Entech U-BLUE User manual

#362, Gwangmyeong Sibeom Industrial Complex,
201 Haan Dong, Gwangmyeong Si,
Gyeonggi Do, Korea
T : 82-2-898-7005 F : 82-2-897-7009
Warning: Incorrect installation and/or operation could void your valuable warranty.
Please protect your investment! READ THIS MANUAL CAREFULLY
OPERATION MANUAL
U-BLUE
ALKALINE WATER IONIZER
Undersink

2 3
Power Related
Installation Precautions
During Usage
pH Reagent Liquid Precautions
Some helpful tips
Description
Safety Precautions
TABLE OF CONTENTS
03
03
04
05
05
Names and functions of Parts I
Names and functions of Parts II
Accessoriesl
How to Install
How to use
How to measure pH
How to set your individual pH levels
How to replace the filter
Filter composition
Water flow diagram
How to Use
Customer Service
Trouble shooting guide
Specifications
Warranty Card
06-07
08-09
10
11-12
13-16
17
18-19
20-21
22
23
24-25
26
27
Safety Precautions
If a break down occurs, do not make a repair by yourself. Contact the place of purchase or A/S center.
Electrical power precautions
If your ionizer becomes submerged
in water, unplug the power cord from
the wall BEFORE removing the
ionizer from the water.
Failure to do so may cause electric shock!
NEVER attempt to repair or service the unit yourself.
Contact your dealer.
Attempting to do so will void your valuable warranty!
Do not use your ionizer at voltages other than specified
(AC 110V FOR USA).
Use a GFI outlet. Do not plug in your ionizer where it
will exceed the rating of outlet or electric wiring.
Failure to do so can result in fire, injury and/or
damage to yourself, wiring or ionizer!
NEVER touch the power cord or plug with wet hands
- this may result in electric shock!
220V
Ensure the power plug is firmly and
properly inserted into the outlet
- failure to do so may result in electric
shock or fire!
Do not wash your ionizer by immersion or by pouring
water over the main body;
always unplug your ionizer while cleaning the casing.
Clean with damp sponge or cloth.
Protect your ionizer from freezing
temperatures.
Protect your ionizer from direct
sunlight.
Do not put anything heavy on top of your ionizer.
Do not install your ionizer on an unstable or soft
surface. Install only on a hard and level surface.
Installation Precautions
Maintenance Precautions
Always unplug your ionizer when changing the fuse or cleaning your ionizer
- failure to do so may result in electric shock.

4 5
Safety Precautions
Common Sense Precautions
Do not attempt to repair or service the unit yourself. Contact your dealer.
Attempting to do so will void your valuable warranty!
Make sure to use your ionizer only with potable water which is suitable for
human consumption.
DO NOT use your ionizer with well water, water with extreme hardness,
high sediment or TDS levels without first consulting your dealer.
During Use
Do not run hot water through your ionizer.
Do not clean by pouring water over or spraying the
ionizer.
Do not close, bend, pinch, press or otherwise obstruct
output ports or hoses.
If the appliance makes strange or unusual noises or
burning smells are detected, unplug the power cord
immediately and contact your dealer to arrange service.
Unplug your ionizer if you plan not to use it for an
extended period or turn off the main power switch on
the back of the unit.
Filter replacement may be necessary
pH Reagent Liquid Precautions
Do not expose the pH measuring reagent to extreme heat, flames
or fire. It is combustible.
Do not drink the pH reagent liquid, put it in the eyes or apply to the body.
- If the liquid is ingested, induce vomiting immediately and call
a doctor.
- If the liquid gets in the eyes, flush immediately and thoroughly
with cool water; call a doctor.
- If spilled or dropped on your body, wash if off immediately.
Make sure to keep the pH reagent liquid tightly closed and out of the reach of children.
Some helpful tips
For storing your alkaline water, glass or ceramic is best. Always try and
keep your stored water cool and away from direct sunlight.
You can use plastic, but only use lexan (number7) or poly bottles
(Nalge type). It is always best fresh out of the machine and ideal
if consumed on a day-today basis.
Do not store alkaline water in stainless steel, bronze or
aluminum containers.
Save the box and Styrofoam your ionizer came packed in.
This will help if your ionizer needs to be transported at a later date.
Do not use an ionizer downstream of a sodium-based ion exchange
softening system or Reverse Osmosis system without first consulting
with your dealer.

