WTC-1218
12’x18’ CANVAS WALL TENT
Instruction Manual
ENCOMPASSINTL.COM

WALL TENT CANVAS
• 1 12’ x 18’ Wall Tent Canvas Part # WTC-1218
• 36 Ground Stakes Part # 10230
• 14 Guy-Ropes Part # 10232
• 14 Tie-Down Adjustments Part # 10234
• 1 Zippered Screen Door Part # ZSD-1218
WALL TENT FLOOR
• 1 12’ x 18’ Wall Tent Floor Part # WTF-1218
WALL TENT INNER ROOM
• 1 Inner Room Part # IR-1218
WALL TENT FRAME
• 8 Horizontal M Part # WTHM-1218
• 8 Horizontal F Part # WTHF-1218
• 8 Rafter M Part # WTRM-1218
• 8 Rafter F Part # WTRF-1218
• 2 Ridge Cap Peak Joints Part # WTPJ
• 4 Corner Joint Part # WTCJ
• 6 Intersection Joint Part # WTIJ
• 8 Frame Leg Part # WTFL
• 2 Ridge Cap Bolt Part # 10156
Included in these instructions are the tent, frame and floor parts lists, assembly and other details. If all components were
not purchased together, please refer to the assembly instructions specific to the component you purchased when setting
up.
KEEP ALL FLAME AND HEAT SOURCES
AWAY FROM THIS TENT. THIS
TENT MEETS THE FLAMMABILITY
REQUIREMENTS OF CPAI-84. Fabric will
catch re if exposed to ame. This tent
is made with ame resistant fabric. IT IS
NOT FIRE PROOF. This fabric will burn if
left in continuous contact with any ame/
extreme heat source. The application of
any foreign substance to the fabric may
render the ame resistant properties
ineffective.
WARNING
Mantener todo tipo de fuego y systemas de
calor lejos de la tela de esta tienda de campaña.
ESTA TIENDA CUMPLE LOS REQUISITOS DE LA
INFLAMABILIDAD DE CPAI-84. La tela puede
prender en fuego si se expone. Esta tienda de
campaña esta hecha con tela resistente al
fuego. No es totalmente resistente al fuego.
Esta tela se quema si se deja en contacto
continuo con cualquier systema de calor
extremo y de fuego. La aplicación de cualquier
sustancia extraña a la tela puede rendir las
propiedades de resistencia al fuego inecaz.
ADVERTENCIA
TENIR LE TISSU DE CETTE
TENTE LOIN DE TOUTE FLAMME
ET DE TOUTE SOURCE DE
CHALEUR. CETTE TENTE
RÉPOND AUX EXIGENCES
D’INFLAMMABILITÉ DE CPAI-84.
Cette tente est fabriquée d’un
tissu résistant au feu, mais qui
n’est pas ininammable. Ce
tissu brûlera s’il est laissé en
contact continu avec une source
d’inammation.
MISE EN GARDE
GENERAL GUIDELINES FOR YOUR TENT
Store your tent in a cool dry place, free of
native brush, dirt & any debris.
Avoid leaving tent outdoors for any ex-
tended period of time. Prolonged exposure
to sunlight may cause fabric to fade.
Never allow children to play with this prod-
uct without adult supervision.
Never store tent wet or damp.
Never allow material to cover your face. It
can cause suffocation, death.
Never allow anyone to use lighted candles,
matches or other sources of re near this
product.
Never expose this tent to any open ame.
This product is not reproof.
Never use a heater in this tent.
Keep these instructions
for future reference.
For your safety, be sure to read all instructions and warnings carefully.
WARNING
Instruction and Safety Manual
PACKAGE CONTENTS

