Endress+Hauser Prosonic S FMU95 User manual

Operating Instructions
Prosonic S FMU95
Slot-Index Lists for PROFIBUS DP
AUTHORIZED DISTRIBUTOR:
InstrumentsAndControl.com
Houston, Texas USA
[e-mail]
832-615-3588

Prosonic S FMU95 - PROFIBUS DP Table of Contents
Endress + Hauser 3
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . 4
2 Slot-Index Lists. . . . . . . . . . . . . . . . . . . 5
2.1 Resource Block (RB) . . . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Display Block (DY) . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Sum Block (SX) . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2.4 Average Block (AX) . . . . . . . . . . . . . . . . . . . . . . . . 38
2.5 Current Output Block (CO) . . . . . . . . . . . . . . . . . . 44
2.6 Transducer Block (TB) . . . . . . . . . . . . . . . . . . . . . . 47
2.7 Analog Input Block (AI) . . . . . . . . . . . . . . . . . . . . . 50
2.8 System Block (SY) . . . . . . . . . . . . . . . . . . . . . . . . . 53
2.9 External Temperature Block (XT) . . . . . . . . . . . . . . 54
2.10 Binary Input Block (BI) . . . . . . . . . . . . . . . . . . . . . 56
2.11 UG Block (UG) . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
2.12 Ultrasonic Sensor Block (US) . . . . . . . . . . . . . . . . . 58
2.13 Level Block (LE) . . . . . . . . . . . . . . . . . . . . . . . . . . 68
2.14 Sum Block (SV) . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
2.15 Average Block (AV) . . . . . . . . . . . . . . . . . . . . . . . . 82

Introduction Prosonic S FMU95 - PROFIBUS DP
4Endress + Hauser
1Introduction
This document comprises the Slot-Index tables for all user parameters of the Prosonic S.
The parameters are arranged according to the function blocks of the Prosonic S. All function blocks
containing user parameters are taken into account. Some of these blocks are not available in every
version of the instrument.
For each block, there is a list of instances. A slot number and a start index is given for each instance.
The structure of each block is only given once. This structure is valid for all instances of the
respective block.

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 5
2 Slot-Index Lists
2.1 Resource Block (RB)
2.1.1 Instances
2.1.2 Structure
Instance Slot Index
1016
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class
Target Mode RBTargetMode 0 21 1 Unsigned8 Auto,
OOS
8 ... 8 0 - RW static
code RBLockingCode DX104 0 34 2 Unsigned16 Auto,
OOS
0 ... 65535 2457 - RW non-
vol.
reset RBResetCode DX104 0 35 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RW dyna-
mic
ident number RBIdentNumberSelector OXC11 0 40 1 Unsigned8 Auto,
OOS
0 : profile
1 : manufacturer
manufac-
turer
-RWstatic
instrument addr. RBDeviceBusAddress OXC01 0 59 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO non-
vol.
profile version RBPAProfileRevision OXC01 0 64 32 VisibleString Auto,
OOS
32 3.0 - RO const
device name RBDeviceName CX901 0 90 16 VisibleString Auto,
OOS
16 PROSO-
NIC S
FMU95
-RWstatic
device family RBDeviceFamily CX901 0 91 16 VisibleString Auto,
OOS
16 FMU95 - RW static
order code RBOrderCode 0 92 24 VisibleString Auto,
OOS
24 FIELD-
TEST
-RWstatic
serial no. RBSerienNr CX901 0 93 16 VisibleString Auto,
OOS
16 ------------
----
-RWstatic
software version RBSWVersion CX901 0 94 16 VisibleString Auto,
OOS
16 ------------
----
-ROdyna-
mic
comunicat. type RBCOMVersion 0 95 1 Unsigned8 Auto,
OOS
0 : HART
1 : Profibus DP
2 : Profibus PA
3 : FF
4 : Ethernet
Profibus
DP
-ROnon-
vol.
date of product. RBProductionData 0 96 10 VisibleString Auto,
OOS
10 ---------- - RW static
dev. rev. RBDeviceRevision IX107 0 97 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RW non-
vol.
