Hydac MRF7 User manual

MRF7
MultiRheo Filter
16 bar
Installation and Maintenance Instructions
English (translation of original instructions)
Documentation no.: 3635531

MRF7 Trademarks
Trademarks
The trademarks of other companies designate the products of those companies
exclusively.
Copyright © 2011 by
HYDAC FILTER SYSTEMS GMBH
all rights reserved
All rights reserved. This manual may not be reproduced in part or whole without the
express written consent of HYDAC Filter Systems GmbH. Contraventions are liable
to compensation.
Exclusion of liability
We have made every endeavor to ensure the accuracy of the contents of this
document. However, errors cannot be ruled out. Consequently, we accept no liability
for such errors as may exist nor for any damage or loss whatsoever which may arise
as a result of such errors. The content of the manual is checked regularly. Any
corrections required will be incorporated in future editions. We welcome any
suggestions for improvements.
All details are subject to technical modifications.
All content of this manual is subject to revision without notice.
HYDAC FILTER SYSTEMS GMBH
Postfach 12 51
66273 Sulzbach / Saa
r
Germany
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Telephone: ++49 (0)6897 509 1511
Fax: ++49 (0)6897 509 1394
E-Mail: [email protected]
HYDAC FILTER SYSTEMS GMBH en(us) Page 2 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Content
Content
Trademarks ...............................................................................................................2
Documentation Representative...............................................................................2
Content......................................................................................................................3
Preface ...................................................................................................................... 5
Customer Service ...................................................................................................6
Modifications to the Product ...................................................................................6
Warranty .................................................................................................................6
Using the Documentation .......................................................................................7
Safety information and instructions.......................................................................8
Obligations and Liability..........................................................................................8
Explanation of Symbols and Warnings, etc. ........................................................... 9
Proper/Designated Use .......................................................................................... 9
Improper Use or Use Deviating from Intended Use................................................9
Training of personnel ............................................................................................10
Dangers by pressure in the hydraulic system....................................................... 11
MRF modification.................................................................................................. 11
Unpacking MRF ......................................................................................................11
Storing the MRF...................................................................................................... 11
Checking the scope of delivery.............................................................................12
Technical specifications ........................................................................................ 13
Restrictions pertaining to use ...............................................................................13
Calculating the pressure differential of the filter housing / filter
element.................................................................................................................... 14
Housing : Pressure loss curve, housing.......................................................... 14p
Connection DIN DN 100 ....................................................................................... 14
connection DIN DN 200 ........................................................................................15
Filter element- : pressure loss calculation, filter element ................................. 15p
R (Resistance) Factors .........................................................................................16
Filter material ....................................................................................................16
Maximum differential pressure at the filter element ..........................................16
Filter element FlexMicron P (Premium).............................................................16
Filter element FlexMicron S (Standard) ............................................................17
Filter element FlexMicron E (Economy) ............................................................ 17
MRF components ...................................................................................................18
Hydraulic diagram .................................................................................................. 19
HYDAC FILTER SYSTEMS GMBH en(us) Page 3 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Content
HYDAC FILTER SYSTEMS GMBH en(us) Page 4 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
Dimensions .............................................................................................................20
Setting up / fastening MRF .................................................................................... 21
Hydraulic connection of the MRF .........................................................................21
Notes on pipes and hoses ....................................................................................22
Starting up the MRF ............................................................................................... 23
Performing maintenance .......................................................................................23
Replacing the filter elements ................................................................................24
Spare parts.............................................................................................................. 27
Disposing of the MRF.............................................................................................29
Customer Service................................................................................................... 29
Technical data ........................................................................................................ 29
Model code.............................................................................................................. 30