6 7
Names and functions of Parts I
Tap water inlet Acdic water outet
Front Back
Alkaline outlet cap
Body
Filter cover
Volume controller
Fuse holder
AC Power cord
Main switch
Rear cover
Faucet cable harness port

8 9
Names and functions of Parts II
Faucet Display
Function display panel
Acidic Water Outlet
Body
Alkaline Water Outlet
pH level indicator
ALKALINE WATER BUTTON
Filter life indicator
POWER BUTTON
ACIDIC WATER BUTTON
FILTERED WATER BUTTON
Power button
Starts and stops water flow into your ionizer.
pH level indicator
This 4 of LEDs display will indicate which level (1-4) is selected.
Alkaline water button
Used to select alkaline water and the desired level (1-4)
Acidic water button
Used to select acidic water and the desired level (1-4)
Filtered water button
Used to select filtered water.
Filter life indicator
Displays the current filter life used.
When the color change the Orange and flickers,
it is time to replace your filter.

10 11
How to install
Product Requirement :
Water pressure should be maintained at a constant rate,
when the water pressure is too low, water cannot flow through the unit.
PE Hose (1/4") PE Hose (5/16")
Circle nut
Gasket
(installed under
the Faucet)
Alkaline Water
Outlet Adapter
Dust Pre-Filter
To connect the U-Blue faucet
Circle nut
1
2
Use appropriate tools to make 29mm
diameter hole in the location where you will set
up the faucet. Make sure the faucet location
will allow both spouts to reach the sink.
Place the faucet in the hole properly over
the gasket.
3
4
Insert the faucet in the hole and then screw
it with a nut to make it be fixed.
29mm
Harness
1/4” Red color Tube
(Acidic Water)
1/4” White color Tube
(Alkaline Water)
Red color
(Acidic Water)
White color
(Alkaline Water)
Harness
All the fittings are push in style fittings. To attach the hoses to any fitting, firmly insert the end of
the hose into the fitting. Pull firmly to check to connection - you should not be able to pull the
hose out. To release the hose from the fitting, you must push the spring loaded ring protruding
from the end of the fitting while pulling the hose out.
WARNING: incorrect installation could void your valuable warranty
- professional installation is recommended.
After the faucet is fixed, connect it to fitting
with 1/4” hose(for Alkaline) like figure 4.
Check the hose whether it is inserted properly
or not. Also, connect it with 1/4” hose(for Acidic)
like figure 4 and connect the faucet to the body
with connector cord.
Figure 2
Figure 1
Figure 2
Figure 3
Figure 4
Alkaline Water
Outlet Adapter
(Hole size : 5/16”)
Please connect to top cap of the ionizer
for installation Faucet.
Accessories
5/16”
1/4”
1/4”
1/4”
1/4”
1/4”
5/16”
1/4”
Acidic hose Alkaline hose

12 13
How to install
6
7
8
9
10
11
12
Place the Ionizer in an appropriate place under your sink
Connect the 1/4inch Acidic Water Hose to the small fitting on the Acidic Hose extending
from the faucet to Acidic Water Outlet on the Ionizer. Pull firmly to check to connection -
you should not be able to pull the hose out.
Connect 1/4 inch Alkaline Water Hose attached to the Fitting of the faucet to the
Alkaline Water Outlet on the ionizer. Pull firmly to check to connection - you should not be
able to pull the hose out.
Install the dust pre-filter in the middle of a length of 1/4 inch hose with the arrow pointed at
the ionizer. Connect the 1/4 inch hose with dust filter to Tap Water Inlet on the bottom of
the ionizer. Pull firmly to check to connection - you should not be able to pull the hose out.
Join the wire from the faucet to the Connect Wire(Harness). Plug the Connector Cord into the
Connector Port on the top of the ionizer.
Connect the power cord into an appropriate outlet.
Make sure the outlet you plug your U-Blue into is live, and remember that many outlets under
the sink are controlled by an on/off switch.
1
2
3
1
2
3
4
POWER UP YOUR IONIZER.
Turn the power button on.
Turn the power button to the "ON" position
on the back of the ionizer.
- The power button is ALWAYS left on.
- The power button is ALWAYS left on.
TURN ON THE WATER
Turn on the water by opening the water supply valve.
To select Alkaline water
Initial operation
START WATER FLOW THROUGH YOUR IONIZER
- Depress the "POWER" button on the top of your faucet to start the water flow.
- NOTE: The water may initially come out discolored (light to charcoal gray) due to carbon
particulates in the new filter.
- This is not harmful and is typical of all carbon filters. Allow the water to flow for 2-3 minutes
in the "Filtered" mode and this will flush all the carbon dust.
With the water running through your faucet then:
Depress the "ALKALINE" button to select the desired setting from 1 - 4. The alkaline water will come
out from the top spout. The display panel on the front of the faucet will show a blue Alkaline indicator
and blue number corresponding to the level selected.
Note: Your ionizer will always "remember" the last setting used.
If the previous selection was Alkaline Level 2, when you start flow through the ionizer next time
you use the ionizer it will automatically process at Alkaline Level 2.
How to Use
After 20 liters of water have flowed through the units,
After 20 liters of water have flowed through the units,
it will do an autoclean for 15 seconds.
it will do an autoclean for 15 seconds.
For example, if the ionizer is used first for 15 liters and then is used for 5 liters,
For example, if the ionizer is used first for 15 liters and then is used for 5 l i t ers,
upon the next use, the unit will do an auto clean for 15 seconds.
upon the next use, the unit will do an auto clean for 15 seconds.
CAUTION
CAUTION

