ENERMAX MODU82 PLUS II User manual

MODU82+ II Power supply series
MODU82+ II Power supply series
www.enermax.co.uk
425W/525W/625W
erie
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
s
eries
e
r
i
e
s
e
r
i
e
s
e
r
i
e
s
e
e
s
80PLUS® Bronze efficiency
84-88% efficiency at 230V and 20-100% load. 80PLUS® Bronze certified.
Intel ATX12V v2.3
Compliant with the latest desktop power supply design guide. Full support of most current CPU: Intel® Core 2 Duo™/
Quad™/ Extreme™ / i7™ / i5™ / i3™ und AMD® Athlon™ 64X2/X4 oder Phenom™ X3/X4.
Future ready and flexible
All-round modular cable management. 10/12P sockets for possible connector changes of upcoming high-performance
CPU and graphics card generations.
Stable and reliable
Three high performance and massive 12V rails.
New: DXXI ready!
Full support of most current DX11 graphics cards due to 6+2P (8P) connectors.
Full graphics power
Supports SLI™ systems (MODU82+II 525/625W) and CrossFireX™ systems.
New: HeatGuard
Keeping PSU fan running for 30-60 seconds after shut down to dissipate the remaining system heat and prolonging
system lifetime.
SpeedGuard
Patented fuzzy logic 12cm fan speed control for optimal cooling and minimum noise.
AirGuard
Patented air-intake with optimal aero-dynamical design reduces noisy air turbulences.
SafeGuard
Industry-leading octuple protection circuitry of OCP, OVP, AC UVP, DC UVP, OPP, OTP, SCP & SIP.
New: CordGuard
Fixing the AC cord tightly to avoid accidental shutdowns of your PC.
Non-Stop @ 40°C
Non-stop industrial class performance at 40°C/104°F ambient.
EMC ready!
Full-scale electromagnetic filtering protects against radiation interferences (CE EMC EN61204 compliance).
Worldwide compatibility
100-240V AC input with automatic adjustment and up to 99% active Power Factor Correction (PFC) for global usage.
Dimensions (W x H x D) 150 mm x 85 mm x 140 mm.
Warranty
3 years manufacturer warranty.
Features
外框線

www.enermax.co.uk
Cables & Connectors
Specifications
Certifications & Standards
EMD425AWTII EMD525AWTII EMD625AWTII
AC Input Rating
Input Voltage 100-240VAC, 50-60Hz, Active PFC
Input Current 6.7-3A 7.5-3.5A 9.5-4A
DC Output Rating
+3.3V 0.1–20A 120W 0.1–24A 140W 0.1–24A 140W
+5V 0.1–20A 0.1–24A 0.1–24A
+12V1 0.1–22A
396W
(33A)
0.1–25A
480W
(40A)
0.1–25A
600W
(50A)
+12V2 0.5–22A 0.5–25A 0.5–25A
+12V3 0–22A 0–25A 0–25A
-12V 0–0.6A 7.2W 0–0.6A 7.2W 0–0.6A 7.2W
+5Vsb 0–3A 15W 0–3A 15W 0–3A 15W
Total Power 425W 525W 625W
Peak Power 470W 580W 690W
Modular
cable management
82Plus Efficiency
Up to 88% at 230V SpeedGuard SafeGuardAirGuard
PSU Loading
FAN RPM (±10%)
0
25% 50% 75% 100%
500
450 450 450 450 600
800
1000
1500
2000
2500
1200
1500
PSU Loading
20% 50% 100%
PSU Efficiency
%
88
86
84
82
80
230VAC
115VAC
Leading technology for highest efficiency. Patented fuzzy logic 12cm fan speed
control for optimal cooling and minimum
noise.
Patented air-intake with
optimal aero-dynamical design
reduces noisy air turbulences.
Sextuple protection circuitry of OCP, OVP,
UVP, OPP, OTP and SCP.
Native cables Modular cables
Mainboard +12V
CPU
EMC011
3x SATA
45/55/65cm
EMC012
3x 4P Molex
45/55/65cm
EMC013
3x 4P Molex
+1x FDD
45/55/65/75cm
EMC014
2x 6+2P(8P)
PCI-E 2.0
50cm
EMC015
1x 6+2P(8P)
PCI-E 2.0
50cm
EMD625AWTII 24P, 55cm 8P & 4P, 60cm 3x 1x 1x 2x -
EMD525AWTII 24P, 55cm 8P & 4P, 60cm 2x 1x 1x 1x 1x
EMD425AWTII 24P, 45cm 4+4P (8P), 60cm 1x 1x 1x 1x -