MRF7 Preface
Preface
For you as the owner of a product manufactured by us, we have produced this
manual, comprising the most important instructions for its operation and
maintenance.
It will acquaint you with the product and assist you in obtaining maximum benefit in
the applications for which it is designed.
Keep the manual in the vicinity of the device for immediate reference.
Sometimes the information contained in this documentation cannot always keep up
with changes made to the product as we attach considerable importance to keeping
our products cutting-edge.There may be deviations in technical details, figures, and
dimensions as a result.
If you discover errors while reading the documentation or have additional
suggestions or notes, contact us at:
HYDAC FILTER SYSTEMS GMBH
Technische Dokumentation
Postfach 12 51
66273 Sulzbach / Saar
Germany
The editorial department looks forward to receiving your input.
Our motto: “Putting experience into practice”
HYDAC FILTER SYSTEMS GMBH en(us) Page 5 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Preface
HYDAC FILTER SYSTEMS GMBH en(us) Page 6 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
Customer Service
Contact our technical sales department if you have any questions on our product.
When contacting us, always include the model/type designation, serial no. and part-
no. of the product:
Fax: ++49 (0) 6897 / 509 - 846
E-Mail: [email protected]
Modifications to the Product
We would like to point out that changes to the product (e.g. purchasing options, etc.)
may result in the information in the operating instructions no longer being completely
accurate or sufficient.
When making modifications or performing repair work to components affecting the
safety of the product, the product may not be put back into operation until it has
been examined and released by a HYDAC representative.
Please notify us immediately of any modifications made to the product whether by
you or a third party.
Warranty
For the warranty provided by us, please refer to the General Terms of Sale and
Delivery of HYDAC FILTER SYSTEMS GmbH.
They are available at: www.hydac.com -> Legal information.

MRF7 Preface
Using the Documentation
Please note that the method described above of locating specific
information does not release you from your responsibility for carefully
reading the entire manual prior to starting the unit up for the first time
and carefully rereading the manual at regular intervals later on.
WHAT do I want to know?
I determine the topic I am looking for.
WHERE can I find the information I’m looking for?
The documentation has a table of contents at the beginning. There, I select
the chapter I'm looking for and the corresponding page number.
de
HYDACFiltertechnikGmbH
BeWa123456ade
Se ite x
Produkt/Kapitel
200x-xx-xx
Chapter
Page number
Edition date
Document language
Documentation No.
with Index /
File name
The documentation number with its index enables you to order another copy of the
operating and maintenance instructions. The index is incremented by one every time
the manual is revised or changed.
HYDAC FILTER SYSTEMS GMBH en(us) Page 7 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Safety information and instructions
HYDAC FILTER SYSTEMS GMBH en(us) Page 8 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
Safety information and instructions
These installation and maintenance instructions contain the key instructions for
properly and safely operating the MRF.
Obligations and Liability
The basic prerequisite for the safe and proper handling and operation of the MRF is
knowledge of the safety instructions and warnings.
These operating instructions in general, and the safety precautions in particular, are
to be adhered by all those who work with the MRF.
In addition, the accident prevention rules and regulation applicable at the location of
use are to be observed.
The safety precautions listed herein are limited solely to using the MRF.
The MRF has been designed and constructed in accordance with the current state
of the art and recognized safety regulations. Nevertheless, hazards may be posed
to the life and limb of the individual using the product or to third parties. Risk of
damage may be posed to the product or other equipment and property.
Use the MRF:
Solely for its designated use
Only when in safe, perfect condition.
Immediately remedy any malfunctions that might impair safety.
Our General Terms and Conditions apply. They are provided to the owner upon
conclusion of purchase of the unit at the latest. Any and all warranty and liability
claims for personal injuries and damage to property shall be excluded in the event
they are attributable to one or more of the following causes:
improper use of the MRF or use deviating from its designated use
improper assembly, installation, commissioning, operation and maintenance of
the MRF
modifications to the MRF made by the user or purchaser
improperly performed repair work
Always keep these instructions near the unit.
In addition to the operating instructions, the general and local regulations on
accident prevention and environmental protection are to be made available and
observed.
All safety guidelines and hazard warnings on the machine must be maintained in
legible condition and replaced as required.

