Installing the Enterasys Wireless Controller C5110
Unpacking the Controller
1. Unpackyourcontrollerandconfirmthatthecartoncontainsthe
followingcontents:
‐TheEnterasysWirelessControllerC5110
‐AProductInformationGuide
‐Arackmountingkit,includingdocumentation
‐TwoACpowercables
‐Frontpanelbezel
‐ThisQuickReference
2. ReadtheincludedProductInformationGuideforSafetyandRegulatory
Complianceinformation.
Mounting the Controller
Ifyouareinstallingthecontrollerinarack:
1. ReadtheRackInstallationGuideincludedwiththerackmountingkit.
Referto“InstallinginaRack”and“RackMountingKitDetails”below
formoreinformationabouttherackmountingkit.
2. Installtherailsandthecontrollerintherack.
Ifyouaretablemountingthecontroller,ensureatleast6cmofclearance
onallsidesofthecontrollerforproperventilation.
Connecting to Power
RefertoFigure 1forthelocationofthebackpanelfeatures.
1. ConnectthetwoACpowercablesshippedwiththecontrollerto
powersupplies1and2.Thesetwopowersuppliescombinetocreatea
redundantpowersupply.
2. Optionally,secureandbundlethesystemcableswiththeVelcrostraps
thatshippedwithyoursystem.Loopthepowercableandusethe
Velcrostrapstoattachthecabletothehandle.
3. Plugtheotherendofthecablesintogroundedelectricaloutletsorto
separatepowersourcessuchasanuninterruptedpowersupply(UPS)
orapowerdistributionunit(PDU).
4. Poweronthecontroller.Thepowerbuttonisonthefrontpanelas
showninFigure 2.
Figure 1 Enterasys Wireless Controller C5110 Back Panel Layout
Electrical Hazard: Only qualified personnel should perform installation
procedures.
Caution: An antistatic wrist strap is required to perform the following
procedures to minimize ESD damage to the devices involved.
1Serial connector 8Not used
2Data port, 10 GbE SR-XFP single
port NIC (esa1)
9System status indicator connector
3Video connector (not used) 10 System status indicator
4USB connectors (2) 11 System ID button
5Data port, 10 GbE SR-XFP single
port NIC (esa2)
12 AC Power supply 1 (PS1)
6Management port, Ethernet
connector, 1 GbE RJ45 (Admin)
13 AC Power supply 2 (PS2)
7Data port, 1 GbE RJ45 (esa0)
Note: Although the controller has 4 USB connectors (2 on the front panel
and 2 on the back panel), only one USB connector can be in use at any one
time.
Redundant Power Supply Indicator Codes
Indicatorsontheredundantpowersuppliesshowwhetherpoweris
presentorwhetherapowerfaulthasoccurred.SeeTabl e 1fordescriptions
oftheindicators’functions.
Ifaproblemwiththepowerredundancyoccurs,theSystemstatus
indicatorblinksamber,andthefollowingmessageisdisplayed,inaloop,
ontheLCDpanel:E1614PS<#>StatusE161CPS<#>InputLostE1624PS
Redundancy.
Figure 2 Enterasys Wireless Controller C5110 Front Panel Layout
Hard Drive LED Indicator Patterns
TheharddrivehastwoLEDindicatorsvisiblefromthefrontofthesystem
—oneagreenLEDfordiskactivity,andtheotherisdisabledandalways
off.TheactivityLEDhasthefollowingstates,asdescribedinTable 2.
Attaching the Front Bezel
Thecontrollercomeswithanoptionalfrontpanelbezel,whichcanbe
attachedtothefrontofthechassisbysnappingitonthechassishandles.A
keylockallowsyoutolockthebezelinplacetorestrictaccesstothe
controlsonthefrontpanel.You canmonitorthesystemstatusindicators
withthebezelinplace.
Figure 3 Attaching Optional Bezel
Table 1 Redundant Power Supply Indicators
Indicator Function
Green Indicates that the power supply is operational and
providing DC power to the system.
Amber Indicates a problem with the power supply.