device marking RBDeviceTag 0 98 32 VisibleString Auto,
OOS
32 ------------
------------
--------
-RWstatic

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
6Endress + Hauser
distance unit RBDistanceUnit16 DX019 0 99 2 Unsigned16 Auto,
OOS
1010 : m
1018 : ft
1013 : mm
1019 : inch
m-RWstatic
temperature unit RBTemperatureUnit16 DX01A 0 100 2 Unsigned16 Auto,
OOS
1001 : °C
1002 : °F
°C - RW static
no.of decimals RBNrOfDecimalsUpTo3 DX212 0 101 1 Unsigned8 Auto,
OOS
0 : x
1 : x.x
2 : x.xx
3 : x.xxx
x.xx - RW static
operating mode RBOperationMode 0 102 2 Unsigned16 Auto,
OOS
30001 : level
30002 : level + flow
30003 : flow
30004 : flow+backwater
level - RW static
controls RBControl 0 103 2 Unsigned16 Auto,
OOS
30005 : no
30006 : pump control
30007 : rake control
no - RW static
status RBStatusLocking DX104 0 104 1 Unsigned8 Auto,
OOS
0 : switch locked
1 : key locked
2 : code locked
3 : unlocked
4 : service unlock
5 : debug unlocked
6 : WHG locked
7 : SIL locked
8 : PM temp locked
9 : PM perm locked
10 : SM temp locked
11 : SM perm locked
12 : upload active
13 : downl. active
14 : WHG/SIL lock.
unlocked - RO dyna-
mic
operation hours RBOpHourCounter_h IX403 0 106 4 Unsigned32 Auto,
OOS
0 ... 999999 0 h RO dyna-
mic
uptime RBUpTimeStr S0040 0 107 10 VisibleString Auto,
OOS
10 0.000000 - RO dyna-
mic
reset errorlist RBClearErrorList S0140 0 108 1 Unsigned8 Auto,
OOS
0 : keep
1 : erase
keep - RW dyna-
mic
build number RBBuildNumber S0040 0 109 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
DD version RBDD_REV IX108 0 110 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 1 RBActualError1 0 111 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 2 RBActualError2 0 112 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 3 RBActualError3 0 113 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 4 RBActualError4 0 114 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 5 RBActualError5 0 115 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 7
actual error 6 RBActualError6 0 116 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 7 RBActualError7 0 117 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 8 RBActualError8 0 118 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 9 RBActualError9 0 119 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
actual error 10 RBActualError10 0 120 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO dyna-
mic
last error 1 RBLastError1 0 121 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 2 RBLastError2 0 122 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 3 RBLastError3 0 123 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 4 RBLastError4 0 124 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 5 RBLastError5 0 125 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 6 RBLastError6 0 126 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 7 RBLastError7 0 127 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 8 RBLastError8 0 128 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 9 RBLastError9 0 129 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
last error 10 RBLastError10 0 130 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RO non-
vol.
startdelay relay RBDelayTimePowerOn 0 132 2 Unsigned16 Auto,
OOS
0 ... 300 5 s RW static
card1 name RBCard1Name S0050 0 169 23 VisibleString Auto,
OOS
23 ---------- - RO static
card1 serial no RBCard1SerialNo S0050 0 170 16 VisibleString Auto,
OOS
16 ---------- - RO static
card1 hwversion RBCard1HardwareVersion S0050 0 171 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card1 hwrev RBCard1HardwareRevision S0050 0 172 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card2 name RBCard2Name S0050 0 173 23 VisibleString Auto,
OOS
23 ---------- - RO static
card2 serial no RBCard2SerialNo S0050 0 174 16 VisibleString Auto,
OOS
16 ---------- - RO static
card2 hwversion RBCard2HardwareVersion S0050 0 175 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card2 hwrev RBCard2HardwareRevision S0050 0 176 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
8Endress + Hauser
card3 name RBCard3Name S0050 0 177 23 VisibleString Auto,
OOS
23 ---------- - RO static
card3 serial no RBCard3SerialNo S0050 0 178 16 VisibleString Auto,
OOS
16 ---------- - RO static
card3 hwversion RBCard3HardwareVersion S0050 0 179 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card3 hwrev RBCard3HardwareRevision S0050 0 180 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card4 name RBCard4Name S0050 0 181 23 VisibleString Auto,