14 15
How to Use How to Use
4
To select a different level, depress the "ALKALINE" button to move to next level until the
desired setting level is achieved. The blue number will change accordingly.
Level 1 Level 2 Level 3 Level 4
Acidic Water
Alkaline Water
Acidic Water
To select Acidic water
Note: Acidic water is for external use only. DO NOT DRINK
1
2
With the water running through your faucet then:
Depress the "ACIDIC" button to select the desired setting.
The display panel will show an orange LEDs corresponding to the level selected.
The Acidic water will come out from the top spout.
4
3
To select a different level, depress the "ACIDIC" button to move to next level until the desired
setting level is achieved. The orange number will change accordingly.
Note: Your ionizer will always "remember" the last setting used.
If the previous selection was Acidic Level 2, when you start flow through the ionizer next time
you use the ionizer it will automatically process at Acidic Level 2.
Level 1 Level 2 Level 3 Level 4
Alkaline water levels Note: pH levels will always vary with different source water.
Weak Alkaline water (pH7.5 -
pH8.5). This level is used for
initial consumption period
(4-7 days). Let your body
adjust slowly to this increase
in pH.
Weak to Medium Alkaline
water (pH8 - pH9). Move
up to this level after the
initial adjustment period.
Adjust to this level for 3-4
days. Most people will drink
at level 2 or 3.
Strong Alkaline water (pH9.5
- pH10+). Generally, most
people find this very strong
tasting and with powerful
detoxifying effects.
Medium to Strong Alkaline
water (pH8.5 - pH9.5).
This is the most common level
of alkalinity for drinking
purposes. Some people may
start to detect a strong change
in taste.
Descriptions of Acidic water levels Note: pH levels will vary with different source water.
Weak Acidic water (pH6.5 -
pH5.5). Used for oral hygiene,
mouth wash etc.
Weak to Medium Acidic
water (pH6 - pH5.5).
For skin care, as an
astringent.
Strong Acidic water
(pH5 and lower).
For sterilization purposes.
Medium to Strong Acidic water
(pH5.5 - pH5).
For cleaning in the kitchen.
Alkaline Water
Level 1
Level 1
Level 3
Level 3
Level 2
Level 2
Level 4
Level 4
Level 1
Level 1
Level 3
Level 3
Level 2
Level 2
Level 4
Level 4

16 17
How to Use How to measure pH
To select "Filtered" water
1With the water running through your faucet, press the "FILTERED" button.
The display panel will show a green symbol.
The purified water will come out of the top spout.
With the water running through your faucet then depress
the power button. The water will stop and the display panel
will go dark indicating the ionizer is in standby or "asleep".
How to Shut off the water flow from your ionizer
Filtered
Filtered Water
Filtered Water
1
2
3
If the reagent and water are not mixed well, the correct result may not be
displayed.
Fill one of the receptacles provided about 1/4 full
with alkaline, acidic or purified water.
ALKALINE
WATER
ACIDIC
WATER
PURIFIED
WATER
ALKALINE
WATER
ACIDIC
WATER
PURIFIED
WATER
How to Measure pH
Drop 2 or 3 drops of the pH reagent into the container
and shake it.
The pH value is determined by matching the color the pH
color chart provided.
DO NOT consume water containing reagent
Keep the pH reagent liquid, color chart, and test tubes away from direct sunlight
KEEP pH reagent liquid AWAY FROM CHILDREN and OPEN FLAMES!
For contact with eyes, flush liberally with fresh water, seek medical help
If ingested, induce vomiting, seek medical help
Important Note: Water quality and mineral content vary greatly in different localities
and will directly impact performance of your ionizer with respect to pH.

