INSTALLATION INSTRUCTIONSHI FLOW WASTE
TM
1235385-A02-A 21/03/2014
CLEANING AND MAINTENANCE INSTRUCTIONS
1235385-A02-A 21/03/2014
INSTALLATION
INSTRUCTIONS
SHOWER
www.englefield.co.nz
HI FLOW WASTE
Englefield has a history
of making superb showers
and their popularity is
testament to their quality
and affordability.
It’s the details that Englefield
cares about - from pioneer-
ing the latest technology, to
innovative design, it’s all to
make your showering
experience the very best it
can be.
(a) Gently prise waste lid assembly from
lock ring in shower base.
(b) Remove any obstruction then wipe clean.
(c) Replace and rotate waste lid until it
snaps into place.
Instructions, drawings, and diagrams contained in this manual present information available at the time of printing.
Although every attempt has been made to keep them up-to-date, Engleeld reserves the right to implement product
changes without further notice.

LOCK RING
TOOL
R466105
LOCK RING
R466065
WASTE LID
WASTE LID
ADAPTER
R466045
O RING 80 x 2.5
R466025
LOCK RING
SEAL
R466030
SHOWER
TRAY
H RING
SEAL
R466005
WASTE
BODY
40 mm R466084
SPARE PARTS
Page 31235385-A02-A 21/03/2014
INSTALLATION INSTRUCTIONSHI FLOW WASTE
R4665XX
ENGLEFIELD
Page 2
1235385-A02-A 21/03/2014
Before installing please read these instructions carefully to familiarise yourself with the
required tools, materials and installation sequences. Please leave these instructions for the
consumer after installation.
It is recommended that the HI FLOW WASTE is fitted to the shower tray prior to installation.
All installation must comply with council and local authority by-laws. It is the responsibility
of the installer to ensure that the waste is made watertight.
INSTALLATION INSTRUCTIONSHI FLOW WASTE
BEFORE YOU BEGIN
!IMPORTANT
(a) Align fingers on adapter with slots in
waste lid, then snap fit together.
(b) Ensure lock ring seal is correctly fitted.
(c) Fit Hi Flow Waste to shower tray.
Use lock ring tool to tighten lock ring
against ‘H’ ring and waste body.
Remove lock ring tool before snap
fitting waste lid.
INSTALLATION
ROUGH-IN
ENGLEFIELD
LOCK RING
TOOL
SHOWER
TRAY
LOCK RING
‘H’ RING
WASTE
BODY
LOCK RING
SEAL
TO SUIT 40 mm
PVC WASTE PIPE
SHOWER
TRAY
73.5
113
89
WASTE LID
SLOT
ADAPTER
FINGER
LOCKING
SEAL
