PRODUCT SPECIFICATIONS & MANUAL
Product Name LiFePO4 Battery Pack | 12.8V 150Ah
Model JG-4IFR12.8-150-Y (26650-3.2V-4S40P)
Doc. No. 19-WJY014
Rev. R3.2

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Table of Contents
Quality Statement ........................................................................................................................................ 3
Product Index ............................................................................................................................................... 4
Product Parameters .................................................................................................................................. 4
Battery Usages .............................................................................................................................................. 5
Charge ....................................................................................................................................................... 5
Discharge ................................................................................................................................................... 5
Battery Test .................................................................................................................................................. 5
Standard Test Requirements .................................................................................................................... 5
Standard Charge ....................................................................................................................................... 5
Standard Discharge ................................................................................................................................... 5
Battery Service Environment ....................................................................................................................... 6
Special Attentions ........................................................................................................................................ 6
Battery Using and Maintenance .................................................................................................................. 7
Battery Storage ......................................................................................................................................... 7
Battery Checking Before Using ................................................................................................................. 7
Battery Installation Notes ......................................................................................................................... 7
Battery Working Requirements ................................................................................................................ 8
Battery Using and Maintenance ............................................................................................................... 8
Battery Common Problems and Solutions ................................................................................................ 9
Other Technical Indicators ......................................................................................................................... 10
Products Disclaimer .................................................................................................................................... 10
Distributor Information .............................................................................................................................. 10

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Quality Statement
Proper use and maintenance will ensure that the battery (or battery system) will operate reliably and
consistently for long periods of time.
• After receiving the product, please check if the packaging is in good condition. If the packing is
broken, it may cause damage to the product. If there is any damage, please contact our after-
sales or sales staff within five working days.
• Anyone who does not use or maintain the battery according to the manual shall be deemed to
give up the warranty right. Suppliers and its service station have the right to no longer guarantee
the warranty, and will not compensate for any losses arising from it. However, the corresponding
paid service can be provided according to the situation.

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Product Index
Product Parameters
Item Parameter
Product Model JG-4IFR12.8-150-Y (26650-3.2V-4S40P)
Normal Voltage 12.8V
Rated Capacity 150Ah (C5)
Min Capacity
145.5
Ah
(C
5
)
Energy About 1920Wh
Internal Resistance ≤35 mΩ
Size 483±4 * 170±2 * 235±3 mm
Weight 18.5±0.4 kg
Shell material Plastic
Charge Voltage 14.4±0.15V
Standard Cut
-
off
Voltage about 10.0V
Charge Current ≤75A
Charging cut-off current 1.5A~3A
Discharge Current Normal Current 75A
Max Continuous Current 150A
Passive Protection
Over charge protection, Over discharge protection, Temperature protection,
Balanced function
Charge Connector M8 threaded hole
Discharge Connector M8 threaded hole
Communication Bluetooth
Charge Retention
After charging according to standard 3.2, placing the battery for 28 days
under the standard test conditions, then discharge it under standard 3.3,
and the charge retention rate is ≥80%.
Cycle time
The cycle life is not less than 1500, the capacity retention rate is ≥80%.
(Charging according to 3.2 standard, leaving 0.5~1h; discharging according
to 3.3 standard, leaving 0.5~1h, counting 1 cycle time).

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Battery Usages
Charge
Charging terminal of battery is connected to charger appropriate with it, and then charge.
Charging voltage is 14.4±0.15V.
Do not reverse.
Discharge
Note that the positive and negative (poles are not reversed as indicated by the battery case logo), then
connect to the matching load.
Battery Test
Single cell and Protection board specification are only results of standard test, this is for reference.
Standard Test Requirements
Battery tested must be done within 1 month after production. If the battery is not tested on time due to
transportation or other reasons, the battery can be recharged and discharged for testing.
All tests in this specification should be done in standard atmospheric conditions. (Temperature: 25±2°C;
relative humidity: 65±20%).
Standard charge voltage is 14.4±0.15V, standard discharge cutoff voltage is about 10.0V; standard
current is I5 (when I5 > the normal work current, test according to the normal current).
Standard Charge
Charge the battery with Lithium ion battery special test cabinet, with standard charging voltage,
standard current, constant current and constant voltage charging to the current dropping to 0.05 I5.
Standard Discharge
Discharge the battery with Lithium ion battery special test cabinet, discharge to standard discharge
cutoff voltage with standard current, constant discharging or until the battery stops.

