Enlite WP102PH-EN User manual

Document Version: EN-WP102_EM_MS_PH_V1_17_Eng
ENLITE
Tel: [phone]
Fax: [phone]
Website: www.enlitelighting.com
Email: [email protected]
21
6
EN-WP102, EN-WP102EM, EN-WP102MS & EN-WP102PH
3
4A MICRO SENSOR
STANDARD PHOTO CELLEMERGENCY
4B 4C 4D
knockout
Live - Brown (L)
Earth - Green/Yellow e
Neutral - Blue (N)
Live - Brown (L)
Earth - Green/Yellow e
Neutral - Blue (N)
5
Live - Brown (L)
Earth - Green/Yellow e
Neutral - Blue (N)
Unswitched Live - Brown (L)
Switched Live - Brown (L)
Earth - Green/Yellow e
Neutral - Blue (N)
Screw to wall
194mm
220mm
240mm

PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION
LEAVE A COPY FOR THE USER / MAINTENANCE ENGINEER FOR FUTURE REFERENCE
IMPORTANT USER INFORMATION
• Installation should be carried out in accordance with the latest edition of the National Wiring Regulations, if in doubt consult a qualied electrician.
• All luminaires run hot. It is the installer’s responsibility to consider re risk and take appropriate precautions.
• Input voltage - 240V 50Hz AC.
• Ta: 50�C
• This tting is IP65 and are protected against dust and low pressure water jets. Ensure all connections are to the same standard.
This luminaire is not suitable for covering with insulation material.
Terminals should be connected as follows
Live - Brown (L), Earth - Green/Yellow e, Neutral - Blue (N)
FOR EMERGENCY VERSIONS
• Ensure un-switched permanent live is connected (See Figure 6).
• The battery charging circuit is energised when the power supply is switched on.
• 3 hours emergency operation.
• The green charge indicator is visible through the diffuser.
• Terminals should be connected as follows
Unswitched Live - Brown (L), Switched Live - Brown (L), Earth - Green/Yellow e, Neutral - Blue (N)
OPERATION
When charged, the Battery/Invertor unit will provide power to the tting during an interruption in the power supply. After installation the luminaire
should be routinely tested by qualied and competent personnel using the schedule provided in this installation guide.
BATTERIES AND DISPOSAL
Replacement of complete luminaire is required when the battery or Leds no longer meet their rated duration of operation.
FOR MICROWAVE VERSIONS
Environmental Protection (W.E.E.E.) – Enlite’s WEEE Reg.No. WEE/BG0130YX (UK Only)
Waste Electrical & Electronic Equipment Regulations (WEEE) requires that any of our products showing this marking (left) must not be disposed of with other household
or commercial waste. Enlite does not levy any WEEE disposal charges to its customers for affected WEEE related products. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate any such product from other waste types and recycle it responsibly at your local facilities. Check
with your Local Authority, Recycling Centre or retailer for recycling advice. If, when you purchased any Enlite product, your supplier included a WEEE disposal fee, you
should then contact your supplier for advice on his take back of the product for the correct disposal.
GUARANTEE
This product is guaranteed for a period of 3 years from the date of purchase. The guarantee is invalid in the case of improper use, installation, tampering, and removal of the Q.C.
date label, installation in an improper working environment or installation not according to the current edition of the National Wiring Regulations. Should this product fail during the
guarantee period it will be replaced free of charge, subject to correct installation and return of the faulty unit. Enlite does not accept responsibility for any installation costs associated
with the replacement of this product. This warranty is in addition to the statutory rights in your country of purchase. Enlite reserves the right to alter specifications without prior notice.
GB
DETECTION AREA
Detection area can be reduced by selecting the combination on the DIP
switches to t precisely each application.
HOLD TIME
Refers to the time period the lamp remains at 100% illumination after no
motion detected.
DAYLIGHT SENSOR
The sensor can be set to only allow the lamp to illuminate below a dened ambient brightness
threshold.
When set to Disable mode, the daylight sensor will switch on the lamp when motion is
detected regardless of ambient light level.
50lux: twilight operation, 10lux, 5lux & 2lux: darkness operation only.
100%
75%
50%
30%
10%
5s
30s
1min
5min
10min
20min
30min
