ENERGY KINETICS RESOLUTE RT Service manual

Resolute RT Gas – P/N 10-2016RTNovember 2020
MH27877
ANSI Z21.13b-2012
Low-Press Boiler
RESOLUTETM RT BOILER
OWNER AND INSTALLATION MANUAL
GAS HEAT EDITION
Manufactured By:
Energy Kinetics, Inc.
51 Molasses Hill Road
Lebanon, NJ 08833
[phone]
www.energykinetics.com
INSTALLER: HANG THIS INSTRUCTION MANUAL AND ACCESSORY INSTRUCTIONS VISIBLY
NEXT TO THE BOILER USING THE SUPPLIED POUCH.
HOMEOWNER/USER: READ AND SAVE THIS INSTRUCTION MANUAL AND ACCESSORY INSTRUCTIONS
FOR FUTURE REFERENCE.
ASME certified by EKI.
Certificate plate is under
the jacket on the steel
vessel.
UL Energy Verified, your
trusted alternative to
AFUE industry listings.
National Board
Listed

Resolute RT Gas – November 2020 2
Please Read This First
Special Attention Flags
Please pay particular attention to the following flags when you see them throughout this manual.
DANGER: Notifies you of hazards that WILL cause severe personal injury, death or substantial property damage.
WARNING:Notifies you of hazards that CAN cause severe personal injury, death or substantial property damage.
CAUTION: Notifies you of hazards that WILL or CAN cause minor personal injury or property damage.
NOTICE: Notifies you of special instructions on installation, operation, or maintenance that are important, but not
normally related to injury or property damage hazards.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result, causing
property damage, personal injury or loss of life.
WARNING: Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other gas appliance.
Provide unobstructed combustion air openings sized and located per boiler
manual and applicable codes.
WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use
any phone in your building.
•Immediately call your gas supplier from an outside phone.
•Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
WARNING: Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
Retain this manual for use by your qualified service technician only.
Should you observe unusual or abnormal operation of the burner or
boiler, contact your qualified service technician immediately. Do not
attempt to service or repair this product yourself.

Resolute RT Gas – November 2020 3
WARNING:
Have the burner/boiler started up and serviced at least once annually by a
qualified service technician. Professional care is necessary to properly service
your equipment and verify it is operating reliably. Failure to properly maintain the
equipment could result in severe personal injury, death or substantial property
damage.
WARNING:
You must keep the area around the burner/boiler free from the following.
•
Do not store or use gasoline or other flammable vapors or liquids near or in
the same room as the burner.
•
Do not use or store laundry products, paint, varnish, thinner or other such
chemicals near or in the same room as the burner/boiler. These chemicals
cause creation of acids in the burner, heat exchanger and vent system that
can cause severe damage.
•
Do not store combustible materials near or in the same room as the
burner/boiler.
•
Failure to comply could result in severe personal injury, death or
substantial property damage due to potential fire, explosion or equipment
damage from corrosive flue products.
General care and maintenance

 Please read through the information provided for you in this manual. Ask your qualified
service technician to explain normal operation of your equipment.

 Daily inspect the space around the burner/boiler to verify the area is clean and free of the
materials listed above.


Periodically watch the operation of your burner/boiler through an operating cycle to verify
normal operation. If you notice unusual conditions or equipment behavior, contact your
qualified service technician. Follow the instructions on the next page to shut down the
burner/boiler while waiting for the technician.
WARNING: Improper installation, adjustment,
alteration, service or maintenance can cause
property damage, personal injury (exposure to
hazardous materials) or loss of life. Refer to the
user’s information manual provided with this boiler.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier (who must read and follow the supplied
instructions before installing, servicing, or
removing this boiler. This boiler contains materials
that have been identified as carcinogenic, or
possibly carcinogenic, to humans).

Resolute RT Gas – November 2020 4
FOR YOUR SAFETY READ BEFORE OPERATING
A. This burner does not have a pilot. It is
equipped with an ignition device which
automatically lights the burner. Do not try
to light the burner by hand.
C. Use only your hand to turn the gas control
knob. Never use tools. If the knob will not
turn by hand, don’t try to repair it, call a
qualified service technician. Force or
attempted repair may result in a fire or
explosion.
B. Before OPERATING, smell all around the
boiler area for gas. Be sure to smell next to
the floor because some gas is heavier than
air and will settle on the floor. See below.
WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electric switch; do not
use any phone in your building
•Immediately call your gas supplier from a
neighbor’s phone. Follow the gas
supplier’s instructions.
•If you cannot reach your gas supplier, call
the fire department.
D. Do not use this boiler if any part has been
under water. Immediately call a qualified
service technician to inspect the boiler and
to replace any part of the control system
and any gas control, which has been under
water.
OPERATING INSTRUCTIONS
1. STOP! Read the safety information above.
2. Set the thermostat(s) to their lowest setting.
3. Turn off all electrical power to the burner/boiler.
4. This burner is equipped with an ignition device which automatically lights the burner.
5. Do not try to light the burner by hand.
6. Turn Gas control knob clockwise to OFF.
7. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the floor. If you
smell gas, STOP! Follow the safety information above. If you don’t smell gas, go to the next
step.
8. Turn Gas control knob counterclockwise to ON.
9. Set thermostat(s) to desired setting.
10. Turn on all electric power to the burner and boiler.
11. If the burner/boiler will not operate, follow the instructions “TO TURN OFF GAS TO THE
BURNER” below and call your service technician or gas supplier.
TO TURN OFF GAS TO THE BURNER
1. Set thermostat(s) to their lowest setting.
2. Turn off all electric power to the burner and boiler if service is to be performed.
3. Turn Gas control knob clockwise to OFF. Do not force.
WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.

