Endress+Hauser FieldEdge SGC200 User manual

Products Solutions Services
Operating Instructions
FieldEdge SGC200
Bluetooth Edge Device to connect measuring
technology to the Netilion Cloud
BA02058S/04/EN/01.20
71494807
2020-08-17

Revision history FieldEdge SGC200
2 Endress+Hauser
Revision history
Product version Operating Instructions Changes Comments
1.00.XX BA02058S/04/EN/01.20 Initial version –

FieldEdge SGC200 Table of contents
Endress+Hauser 3
Table of contents
1 About this document ........... 4
1.1 Document function ................... 4
1.2 Symbols used ........................ 4
1.3 Documentation ...................... 5
1.4 Registered trademarks ............... 6
2 Basic safety instructions ....... 6
2.1 Requirements for the personnel ........ 6
2.2 Designated use ...................... 6
2.3 Workplace safety .................... 6
2.4 Operational safety ................... 7
2.5 Product safety ....................... 7
2.6 Device-specific IT security ............. 7
3 Product description ............. 7
3.1 Function ............................ 7
3.2 System design ....................... 8
3.3 Communication and data processing .... 8
4 Incoming acceptance and
product identification .......... 9
4.1 Incoming acceptance ................. 9
4.2 Product identification ................. 9
4.3 Storage and transport ................. 9
5 Installation .................... 10
5.1 Installation conditions ............... 10
5.2 Mounting the device ................ 10
5.3 Post-installation check ............... 13
6 Electrical connection .......... 14
6.1 Connection conditions ............... 14
6.2 Connecting the device ............... 15
6.3 Post-connection check ............... 15
7 Operation options ............. 15
8 System integration via
SmartBlue app ................. 16
9 Commissioning ................ 16
9.1 Function check ..................... 16
9.2 Configuring the device ............... 17
10 FieldEdge SGC200 and
Netilion ........................ 23
10.1 Using the FieldEdge SGC200 in
Netilion ........................... 23
10.2 About Netilion ..................... 24
11 Maintenance .................. 24
12 Repairs ......................... 24
12.1 General notes ...................... 24
12.2 Return and / or cancellation of Netilion
Subscription ........................24
12.3 Disposal ........................... 25

About this document FieldEdge SGC200
4 Endress+Hauser
1 About this document
1.1 Document function
These Operating Instructions contain all the information that is required in various phases of
the life cycle of the device: from product identification, incoming acceptance and storage, to
mounting, connection, operation and commissioning through to troubleshooting,
maintenance and disposal.
1.2 Symbols used
1.2.1 Safety symbols
DANGER
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.2.2 Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation.
A
Reference to page.
Reference to graphic.

FieldEdge SGC200 About this document
Endress+Hauser 5
Symbol Meaning
Notice or individual step to be observed.
1.
,
2.
,
3.
… Series of steps.
Result of a step.
Help in the event of a problem.
Visual inspection.
1.2.3 Symbols in graphics
Symbol Meaning Symbol Meaning
1, 2, 3,... Item numbers
1.
,
2.
,
3.
… Series of steps
A, B, C, ... Views A-A, B-B, C-C, ... Sections
-
Hazardous area
.
Safe area (non-hazardous area)
1.2.4 SmartBlue icons
Symbol Meaning
SmartBlue
Accessible field devices
Home
Menu
Settings
1.3 Documentation
FieldEdge SGC200
• Operating Instructions BA02058S
• Technical Information TI01452S

Basic safety instructions FieldEdge SGC200
6 Endress+Hauser
1.4 Registered trademarks
Bluetooth®
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG,
Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and
trade names are those of their respective owners.
Apple®
Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the
U.S. and other countries. App Store is a service mark of Apple Inc.
Android®
Android, Google Play and the Google Play logo are trademarks of Google Inc.
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill the
following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Are authorized by the plant owner/operator.
‣Are familiar with federal/national regulations.
‣Before starting work, read and understand the instructions in the manual and
supplementary documentation as well as the certificates (depending on the application).
‣Follow instructions and comply with basic conditions.
The operating personnel must fulfill the following requirements:
‣Are instructed and authorized according to the requirements of the task by the facility's
owner-operator.
‣Follow the instructions in this manual.
2.2 Designated use
The FieldEdge SGC200 must be installed, connected and configured in accordance with the
instructions in this manual.
The FieldEdge SGC200 is not approved for hazardous areas.
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.