MRF7 Safety information and instructions
Explanation of Symbols and Warnings, etc.
The following designations and symbols are used in this manual to designate
hazards, etc.:
DANGER
DANGER denotes situations
which can lead to death if
safety precautions are not
observed.
WARNING
WARNING denotes situations
which can lead to death if
safety precautions are not
observed.
CAUTION
CAUTION denotes situations
which can lead to severe
injuries if safety precautions
are not observed.
NOTICE
NOTICE denotes situations
which can lead to property
damage if safety precautions
are not observed.
Proper/Designated Use
The MultiRheo Filter MRF is a stationary filtration unit used for full-flow or bypass
filtration of low-viscosity fluids.
Proper or designated use of the product extends to the following:
Maintaining adherence to all the instructions contained herein.
Performing requisite inspection and maintenance work.
Improper Use or Use Deviating from Intended Use
Improper use may result in hazards.
Example of improper use:
Improper connection of the pressure and return flow hoses and oil leakage pipe.
Noncompliance with the restrictions on use
HYDAC FILTER SYSTEMS GMBH en(us) Page 9 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Safety information and instructions
HYDAC FILTER SYSTEMS GMBH en(us) Page 10 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
Training of personnel
The MRF may only be operated by properly trained and instructed personnel.
The areas of responsibility of your staff must be established in a clear-cut manner.
Staff undergoing training may not use the MRF unless supervised by an
experienced staff member.
Individuals Instructed individuals Personnel with technical training/engineering background Electricians Supervisor with the appropriate authority
Activity
Packing / Transportation X X X
Commissioning X X X
Operation X X X X
Troubleshooting/
locating the source of malfunction X X X
Troubleshooting, mechanical
problem X X
Remedying of electrical faults X X
maintenance X X X X
Servicing X
Decommissioning / Storage X X X X

MRF7 Unpacking MRF
Dangers by pressure in the hydraulic system
WARNING
Hydraulic systems are pressurized
Danger of bodily injury
►The hydraulic system must be depressurized
before performing any work on the hydraulic
system
MRF modification
Do not make any modifications (design modifications, extensions) to the MRF
without the prior consent of the manufacturer.
Immediately replace any unit components which are not in perfect condition.
Use only original spare parts (OEM).
Unpacking MRF
When receiving and unpacking the unit, check it for damage in transit.
The connectors/ports are closed off so that no contamination can enter the unit
while it is in transit.
Dispose of the packaging material as appropriate for your area.
Storing the MRF
Store the filter in a clean, dry place.
Drain the filter housing completely before putting it into storage.
Check the external corrosion protection (paint coat) for damage, apply a new coat or
touch up the existing one as needed.
Wet the cleaned filter interior and all sealing surfaces such as the flange with a
suitable corrosion inhibitor, e.g. ANTICORIT 3 by Fuchs-DEA.
Storage temperature: 5 … 30°C
Humidity: up to 50% relative humidity
HYDAC FILTER SYSTEMS GMBH en(us) Page 11 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Checking the scope of delivery
Checking the scope of delivery
Upon receiving the MRF check it for any damage in transit. Do not put the MRF into
operation unless it is in perfect condition. Report any damages in transit to the
transport company or the responsible agent immediately. Do not put the unit into
operation.
The following items are included in the scope of delivery:
Item Qty. Designation
1 1 MultiRheo Filter
- 104/- Filter elements (type and quantity as per order)
- 1 Installation and Maintenance Instructions
HYDAC FILTER SYSTEMS GMBH en(us) Page 12 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Technical specifications
HYDAC FILTER SYSTEMS GMBH en(us) Page 13 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
Technical specifications
The MultiRheo Filter MRF is a stationary filtration unit used for full-flow and bypass
filtration of low-viscosity fluids for the separation of particles of 100 ... 1 µm
(absolute).
The MultiRheo Filter is part of a filter series for the use of Flexmicron filter elements.
Restrictions pertaining to use
NOTICE
Impermissible operating media
The filter will be damaged.
►The unit is only to be used with mineral oils or mineral oil-based raffinates or
for cooling lubricants.