Resolute RT Gas – November 2020 5
RECORD OF INSTALLATION
INSTALLER NAME:
INSTALLER ADDRESS:
INSTALLER CITY, STATE:
DATE INSTALLED:
NOTES:
SCOPE
This manual covers the Energy Kinetics Resolute RT gas boiler. The boiler is designed and equipped and has been
tested to generate hot water in a low pressure closed loop system. The boiler is a major component of a closed loop
system that can be used as a heat source for hydronic, radiant, domestic hot water, spa, and/or pool heating systems.
Call Energy Kinetics to obtain piping and wiring instructions for applications, such as hydronic heating, radiant heating,
domestic hot water, swimming pool heating, multiple boilers, injection loops, etc. The installer of the system is
responsible for the final design of the system and for adding the balance of the needed parts to complete the system.
COMMONWEALTH OF MASSACHUSETTS
When the boiler is installed within the Commonwealth of Massachusetts:
•This product must be installed by a licensed plumber or gas fitter where required by law
•If antifreeze is used, a reduced pressure backflow preventer device shall be used
INSTALLER NOTE:
ALL INSTALLATIONS MUST BE MADE IN ACCORDANCE WITH ALL NATIONAL, STATE AND LOCAL,
PLUMBING, HEATING AND ELECTRICAL CODES THAT MAY DIFFER FROM THIS MANUAL AND IN
ACCORDANCE WITH THE FOLLOWING CODES, AS APPLICABLE:
N.F.P.A. No. 70: National Electrical Code
Canadian Electrical Code Part I, CSA 22.1
A.N.S.I. / N.F.P.A. No. 211: Chimneys, Fireplaces, Vents and Solid Fuel Burning Appliances
A.N.S.I. Z223.1/ N.F.P.A. No. 54: National Fuel Gas Code
Where required by the authority having jurisdiction, the installation must conform to the Standard for:
ANSI/ASME CSD-1 Controls and Safety Devices for Automatically Fired Boilers
These codes are available from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02269-9101.
A hot water boiler installed above radiation level or as required by the Authority having jurisdiction, must be
provided with a low water cutoff device.
A boiler should be installed in such a manner that, if the pressure vessel or any connection thereto should leak,
the resulting flow of water will not cause damage to the area in which it is installed.
A hot water storage tank should be installed in such a manner that, if the storage tank or any connection thereto
should leak, the resulting flow of water will not cause damage to the area in which it is installed.
A boiler’s pressure relief valve, hot water storage tank T&P relief valve, backflow preventer, and all other
devices must be piped to the nearest drain to avoid damage in the event the valve is actuated.
Make sure relief discharge pipes from all reliefs are properly placed to safely contain discharge. Make sure
relief discharge pipes, such as from a boiler or a hot water storage tank, will safely contain hot water and/or
boiling water. Make sure relief discharge pipes, such as from a boiler or a radiant heating system, will safely
contain water treated with boiler chemicals and/or antifreeze. Reliefs include the boiler pressure relief valve, the
back flow preventer discharge port, and the domestic hot water tank temperature and pressure relief valve. Any
other reliefs, such as from radiant heating systems, must also follow these guidelines.

Resolute RT Gas – November 2020 6
TABLE OF CONTENTS
OWNER AND INSTALLATION MANUAL .............................................................................................................................1
GAS HEAT EDITION..............................................................................................................................................................1
RECORD OF INSTALLATION...............................................................................................................................................5
SCOPE....................................................................................................................................................................................5
RESOLUTE RT BOILER........................................................................................................................................................7
RECEIVING and UNPACKING..............................................................................................................................................8
LOCATION and CLEARANCE ..............................................................................................................................................8
SMART VENT SYSTEM.........................................................................................................................................................9
GAS BURNER MOUNTING .................................................................................................................................................10
GAS BURNER SETTINGS...................................................................................................................................................10
GAS PIPING SYSTEMS.......................................................................................................................................................10
GENERAL ASSEMBLY........................................................................................................................................................12
BOILER MOUNTING............................................................................................................................................................12
PIPING..................................................................................................................................................................................12
ZONE CONTROL .................................................................................................................................................................14
FILLING WITH WATER, VENTING, and PURGING ...........................................................................................................14
BOILER WATER TREATMENT...........................................................................................................................................14
ANTI-FREEZE.......................................................................................................................................................................14
WINTERIZING.......................................................................................................................................................................15
LINE VOLTAGE WIRING DIAGRAMS ...............................................................................................................................15
Five Zone Display Manager................................................................................................................................................17
EXPANDED ENERGY MANAGER ......................................................................................................................................19
15 ZONE MANAGER INSTALLATION INSTRUCTIONS....................................................................................................19
HYDRONIC CONTROL SETTINGS.....................................................................................................................................20
PREPARE FOR START UP.................................................................................................................................................20
START UP PROCEDURE....................................................................................................................................................20
The AIR-FREE METHOD of MEASURING CO...................................................................................................................21
GAS BURNER OPERATION................................................................................................................................................22
ENERGY MANAGER OPERATION.....................................................................................................................................23
ENERGY MANAGER CHECK..............................................................................................................................................24
2-MINUTE ENERGY MANAGER DIAGNOSTIC..................................................................................................................24
ADDITIONAL NANAGER TESTS........................................................................................................................................25
DISPLAY MANAGER RETURN SENSOR (THERMISTOR) TESTING...............................................................................26
LINE VOLTAGE RELAYS....................................................................................................................................................26
LINE VOLTAGE....................................................................................................................................................................26
SURGE SUPPRESSION ......................................................................................................................................................26
TROUBLESHOOTING with the ENERGY MANAGER.......................................................................................................27
OPERATION WITHOUT the ENERGY MANAGER.............................................................................................................28
EMERGENCY HEAT WITHOUT ENERGY MANAGER or RELAY BOARD......................................................................29
TROUBLESHOOTING THE SAFETY PRESSURE SWITCHES.........................................................................................30
ANNUAL TUNE UP & INSPECTION ...................................................................................................................................31
AMULET REPLACEMENT...................................................................................................................................................33
COMBUSTION CHAMBER REPLACEMENT......................................................................................................................33