Alternating green/amber When hot-adding a power supply, indicates that the
power supply is mismatched with the other power supply
(High Output power supply and an Energy Smart power
supply are installed in the same system).
1Power button, power-on indicator 6LCD panel
2NMI button (not used) 7Slot for DVD drive (not used)
3USB 2.0 compliant connectors
(2)
8System ID button
4Video connector (not used) 9SATA 250 GB hard drive
5LCD buttons
Table 2 Hard Drive LED Indicator patterns
Hard Drive Condition Activity LED Patterns
Active or idle power
condition
The LED is normally off, but flashes on and off when
commands are processed.
Standby or stopped power
condition
LED off.
Spinup/Spindown LED flashes in .5 second intervals.
1Release latch 3Bezel cover
2Keylock 4Hinge tab
Replacing a Power Supply
Thecontrollerhastwopowersupplies,supplyinghot‐pluggablepower
redundancy.Thesystemdistributesthepowerloadacrossbothpower
suppliestomaximizeefficiency.Whenapowersupplyisremovedwith
thesystempoweredon,thefullpowerloadispickedupbytheremaining
powersupply.
Removing a Power Supply
1. Disconnectthepowercablefromthepowersource.
2. Disconnectthepowercablefromthepowersupplyandremovethe
Velcrostrapsthatbundleandsecurethesystemcables,ifinstalled.
3. Releasethelockingtabontheleftsideofthepowersupplybypressing
intowardtheright,asshowninFigure 4.
4. Pullthepowersupplystraightouttoreleaseitfromthepower
distributionboardandclearthechassis.
Figure 4 Installing and Removing the Power Supply
Replacing a Power Supply
1. Slidethenewpowersupplystraightintothechassis.SeeFigure 4.
2. Pushthehandleallthewaydownuntilitiscompletelyflushwiththe
powersupplyfaceplateandthelockingtabengages.
3. Connectthepowercabletothepowersupply.
4. Optionally,secureandbundlethesystemcableswiththeVelcrostraps
thatshippedwithyoursystem.Loopthepowercableandusethe
Velcrostrapstoattachthecabletothehandle.
5. Plugtheotherendofthecableintoapowerdistributionunit(PDU)or
poweroutlet.
6. Allowseveralsecondsforthesystemtorecognizethepowersupply
anddeterminewhetheritisworkingproperly.Thepowersupply
statusindicatorwillturngreentosignifyproperfunctioning.See
Table 1.
Configuring the Enterasys Wireless Controller C5110
AconfigurationwizardisnowavailabletohelpconfiguretheEnterasys
WirelessController.Thewizardguidesyouthroughtheinitialsystem
configurationstepsthatarenecessarytodeploytheEnterasysWireless
Controller.Thewizardisautomaticallylaunchedwhenanadministrator
logsintotheEnterasysWirelessControllerforthefirsttime.
Alternatively,youmaystillelecttoprovisionthesystembymeansof
directelementconfigurationasdescribedindetailintheHiPathWireless
Controller,AccessPointsandConvergenceSoftwareGettingStartedGuideand
HiPathWirelessController,AccessPointsandConvergenceSoftwareUser
Guide.
Fordetailedconfigurationinformation,refertotheHiPathWireless
Controller,AccessPointsandConvergenceSoftwareGettingStartedGuideand
HiPathWirelessController,AccessPointsandConvergenceSoftwareUserGuide
locatedatthefollowinglink:
http://www.enterasys.com/support/manuals/h‐l.html#H
Note: The system requires one power supply to operate the system
normally. Remove and replace only one power supply at a time in a system
that is powered on.
1Power supply 2Velcro strap 3Release latch
Configure the Management Interface
YoucanretainthedefaultIPaddressofthecontroller’smanagement
interfaceifyoudonotintendtoconnectthecontrollertoyourenterprise
network.Ifyoudointendtoconnectthecontrollertoyournetwork:
1. Connectalaptoptothemanagementportofthecontroller.
2. ConfiguretheEthernetportofthelaptopwithastaticallyassigned
unusedIPaddressinthe192.168.10.0/24subnet.