MRF7 Calculating the pressure differential of the filter housing / filter element
Calculating the pressure differential of the filter housing / filter
element
The total pressure of the filters at a specific flow rate is comprised of the housing
and the filter element . The pressure loss of the housing can be determined
using the following pressure loss curve. The pressure loss of the filter elements is
computed on the basis of the R factors.
pp
Housing : Pressure loss curve, housing
p
The upper housing curve holds for mineral oil with a density of 0.86 kg/dm³ and a
kinematics viscosity of 30 mm²/s. The lower housing curve holds for water at 20°C.
For turbulent flow, the differential pressure will change proportionally to the density;
for laminar flow, it will change proportionally to the density and viscosity. The flow
velocity should not exceed 3 m/s at the filter inlet for oil and 4 m/s for water.
Connection DIN DN 100
Differential pressure (bar)
Flow rate (l/min)
HYDAC FILTER SYSTEMS GMBH en(us) Page 14 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Calculating the pressure differential of the filter housing / filter element
connection DIN DN 200
Differential pressure (bar)
Flow rate (l/min)
Filter element- : pressure loss calculation, filter elementp
The following calculation is based on clean filter elements:
1000)(
min)/()/²(
)( 



inchLn
lQsmmVR
barp
R = R Factor
V = viscosity (mm²/s)
Q = flow rate (l/min)
N = Numbers of elements
L = Length of element (inch)
HYDAC FILTER SYSTEMS GMBH en(us) Page 15 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Calculating the pressure differential of the filter housing / filter element
HYDAC FILTER SYSTEMS GMBH en(us) Page 16 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
R (Resistance) Factors
Filter material
Abbreviation = Designation
PA = Polyamide
PP = Polypropylene
PES = Polyester
GF = Glass fiber
Maximum differential pressure at the filter element
The maximum differential pressure Δpmax and the permitted temperature at the filter
element are:
Filter material
Fluid temperature PP PA PES
-10 ... 30 °C 4 bar 7 bar 8 bar
-10 ... 60 °C 2 bar 5.5 bar 6.5 bar
-10 ... 100 °C - 3.5 bar 5 bar
Filter element FlexMicron P (Premium)
Aqueous fluids Oils
Filtration rating PES* PES* GF**
1 µm 32.0 10.4 5.4
3 µm 24.0 7.5 -
5 µm 18.0 4.4 4.3
10 µm 17.0 1.8 3.2
20 µm 15.0 1.8 -
30 µm 14.0 0.9 -
40 µm 14.0 0.9 -
* ß > 5,000
** ß > 20,000

MRF7 Calculating the pressure differential of the filter housing / filter element
HYDAC FILTER SYSTEMS GMBH en(us) Page 17 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
Filter element FlexMicron S (Standard)
Aqueous fluids
Filtration rating PA PP
1 µm 274 321
3 µm 116 186
5 µm 42 132
10 µm 15 99
20 µm 11 54
30 µm 6.0 16
40 µm 3.8 12
50 µm 1.9 10
70 µm 1.1 8
90 µm 0.6 6
Filter element FlexMicron E (Economy)
Aqueous fluids
Filtration rating PP
1 µm 37
3 µm 29
5 µm 20
10 µm 11
20 µm 8.0
30 µm 6.8
40 µm 5.4
50 µm 4.2
70 µm 3.1

MRF7 MRF components
MRF components
Item Designation
1 Body
2 Cover
3 crank screw
4 Air bleed plug
5 Inlet flange (IN)
6 Outlet flange (OUT)
7 Drain valve, clean side
8 Drain valve, dirt side
9 clogging indicator (optional)
10 Cover lifting device
HYDAC FILTER SYSTEMS GMBH en(us) Page 18 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Hydraulic diagram
Hydraulic diagram
Item Designation
4 Deaerating
5 Inlet flange (IN)
6 Outlet flange (OUT)
7 Drain valve, clean side
8 Drain valve, dirt side
9 clogging indicator (optional)
HYDAC FILTER SYSTEMS GMBH en(us) Page 19 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25

MRF7 Dimensions
Dimensions
HYDAC FILTER SYSTEMS GMBH en(us) Page 20 / 32
MoWa MRF7 3635531 en-us 2011-05-25.doc 2010-05-25