Resolute RT Gas – November 2020 7
RESOLUTE RT BOILER
IMPORTANT MESSAGE TO HOMEOWNER/USER:These instructions should be carefully read and kept for future
reference to gain the best performance from your Resolute RT boiler.
CONGRATULATIONS ON YOUR PURCHASE OF THE RESOLUTE RT BOILER with its highly efficient low mass
hydronic heat exchanger, the Energy Converter. It is the product of years of engineering and advanced design, which
brings together in a single system all elements needed to provide efficient home heat and hot water. This operation and
maintenance information has been prepared so that you may better understand and use your Energy Kinetics Resolute
RT Boiler and Heating System.
RESOLUTE RT BOILER - PRINCIPLE OF OPERATION
Resolute RT comprises a heat source, the energy converter, circulating water, and five (or more) zones controlled by
an electronic control, the Energy Manager.
The boiler sits cold until a thermostat calls for heat. The Energy Manager receives the call for heat and turns on the
main circulator and burner. Water circulates within the boiler as it warms up to operating temperature. When ready, the
zone valves open and deliver heat to the zones calling for heat. When the thermostats are satisfied, the Energy Manager
turns off the burner and enters the energy recovery stage. The circulator and zone valve stay energized to deliver the
heat remaining in the boiler to your home or to the domestic hot water storage tank.
When energy recovery is complete and the boiler has been cooled off, the Energy Manager turns off the system and
waits for another thermostat (or tank aquastat) to call for heat. Resolute RT runs the burner only when you need heat
and delivers that heat only where you need heat.
The Energy Converter is the product of advanced thermal engineering. It is designed with two separate
passageways, nearly 15 feet long, coiled around each other. Water travels along one passageway from your home
toward the center of the unit and heated gases travel from the unit center toward the chimney. This is a “forced circulation
counter-flow” design and it provides very efficient transfer of heat from the burning fuel to the circulating water. The
superior insulation of the boiler minimizes heat losses to the surroundings, resulting in directing heat to your home in an
efficient and quiet manner.
Resolute RT has an extremely high annual efficiency (over 95% of steady state) because it runs only when your
home or hot water storage tank needs heat. Energy recovery is completed at the end of each heat call, virtually
eliminating off cycle losses.
Your Resolute RT holds a minimal quantity of water so it begins to supply heat in about 2 minutes. This rapid
response means that your rooms can be heated quickly when cold. The Resolute RT can also provide heating of
domestic water just as quickly.
A modern retention head gas burner fires into the center of Resolute RT where a high temperature, light weight
stainless steel chamber provides ideal conditions for “near perfect” efficient, pollution-free combustion. Your Resolute RT
is tightly sealed so all products of combustion pass only to the Smart Vent system.
The Resolute RT boiler is designed with a hinged front cover that allows access to the inside of the boiler for
inspection and cleaning. All access for service is from the front, so the Resolute RT boiler can be placed against a wall or
into a closet.
ENERGY MANAGER - PRINCIPLE OF OPERATION
The left side of the Manager is the input side, which provides 24-volt power supply and connections for thermostats.
The right side is the output side, which starts the burner, circulator, zone valves or zone circulators and the domestic hot
water circulator. See photo of the Manager on the cover.
Lights on the Energy Manager indicate what is calling for heat (left side) and (right side) lights indicate active zone(s),
burner operation and circulator operation. These function lights are an aid in servicing. The following is a typical cycle.
1. SYSTEM WAITING FOR A CALL: The boiler is turned off and sits cold, waiting until a call for heat. The red power
light on the Manager is glowing.
2. CALL FOR HEAT: A room thermostat call starts the cycle. The thermostat light on the left side will turn on for that
zone.
3. PRE-HEAT: Output lights for the main circulator and burner turn on, the circulator starts, and the burner begins firing.
The boiler water circulates through the energy converter via the bypass line, heating up the water.
4. HEAT: Once the boiler water has heated to 140°F (about 90 seconds), the Manager will turn on the zone output light
on the right side. The zone valve will open and hot water will flow to the zone needing heat. The burner runs as long
as there is a thermostat calling and as long as heat is being delivered to the zone. The burner may shut off if the
return temperature exceeds 170°F/190°F (RED burner light turns off) or if the high limit temperature is exceeded
(RED burner light stays on, but the high limit aquastat shuts the burner off).
5. ANOTHER CALL FOR HEAT: If another zone calls for heat while the burner is already running and the return
temperature is above 140°F, the zone output will turn on, immediately supplying heat to the zone.

Resolute RT Gas – November 2020 8
TIP:
6. MONITOR RETURN TEMPERATURE: The Energy Manager continually senses the return temperature and will turn
off the zone outputs if the return temperature drops below 120oF (130o F if Option Switch #1 is ON). With the zone
outputs closed, the boiler water will quickly reheat and once the return temperature reaches 140oF (150o F if Option
Switch #1 is ON), then the Energy Manager will reopen the zone valves.
7. THERMOSTAT SATISFIED: The thermostat light on the left side will go out. The burner light and the burner will then
turn off.
8. ENERGY RECOVERY: The circulator and zone valve remain energized. The circulating water will remove the energy
from the converter, sending the heat to the last zone that called. The energy recovery stage continues until the return
temperature has dropped sufficiently or until maximum timing has been reached. The boiler is now sitting cold,
waiting for the next call for heat. Maximum timing for heat recovery stage is usually set at twenty minutes for space
heating zones and is fixed at five minutes for the Hot Water zone. (See Energy Manager Option Switch Settings).
RECEIVING and UNPACKING
Inspect shipment upon receipt for external damage. When
unpacking and uncrating, inspect each item for internal
damage. Any damage found should immediately be
reported to the freight carrier before installation. The
receiver is responsible for following the claims procedure of
the freight carrier. The freight carrier is responsible for taking prompt action
on all claims. If freight cannot be inspected at the time of delivery, sign the
bill of lading “Subject to Inspection” and inspect the shipment as soon as
possible after receipt. Replacements for parts damaged in shipment are
available upon receipt of a signed copy of a claim report (concealed damage
claims should be filed immediately against the freight carrier by the
consignee).
After unpacking, check each item against the packing list. Inspect it
thoroughly for loose parts, instruction sheets and packing lists. Immediately
report any missing items. It is wise to complete the installation before
discarding packing material. Store all parts where they will not be damaged
or lost during installation.
LOCATION and CLEARANCE
DANGER:Provide clearance to combustible surfaces in accordance with
all local and national codes. Follow National Fire Protection
Association Bulletin NFPA Installation of Oil Burning Equipment and all applicable codes.
* Minimum recommended clearance to allow door to fully open.
Installation Clearances from Boiler
Surfaces, Inches
Clearance to
Combustibles
Recommended
Clearance for Service
Front of boiler*
10”
20”
Left side of boiler body
0”
5”
Right side of boiler body
0”
12”
Back of boiler body
4”
4”
Top of boiler body
10”
16”
Bottom of boiler legs to floor
0”
0”
Polypropylene Venting (230° Max)
0”
0”
Boiler Weight and Water Content
Weight
405 lbs
Water Content
3 gallons
Air Inlet Pipe Size
3" PVC
Boiler Flue Outlet
3" Polypropylene
Flue: 3" Polypropylene
0" Clearance to Combustables
3" PVC Air Inlet
51
2"
2"
131
4"
21
4"

Resolute RT Gas – November 2020 9
Resolute RT boilers come with a stand mounted at the factory which provides a convenient, solid, level and smooth
foundation for the boiler. Place the unit as near to the venting location as possible allowing clearance for front cleaning
and service as shown in Figure 1B
NOTICE: The stand must be level to slightly higher at the back, to allow for proper venting of air from the boiler.
SMART VENT SYSTEM
The Smart Vent with Dilution Air System is a complete vent system that has been specifically designed for use with
Energy Kinetics’ Resolute RT boiler. It uses a Dilution Air Exhaust Fan (inducer) and requires outside air for combustion
air. Each part of this system works together and must be installed properly to work correctly.
Starting with combustion air, outside air must be piped directly to the factory supplied PVC air inlet tee. The PVC
branch on the inlet tee is connected to the sealed air box and provides combustion air using PVC pipe and elbows
supplied.
The Dilution Air Exhaust Fan (inducer) assembly is factory mounted directly on the boiler breech. The boiler pressure
vessel is maintained at negative pressure by the forced draft fan. A fan proving safety switch is wired in series with the
puff switch and blocked inlet switch to the ‘BV’ terminals on the primary control. A safety recycle or lockout occurs on the
primary control if ‘BV’ is interrupted if operation of the forced draft fan is not proven. The system requires no draft
adjustment when installed as recommended and is designed for use without any draft damper.
Combustion air is piped from the branch of the dilution air tee to the PVC male adapter on the sealed air box frame.
Piping of outside air directly to the boiler is required to ensure that adequate fresh air is available for combustion and
proper dilution of flue gasses. It completely isolates the boiler from the home environment, as well as greatly reducing
operating noise from the boiler. A blocked air intake safety switch is wired in series with the standard Resolute RT
blocked vent switch and fan prover. Burner operation will be prevented if the air inlet is blocked or if the boiler flue
passage is blocked.
The Smart Vent system for the Resolute RT boiler must be installed according to the Smart Vent with Dilution Air
installation manual.
Figure 1B - Boiler Clearance for Cleaning and Service
Burner
Dim “A”
W/O Silent Burner
Cover
With Silent Burner
Cover
Carlin EZ-
Gas 14-1/2” 15-1/4”
20"
48"
49-1/2" 30-1/2"
"A"
Level bottom of stand,
or slightly higher in back