FieldEdge SGC200 Product description
Endress+Hauser 7
2.4 Operational safety
Risk of injury!
‣Operate the device only if it is in proper technical condition, free from errors and faults.
‣The operator is responsible for interference-free operation of the device.
Modifications to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers:
‣If modifications are nevertheless required, consult with Endress+Hauser.
2.5 Product safety
The FieldEdge SGC200 meets the legal requirements of the relevant EU directives.
Endress+Hauser has affixed the CE mark as confirmation that the FieldEdge SGC200 has been
successfully tested.
2.6 Device-specific IT security
2.6.1 Access via Bluetooth® wireless technology
Signal transmission via Bluetooth® wireless technology uses a cryptographic technique
tested by Fraunhofer AISEC.
• Connection via Bluetooth® is not possible without specific Endress+Hauser devices.
• Only one point-to-point connection between one device and one smartphone or tablet is
established.
3 Product description
3.1 Function
The FieldEdge SGC200 enables the connection of Endress+Hauser devices to the
Netilion Cloud via Bluetooth. The FieldEdge transmits device IDs, device readings and status
information. Connection to the web is via an integrated LTE modem with a global SIM card.
The FieldEdge is configured via the Endress+Hauser SmartBlue app.
You can use the transmitted data via the following offers:
• Netilion Connect or
• Netilion Services
Netilion Connect
The transmitted data can be retrieved directly via a software interface (REST JSON Application
Programming Interface (API)) and integrated into a user application.
The Application Programming Interface (API) is provided as part of the Netilion Connect
Subscription.

Product description FieldEdge SGC200
8 Endress+Hauser
Netilion Services
Netilion Services can be used for example for remote monitoring with a Netilion Service
Subscription.
3.2 System design
13 4 5
10 6
6 7
8
Netilion
9
2
 1 Network architecture
1 Endress+Hauser field devices based on Bluetooth® Wireless technology
2 Encrypted, wireless remote access via Bluetooth®
3 FieldEdge SGC200
4 LTE connection
5 Netilion Cloud
6 https Internet connection
7 Netilion Services: Netilion Service app based on internet browser
8 User application
9 Netilion Connect: Application Programming Interface (API)
10 Endress+Hauser SmartBlue app
3.3 Communication and data processing
Bluetooth IEEE 802.15.1
4G/LTE

FieldEdge SGC200 Incoming acceptance and product identification
Endress+Hauser 9
4 Incoming acceptance and product identification
4.1 Incoming acceptance
• Check the packaging for visible damage arising from transportation.
• To avoid damage, remove the packaging with care.
• Keep all the accompanying documents.
The system may not be put into operation if the contents are found to be damaged
beforehand. In this case refer to the information on https://netilion.endress.com/legal/terms-
of-service. Return the system to Endress+Hauser in the original packaging where possible.
4.2 Product identification
4.2.1 Nameplate
 2 FieldEdge SGC200 nameplate
4.2.2 Manufacturer's address
Endress+Hauser Process Solutions AG
Christoph Merian-Ring 12
CH-4153 Reinach
Switzerland
www.endress.com
4.3 Storage and transport
Always use the original packaging when transporting the product.
4.3.1 Ambient temperature range
–40 to 80 °C (–40 to 176 °F)
4.3.2 Storage temperature
–40 to 80 °C (–40 to 176 °F)

