ENERGY SISTEM Wireless Charger Qi User manual

1/8 energysistem.com
ENGLISH
Introduction 3 .....................................................................................................................................................................
Maintenance 3 ....................................................................................................................................................................
Features 3 ...........................................................................................................................................................................
Content 4 .............................................................................................................................................................................
General overview 5 ............................................................................................................................................................
Power management 6 ........................................................................................................................................................
Funcionality 7 .....................................................................................................................................................................
Warranty 7 ...........................................................................................................................................................................
Warranty procedure 7 .......................................................................................................................................................
Declaration of conformity 8 ..............................................................................................................................................

2/8 energysistem.com

3/8 energysistem.com
Introduction
Energy Sistem ™ Thanks you for buying Qi Wireless Charger, we hope you enjoy it.
This wireless charger is compatible with Phone Pro Qi as well as other smartphones ready for Qi wireless
charging. In addition to the charging option, it has a speaker, microphone and bluetooth function which you can
make calls (handsfree) and play audio.
The power transfer from the charger to the smartphone is made by magnetic induction. The charger has a
transmiter power supply and the smartphone has a receiver coil. We recommend you to read this manual to
enjoy your device in a safe way and with maximum performance.
Maintenance
Do not expose your Qi Wireless Charger to impacts, dust, direct sunlight, humidity or high temperatures.
Do not use abrasive or corrosive cleaners.
Keep the device clean and dust free using a soft, dry cloth.
Do not disassemble the device. Any repairs must be carried out by Energy Sistem Soyntec S.A. qualified
personnel only.
Features
Input: AC 100-240V, 50/60Hz.
Output: DC 5V, 1000mA (1A).
Fuse: 0.3A.

4/8 energysistem.com
LED status indicator.
Micro USB connector.
1. Features of the transmitter
Size: 80x80x11.5mm
Otuput nominal voltage: 5V
Operating voltage: 5V
Operating frequency: 110KHz-205KHz
Input current: 1.5A
Output current: 1A
Maximum efficiency (500mA output): >70%
Operating temperature: -15~40ºC
2. Features Bluetooth speaker
Operating voltage: 5V
Operating nominal current: 200mA
Speaker system: one channel
Bluetooth specifications: V3.0+EDR
Output nominal power: 0.5W
Signal to Noise Ratio (SNR) >75dB
Frequency response: 80Hz-15KHz
Distortion (THD): <1%
Transmission distance <10M
Operating temperature: -15~40ºC
Content
Wireless Charger Qi.
Quick guide.
MicroUSB-USB cable.

5/8 energysistem.com
General overview

6/8 energysistem.com
Power on / off Bluetooth1.
Status Led2.
Microphone3.
MicroUSB input4.
Speaker5.
Power management
To use the Wireless Charger Qi, it must be connected previously to a socket, computer or other device via the microUSB
port (4). Inside the product you will find a microUSB-USB cable for the connection. In order to connect it to a socket you
can use the AC/DC adapter included in the Phone Pro Qi or another with similar specifications 5V/1A (not included).
Then, you only need to place your Phone Pro Qi (or other smartphone which addmitts wireless charger) above the
charger. For a correct operation (6), your smartphone should be centered on the charger because the emitter and
receiver coils must be aligned. The transfer of energy will be correct if the LED of the Wireless Charger Qi blinks green.
Do not place metal or magnetic objects between the wireless charger and the smartphone to prevent an inadequate
charge.

7/8 energysistem.com
Funcionality
BLUETOOTH CONNEXION
To activate the bluetooth connection of the Qi Wireless Charger it should be connected to a socket, computer or other
device via microUSB input (4). Inside the packaging you will find a microUSB-USB cable for the connection. Then hold
the on / off switch (1) for 5 seconds until the status LED (2) lights blue and a notification sounds.
After that, you must activate the Bluetooth function on your Phone Pro Qi or another transmitter device, search for the
device whose name is "Qi Charger" and synchronize.
To turn off the bluetooth connection you must keep the on / off switch (1) during 5 seconds. The status LED will leave
lighting.
STATUS LED
The following table shows the meaning of the status LED (2) according to the behavior and color of this one:
Status Status description
Blue light on Bluetooth activated
Insert power and led off Standby
Green light blinking Normal charging
Red light blinking Abnormal charging
Green light on Charging finished
Warranty
Energy Sistem Soyntec SA is liable for any lack of conformity which exists at the time the goods were purchased during
a period of 36 months. Batteries are excluded from the 36-month warranty, having a warranty period of 12 months.
This warranty covers any defects in workmanship or materials. This warranty doesn’t cover any failure of the product
due to accidents, misuse or alteration made by an unauthorized person.
The special 36-months warranty is valid for the European Union. For other countries, please refer to your specific
legislation or your local distributor.
All company, brand and product names are trademarks or registered trademarks of their respective companies.
© 2014 by Energy Sistem Soyntec S.A. All rights reserved.
Warranty procedure
Visit the Support section at http://support.energysistem.com and select your product to view the FAQ (Frequently Asked
Questions), user manuals, drivers and updates available, as the possibility to submit a query to the Technical Service or
consult the warranty.
You can check the availability of the user manual in your language at:
http://www.energysistem.com/en/guide/420551

8/8 energysistem.com
Alternatively, you may prefer to contact the distributor from which you purchased the product, presenting the purchase
receipt or invoice. Specifications are subject to change without notice.
Declaration of conformity
Manufacturer Name: Energy Sistem Soyntec S.A. DATE: 01/11/2014
Address: Pol. Ind. Finestrat - C/.Calpe, 1 - 03509, Finestrat, Alicante (Spain)
Tel: [phone]
Fax: [phone]
NIF: A53107488
We declare under our own exclusive responsibility the conformity of the product:
Energy Sistem™ Wireless Charger Qi
Manufacturing country: China
Is in compliance with the essential norms and standards of the Directive 1999/5/EC of the European Parliament and of
the Council of March 09th 1999.