Resolute RT Gas – November 2020 10
WARNING: Ensure that all gear clamps on the Dilution Air adapter are tightened. After installation pull upwards on the
vent to confirm a good mechanical connection. Failure to properly tighten all gear clamps can result in a failure of the
venting system.
WARNING: Sidewall venting and combustion air piping from outside the building is required. The Energy
Kinetics Smart Vent kit contains specific instructions for installation that must be followed. For length of run for intake air
and for the vent connection, refer to the Smart Vent with Dilution Air installation manual. Combustion air may be supplied
through PVC pipe. A Tek-screw joint allows the door to swing down when the air inlet pipe is disconnected.
GAS BURNER MOUNTING
Resolute RT boilers are shipped from the factory with the gas burner mounted. The burner flanges are designed to
insert the burner head 2-3/8” into the boiler. Energy Kinetics installs a ceramic sleeve, the amulet, to protect the burner
head from the heat of combustion, and then seals the air tube flange joint with a high-grade retort cement.
NOTICE: Gas burners for field installation or for field replacement should be installed according to burner manufacturer
instructions, according to installation instructions below, and with consultation from Energy Kinetics for any special
considerations or adjustments.
Follow these instructions for field installation or replacement of Energy Kinetics supplied burners. Start by checking
electrode and flame sense rod position per manufacturer’s specifications prior to assembly to unit. Test fit the amulet by
inserting the amulet into the boiler opening. If the amulet doesn't easily slide into the boiler, then gently sand the outside
diameter of the amulet until it will fit into the boiler opening. Test fit the amulet onto the burner head. The amulet for the
Carlin burners has a smooth interior. If the amulet is a tight fit on the burner head, then slightly moisten inside the amulet
with water.
Place a 3/8" bead of retort cement onto the burner head at the flange to air tube joint, and slide the (moistened)
amulet over the burner head and against the flange. Ensure proper seating of the amulet by pressing the amulet onto the
burner with a flat object. Leave the excess retort cement at the amulet to flange joint and the cement will provide an
airtight seal of the air tube flange to the boiler face.
The Carlin amulet does not have an edge and when fully seated the amulet will be flush with the front of the Carlin
burner head. If needed, trim the front edge of the amulet to be flush with the front of the burner head.
Once the amulet has been seated and trimmed, then install the burner into the boiler by carefully inserting the air tube
with amulet into the boiler opening while aligning the burner flange holes with the boiler studs. Install flat washers and
nuts onto the boiler studs and tighten all nuts evenly.
GAS BURNER SETTINGS
Resolute RT gas boilers are shipped from the factory preset for 100,000 Btu/Hr firing rate.The following table lists
approximate settings for Carlin EZ-Gas burners based on extensive testing.
CAUTION: Final settings for a particular installation must be determined by using combustion test equipment and
following the instructions given under "Start Up Procedure".
Input
Btu/Hr
Burner Orifice
Drill size Approximate air
band setting UTL - air tube insertion length
Diffuser
Natural Gas Propane Gas 1 Slot inches
100,000*
#1 (0.228)
#16 (0.177)
15
2-3/8”
B
120,000
C (0.242)
#13 (0.189)
20
2-3/8"
B
150,000
J (0.277)
7/32 (0.219)
35
2-3/8"
B
*Default Factory Setting
GAS PIPING SYSTEMS
The boiler and its individual shutoff valve must be disconnected from the gas supply piping system during any
pressure testing of the gas supply piping system at test pressures in excess of 1/2 psi (3.5 kPa, 14 in wc).
The boiler must be isolated from the gas supply piping system by closing its individual manual shutoff valve during
any pressure testing of the gas piping system at test pressures equal to or less than 1/2 psi (3.5 kPa, 14 in wc).
A manual shut off valve and a sediment trap must be provided in the gas piping upstream of the electric combination
gas valve at the boiler. The boiler and its gas connection must be tested for gas leakage before placing the boiler in
operation.
Gas piping must be properly sized in accordance with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or
according to state and local codes as applicable. Gas piping must be sized to provide the maximum firing rate gas flow

Resolute RT Gas – November 2020 11
for all appliances in the building. For Natural Gas installations, be sure to verify that the gas meter is properly sized for all
appliances. Do not use any service 90oelbows. Use only full port shutoff valves. If in doubt, oversize the piping.
BEST PRACTICE: Always size piping based on natural gas pipe size guidelines.
The following tables provide suggested sizing for Black Iron Pipe. Be sure to add the appropriate equivalent length for
every fitting and elbow used. For other types of pipe or tubing, consult NFPA 54 or the manufacturer of the pipe or tubing
or your gas supplier for pipe sizing information.
For LPG, drawing up to 150,000 Btu/Hr (60 Cubic Feet per Hour)
For Natural Gas, drawing up to 150,000 Btu/Hr (140 Cubic Feet per Hour)
Natural Gas
LPG Gas
Iron Pipe Size
Maximum
Equivalent Length
Iron Pipe Size
Maximum
Equivalent Length
3/4 inches
30 feet
3/4 inches
90 feet
1 inch
100 feet
1 inch
200 feet
1-1/4 inches
200 feet
1-1/4 inches
200 feet

