User Manual
1/2.8” HD , Day&Night,
1920x1080, Infrared,
IP66
MEB-62V2812P0B
MEB-62F0036P0A

Safety Precaution
03
ULTRA CLEAR RESOLUTION CAMERA
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent electric shocks and risk of fire hazards, do NOT use other than
specific power source.
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of uninsulated
"dangerous voltage" within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
Warning :
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
Caution :
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority
to operate the equipment.
Mains power quality should be that of a typical commercial environment. If the user
of the model requires continued operation during power mains interruptions, it is
recommended that the model be powered from an uninterruptible power supply
(UPS) or a battery.

ULTRA CLEAR RESOLUTION CAMERA
Safety Precaution
04
NOTICE
The image used in this instruction manual are processed to help comprehension
and may differ from actual video of the camera.
Avoid installing areas where has shock or vibration which results in the problems.
Pay attention to safety when laying the connection cable and observe that the cable
is not subjected to heavy loads, kinks or damage and no moisture can get in.
The warranty becomes void if repairs are undertaken by unauthorized persons.
Maintenance and repair have to be carried out only by authorized service centers.
Use only a mild detergent to clean the housing.
The camera should never be operated beyond the technical specifications.
This can lead to destruction.
The camera should never be operated in water.

ULTRA CLEAR RESOLUTION CAMERA
Contents
05
Safety Precaution
p.03~04
Contents
p.05
Features
p.06
Composition
p.07
Dimensions
p.07
Part Names
p.08
Installation Instructions
p.09~10
Operating Instructions
p.11~28
Specifications
p.29~30

ULTRA CLEAR RESOLUTION CAMERA
Features
Key Features
06
• 1/2.8” SONY Exmor CMOS sensor
• 1080P TVI mode, CVI mode, AHD Video or 960H CVBS Video Selectable
• TVI mode/CVI mode/AHD Video Transmission Distance over Coax.; 500M
• Automatically removable IR Cut filter by Dual filter switcher
• Lens
> MEB-62V2812P0B : f=2.8~12mm F1.3 Mega pixel DC Auto Iris Vari-focal lens
> MEB-62F0036P0A : f=3.6mm F2.0, Mega pixel fixed lens
• Sensitivity of Color 0.3 Lux / BW 0.005 Lux (@IRE 40, Sens-up On, IR Off)
• D-WDR (Wide Dynamic Range)
• Improved noise reduction 2D+3DNR(TVI mode/CVI mode/AHD), 2DNR(CVBS)
• FOCUS ASSIST for Error free focus adjustment
• 2 Auto(AE/AWB) control
• LSC (Lens Shading Compensation)
• DPC (Defective Pixel Compensation)
• Motion detection, Privacy mask, BLC/HSBLC, Defog, Sens-up(~x30),
Mirror/Flip, Freeze, Negative Image, IR Smart, Cam Title
• Built-in 4pcs High power SMD LED
• UTC control through HD DVR. (Hikvision, Pelco-C)
• OSD MENU & CVBS output for easy installation & maintenance
• Dual Window, 3-Axis bracket
• IP66 Protection

07
Composition
ULTRA CLEAR RESOLUTION CAMERA
Dimensions
(unit : mm)
Plastic Anchor:
6 x 30mm (3pcs)
Operating
Instruction
Camera
Mounting Screw:
3.5 x 25mm (3pcs)
Mounting
Template
Ø66
Ø78.5
120
135
214
199
Video Sub-out Cable

ULTRA CLEAR RESOLUTION CAMERA
Part Names
08
• Extreme care should be taken NOT to scratch the surface of window while
the camera installing or adjusting.
• Care should be taken the cable is NOT to be damaged, kinked or exposed in
the hazardous area.
• Do not expose the camera directly to a strong light source such as the sun or
spot light.
CAUTION
DUAL WINDOW
SUNSHIELD BOLT
SUNSHIELD
POWER Cable
FRONT CASE
BRACKET
REAR CASE
• When assembling the front case, be sure that a Rubber sealing is not protrusive.
If the front case is tightened excessively, sealing may not be ensured.
Case open
Zoom Lever
Focus Lever
■ Focus/Zoom Adjustment
(MEB-62V2812P0B)

ULTRA CLEAR RESOLUTION CAMERA
Installation Instructions
09
Mounting Screw
: 4x40mm
1. Locate the mounting template at the installation position and drill the ceiling
or wall if needed.
2. Route the Power cable to the connecting place.
3. Place the camera bracket on pre-drilled position and fix it through using
mounting screws.
4. Set the camera’s viewing angle by using the driver. (Refer to ‘TIP’ ).
5. Put the sunshield to the camera unit and tighten the sunshield-bolt.
Pan & Tilt adjustments
1) Pan limit:
Pan is limited to +/- 90°.
2) Tilt limit:
Tilt is limited to 0°(2°) min ~ 90° max.
for wall(ceiling) installation respectively
with reference to the wall(ceiling) when
the inclination of camera module is 0°,
that is, the image is aligned horizontally.
90° 90°
Plastic Anchor
: 6x30mm
• Pan: Adjusts view direction
• Tilt: Adjusts view angle
• Inclination: Adjusts view rotation

ULTRA CLEAR RESOLUTION CAMERA
Installation Instructions
10
Adjustment of viewing angle with 3-Axis bracket.
① Lock/Unlock Screw
② Sub-Lock Screw
3) Inclination limit
(Horizontal image alignment):
Inclination limited to +/-90° max.
• Unlock the Lock/Unlock screw on the camera bracket using the driver.
• Adjust the camera’s viewing angle then lock the Lock/Unlock screw and fix
the sub-lock screw on the other side of bracket.
90°
90°
±90°
• on the wall • on the ceiling
Pan
Tilt
Inclination
[ TIP ]