Installation FieldEdge SGC200
10 Endress+Hauser
4.3.3 Humidity
10 to 95 %
4.3.4 Vibration resistance
DIN EN 60068-2-64
IEC 60068-2-64: 20 to 2 000 Hz(1 m/s)2 Hz
4.3.5 Degree of protection
The device can be used in buildings and outdoors and has IP67 protection from
immersion.
5 Installation
5.1 Installation conditions
Please note the following to ensure correct operation of the FieldEdge SGC200:
• Fit the LTE antenna supplied or ordered as an optional extra on the device
• Connect the device to a voltage supply.
• Use the SmartBlue app to determine the best location for the device →  15
• The device can be used in buildings and outdoors and has IP67 protection from immersion.
• Can be installed up to a maximum altitude of 2 000 m (6 562 ft) above sea level.
• Supply voltage 8 to 30 VDC
• Permitted voltage fluctuation ± 10 %
• Input current 0.2 A
• Pollution degree 4 in accordance with IEC 61010
• Ambient temperature range –40 to 80 °C (–40 to 176 °F)
• Humidity 10 to 95 %
• Vibration resistance in accordance with IEC 60068-2-64 and DIN EN 60068-2-64:
20 to 2 000 Hz (1 m/s) 2 Hz
Only use the LTE antenna provided or the optional remote antenna; otherwise the
operating permit will lose its validity.
5.2 Mounting the device
Dimensions
• FieldEdge SGC200 without LTE antenna:
100.5 mm ⋅ 40 mm ⋅ 118.44 mm (3.94 in ⋅ 1.57 in ⋅ 4.65 in)
• FieldEdge SGC200 with angled LTE antenna (supplied):
350 mm ⋅ 40 mm ⋅ 155 mm (13.78 in ⋅ 1.57 in ⋅ 6.10 in)

FieldEdge SGC200 Installation
Endress+Hauser 11
110 (4.33)
86 (3.39)
100 5 (3.94).
40 (1.57)
97 5 (3.82).
118 44 (4.65).
3
21
 3 Dimensions of FieldEdge SGC200 without LTE antenna in mm (in)
1 5-pin connector for connecting power supply
2 5-pin socket for future use
3 Connection for LTE antenna (supplied) or for optionally available remote LTE antenna

Installation FieldEdge SGC200
12 Endress+Hauser
90°
4.15 0 16( . )
Ø
Ø
12.7
0 5( . )
Ø
Ø
12.9
5.08( )
31.1
1.22( )
±4
294.1 (11.58
±0.16
)
A0043632
 4 Dimensions of LTE antenna in mm (in)
5.2.1 Installing the mounting bracket
The mounting bracket is optionally available to order. www.endress.com/sgc200

FieldEdge SGC200 Installation
Endress+Hauser 13
72 (2.83)
88,8 (3.46)
100 (3.94)
168 (6.61)
110 (4.33)
20,5 (0.79)
31 (1.22)
6 (0.24)
83 (3.27)
6 (0.24)
26,41 (1.02)
55 (2.17)
 5 Dimensions of mounting bracket in mm (in)
The mounting bracket is suitable for installation on a wall and on pipes with the
following diameters: 45 to 60 mm (1.77 to 2.36 in).
5.2.2 Mounting the LTE antenna
Screw the LTE antenna provided or the optional remote LTE antenna onto the screw thread
on the FieldEdge.
A remote LTE antenna (3 m) is optionally available to order. www.endress.com/sgc200
5.3 Post-installation check
Are the mounted components undamaged (visual inspection)? 
Do all the components meet the required specifications? For example:
• Ambient temperature
• Humidity


Electrical connection FieldEdge SGC200
14 Endress+Hauser
Are all the securing screws tightened securely? 
Is the LTE antenna mounted on the FieldEdge? 
6 Electrical connection
6.1 Connection conditions
NOTICE
Cause of damage: Antenna is not installed.
If the antenna is not installed, this may damage the device.
‣Never connect the device to the supply voltage without the antenna installed.
‣Never operate the device without the antenna installed.
The following conditions must be met:
• Ensure the cable is de-energized when connecting to the FieldEdge SGC200
• Please follow the connection information in this manual
• Supply voltage 8 to 30 VDC
• Permitted voltage fluctuation ± 10 %
• Input current 0.2 A
The power unit must meet the following requirements:
• The power unit must be certified in accordance with IEC 60950-1 or IEC61010-1
• The power unit must comply with the manufacturer's specification in order to guarantee the
required level of protection.
• If using an external power supply with more than 10 A or 16 A, install an external fuse with
10 A or 16 A.
• If the power supply is installed outside, it must be certified for outdoor applications.
• If the power supply is not certified for outdoor applications, it must be installed in the
building.
The wiring must meet the following requirements:
• Wire cross-section 0.5 mm²
• Temperature resistance of 105 °C (221 °F)