Resolute RT Gas – November 2020 12
GENERAL ASSEMBLY
Assembly of various packaged units is illustrated throughout this manual. The use of non-Energy Kinetics supplied
pump, controls and accessories should follow good practices. The diagrams and locations presented in the manual are
recommended.
BOILER MOUNTING
PIPING SO THE DOOR CAN OPEN: To avoid conflicts with the door opening, piping should be in accordance
with FIG. 2 or dimension D in Fig. 1B. The door opens and drops down to the front of the boiler. The burner and air box
also need clearance when the door opens. Do not locate any piping in front of the boiler unless clearance from the door is
verified. This also applies to the oil line piping and the combustion air piping. NOTICE: Air inlet pipe must be
disconnected to allow door to swing down.
BOILER MOUNTING on BASE, FIG. 2: The boiler comes on a factory mounted base.
BOILER PITCH: The Resolute pressure vessel is manufactured level with the base. Install the boiler so it is level to
slightly higher at the rear.
Figure 2
Relief Valve
System Circ
T&P Gauge
Air Vent
Supply
Return
Zone Valves Return Manifold
Junction Box
Return Ball & Purge Valve
Premier Option: Combo Auto
Feed/Backflow Preventer
Combustion Air Inlet
Flue Box Test Port
Over Fire Test Port
Bocked Vent (Puff) Switch
Optional Trim Kit:
#30 Expansion Tank
Oil Filter Kit
Premier Option:
4 Port Header Kit
3 Zone Zalves (2 Wire)
Return Ball Valve and Purge
Along with Required Nipples & Fittings
Oil Filter Kit

Resolute RT Gas – November 2020 13
PIPING
Figure 2C indicates a typical flow schematic for boiler water feeding multiple zones. Each system will vary according to
job location.
Supply and return connections are 1”NPT on the Resolute RT.
Call Energy Kinetics to obtain piping and wiring instructions for alternate applications, such as hydronic heating, radiant
heating, domestic hot water, swimming pool heating, multiple boilers, injection loops, etc.
Figures 2C and 2D indicate general system piping arrangement and options. Piping of individual systems may vary from
figures.
Some site specific heating zone piping configurations may allow heat migration, in which case a flow check(s) may be
installed to prevent the gravity flow of heat.
Figure 2C
Zoning with Zone Valves
Use Energy Kinetics
Smart Thread Sealant
P/N 10-0620
Supply
Return
Return Supply
Boiler Feed
Energy Converter
Factory piping shown within dashed line
Supply
Digital Sensor
Boiler Bypass
Typical Flow Schematic

Resolute RT Gas – November 2020 14
ZONE CONTROL
ZONE CONTROL BY VALVE: The Resolute RT boiler is designed to provide multi-zone control of the heating system
and optionally can supply domestic hot water. Energy Kinetics recommends and supplies two wire, full port, 24-volt zone
valves for control of each heating zone. A system with a single heating zone still requires a zone valve to provide control
for preheat of unit and to maintain minimum temperature during operation.
ZONE CONTROL BY CIRCULATOR:
Zone control by circulators requires a
flow valve, circulator and 24-volt relay
(EK# 10-0412-RIB or equivalent) for
each zone. The main circulator and
boiler bypass line are still used in these
cases.
NOTICE: An additional tee must be
installed into the supply on the inlet
side of the main circulator. This tee is
the supply for circulators with returns
for these zones into normal return
location. Call Energy Kinetics and
request “Zoning with Circulators”
diagram.
ZONE PURGING: Valves to isolate
and purge individual zones should be
installed according to good piping
practices.
EXPANSION TANK SIZING: The type and size of expansion tank depends on the total system water volume. The
Resolute RT contains 3 gallons of water. NOTICE: Sizing must consider cold start and hot operation due to system
concepts of energy recovery and rapid heat up.
BOILER BYPASS LINE AND VALVE
NOTICE: Systems are piped at the factory with the boiler bypass line and bypass ball valve. The bypass
valve must be at least partially open for the boiler to operate properly.
FILLING WITH WATER, VENTING, and PURGING
When piping is completed and all accessories installed the Converter and piping should be filled with water. The
Converter purges itself of air when properly installed. NOTICE: AIR VENT CAP MUST REMAIN OPEN.Vent cap
should be removed and kept in a safe location. Each zone should be purged until a steady stream of water without air
passes out of purge hose. Vent all radiation.
NOTICE: DO NOT START BURNER UNTIL CONVERTER AND SYSTEM ARE FULL OF WATER.Fill to normal
cold system pressure, 10 to 12 psi on pressure gauge. Before placing system in operation, carefully check for leaks
throughout system. Tighten pipe joints, circulator flanges; check gaskets, etc., as needed.
BOILER WATER TREATMENT
Addition of boiler water treatment is recommended to reduce lime buildup inside the boiler. Energy Kinetics
recommends addition of one quart of 8-Way Boiler Treatment per 30 gallons system water. 8-Way Boiler Treatment is
recommended to treat water up to medium hardness. Call Energy Kinetics for more details about boiler water treatment
and about hard water conditions.
ANTI-FREEZE
Only non-toxic antifreeze (such as Propylene Glycol) should be used if adding anti-freeze to a system that produces
domestic hot water. Hard water should not be used in combination with generic antifreeze. Energy Kinetics supplies a
quality inhibited Propylene Glycol anti-freeze with orange dye and an antifoam agent. 8-Way Boiler Treatment can be
added to Energy Kinetics anti-freeze and is recommended in areas of medium water hardness. NOTICE: Thoroughly
clean system prior to adding antifreeze. TSP is recommended for removing flux and other oil based compounds.
Once system has been cleaned and flushed, then add antifreeze to obtain approximately a 30% by volume mixture of
antifreeze in water. Call Energy Kinetics for assistance in calculating how much anti-freeze to add to system.
System Manager
TEMP. SENS.
R
S
B
A2
A1
B2
CIRC
B1
24VAC
IND
T3
T1
T2
THW
T4
Z1
Z2
Z3
Z4
ZHW
Ground
Neutral Line
120 VAC
Circulators w/Flow Checks
(Supply Side Preferred*)
*Circulator may be Installed
Return Side
Remove 1" NPT Plug From Branch in Tee
Located in Supply Pipping Ahead of System Circ
And Pipe all Zone Circs From Tee Branch