3. LaunchyourWebbrowserandinthebrowseraddressbar,type
https://192.168.10.1:5825.(192.168.10.1isthedefaultIPaddressonthe
controller’smanagementport.)
ThislaunchestheHiPathWirelessAssistantonthecontrollerandthe
logonscreenisdisplayed.
4. IntheUserNamebox,typeadmin,andinthePasswordbox,type
abc123.
5. ClickLogin.
6. Fromthemainmenu,clickWirelessControllerConfiguration.
7. Intheleftpane,clickIPAddresses.TheInterfacestabisdisplayed.
8. ClicktheManagementPorttab.
9. Typethefollowinginformation:
–Hostname–ThenameoftheEnterasysWirelessControllerC5110
–Domain–TheIPdomainnameoftheenterprisenetwork
–IPAddress–ThenewIPaddressforthecontroller’smanagement
port.Changethisasappropriatefortheenterprisenetwork.
–Subnetmask–TheappropriatesubnetmaskfortheIPaddressto
separatethenetworkportionfromthehostportionoftheaddress
(typically255.255.255.0)
–ManagementGateway–Thedefaultgatewayofthenetwork
10. Intheleftpane,clickDNSServers.TheDNSServersscreenis
displayed.Typethefollowing:
–PrimaryDNS–TheprimaryDNSserverusedbythenetwork
–SecondaryDNS–ThesecondaryDNSserverusedbythenetwork
11. ClickSave.TheIPaddressesarenowsettothenetworkyoudefined.
TheWebconnectionbetweenthelaptopandthecontrollerisended.
12. Disconnectyourlaptopfromthecontroller’smanagementport.
13. Connectthecontroller’smanagementporttotheenterpriseEthernet
LAN.
14. LogontotheHiPathWirelessAssistant.Thesystemisnowvisibleto
theenterprisenetwork.
Configure the System
1. Beforeyoubeginconfiguration:
ResearchthetypeofWLANdeploymentthatisrequired.Forexample,
SSIDs,securityrequirements,andfilterpolicies.
2. Preparethenetwork:
Ensurethatoptionalexternalservers(forexample,DHCPand
RADIUSservers)areavailableandappropriatelyconfigured.
3. UsingtheHiPathWirelessAssistant,configuretheIPaddressesofthe
controller’sdataports,port1throughport4.
–ConfigurethedefaultIPaddressestobetherelevantsubnetpointof
attachmenttotheexistingnetwork,andsetuptheroutingprotocol
table.ThedefaultIPaddressis10.0.#.1.
–ConfigurethedataportstobeonseparateVLANs.
–Tomanagethecontrollerthroughtheinterface,selecttheMgmt
checkboxontheInterfacestab.
4. Selectthecountryandtimezone,thenrestartthecontroller.
5. Installthecontrollerlicenseandconfirmthelatestfirmwareversionis
loaded.
6. ConfiguretheVNS.
7. Install,register,andassignWirelessAPstotheVNS.
ForinformationoninstallingandpoweringtheWirelessAPs,seethe
EnterasysWirelessdocumentationat
http://www.enterasys.com/support/manuals/h‐l.html#H

Installing in a Rack
ArackmountingkitandRackInstallationInstructionsareincludedwith
thecontroller.Therackmountingkitallowsyoutoinstallthecontroller
intoafour‐postrackcabinet.Refertotheinstallationguideforcomplete
installationinstructions.