18 19
How to set your individual pH levels
User can regulate the electrical current of the water ionizer
based on the water source.
Depress the "FILTERED" button for 5 seconds
on the faucet.
Depress the "ALKALINE" button to raise to
the desired setting, and depress the "ACIDIC"
button to lower to the desired setting.
With the beep sound, the default setting
level 4 appears on the pH level indicator
of the display panel.
(You can select the desired setting from 1-7) To fix the setting you selected, depress
the "POWER" button on the faucet.
Raise (+) Lower (-)
Ex) Level 4
Level 1 Level 2 Level 3 Level 4
Level 5 Level 6 Level 7

20 21
When the LED filter life indicator lighting,
it is time to replace your filter.
Open the filter housing cover.
First, slide the cover upwards (figure 1) then,
slide the cover to the left (figure 2) and remove it.
How to Replace the Filter
IMPORTANT! Stop water flow prior to filter replacement.
Remove the expired filter.
- Taking hold of the filter securely with your right hand,
press the filter firmly down against the spring loaded
mechanism (figure1) to disengage the top of the filter
and then pull it toward you (figure2) and up to remove it.
- The upper part of the filter is separated from housing by
pressing firmly down. Once you have engaged the spring
loaded mechanism, you can then easily remove the filter
from the main body by pulling it toward you.
Insert the new filter into the compartment.
- Remove the plastic caps covering both ends of the new filter.
- Seat the large opening on the bottom of the filter cartridge
onto the base in the center of the filter cushion.
- Push the filter down and into the housing compartment
ensuring the opening at the top of the filter is seated
properly into the fitting at the top of the housing.
5
6
Check for leakage by running water through your ionizer
before replacing the housing cover.
Flush out the GAC carbon dust.
- The water will initially come out discolored (light to charcoal
gray) due to carbon particulates in the new filter.
This is not harmful and is typical of all GAC filters.
Allow the water to flow for 2-3 minutes in the "Purified" mode
and this will flush all the carbon dust.
7
Immediately after filter replacement, the water will come
out black and unclear due to the activated carbon particulates
in the new filter but will become clear momentarily.
(It is not harmful.)
Press the reset button(Alkaline Button) located on the top of the faucet,
and depress for 3 seconds.
NOTE: When filter life indicator is reset, and also when
machine is new, no lighting will be showing.
for 3 seconds

22 23
Filter Composition Water Flow Diagram
Calcium:
It slightly increases the alkaline mineral content in your water. It improves water taste and odors,
You get calcium on tap!
Tourmaline:
Tourmaline emits Far Infra Red (FIR) energy naturally. FIR produces well documented health
benefits and it also has an amazing effect on water.
The Biostone contains the semi -precious gemstone tourmaline in ceramic form,
so you get FIR on tap!
Non-woven fabric filter
Filters out sediment and particulate.
Granular Activated Carbon (GAC) :
The workhorse of the filtration media. GAC is especially effective at removing chlorine, its odor
and taste, agricultural chemicals, phenol, trihalomethane and other chemical contaminants.
Silver is impregnated into the granular activated carbon to inhibit bacterial growth in
between use.
Non woven fabric filter :
Filters out sediment and particulate.
Composition of filter
Water flow
sensor
Water
cell
Filter
Tap water
Solenoid valve