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Battery Service Environment
Battery discharge ambient temperature is (-20°C) ~ (+60°C) (When the ambient temperature >45°C,
please pay attention to the ventilation and heat dissipation), Charging temperature is 0°C ~ (+45°C).
Ambient humidity RH is ≦ 85%. Pay attention to waterproof when ambient humidity is > 85%, at the
same time the battery surface condensation phenomenon should be avoided.
Special Attentions
In order to make full use of the energy efficiency of the battery and prevent accidents such as leakage or
heat generation, please prohibit the followings:
 Do not immerse the battery in the water. Once it is in the water or water enters the battery,
isolate it immediately and ask a professional to deal with it.
 Do not charge, discharge and leave the battery at temperatures over 60°C. Also keep away from
fire, heater or corrosive materials. Otherwise, it can cause overheat, fire, or function failure,
shortened life, or even danger happening.
 Do not charge the battery at temperature below 0°C.
 Do not reverse the positive and negative terminals. Do not short the positive and negative of the
battery.
 Do not combine the battery in series or in parallel.
 Do not reverse polarity charging. Do not connect the battery electrodes to an electrical outlet.
 Do not transport or store the battery together with metal objects such as hairpins, necklaces,
etc.
 Do not strike, trample, throw, fall and shock the battery.
 Do not directly weld the battery and pierce the battery with a nail or other sharp objects.
 Do not use the battery in the location where static electricity and magnetic field is strong.
Otherwise the battery protection circuit may be damaged.
 Do not overload the battery.
 Do not machine the circuit board, which may damage the internal circuit and cause function
failure.
 Do not deform the product under pressure, which may cause electronic components or part of
the circuit damage, and make the product unstable.
 Do not remove the case, in case of unnecessary damage.
 Do not overcharge or over discharge the battery.
 Please use special charger for charging.
 Please charge the battery within 12 hours after using. If the battery is not charged for more than
12 hours after using, please test the battery voltage before charging. If the voltage of the
battery is < 8.0V, do not charge, need to place in isolation. Meanwhile please contact our
technical staffs.

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
 If the battery leaks and liquid splashes into the eyes or skin, do not rub, wash it with clean
water, and immediately seek medical attention.
 In case of accidental fire, dry powder fire extinguisher or sand should be used.
 If the battery gives off strange odor, generates heat, becomes discolored or deformed, or any
abnormality appears during use, storage, or charging, stop charging and using immediately,
remove and isolate it from the device in the safe way.
 The electrode of the discarded battery terminal should be covered with insulating paper to
reduce the safety hazard when laying aside.
 Reversing the Positive and negative charging terminal will burn the internal circuit board, so pay
attention to it.
Battery Using and Maintenance
Battery Storage
Storage temperature 0℃ ~ 40°C (Optimum storage temperature 15°C ~ 25°C, dry preservation).
Battery performance is affected by temperature, the most obvious is the change in battery capacity, this
is normal phenomenon. Avoid condensation caused by temperature changes during storage, otherwise
it will lead to the rust of batteries or metal parts.
Battery Checking Before Using
 After receiving the battery, first check the packing carefully, please ensure there’s no shock on
the battery during the handling process.
 Please check the battery case and accessories if there’s any damage or leakage, if so, please
contact us immediately.
 Please check the output connector is correct or not, measure whether the positive and negative
is reversed and whether the voltage is within the normal standard. In case the battery terminals
are dirty or rust, clean the terminals with a dry cloth before use. Otherwise poor performance
may occur due to the poor connection with the instrument.
Battery Installation Notes
 Please clean up the installation position of the battery to ensure no dust, metal or other foreign
materials. No smoking or fire during installation to avoid short-circuit of battery and prevent
equipment damage or personal injury.
 The battery should be installed under the condition with well-ventilated and no sunlight. Don’t
put it under place with possible flooding. The using and storage of the battery should be kept
away from inflammable and explosive materials.
 When fastening battery terminals, please don’t use excessive force, or the terminals could be
damaged.