Resolute RT Gas – November 2020 15
WINTERIZING
NOTICE: If the Resolute RT boiler may be exposed to freezing temperatures, such as a vacation home shut down for
the winter, then anti-freeze should be added. When a home is winterized by draining all domestic water piping, then the
Resolute RT boiler must be protected. It is not recommended to drain the boiler, because introducing air into the boiler
can cause rusting inside the boiler shell and also because the Energy Converter has a spiral water passage that cannot
be completely drained of water. When draining the domestic water piping system, be sure to drain the domestic side of
the plate heat exchanger. If the hydronic system will not be drained, then add enough anti-freeze to protect the entire
hydronic system including the boiler, piping, radiation, circulators, etc. If the hydronic system will be drained, then add
shut off valves to isolate the boiler and add anti-freeze to the boiler only, as follows. Drain water from the boiler and then
add anti-freeze to the boiler. Refill boiler with water and run boiler circulator through the bypass to distribute antifreeze
within boiler. Propylene Glycol in water will provide the following freeze protection: 30% down to +8°F, 40% to -8°F, 50%
to -27°F. Energy Kinetics recommends using 30% anti-freeze to obtain the best boiler performance. Use over 30% anti-
freeze only if lower temperature freeze protection is mandatory.
Caution: Always keep the fuel supply valve shutoff if the burner is shut down for an extended period of time.
LINE VOLTAGE WIRING DIAGRAMS
WIRING and CONTROLS
The Resolute RT Heating System is furnished with controls and basic accessories as illustrated and described in this
manual. Control, burner and accessory instruction sheets and system wiring diagrams should be attached to this manual
for future reference.
DANGER: All wiring for installations in the United States must comply with the NEC, and any local codes. All wiring for
installations in Canada must be done in accordance with the Canadian Electrical Code, Part I.
TRANSFORMER
POWER LEADS
WHITE
WHITE
BLACK
GREEN
SWITCH
SYSTEM
#14 GREEN
WHITE
#14 BLACK
HOT
NEUTRAL
GROUND
BLACK
BLACK
TOBURNER
DOOR SWITCH
BLACK
WHITE
RED
ORANGE
BLACK
GREEN
BLUE
120 VAC POWER IN
BLACK
BLACK
MAIN CIRC
DOMESTIC HOT
WATER CIRC
L1 L2 LWCO LIMIT
WHITE
RED
BLACK
BLUE
WHITE
BLACK
DUALGARD CONTROL
LWCO/LIMIT
RED
YELLOW
YELLOW
-24 V
-B2
-B1
-IND
-ZHW
-CIRC
(GRN)
(BLU)
(WHT)
(RED)
(ORG)
DIGITALMANAGER
RIGHTSIDE
GROUND
SCREW
#14 WHITE
BLACK
WHITE
AUX IND HW
24
VAC
CIRC
24V
AUX IND
HW
CIRC
MAI N
CIRC
120V
XF MR P WR
GND
BURN
AUX IND HW CIRC
BURN/M AIN CIRC
1
2
0
V
N
E
U
T
R
A
L
-B1
(BLK)
INDUCER FAN POWER
RED
TT
Limit(HOT)
Valve on Primary
Valve Transformer
L2NEUTRAL
L1 POWER (HOT)
Transformer
50 VA
Line
Voltage
A1 24 V A2
L1 DualGard L2
W
R/W BK
Black
(Hot) (Neutral)
White
System
Emergency
Switch
NO. Relay
Ind/Aux
Inducer
Domestic
HW Circ
NO. Relay
HW Circ
NO. Relay
Burner &
MainCirc
MainCirc
Burner Door
Switch
Green
(GND)
Dual Limit
Aquastat &
LWCO
(Integr atedin
DualGar d)
Igniter
GN
M
OR
Y
W
CarlinAir
Prover Gas
Valve
V
Y
Stack Limit
OR
Burner Motor
Blocked Intake
Air Interlock
Fan Prover
Interlock
24 V
Transformer
USE COPPER CONDUCTORS ONLY
FIELD WIRING
LabelPartNumber:09-0456
BL
Blocked Vent
(Puff Switch)
BB BV
TT
RED/ WHITE
R
ORANGE
ORANGE

Resolute RT Gas – November 2020 16
ELECTRICAL CONNECTION - LINE VOLTAGE
POWER SUPPLY: 120 VOLT 60 HZ, 7.5 Amperes
Resolute RT requires 120 VAC. The supply voltage must be within 108 VAC min / 132 VAC max for reliable operation
of the boiler and the Manager. An easy way to check the supply voltage is to plug a voltmeter in at the service outlet
located on the side of the system junction box.
DANGER: Make All Connections with Power Off at Main Circuit Box
Figure 3A: Connect power from a separate 15 AMP fused circuit. Install 3rd wire grounding for proper bond between all
electrical accessories. The system switch is included so power can be shut off at the unit for servicing.
Pigtails are provided for the line voltage power connection. Connect black pigtail to hot, white pigtail to neutral, and the
green pigtail to ground.
WARNING: The junction box is wired at the factory with the service outlet always powered, even with the System
Emergency Switch turned off. To have the service outlet controlled by the System Emergency Switch, move the service
outlet black lead to top lug of system switch. A low water cut-off may be field installed if required by local codes and is
available from Energy Kinetics.
LOW VOLTAGE WIRING
ENERGY MANAGER OPERATES ONLY ON 24 VOLTS 60 HZ POWER
WARNING: Make All Connections with Power Off at Main Circuit Box
A typical low voltage wiring diagram for the Energy Manager is shown in Figure 4A. Thermostats must be
located on inside walls away from cold drafts, windows or heat from fireplaces, appliances or sunlight. Set thermostat
heat anticipators to 0.1 amps or Hydronic option. Call Energy Kinetics to request alternate low voltage wiring diagrams to
handle special situations such as air handler wiring, heat pump wiring, isolation relays for thermostats, and isolation relays
for heat motor style zone valves or circulators, etc.
The single 24-volt/50VA transformer is suitable for the Energy Manager and five zone outputs (zone valves or
relays). NOTICE: Additional load such as extra valves may require greater transformer capacity. To add transformers,
wire in parallel as follows: wire terminal “A” on one transformer to “A” on the other. Repeat with other low voltage terminal
“B”. Be sure to verify 24VAC output from all transformers.
The Energy Manager is designed to heat domestic water and up to four (4) heating zones. Use Energy Kinetics
supplied zone valves with two wire connections. For more than four heating zones, use Energy Kinetics expanded 10 or
15 zone Energy Manager, or call Energy Kinetics for alternatives.
LOW VOLTAGE WIRING DIAGRAM
INSTALL ENERGY MANAGER
The Energy Manager is shipped in its own protective shipping box. NOTICE: The option switches can be set very
easily before the Manager is installed. Locate the pre-wired quick connectors fastened to the front of the junction box by
two cable ties. Cut the two cable ties and discard. Fasten the Energy Manager to the junction box with the four corner
screws. Slide the two quick connectors onto the Energy Manager. Label each zone on the manager, using the adhesive
labels supplied.
TEMP. SENS.
RED
WHITE
R
S
BLACK
B
A2
A1
B2
CIRC
B1
MAIN CIRC RELAY
24VAC
IND
ZONE 2
ZONE 1
HOT WATER TANK
ZONE 1
ZONE 2
ZONE 4
LOAD
AB
Thermistor or
Digital Sensor
(Located in Boiler
Return Piping)
T3
T1
T2
THW
T4
Z1
Z2
Z3
Z4
ZHW
HOT WATER CIRC RELAY
ZONE 3
or ADDITIONAL ZONE
ZONE 3
ZONE 4
Transformer
24VAC 50VA
T2
T4
A2
S
TEMP. SENS.
R
B
A1
T3
THW
T1
Tx*
CR W
T2
T4
A2
S
TEMP. SENS.
R
B
A1
T3
THW
T1
Tx*
Resistor between
A2 and Tx
POWER STEALING OR WIFI THERMOSTATS THAT
REQUIRE A COMMON
CONNECT THE COMMON OR C TERMINAL ON THE
THERMOSTAT TO THE A2 TERMINAL ON THE
MANAGER
*Tx CAN BE T1, T2, T3, T4 OR EVEN THW IF USED AS A
HEATING ZONE
POWER STEALING THERMOSTAT
USING 2 WIRES
USING 15 WATT 200 OHM RESISTOR
(OR ISOLATE FROM MANAGER WITH A RELAY)
*Tx CAN BE T1, T2, T3, T4 OR EVEN THW IF
USED AS A HEATING ZONE
RW
FIELD WIRING
FACTORY WIRING
*Field Wiring terminated to input terminal A1 and to output terminal 24VAC are to
be wired into the open lugs provided at those locations.
NOTE: ALL ENERGY DISPLAY MANAGERS (W/LCD DISPLAY} ARE DESIGNED TO WORK WITH NEST THERMOSTATS WIRED DIRECT USING ONLY 2 WIRES
Injection Zone
Valve
ZONE 3
Loop Circ Relay
Connected to Z11
ZONE 4
N
L1
WHEN SECONDARY ZONES ARE ENABLED
(PRIMARY/SECONDARY PIPING)
ZONE 3 BECOME THE INJECTION ZONE
ZONE 4 BECOMES THE LOOP CIRC
STACK LIMIT
T
T
TO BURNER
RELAY
Figure 4A

