the sign disappear.
Push press button to mute to start mute , main interface have the
sign.
Frequency setting
Short press switch button into frequency.
Press up an down button to select frequency by stepping 25KHz.
Gain setting
Short press switch button into Gain.
Press up and down button to select 3 level including -10dB , +00dB
and 10dB.
Press set button to confirm selection , display group information in
the main interface.
Ps: over +10dB will cause signal over adjustment and AF
distortion , it can adjust Gain according to the user sound
pressure.

18
SUGGESTION AND TIPS
In Order To Reach The Best Receiving
Transmitter effective receiving range depend on operation environment and condition. Maybe
in 10 meters or 150 meters.
When receiving condition is not good , receiver should connecting two separate antenna by the
antenna cables.
Receiver and transmitter should be keep at least 5 meters distance which can avoid wireless
signal of receiver over modulation.
Receiving antenna should keep at least 50cm distance with steel plate or wall and adjust the
antenna with V shape.
Multi- Frequency Operation
Every channel from A to J all including anti-interference pre-set frequency (fixed frequency ).
Select the available frequency from frequency data (factory frequency range ).
Setting frequency between 1 to 14 in frequency range (check page 10).
Each transmitter should keep at least 20 meters distance to avoid transmit interference.
Please using ENBAO recommended multi-frequency equipment application.