OOS
23 ---------- - RO static
card4 serial no RBCard4SerialNo S0050 0 182 16 VisibleString Auto,
OOS
16 ---------- - RO static
card4 hwversion RBCard4HardwareVersion S0050 0 183 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card4 hwrev RBCard4HardwareRevision S0050 0 184 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card5 name RBCard5Name S0050 0 185 23 VisibleString Auto,
OOS
23 ---------- - RO static
card5 serial no RBCard5SerialNo S0050 0 186 16 VisibleString Auto,
OOS
16 ---------- - RO static
card5 hwversion RBCard5HardwareVersion S0050 0 187 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card5 hwrev RBCard5HardwareRevision S0050 0 188 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card6 name RBCard6Name S0050 0 189 23 VisibleString Auto,
OOS
23 ---------- - RO static
card6 serial no RBCard6SerialNo S0050 0 190 16 VisibleString Auto,
OOS
16 ---------- - RO static
card6 hwversion RBCard6HardwareVersion S0050 0 191 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card6 hwrev RBCard6HardwareRevision S0050 0 192 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card7 name RBCard7Name S0050 0 193 23 VisibleString Auto,
OOS
23 ---------- - RO static
card7 serial no RBCard7SerialNo S0050 0 194 16 VisibleString Auto,
OOS
16 ---------- - RO static
card7 hwversion RBCard7HardwareVersion S0050 0 195 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card7 hwrev RBCard7HardwareRevision S0050 0 196 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card8 name RBCard8Name S0050 0 197 23 VisibleString Auto,
OOS
23 ---------- - RO static
card8 serial no RBCard8SerialNo S0050 0 198 16 VisibleString Auto,
OOS
16 ---------- - RO static
card8 hwversion RBCard8HardwareVersion S0050 0 199 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
card8 hwrev RBCard8HardwareRevision S0050 0 200 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO static
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 9
download mode RBDownloadMode 0 206 1 Unsigned8 Auto,
OOS
0 : parameter only
1 : param+cust.map
2 : mapping only
parameter
only
-RWdyna-
mic
modem sync RBSyncGSMModem S0140 0 212 1 Unsigned8 Auto,
OOS
0 : off
1 : on
off - RW static
device marking RBDeviceTag23 DX102 0 237 23 VisibleString Auto,
OOS
23 ------------
-----------
-RWstatic
order code RBOrderCode23 CX901 0 238 23 VisibleString Auto,
OOS
23 ------------
-----------
-RWstatic
copy of RBCopyLevelSrc 0 242 2 Unsigned16 Auto,
OOS
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
level 1 - RW static
paste to RBCopyLevelDest 0 243 2 Unsigned16 Auto,
OOS
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
level 2 - RW static
start RBStartCopyLevel 0 244 1 Unsigned8 Auto,
OOS
0 : no
1 : yes
no - RW dyna-
mic
copy of RBCopySensorSrc 0 245 2 Unsigned16 Auto,
OOS
30210 : sensor 1
30211 : sensor 2
30212 : sensor 3
30213 : sensor 4
30214 : sensor 5
30215 : sensor 6
30216 : sensor 7
30217 : sensor 8
30218 : sensor 9
30219 : sensor 10
sensor 1 - RW static
paste to RBCopySensorDest 0 246 2 Unsigned16 Auto,
OOS
30210 : sensor 1
30211 : sensor 2
30212 : sensor 3
30213 : sensor 4
30214 : sensor 5
30215 : sensor 6
30216 : sensor 7
30217 : sensor 8
30218 : sensor 9
30219 : sensor 10
sensor 2 - RW static
start RBStartCopySensor 0 247 1 Unsigned8 Auto,
OOS
0 : no
1 : yes
no - RW dyna-
mic
copy of RBCopyFlowSrc 0 248 2 Unsigned16 Auto,
OOS
30220 : flow 1
30221 : flow 2
flow 1 - RW static
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
10 Endress + Hauser
paste to RBCopyFlowDest 0 249 2 Unsigned16 Auto,
OOS
30220 : flow 1
30221 : flow 2
flow 2 - RW static
start RBStartCopyFlow 0 250 1 Unsigned8 Auto,
OOS
0 : no
1 : yes
no - RW dyna-
mic
View1 RBPBView1 0 251 17 VisibleString Auto,
OOS
17 - - RO dyna-
mic
ProcessorSW-
Vers.
RBuCSWVersion S0050 1 75 16 VisibleString Auto,
OOS
16 ------------
----
-ROdyna-
mic
DSPSWVers. RBDSPSWVersion S0050 1 80 16 VisibleString Auto,
OOS
16 ------------
----
-ROdyna-
mic
DisplaySWVers. RBDisplaySWVersion S0050 1 85 16 VisibleString Auto,
OOS
16 ------------
----
-ROdyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 11
2.2 Display Block (DY)
2.2.1 Instances
2.2.2 Structure
Instance Slot Index
1410
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class
Target Mode DYTargetMode 0 5 1 Unsigned8 Auto,
OOS
8 ... 8 0 - RW non-
vol.