Resolute RT Gas – November 2020 17
Five Zone Display Manager
The Display Manager is an Energy Manager that is equipped with an LCD display, and four pushbutton keys.
With the exception of the Fuel Type (oil/gas) and Venting (chimney/inducer) options, all setup options are selected
through option screens via the display and keys. The Fuel Type and Venting options can be viewed, but not set, in the
option screens. These two options can only be set using the physical option switches on the bottom of the Display
Manager board.
•To access the option screens, you must first ensure the manager is powered; if the manager is powered, the blue
“PWR” LED will be on. If the blue LED is on, but the screen is not illuminated, press any key to wake the display.
•Use the UP/DOWN keys to view additional menu screens. Use the ENTER/ESC keys to enter/exit submenus. The
ENTER key is also used to change options from the option screens.
How to Use Self-Guided On-Screen Prompts To Edit Options
From the system status screen, press the DOWN key twice, or until the
Option Setup (edit) menu screen is displayed. Press the ENTER key to enter into the option screens. From there, use
the UP/DOWN keys to view each option. Use the ENTER key to change the selected option.
Setting features are self-guided through on-screen prompts
Restore Settings
System Info
Restore Settings
Runtime
Software Version
Additional Info
Confirm Reset?
Reset Confirmed!
Fuel Type (view-only)
Venting (view-only)
SmartBoost
Smart Boost Delay
HW Zone
HW Priority
Multipurge
Zone Purge Times
Secondary Zones
Option Setup
System Status
Purge Time Zone 1
...
Purge Time Zone X
Zone turge Time
Secondary Zone 1
...
Secondary Zone X
Secondary Zones
Option Switches

Resolute RT Gas – November 2020 18
Figure 4B
Option Switch Settings
Set option switches for Fuel type: Oil or Gas and Vent type: Chimney or Dilution Air Exhaust Fan (inducer)
Display Manager Option Menu Descriptions
Fuel Type - VIEW-ONLY. Must be set using physical option switch on bottom of Manager Board
This menu can be used to view the setting of physical option switch one, which determines the Fuel Type setting.
Venting - VIEW-ONLY. Must be set using physical option switch on bottom of Manager Board
This menu can be used to view the setting of physical option switch two, which determines the Venting setting.
SmartBoostTM - Default setting is OFF
This option turns the SmartBoost function ON or OFF. While ON, if a zone has been calling for heat for 25 minutes
(optionally 45 minutes), then SmartBoost kicks in to help satisfy that zone sooner by boosting the maximum return
temperature to be 190°F/175°F from the standard 170°F/155°F. The boosted zone will stay at the 190°F/175°F
setting for up to 25 minutes after the call is satisfied.
SmartBoostTM Delay - Default setting is 25 Minutes
This option sets the delay to either 25 minutes or 45 minutes before SmartBoost raises the maximum return
temperature to be 190°F/175°F. This option only impacts boiler operation if SmartBoost is ON.
HW Zone - Default setting is Hot Water
This option will allow the hot water zone to be turned into a heating zone. While this option is set to Heating, the “Hot
Water Zone” will act as a heating zone with 20 minutes of thermal purge. This change will allow the hot water zone to
become a fifth heating zone, for those cases where domestic hot water isn’t required.
HW Priority - Default setting is NO
This option allows the Hot Water Zone to have priority over heating calls for 20 minutes. While this option is set to
YES, the Energy Manager will ignore heating calls to the system for the first 20 minutes of a hot water call. After 20
minutes, or when the hot water call is satisfied, the system will resume providing heat to the rest of the zones.
MultiPurgeTM - Default setting is OFF
This option turns the Multipurge function ON or OFF. While ON, any zones finishing in the prior 20 minute period will
purge with the last zone satisfied. Setting the Purge Time for a given zone to 5 minutes prevents that zone from multi-
purging.
Zone Purge Times - Default setting for each zone is 20 Minutes
This option sets either a 20 minute or 5 minute purge time for heating zones. After all zone calls have been satisfied,
there may still be heat remaining in the boiler. Instead of wasting that remaining heat, the Energy Manager will keep
the last calling zone (or zones, if Multipurge is ON) open to allow the heat to be purged out of the boiler and into the
system. The user is able to choose to let the boiler purge for either 5 minutes or 20 minutes before closing the zone.
Any zone set to 5 minutes will also have Multipurge disabled for that zone. Regardless of the selected option, the
Energy Manager will always end purging and close the zone when the return temperature has dropped sufficiently.
The following types of zones are recommended to have a 5 minute purge time.
•AIR HANDLER / FAN COIL
•VERY SMALL ZONE (like an individual bathroom)
•RADIANT ZONE with STORAGE TANK
Secondary Zones - Default setting for each zone is OFF
This option allows for primary/secondary operation. If any secondary zone is enabled, the manager will assume that
zone 3 controls the injection zone (IZ) and zone 4 controls the loop circulator (LC). Any zone that gets a call while set
as a secondary zone will also activate the IZ and LC, when needed. Thermostats connect to zone 1 (T1) and zone 2
(T2). If the hot water zone is set as a heating zone, the HWZ will also be displayed under the Secondary Zones
options.
INSTALLATION TIPS
•Option Switches “OFF”
Display Managers are shipped with
both dip switches “OFF” (set for an oil
system with a chimney).
•Burner Restart
Thermostat short cycle protection is
25 seconds
•Manager Reset
Shutting the power off momentarily
and then back on again resets the
manager from the short-cycle delay
or an error condition.