Images used are for demonstration purposes only and may not depict the actual product.
INITIAL SETUP
Before you take your new tent on a camping trip, you need to
set it up to become familiar with it and allow the material to air
out.
SELECT YOUR CAMPSITE
Find a level spot that is protected from wind. This will
ensure comfort. Remove any lose sticks and stones that may
damage tent oor. Also choose a site that will drain well in the
event that it rains. Layout all your items and become familiar
with them.
TENT ROOF FRAME ASSEMBLY
1. Identify your Poles and Joint Connections.
2. The shortest aluminum poles will make up the horizontal
sections of the frame. Connect two short aluminum pole
sections together by sliding the horizontal male pole into
the horizontal female pole until they click together. This
single pole will make up one horizontal section of the
frame.
3. The longest aluminum poles will make up the rafter
sections of the frame. Connect two long aluminum pole
sections together by sliding the rafter male pole into the
rafter female pole until they click together. This single
pole will make up one rafter section of the frame.
4. Locate the two Peak Joint Connections that have the
Ridge Cap Bolts.
5. Place the four Corner Joints at the four corners of your
frame layout.
6. Lay out the six intersection joints accordingly at the
intersections of the rafter and horizontal sections.
7. Connect all poles and joint connections as pictured
above to create the roof frame of your wall tent.
8. Remove the Ridge Cap Bolts to prepare for the wall tent
canvas.
Rafter Section joining
Rafter M (# WTRM-1218) +
Rafter F (# WTRF-1218)
Horizontal Section joining
Horizontal M (# WTHM-1218) +
Horizontal F (# WTHF-1218)
Peak Joints (# WTPJ)
with Ridge Cap Bolts (# 10156)
Intersection
Joints (# WTIJ)
Corner Joints
(# WTCJ)
1
3
2
Intersection Joint
(# WTIJ)
Ridge Cap Bolt
(# 10156)
Peak Joint
(# WTPJ)

Images used are for demonstration purposes only and may not depict the actual product.
Care instructions:
Spot clean with mild soap and water. Ensure tent is
dry before transporting or storing to prevent mildew and
damage. Store in cool, dry place out of direct sunlight.
To take down tent, reverse the process.
TENT CANVAS AND LEG FRAME ASSEMBLY
1. Unroll Wall Tent Canvas and drape over Frame Roof. Ensure
the grommets in the canvas line up with the Ridge Cap Bolt
holes in the Peak Joints and reinstall the Ridge Cap Bolts.
2. Lift up one side of Roof Assembly and install the Leg
sections until they click into place.
3. Install Leg sections on opposite side of Wall Tent until they
click into place. Pull Canvas down around frame legs and pull
Sod Cloth to inside of tent under frame legs. Secure Wall Tent
Canvas to Frame with ties located on inside of the canvas.
Unroll Wall Tent Floor and place between Legs and Sod
Cloth.
4. Stake out the four corners rst. Tie the guy-ropes through
the grommets as shown. Stake out the remaining holes.
Use the Tie-Down Adjustments to make the tent taut by
pulling away from the tent. This will help the tent stay in
place and keep its shape. Stake out the loops at the base
of the canvas wall.
4

Images used are for demonstration purposes only and may not depict the actual product.
Care instructions:
Spot clean with mild soap and water.
Ensure tent is dry before transporting or
storing to prevent mildew and damage.
Store in cool, dry place out of direct
sunlight.
To take down tent, reverse the
process.
INNER ROOM ASSEMBLY
1. Position the inner room so its door is facing away from the
rear of the canvas wall tent.
2. Attaching the inner room following the numbered sequence
in the picture to the left, begin by hanging the rear corner
of the inner tent on the frame in the rear corner of the wall
tent.
3. You will notice at the bottom of the inner tent there are clips.
The clips attach to the D-rings along the bottom of the wall
tent as shown in the picture below. Attach the inner tent to
the frame above with the nylon straps and attach the clips
below to the tents D-rings, working your way from the rear
of the tent to the front. Feed the nylon straps through the
plastic buckle as shown below.
5
Door Opening
D-Ring
1
2
3 4
5
Inner Room
Floor Clip
Rear of
Wall Tent
