Kon-TEC KT-LFPES512100 User manual

Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów
T: [phone] E: [e-mail] W: www.kon-tec.eu
https://www.kon-tec.eu/
1/5
LITHIUM IRON PHOSPHATE
LIFEPO4 BATTERY PACK
INSTRUCTIONS FOR CONNECTION
THE BATTERY PACK TO VICTRON INVERTERS
51,2V 100Ah
KT-LFPES512100
Before connecting the battery with inverter.make sure the following rules are complied.
Victron devices and Kon-TEC KT-LFPES512100 battery can be used for the following system types:
• Energy Storage Systems (ESS) – Self Consumption
• Grid Backup (DVCC or ESS)
• Off-grid (DVCC)
A GX device is required to establish communication. It is essential to use the CAN-bus connection of the GX device (e.g. Cerbo GX) –
communicates the keep-alive signal, charge and discharge limits, error codes and state of charge (SOC %) between the batteries and
the system.
The minimum required rmware version for the GX Device is v2.40. It is highly recommended to use the latest rmware version on
all connected devices, including the GX device lnverter/Charger and MPPTs.
Both 250Kbps and 500Kbps are supported. If you use a new VE.Can MPPT, it must also be with a GX device that has more than one
CANbus interface, e.g. the Cerbo GX.
Compatible device:
Multi, MultiPlus, MultiGrid, EasySolar-II, Inverter RS & Multi RS and Quattro.
VE.Direct BlueSolar and SmartSolar MPPT Chargers.
2.2.1.1. Both inverter and battery completely off.
2.2.1.2. Connect the communication cable to the system according to the following schematic.
1. The battery system discharge power/current is proper with the inverter power. It is recommended to congure the inverter
capacity with battery in 1: 2 proportion, for example. If you have a 5 kW rated inverter, connect at least 2 batteries (10kWh),
2. If the system is an off-grid system, make sure that conguration can manage to avoid overdischarging the battery. It is strongly
recommended to install a smart generator and MPPT modules (brands like Victron that support DC-coupled application).
3. Make sure that the installation environment, setting and sequence is following the User Manual.
1. PRECONDITIONS
2.COMMISSIONING WITH INVERTER
3.4.2 START SYSTEM
2.1 VICTRON
2.2.1 CABLE CONNECTION
Kon-TEC Battery BMS CAN port Victron GX device (VE. CAN Port
/ BMS CAN Port)
Pin 6 GND Pin 3 GND
Pin 4 H Pin 7 H
Pin 5 L Pin 8 L

KT-LFPES512100 https://www.kon-tec.eu/
2/5
Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów
T: [phone] E: [e-mail] W: www.kon-tec.eu
2.2.2.1 Set the Master battery (ONLY!!!) DIP address according to the User Manual (Picture above).
2.2.2.2 Press the Master battery reset button to switch on all the batteries and then close the battery breaker
2.2.2.3 Close inverter switch, then turn on DC breaker to start MPPT.
2.2.2.4 Switch on AC input and output breaker
2.2.3.1 Conrm the rmware version
2.2.2 START SYSTEM
2.2.3 INVERTER SETUP
MPPT
INSTALACJA PV
PV INSTALLATION
PE
VE Direct/VE CAN
BMS CAN
VE Bus
Wyjście AC2
AC2 out
Wyjście AC1
AC1 out
LINK OUT - PORT OSTATNIEGO AKUMULATORA SLAVE WOLNY
LINK OUT - LAST SLAVE BATTERY PORT NOT CONNECTED
Wejście AC1
AC1 in Sieć
energetyczna
GRID
Cerbo GX
MultiPlus II 3K
Ostatni akumulator Slave
Last Slave battery
Akumulator Master
Master battery
DIP: 0000000
n - równolegle
n - parallel
Rozłącznik DC
DC Breaker
Rozłącznik DC
DC Breaker

Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów
T: [phone] E: [e-mail] W: www.kon-tec.eu
3/5
KT-LFPES512100 https://www.kon-tec.eu/
2.2.3.2 Choose the baud rate, setting-services, ve.can port, select the 250/500 accoring to battery User Manual
2.2.3.3 Odszukać, na urządzeniu GX, akumulator. Sprawdzić parametry CCL i DCL. (50/100A dla jednego akumulatora w
normalnych warunkach.)
2.2.3.4 Set DVCC as below

KT-LFPES512100 https://www.kon-tec.eu/
4/5
Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów
T: [phone] E: [e-mail] W: www.kon-tec.eu
2.2.4.2 Inverter tab
VE Congure Inverter
Parameter
Setting
DC input low shut-down 46V
DC input ow restart 51.2V
DC input low pre-alarm 51.2V
2.2.4.3 ESS assistant setting (if you are using your battery in a grid connected system)
2.2.4.2 Charge tab
VE Congure Charge Parameter Setting
Battery type 48V
Charge curve Fixed
Absorption voltage 56.0 V
Float·voltage 54.6 V
Absorption time 1 hr
2.2.3.5 Congure MPPT via Victron connect.
MPPT Parameter Setting
Battery voltage 48V
Absorption voltage 56.0V
3.1.4.1 General tab
• Check the „Enable battery monitor” function
• Set the battery capacity to the total capacity of the battery, each model is 100Ah
• The other parameters („State of charge when bulk nished”and “Charge efciency”) can be left to their default setting.
3.1.4 VE CONFIGURE SETTINGS

Kon-TEC sp. z o.o.
Boya-Żeleńskiego 12, 35-105 Rzeszów
T: [phone] E: [e-mail] W: www.kon-tec.eu
5/5
KT-LFPES512100 https://www.kon-tec.eu/
ESS Parameter Setting
Dynamic cut-off 47V
Sustain voltage 50.5V
Restart offset: 1.2V (Default)
Send all the setting to the inverter/charger. Then restart the system.