Resolute RT Gas – November 2020 19
EXPANDED ENERGY MANAGER
15 ZONE MANAGER INSTALLATION INSTRUCTIONS
1. Remove cover from junction box.
Use a free knockout on the top of the junction box to mount a second or third transformer, wire black lead to “XFMR”
and white lead to “NEUTRAL” on relay board in box. (Use sections marked “120 VOLTS” only.) A second junction
box is not needed for the expanded Energy Manager. Wire additional transformer(s) in parallel with first transformer.
To wire in parallel, wire terminal “A” on one transformer to “A” on the other. Repeat with other low voltage terminal
“B”. Verify 24VAC output from all transformers BEFORE reconnecting the Manager.
2. Mount long panel on top of box cover with long screws provided in lower 4 holes with spacers down.
3. Mount expanded Energy Manager to cover plate over 4 long screws and 2 wide bolts (top 2 holes).
4. Wire the bottom half of expanded manager as 5 zones Energy Manager. For top half, attach one thermostat lead to a
zone and the other to A1 on lower half of manager. Attach one lead from zone valve or relay to corresponding zone
output and the other lead to 24VAC on lower half.
5. Option switches set fuel type (oil or gas) and venting (chimney or power vented).
See Location of Switches: Figure. 4B.
6. NOTE: When using secondary zones with 15-zone manager, zone 13 controls injection zone, and zone 14 controls
loop circulator.
NOTICE: When operating without an expanded manager, use a 5 zone service board for the lower half. If you do not
have a service board, refer to “Operation of Boilers without Energy Manager” in the Tech Manual.
15 Zone Manager
Figure 4C
®
T9
TEMP. SENS.
RED
SILVER
R
S
BLACK
B
A2
A1
T11
T10
B2
CIRC
B1
T
MAIN CIRC RELAY
T
TO BURNER RELAY
24VAC
IND
ZONE 2
Z11
ZONE 1
ZONE 4
ZONE 9
ZONE 11
ZONE 10
T8
T7
T6
T5
THW
T1
T2
T3
Z10
Z9
Z8
Z7
Z6
Z5
Z4
ZHW
Z1
Z2
ZONE 8
ZONE 7
ZONE 6
ZONE 5
ZONE 1
ZONE 2
ZONE 3
ZONE 11
ZONE 10
ZONE 9
ZONE 8
ZONE 7
ZONE 6
ZONE 5
HW CIRC RELAY
ZONE INPUTS
(THERMOSTATS) ZONE OUTPUTS
24VAC
(ZONE VALVES OR
ZONE CIRC RELAYS)
LOAD
AB
LOAD
AB
TRANSFORMER 1
24VAC (50VA)
(FACTORY WIRED)
Handles first five zones.
TRANSFORMER 2
24VAC (50VA)
(FIELD INSTALLED)
Handles up to ten zones.
LOAD
AB
TRANSFORMER 3
24VAC (50VA)
(FIELD INSTALLED)
Handles up to 15 zones
T4
Z3
T12
T13
T14
Z12
Z13
Z14
ZONE 4
HOT WATER TANK
ZONE 12
ZONE 13
ZONE 14
ZONE 3
ZONE 12
ZONE 13
ZONE 14

Resolute RT Gas – November 2020 20
HYDRONIC CONTROL SETTINGS
Configuration Control Model No. Normal Setting
Residential
Boiler
Auto Reset High Limit
Auto Reset LWCO
Manual Reset Lock Out Temp
DualGard Model: 2450-1
Energy Kinetics PN: 10-0596
215o F Auto Reset High Limit
10oF Differential (215o/205oF)*
250oF Manual Reset Fixed Max
Commercial
Boiler
(conforms to CSD-1)
Auto Reset High Limit Aquastat
Manual Reset LWCO
Manual Reset Lock Out Temp DualGard Model: 2450-2
Energy Kinetics PN: 10-0596-M
215o F Auto Reset High Limit
10oF Differential (215o/205oF)*
250oF Manual Reset Fixed Max
Domestic Hot
Water Tank
Tank Aquastat
(On Tank)
Energy Kinetics PN: 10-0414
‘Hot’, pointer points to 6 pm.
(To suit individual installation)
For legacy controls, contact Energy Kinetics
*Factory Setting
PREPARE FOR START UP
DANGER: MAKE CERTAIN THE FOLLOWING REQUIREMENTS HAVE BEEN SATISFIED BEFORE START UP:
1. The boiler and piping are completely filled with water.
2. Re-check wiring to ensure that it is correct and in accordance with appropriate wiring diagrams and codes.
3. Verify that proper gas orifice size is used.
4. Verify electrode and flame sense rod settings.
5. Verify the burner settings for air band position and head position (see "Gas Burner Settings" Table).
6. Gas supply is connected to burner. Gas supply lines and shut-off valves are open.
7. Gas lines are purged.
8. Verify operating gas pressure at inlet of gas valve.
9. Adjust bypass valve on boiler side of heat exchanger to half open (see #4 under “Gas Burner Operation”).
10. Polypropylene flue pipe properly connected from unit to sidewall vent hood or chimney kit. All joints are secured and
sealed with integrated gaskets – all interior connections must utilize lockrings.
11. Combustion air supply is available and sufficient. (See “Combustion Air”)
12. NOTICE: Do not punch a hole in the polypropylene flue pipe.
13. Loosen both of the 1/8” plugs in front door of the boiler, one for use as the overfire sampling location and the other for
the breech sampling location.
START UP PROCEDURE
Turn on system supply switch and burner supply switch. The Display Energy Manager lights should come on briefly,
the circulator relay should close briefly, and then the Display Energy Manager will show a red light next to 'power' and
yellow lights on the left side if any thermostats are calling.
1. If needed, adjust a thermostat to call for heat. Burner and main circulator should come on at the same time. If not,
check primary control and reset it if necessary.
2. Check for burner light off. If gas piping is not well purged, then several starts may be required to clear air from gas
piping.
3. On light off, water temperature and flue gas temperature will start to rise. A slight odor is common on initial light off as
combustion chamber and converter surfaces warm for the first time.
4. NOTICE: Perform carbon monoxide test two minutes after light off. If the carbon monoxide exceeds 400 ppm air-free
after two minutes of operation, shut off boiler immediately and repeat "Prepare for Start Up" checklist. (See “Air-free
method of measuring CO”)
5. Once the boiler heats up and reaches temperature, Display Energy Manager “Heating” light will signal heat
distribution to zone(s) calling for heat.
6. Allow system to run about 15 minutes before testing and recording burner operation. (See "Gas Burner Operation")