FieldEdge SGC200 Operation options
Endress+Hauser 15
6.2 Connecting the device
1 2
3
4
5
2 1
4
3
5
+
GND
12
1 Connector at housing: power supply
2 Socket at housing: for future use
6.2.1 Ensuring the degree of protection
The device meets the requirements for IP67 degree of protection.
NOTICE
Cause of damage: Opening the FieldEdge SGC200
IP67 degree of protection is voided.
‣The housing of the FieldEdge SGC200 must not be opened.
6.3 Post-connection check
Are the system, devices and cables undamaged (visual check)? 
Do the cables comply with the requirements? 
Do the installed cables have adequate strain relief? 
Does the supply voltage of the components match the specifications on the nameplate? 
Is the terminal assignment correct? 
Is the housing cover locked? 
Are all the cable glands tightened securely? 
7 Operation options
The FieldEdge SGC200 can be operated via the Endress+Hauser SmartBlue app →  16.

System integration via SmartBlue app FieldEdge SGC200
16 Endress+Hauser
8 System integration via SmartBlue app
Signal transmission via wireless Bluetooth technology uses an encryption method tested by a
third party (Fraunhofer AISEC). Without the SmartBlue app, the device is not visible via
Bluetooth. One point-to-point connection is established between the device and a smartphone
or tablet.
The SmartBlue App is available to download for mobile terminals with Android in the Google
Play Store and for devices with iOS in the Apple App Store.
‣
Scan the QR code.
 The Google Play Store or the Apple App Store page for downloading the SmartBlue app
appears.
System requirements
For the system requirements of the SmartBlue app, see either the Google Play page or
the Apple App page.
9 Commissioning
9.1 Function check
Has a Bluetooth connection been established between the FieldEdge SGC200 and the Bluetooth
field devices? The range is dependent on the ambient conditions and is typically 20 m.
Pay attention to the range specifications of the field devices.

Has a connection been established between the device and a cell phone network? 
Has a connection been established between the device and the connected field devices? 
9.1.1 Determining the device location
The cellular network and the field devices to be connected must be accessible at the device
location via the SmartBlue app. The FieldEdge SGC200 is not needed to determine the
location. A cellular-enabled device with the SmartBlue App app installed is sufficient.

FieldEdge SGC200 Commissioning
Endress+Hauser 17
1. Start the SmartBlue app.
2. Tap on the icon (accessible field devices).
 The FieldEdge SGC200 and all field devices that are accessible from the SmartBlue
app at the current position are displayed.
3. Use the cellular-enabled device to determine the location for the installation of the
FieldEdge SGC200 by changing the position. The cellular network and all of the field
devices to be connected must be accessible.
When selecting the location for the FieldEdge SGC200 ensure that the connection to the
cell phone network is good. To improve the connection, use the remote LTE antenna,
which is optionally available to order.
9.2 Configuring the device
The device must be installed at the specified location and supplied with power.
9.2.1 Connecting the device to the SmartBlue app
Use the following access details when logging in for the first time:
• User name: admin
• Password: Serial number of FieldEdge SGC200, as specified on the nameplate
The password must be changed after you have logged in for the first time.
1. Start the SmartBlue app.
 The FieldEdge SGC200 devices that are accessible from the SmartBlue app at the
current position are displayed.
2. Select the FieldEdge SGC200 using the serial number in the TAG.

Commissioning FieldEdge SGC200
18 Endress+Hauser
3. Enter username and password.

 6 Overview of FieldEdge SGC200 and connection status. Where applicable, the
connection status of the field devices is "Not connected".
9.2.2 Checking the cellular network connection status of devices
The device is supplied with a pre-configured cell phone connection. The green check mark in
the "Cellular Network" section of the main menu confirms that the device status is OK.

FieldEdge SGC200 Commissioning
Endress+Hauser 19
Detailed information on the cellular network is shown on the "Cellular Network Carrier" page.
Path: icon (menu) > System > Cellular Network Carrier
9.2.3 Checking the Netilion Cloud connection
The device is supplied with a pre-configured Cloud connection. The green check mark
confirms that the device is connected to the Netilion Cloud.
You can also check the time of the last update in the Netilion Account. Path: ID > EdgeDevices

Commissioning FieldEdge SGC200
20 Endress+Hauser
9.2.4 Connecting the device to Bluetooth field devices
Use the following access details when logging in for the first time:
• User name: admin
• Password: Serial number of the FieldEdge SGC200, as specified on the nameplate.
1. Tap on the icon (menu).