language DYLanguage DX011 0 29 2 Unsigned16 Auto,
OOS
0 : English
1 : Deutsch
2 : Français
3 : EspaÃol
4 : Italiano
5 : Nederlands
6 : Portuguesa
30400 : Russian
30401 : polski
30402 : Czech
30403 : Arab
30404 : Chinese
30405 : Japanese
30406 : Korean
30407 : Bahasa
30408 : Thai
30409 : Vietnamese
English - RW static
back to home DYBackToHome DX200 0 30 2 Integer16 Auto,
OOS
10 ... 9999 900 s RW static
format DYFormatDisplayDecInch DX211 0 31 1 Unsigned8 Auto,
OOS
0 : decimal
1 : ft-in-1/16''
decimal - RW static
sep. character DYSeparationCharacter DX213 0 32 1 Unsigned8 Auto,
OOS
0 : .
1 : ,
.-RWstatic
type DYDisplayModeWithBar-
graph
DX221 0 33 2 Unsigned16 Auto,
OOS
30230 : 1x value+bargr
30231 : 2x value+bargr
30232 : value max size
30233 : alter. 3x2 val
30234 : alter.5x2 val.
30235 : bargr. profil
1x
value+bar
gr
-RWstatic
time DYChangeTime CX000 0 34 1 Unsigned8 Auto,
OOS
0 ... 255 3 s RW static
reset DYResetBlock 0 36 2 Unsigned16 Auto,
OOS
0 ... 65535 0 - RW dyna-
mic
customized text DYLabelText CX000 0 38 1 Unsigned8 Auto,
OOS
0 : no
1 : yes
no - RW static

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
12 Endress + Hauser
value 1 DYInput1Source DX320 0 39 2 Unsigned16 Auto,
OOS
0 : none
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
24 : sum 1
25 : sum 2
26 : sum 3
27 : average 1
28 : average 2
29 : average 3
30 : sum 1
31 : sum 2
32 : sum 3
33 : sum 4
34 : sum 5
35 : average 1
36 : average 2
37 : average 3
38 : average 4
39 : average 5
40 : temp. sensor 1
41 : temp. sensor 2
42 : temp. sensor 3
43 : temp. sensor 4
44 : temp. sensor 5
45 : temp. sensor 6
46 : temp. sensor 7
47 : temp. sensor 8
48 : temp. sensor 9
49 : temp. sensor10
50 : dist. sensor 1
51 : dist. sensor 2
52 : dist. sensor 3
53 : dist. sensor 4
54 : dist. sensor 5
55 : dist. sensor 6
56 : dist. sensor 7
57 : dist. sensor 8
58 : dist. sensor 9
59 : dist. sensor10
none - RW static
input1 status DYInput1Status 0 41 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO dyna-
mic
value 1 DYInput1Value CX000 0 42 4 Float Auto,
OOS
-999999.0 ... 999999.0 0.0 DYIn
put1
Unit1
6
RO dyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 13
input1 unit DYInput1Unit16 0 43 2 Unsigned16 Auto,
OOS
1342 : %
1038 : l
1041 : hl
1034 : m3
1035 : dm3
1036 : cm3
1043 : ft3
1048 : usgal
1049 : i gal
1088 : kg
1092 : t
1094 : lb
1095 : ton
1010 : m
1018 : ft
1013 : mm
1019 : inch
1351 : l/s
1352 : l/min
1353 : l/h
1347 : m3/s
1348 : m3/min
1349 : m3/h
1356 : Ft3/s
1362 : gal/s
1363 : gal/m
1364 : gal/hr
1366 : mgal/d
1367 : igal/s
1368 : igal/m
1369 : igal/h
1355 : Ml/day
1521 : Ml/h
1522 : Ml/min
1523 : Ml/s
1478 : iMgal/day
1001 : °C
1002 : °F
1211 : mA
1996 : Ml
1042 : In
1524 : us mgal
1051 : barrels
1997 :
1995 : customer spec.
%-ROdyna-
mic
cust. text 1 DYInput1Text CX000 0 46 16 VisibleString Auto,
OOS
16 - - RW non-
vol.