24 25
Trouble Shooting Guide
The Function Display
Panel does not come on.
A power plug is not property
inserted, or it is inserted into a
faulty outlet.
The fuse is blown.
The fuse is not inserted properly.
ResolutionCause(s) Abnormal condition ResolutionCause(s) Abnormal condition
Properly insert power plug into
a correctly functioning power
outlet
Replace the fuse. A spare fuse
is included in your reagent kit.
(3A / 250V fuse)
The Function Display Panel /
display indicators do not
come on even after turning
the tap on.
Faulty PCB
(Printed Circuit Board)
Immediately unplug the unit
and contact your dealer to
arrange service.
pH test shows alkaline water
color as neutral (7) while
acidic water color gets
yellow (6). This is normal
if initial pH is 6.5
Faulty or evaporated reagent:
alkaline / acidity are always
produced in inverse proportion.
Therefore, showing an acidic
color means inversely that
alkaline water has to be
generated from the unit.
Lack of alkaline color can
result from a chemical
reaction where carbonic
acid in water evaporates
some test reagent elements.
Test pH value on level
3 or 4 water;
replace reagent.
Power supply is suddenly
cut off while operating the
unit.
Elevated level of salt in the
water or high TDS; extended
operation at high pH;
sudden flux in electrical
current. In these cases your
machine will shut down
automatically to protect the
electrodes and circuitry.
Wait - the unit will become
operational again after about
one hour. Your ionizer has a
safety mechanism built-in to
protect the electrodes and
circuitry. This mechanism will
shut the ionizer down
automatically. This mechanism
protects the unit from overuse
or excessive electric current.
Low output of alkaline water
from the unit.
Filter is clogged. Premature
clogging may be caused by
sudden drop in water quality and
an influx of sediment or other
contaminants, which stress
the filter.
Low pressure in your household
plumbing.
The input hose is bent, kinked or
otherwise restricted.
Replace your filter.
Clean Pre-filter
Ensure water supply valves are
fully open. The water pressure
in house may be too low.
Straighten the bent hose.
Strange smell from
Alkaline water.
Expired filter from ordinary use
or premature clogging due to
flux in water quality.
Sudden flux in water quality with
elevated level of Choline
(not Chlorine). Elevated Choline
levels are observed in some
areas during summer months.
These levels fall within safe
drinking water standards, yet
will cause a reaction with ionized
water causing a unique smell.
Replace your filter.
Select lower pH level (1-2).
If still present, filter replacement
may be necessary.
Water appears milkish;
white snow like particles
in the bottom of your glass.
You have high hardness (calcium
primarily) in your water. The white
is extracted CaCO3 (Calcium
carbonate). After Co2 in water is
bonded with Ca where elevated
levels of CO3 exist in your water.
In water where elevated levels of
CO3 exist, what you see after
ionization is Co2 in the water
bonded with Ca.
This is calcium! It is not only
harmless, but actually good for
you. Remember the ionizer
separates and condenses the
alkaline minerals and this is what
you are seeing. You can lower
the setting (1-2) and reduce
this effect. Typically this only
occurs in hard water areas.
At first no smell, but then
smell from the alkaline
water about one hour after.
Your water bottle or receptacle
is foul and needs cleaning.
Contamination mixes with
alkaline water when filling your
bottle. Expired filter.
Clean your bottle or receptacle.
Try selecting lower pH level
(1~2). Replace your filter.
Water leakage from the
filter cartridge housing.
Filter not installed correctly
into filter housing.
Remove your filter and reinstall it
properly following the filter
replacement instructions.
Increase the quantity of source
water inflow.
No acid water flow from the
acidic output port.
Acidic output hose is bent,
kinked or otherwise restricted.
Straighten the bent hose;
increase water flow from supply.

26 27
Product Specification Warranty card
0.5A
260 X 160 X 350 (mm)
Automatic Cleaning (Every times cleaning)
LED indicator
U-BLUE
230V/50Hz
1.Warranty Detail
This product passed the precise inspection under strict quality control.
In case the product is found to have any defect in production or to
get any spontaneous mechanical malfunction within the warranty term,
return the unit to our sales agency, distributor or our service
center along with this warranty card for repair free of charge.
2.Warranty term
24 months from a purchasing date.
3.Exception to warranty
Expiration of warranty terms.
Defect caused by a natural disaster.
Damage or malfunction resulting from misuse.
4.Compensation criteria
Product repair, product exchange or refund as per the Consumer
Sufferings compensation Criteria regulated by The Ministry of
Commerce and Industry, The Republic of Korea.
Model
Purchasing date
Warranty term
Purchaser name
Address
Distributor Name
Address
U-BLUE
( )th Day, ( )Month, ( )Year
Till( )th Day, ( )Month, ( )Year
Fill in this warranty card upon receipt of new unit.
Receipt can be in force as warranty card.
WARRANTY CARD
