VADO AXCES SIRKEL AX-SIR-MFSRK-DB-CP Instruction Manual

This instruction booklet covers model:
AX-SIR-MFSRK-DB-CP
Version 1, 1-8-19
VADO
Wedmore Road, Cheddar,
Somerset, England BS27 3EB
tel [phone]
fax [phone]
www.vado.com
[e-mail]
MULTI FUNCTION
SLIDE RAIL KIT
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
SIRKEL

23
Please read these instructions carefully before starting installation and keep for
future reference.
Remove all packaging and check the product for missing parts or damage before
starting installation.
Any alterations made to this product and fittings may infringe water regulations and
will invalidate the guarantee.
The installation must comply with all Local/National Water Supply Authority
Regulations/Byelaws and Building and Plumbing Regulations.
To be installed in accordance with BS EN806.
We strongly recommend that you use a qualified and registered plumber.
General installation
Important - please read
Please read these instructions carefully before starting installation and keep for future
reference.
Remove all packaging and check the product for missing parts or damage before
starting installation. Please take great care when installing this mixer not to damage its
surface.
Warning! Please check for any hidden cables and pipes before drilling holes in the wall.
Note: The fixings supplied are for solid walls only. If you are fitting the accessory to a
partition or wall of particularly soft substrate you will need specialist fixings.
Contents of Packaging
Installation guide &
User manual
MULTI FUNCTION
SIDE RAIL KIT
KEEP FOR FUTURE REFERENCE
INSTALLATION /
USER MANUAL
SIRKEL
Handset
Slide rail
Shower hose with 2 washers
Fixing kit
Grub screws x 2
Screws x 2
Rubber
inserts x 2
Wall plugs x 2

4 5
Dimensions
685mm
76mm
110mm
Ø21mm
Installation
Warning! Please check for any hidden
cables and pipes before drilling holes in
the wall.
Position the rail on the wall, bearing in
mind the different heights of people likely
to use the shower.
Make sure that the slide rail is vertical
using a level. Mark the wall to indicate the
position of both brackets and remove.
Find the centre of the marked position.
Suitably fix the wall bracket to the wall
using appropriate fixings.
The supplied fixings are for solid walls.
Level
Top bracket
Bottom bracket
Bracket
Screw Wall plug

6 7
Installation
Slide the rail down through the bottom
bracket (the bottom bracket will need
to be rotated slightly) until if fits under
the top bracket. Then push the rail up
through the top bracket until it is equal
each side of the brackets.
Push a rubber insert into the hole of the
bracket, screw in the grub screw and
tighten.
Push on the cover.
Repeat for the other bracket
Bottom bracket
Top bracket
Bottom bracket
Rubber insert
Cover
Rail
Screw
Handset
Place one of the rubber washer into the
cone end of the hose and screw to the
handset.
Valve
Place the second rubber washer into the
nut end of the hose and attach it to the
valve outlet.
Shower hose
Push the cone end of the hose up through
the hose retainer.
Washer
Hose
Handset
Installation - Shower hose
Cone end
of hose
Hose
retainer

8 9
Operation
The holder can
be repositioned
by pressing the
button and sliding
up and down.
Adjust the angle
of the handset
as required.
The handset has
4 different spray
patterns. Turn to the
required position.
Cleaning instructions
The electroplating on this product is finished to the highest standard. Due care needs
to be taken to ensure the appearance is retained.
We recommend cleaning all products with a soft damp cloth ONLY and advise strongly
against the use of all aggressive/corrosive cleaning products i.e. powders and liquids.
If these instructions are not followed, this may invalidate your guarantee in the event
of a problem occurring.

11
Guarantee
All AXCES by VADO products come with a 2 year guarantee as standard. Within this
guarantee period VADO will provide replacement parts and any labour [SEE NOTE 1,
GUARANTEE CONDITIONS] needed to complete the product repair.
This standard guarantee may be extended by registering your product to give a 10 year
guarantee (2 years parts and labour plus 8 years on parts supply only.).
Operational components such as, but not limited to; thermostatic cartridges, diverters,
headworks and flow control, waste mechanisms, shower hoses, O-rings and seals are
guaranteed for 2 years parts and labour plus 3 years on parts supply only.
Guarantee Conditions
Our products are guaranteed against manufacturing defects from the date of purchase until
the expiry of the relevant guarantee period shown above.
The guarantee is only valid if:
•The product has been installed, used and maintained in accordance with VADO's
instructions and subjected to normal use only.
•The defect is not due to use of an unsuitable or inadequate water or power supply.
•The defect is not due to accident, misuse, neglect or incorrect/inappropriate repair (other
than by VADO or VADO authorised agents) or damage caused by foreign objects
or substances.
•The extended guarantee is only available if you have completed the Guarantee Registration
Process. This can be done via the VADO website or via phone to our aftersales team.
Registration must be completed within 6 months from date of purchase.
Under the extended guarantee period VADO will, at its option, offer to supply any
replacement product (or component part) assessed to be defective [SEE NOTE 2].
The guarantee (whether standard or extended) is non-transferable to any subsequent owner.
All claims under the guarantee should be notified in the first instance to our Aftersales
department, contact details below, this must be done no later than the last day of the
relevant guarantee period. All claims must be accompanied by proof of purchase (sales
receipt or delivery note) from an official AXCES by VADO dealer.
The guarantee does not extend to any consequential loss or damage.
After repair or replacement, the relevant guarantee period will be calculated from the
original date of purchase.
VADO operates a policy of continuous product development and therefore reserves the right
to change the product, packaging and documentation specifications without notice.
NOTES:
[1] Labour via our engineer network is only available in the UK. Attendance by a VADO
engineer or sub-contract engineer will be under our standard terms and conditions.
[2] VADO reserves the right to charge in advance for a product (or replacement part) pending
collection and investigation (at VADO expense) to confirm a defect is due to a manufacturing
issue. If a defect is found the charge will be refunded or cancelled.
This guarantee is in addition to and does not affect your statutory rights as a consumer.
Tel: [phone]
Email: [e-mail]