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
14 Endress + Hauser
value 2 DYInput2Source CX000 0 47 2 Unsigned16 Auto,
OOS
0 : none
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
24 : sum 1
25 : sum 2
26 : sum 3
27 : average 1
28 : average 2
29 : average 3
30 : sum 1
31 : sum 2
32 : sum 3
33 : sum 4
34 : sum 5
35 : average 1
36 : average 2
37 : average 3
38 : average 4
39 : average 5
40 : temp. sensor 1
41 : temp. sensor 2
42 : temp. sensor 3
43 : temp. sensor 4
44 : temp. sensor 5
45 : temp. sensor 6
46 : temp. sensor 7
47 : temp. sensor 8
48 : temp. sensor 9
49 : temp. sensor10
50 : dist. sensor 1
51 : dist. sensor 2
52 : dist. sensor 3
53 : dist. sensor 4
54 : dist. sensor 5
55 : dist. sensor 6
56 : dist. sensor 7
57 : dist. sensor 8
58 : dist. sensor 9
59 : dist. sensor10
none - RW static
input2 status DYInput2Status 0 49 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO dyna-
mic
value 2 DYInput2Value CX000 0 50 4 Float Auto,
OOS
-999999.0 ... 999999.0 0.0 DYIn
put2
Unit1
6
RO dyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 15
input2 unit DYInput2Unit16 0 51 2 Unsigned16 Auto,
OOS
1342 : %
1038 : l
1041 : hl
1034 : m3
1035 : dm3
1036 : cm3
1043 : ft3
1048 : usgal
1049 : i gal
1088 : kg
1092 : t
1094 : lb
1095 : ton
1010 : m
1018 : ft
1013 : mm
1019 : inch
1351 : l/s
1352 : l/min
1353 : l/h
1347 : m3/s
1348 : m3/min
1349 : m3/h
1356 : Ft3/s
1362 : gal/s
1363 : gal/m
1364 : gal/hr
1366 : mgal/d
1367 : igal/s
1368 : igal/m
1369 : igal/h
1355 : Ml/day
1521 : Ml/h
1522 : Ml/min
1523 : Ml/s
1478 : iMgal/day
1001 : °C
1002 : °F
1211 : mA
1996 : Ml
1042 : In
1524 : us mgal
1051 : barrels
1997 :
1995 : customer spec.
%-ROdyna-
mic
cust. text 2 DYInput2Text CX000 0 54 16 VisibleString Auto,
OOS
16 - - RW non-
vol.
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
16 Endress + Hauser
value 3 DYInput3Source CX000 0 55 2 Unsigned16 Auto,
OOS
0 : none
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
24 : sum 1
25 : sum 2
26 : sum 3
27 : average 1
28 : average 2
29 : average 3
30 : sum 1
31 : sum 2
32 : sum 3
33 : sum 4
34 : sum 5
35 : average 1
36 : average 2
37 : average 3
38 : average 4
39 : average 5
40 : temp. sensor 1
41 : temp. sensor 2
42 : temp. sensor 3
43 : temp. sensor 4
44 : temp. sensor 5
45 : temp. sensor 6
46 : temp. sensor 7
47 : temp. sensor 8
48 : temp. sensor 9
49 : temp. sensor10
50 : dist. sensor 1
51 : dist. sensor 2
52 : dist. sensor 3
53 : dist. sensor 4
54 : dist. sensor 5
55 : dist. sensor 6
56 : dist. sensor 7
57 : dist. sensor 8
58 : dist. sensor 9
59 : dist. sensor10
none - RW static
input3 status DYInput3Status 0 57 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO dyna-
mic
value 3 DYInput3Value CX000 0 58 4 Float Auto,
OOS
-999999.0 ... 999999.0 0.0 DYIn
put3
Unit1
6
RO dyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 17
input3 unit DYInput3Unit16 0 59 2 Unsigned16 Auto,
OOS
1342 : %
1038 : l
1041 : hl
1034 : m3
1035 : dm3
1036 : cm3
1043 : ft3
1048 : usgal
1049 : i gal
1088 : kg
1092 : t
1094 : lb
1095 : ton
1010 : m
1018 : ft
1013 : mm
1019 : inch
1351 : l/s
1352 : l/min
1353 : l/h
1347 : m3/s
1348 : m3/min
1349 : m3/h
1356 : Ft3/s
1362 : gal/s
1363 : gal/m
1364 : gal/hr
1366 : mgal/d
1367 : igal/s
1368 : igal/m
1369 : igal/h
1355 : Ml/day
1521 : Ml/h
1522 : Ml/min
1523 : Ml/s
1478 : iMgal/day
1001 : °C
1002 : °F
1211 : mA
1996 : Ml
1042 : In
1524 : us mgal
1051 : barrels
1997 :
1995 : customer spec.
