ENFORCER ST-L0521-TUQ User manual

®
Features:
Specifications:
Installation:
Wiring Diagram:
ST
-
L0521
-
TUQ
USB Keystone Charger
Manual
 Snap-in style USB Keystone Charger adapter
 2.8A Max. output for faster charging
 Uses the latest USB identification circuit;
compatible with most devices
 Useful for equipment racks, conference rooms,
AV systems, planes, boats, buses, gyms, etc.
 Built-in blue power indicator LED
 Connect multiple units together to charge
multiple devices simultaneously
 Synchronous rectification, high efficiency
 Power input with reverse polarity protection diode
 Provides complete fault protection such as
under-voltage lockout, output short-circuit
protection, overcurrent protection, and
thermal shutdown
The USB K
eystone
C
harger fits all standard
telecommunications wall plates.
1. Connect a 9~24 VDC power supply to the
input power terminals using 18~24 AWG wire
.
Daisy chain multiple chargers if desired.
2. Snap the charger into the wall plate from the
back.
3. Check clearance behind adapter to ensure
space for proper bend-radius of cables.
4. Check to see that the LED power indicator is
lit and connect a USB device to
be charged.
Input voltage
9
~24 VDC
Output voltage
5VDC
±5%
Output current
2.8
A max.
*
Standby current
<2mA
Dimensions
11
/
16
"x
13
/
16
"x1
5
/
8
" (17x21x41 mm)
9~24 VDC
Power
Supply
Output to optional
secondary
ST-L0521-TUQ
(+)
(–)
NOTE: Recommended power supply – ST-UV12-S5.0Q.
*
The current drawn by a connected device will depend on the connected device's charge controller IC.

ENFORCER USB Keystone Charger
2 SECO-LARM U.S.A., Inc.
Sample Installation
(Using Cat6 Cable
)
:
PITTW6
MI_ST
-
L0521
-
TUQ_190122.docx
® U.S.A., Inc.
16842 Millikan Avenue, Irvine, CA 92606
Website:
www.seco
-
larm.com
Phone: (949) 261
-
2999 | (800) 662
-
0800
Email: sales@seco
-
larm.com
NOTICE
:
The SECO
-
LARM policy is one of continual development and improvement. For
that reason, SECO
-
LARM
reserves the right to change specifications without notice. SECO-LARM is also not responsible for misprints.
All trademarks
are the property of SECO-LARM U.S.A., Inc. or their respective owners. Copyright © 2018 SECO-LARM U.S.A.,
Inc. All
rights reserved.
WARRANTY:
This SECO
-
LARM product is warranted against defects in material and workmanship while used in normal
service for
one
(1
)
year from the
date of sale to the original customer.
12VDC/5A
Power Supply
200ft (61m) max.**
50ft (15m)* 70ft (21m)* 80ft (24m)*
NOTE
S
:
1. The maximum distance shown above is dependent on the wire gauge, number of wires
used, types of devices connected, number of devices connected, and power supply.
2. For a 12VDC/5A power supply, maximum distance** can be calculated with 1200ft/x,
where "x" is the total current draw of the connected devices. For example, if three
5VDC/1A devices are connected, then maximum distance is 1,200ft/3 = 400ft (122m).
3. The maximum number of devices that can be connected to a 12VDC/5A power supply is
three 5VDC/2A devices or six 5VDC/1A devices.
*Arbitrary distances for illustrative purposes only.
**Using all 4 pairs of a Cat6 cable.
1x 5VDC/2A
USB device
1x 5VDC/2A
USB device
1x 5VDC/2A
USB device
USB
Charger
USB
Charger
USB
Charger