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
 After installation, please check whether the terminal fastening is in place and whether there are
sundries on the surface of the battery. Clean the surface of battery with dry cloth, please don’t
use oil or other volatile organic solvents to clean, or it may damage it.
 Please make sure that the positive (+) & negative (-) polarity is correctly connected, or it may fire
or damage the battery and electrical appliances.
 Test to run the equipment, observe whether the equipment and battery are abnormal.
Battery Working Requirements
 Charge current shall not exceed the specified maximum charge current, which may affect the
service life of the battery or damage the internal circuit, or even cause danger.
 Discharge current shall not exceed the specified maximum discharge current, which may affect
the service life of the battery or damage the internal circuit, or even cause danger.
 When the battery is short of power, it should be charged in time, which is beneficial to extend
the battery life. If the battery is not charged in time, battery is in the state of power shortage for
a long time, battery life will be affected.
 The lithium-ion battery charge and discharge shallow is beneficial to improve the cycle life.
Suggest user each discharge be put to 80% of the nominal capacity.
Battery Using and Maintenance
 The battery would be possible to be at the over-discharged state by its self-discharge
characteristics in case the battery is not used for long time. In order to prevent over-discharging,
the battery shall be charged periodically to maintain a certain voltage range: 13.32V~13.6V, 2
months one cycle. (for battery with communication function, please maintain it once in 1
month) What's more, the SOC/ capacity calibration shall be performed. The calibration method
is to charge fully with charger, then discharge to over-discharged protection state.
 Don’t use organic solvents to clean the battery case.
 Battery is a consumable product with limited cycle life. Please change it in time when the
capacity can’t reach the requirement to avoid any loss of the user.
 In order to prevent the safety problem caused by the failure of the protection board overcharge
protection function, do not charge for a long time. After the battery is fully charged, remove it.
In addition, use the original charger or the one attached to the battery and operate it according
to the instructions. Otherwise, the battery may be damaged or cause danger.
 The shallow charge and discharge of the battery ensures that the battery can be used
economically. Overcharge and over discharge may cause the battery overheat, fire or function
failure, shorten life, or other dangerous.
 The battery switch, battery display board and USB are consumed components, we could offer
valuable after sales service.
 Waste lithium batteries should be recycled and disposed in accordance with local laws.

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Battery Common Problems and Solutions
Battery voltage is too low after fully charged
Battery is in long-term storage with no usage, and not maintenance in accordance with the provisions.
Solution: Please test the battery voltage. If the battery voltage is <8.0V, it can't be charged and need to
be isolated. Please consult the technicians. If the voltage is ≥ 8.0V, the battery can be isolated to charge,
and periodically check to see if it can be charged normally.
Battery Disconnection
Solution: remove the battery to check whether the line is broken or not, the welding joints come off or
not, nickel belt breaks or not, and then repair according to the damage situation.
Protection Board not work
Solution: first, make sure the cable line is contact with the protection board well, then, observe welding
is off or not. If the above conditions are normal, please check the voltage between B+/B- and P+/ P-, the
protection board has been broken if the voltage difference is very high. Then please do testing in details
on protection board, if not pass, please change another new protection board.
Battery suffered fierce collision, with character-external battery case damaged or with electrolyte odor
Solution: It’s not in the scope of maintenance generally. If needing maintenance, we need the
confirmation of the problem whether on the output line or the battery itself.
First, open the battery case, check whether the battery P + / C + and P- / C- lines or joints damaged or
not. If damaged, it needs to be replaced. Then, instigating smell odors method to determine the battery,
if there is irritation electrolyte odor, indicate that the battery has been leaking, and need to test the
battery voltage of each series. If the voltage of one series is quite different from others or much lower
than others, then this series needs to be replaced.
Insufficient capacity
Solution: To charge and discharge the battery with 3~5 cycles generally.
Battery voltage instability or cannot charge or discharge normally.
Faulty welding
Solution: To test the resistance with the internal resistance tester, and confirm the internal resistance of
the battery exceeding a predetermined value or not. If not, the battery would be in faulty welding
condition, the battery needs to be unpacked and be welded again.
Protection board abnormal
Solution: replace the protection board.

Only positive energy
Distributed by: ENERdan GmbH | Max-Planck-Straße 7, D-12489 Berlin, Germany | enerpower.de
Tel: [phone] | Fax: [phone] | [email protected]e
Connector or terminals in poor connecting condition
Solution: change the terminals or connectors
Battery works properly in charging but could not discharge or discharging well but could not charge.
Solution: The protection board is damaged; need to change the protection board.
Other Technical Indicators
If battery protection parameters and other related parameters are needed, please contact our sales or
technical staff, we will provide the information as soon as possible. Your understanding is highly
appreciated.
Products Disclaimer
Before using the battery, please read the specifications, usage instruction and some attentions carefully.
Suppliers are not responsible for the incident caused by not obeying the Manual. The phenomenon such
as incorrect using method or wrong circuit connection, or input power data, working index are
inconsistent with the Manual, cause damage to product, over load and its accessories, we are not
responsible for it.
Distributor Information
ENERdan GmbH
Max-Planck-Straße 7
D-12489 Berlin
Germany
Tel: [phone]
Fax: [phone]
Email: sales@enerdan,de
enerdan.de | enerpower.de | Online Shop: enerprof.de