%-ROdyna-
mic
cust. text 3 DYInput3Text CX000 0 62 16 VisibleString Auto,
OOS
16 - - RW non-
vol.
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
18 Endress + Hauser
value 4 DYInput4Source CX000 0 63 2 Unsigned16 Auto,
OOS
0 : none
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
24 : sum 1
25 : sum 2
26 : sum 3
27 : average 1
28 : average 2
29 : average 3
30 : sum 1
31 : sum 2
32 : sum 3
33 : sum 4
34 : sum 5
35 : average 1
36 : average 2
37 : average 3
38 : average 4
39 : average 5
40 : temp. sensor 1
41 : temp. sensor 2
42 : temp. sensor 3
43 : temp. sensor 4
44 : temp. sensor 5
45 : temp. sensor 6
46 : temp. sensor 7
47 : temp. sensor 8
48 : temp. sensor 9
49 : temp. sensor10
50 : dist. sensor 1
51 : dist. sensor 2
52 : dist. sensor 3
53 : dist. sensor 4
54 : dist. sensor 5
55 : dist. sensor 6
56 : dist. sensor 7
57 : dist. sensor 8
58 : dist. sensor 9
59 : dist. sensor10
none - RW static
input4 status DYInput4Status 0 65 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO dyna-
mic
value 4 DYInput4Value CX000 0 66 4 Float Auto,
OOS
-999999.0 ... 999999.0 0.0 DYIn
put4
Unit1
6
RO dyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Prosonic S FMU95 - PROFIBUS DP Slot-Index Lists
Endress + Hauser 19
input4 unit DYInput4Unit16 0 67 2 Unsigned16 Auto,
OOS
1342 : %
1038 : l
1041 : hl
1034 : m3
1035 : dm3
1036 : cm3
1043 : ft3
1048 : usgal
1049 : i gal
1088 : kg
1092 : t
1094 : lb
1095 : ton
1010 : m
1018 : ft
1013 : mm
1019 : inch
1351 : l/s
1352 : l/min
1353 : l/h
1347 : m3/s
1348 : m3/min
1349 : m3/h
1356 : Ft3/s
1362 : gal/s
1363 : gal/m
1364 : gal/hr
1366 : mgal/d
1367 : igal/s
1368 : igal/m
1369 : igal/h
1355 : Ml/day
1521 : Ml/h
1522 : Ml/min
1523 : Ml/s
1478 : iMgal/day
1001 : °C
1002 : °F
1211 : mA
1996 : Ml
1042 : In
1524 : us mgal
1051 : barrels
1997 :
1995 : customer spec.
%-ROdyna-
mic
cust. text 4 DYInput4Text CX000 0 70 16 VisibleString Auto,
OOS
16 - - RW non-
vol.
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class

Slot-Index Lists Prosonic S FMU95 - PROFIBUS DP
20 Endress + Hauser
value 5 DYInput5Source CX000 0 71 2 Unsigned16 Auto,
OOS
0 : none
30200 : level 1
30201 : level 2
30202 : level 3
30203 : level 4
30204 : level 5
30205 : level 6
30206 : level 7
30207 : level 8
30208 : level 9
30209 : level 10
24 : sum 1
25 : sum 2
26 : sum 3
27 : average 1
28 : average 2
29 : average 3
30 : sum 1
31 : sum 2
32 : sum 3
33 : sum 4
34 : sum 5
35 : average 1
36 : average 2
37 : average 3
38 : average 4
39 : average 5
40 : temp. sensor 1
41 : temp. sensor 2
42 : temp. sensor 3
43 : temp. sensor 4
44 : temp. sensor 5
45 : temp. sensor 6
46 : temp. sensor 7
47 : temp. sensor 8
48 : temp. sensor 9
49 : temp. sensor10
50 : dist. sensor 1
51 : dist. sensor 2
52 : dist. sensor 3
53 : dist. sensor 4
54 : dist. sensor 5
55 : dist. sensor 6
56 : dist. sensor 7
57 : dist. sensor 8
58 : dist. sensor 9
59 : dist. sensor10
none - RW static
input5 status DYInput5Status 0 73 1 Unsigned8 Auto,
OOS
0 ... 255 0 - RO dyna-
mic
value 5 DYInput5Value CX000 0 74 4 Float Auto,
OOS
-999999.0 ... 999999.0 0.0 DYIn
put5
Unit1
6
RO dyna-
mic
Parameter Text Variable Name Position Indicator Slot (relative) Index (absolute) Size [bytes] Type Changeable in Mode Range Default Unit Access Storage Class