Rack Mounting Kit Details
MountingInterface:ReadyRails™
RailType: Sliding
RackTypes Supported:4‐PostSquareHolesand4‐PostUnthreaded
RoundHoles
RackAdjustabilityRange:(representstheallowabledistancebetweenthe
outside‐facingsurfacesofthefrontandrearmountingpostsoftherack)
SquareHoles:
Minimum:692mm(27.2in)
Maximum:756mm(29.7in)
RoundHoles:
Minimum:678mm(26.7in)
Maximum:749mm(29.5in)
RailDepth:(representstheminimumdepthoftherailasmeasuredfrom
therackfrontmountingpostswhentherailrearbracketispositionedall
thewayforward)
WithoutCableManagementAssembly:768*mm(30.2in)
(*WithouterCMAbracketsremoved)
WithCableManagementAssembly:887mm(35in)
Getting Help
Foradditionalsupportrelatedtoyourmodule,orthisdocument,contact
EnterasysNetworksusingoneofthefollowingmethods:
DocumentationURL:http://www.enterasys.com/support/manuals
Notice
Enterasys Networksreservestherighttomakechangesinspecificationsandother
informationcontainedinthisdocumentanditswebsitewithoutpriornotice.The
readershouldinallcasesconsultEnterasys Networkstodeterminewhetheranysuch
changeshavebeenmade.
Thehardware,firmware,orsoftwaredescribedinthisdocumentissubjecttochange
withoutnotice.
INNOEVENTSHALLENTERASYS NETWORKSBELIABLEFORANY
INCIDENTAL,INDIRECT,SPECIAL,ORCONSEQUENTIALDAMAGES
WHATSOEVER(INCLUDINGBUTNOTLIMITEDTOLOSTPROFITS)ARISING
OUTOFORRELATEDTOTHISDOCUMENT,WEBSITE,ORTHEINFORMATION
CONTAINEDINTHEM,EVENIFENTERASYS NETWORKSHASBEENADVISED
OF,KNEWOF,ORSHOULDHAVEKNOWNOF,THEPOSSIBILITYOFSUCH
DAMAGES.
Enterasys Networks, Inc.
50MinutemanRoad
Andover,MA01810
©2009Enterasys Networks, Inc.Allrightsreserved.
PartNumber: 9034514‐01 September 2009
ENTERASYS,ENTERASYSNETWORKS,ENTERASYSSECURENETWORKS,
ENTERASYSMATRIX,andanylogosassociatedtherewith,aretrademarksor
registeredtrademarksofEnterasysNetworks,Inc.,intheUnitedStatesand/orother
countries.ForacompletelistofEnterasystrademarks,see
http://www.enterasys.com/company/trademarks.aspx.
Allotherproductnamesmentionedinthismanualmaybetrademarksorregistered
trademarksoftheirrespectivecompanies.
Regulatory Compliance Information
Forcompleteregulatorycomplianceandsafetyinformation,refertotheProduct
InformationGuidethatwasshippedwiththisproduct.
World Wide Web www.enterasys.com/support/
Phone
1-800-872-8440 (toll-free in U.S. and Canada)
or 1-978-684-1000
For the Enterasys Networks Support toll-free number in
your country:
www.enterasys.com/services/support/contact/
Internet mail
[email protected]
To expedite your message, type [Wireless] in the subject
field of your message.
The latest image and
release notes
www.enterasys.com/services/support/downloads/software
Federal Communications Commission (FCC) Notice
ThisproducthasbeentestedandfoundtocomplywiththelimitsforaclassAdigital
device,pursuanttoPart15oftheFCCrules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferencewhentheequipmentisoperated
inacommercialenvironment.Thisproductuses,generates,andcanradiateradio
frequencyenergyandifnotinstalledandusedinaccordancewiththemanufacturer’s
instructionmanual,maycauseharmfulinterferencetoradiocommunications.
Operationofthisproductinaresidentialareaislikelytocauseharmfulinterference,
inwhichcaseyouwillberequiredtocorrecttheinterferenceatyourownexpense.
ThisdevicecomplieswithPart15oftheFCCrules.Operationissubjecttothe
followingtwoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)
thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
Notice: TheFCCregulationsprovidethatchangesormodificationsmadetothis
devicewhicharenotexpresslyapprovedbyDell™Inc.couldvoidyourauthorityto
operatetheequipment.
DellInc.istheresponsiblepartyforthisproduct.ForanEMCcomplianceissueora
regulatoryinquiry,pleaseusethefollowingcontactinformation:
DellInc.
WorldwideRegulatoryCompliance,EngineeringandEnvironmentalAffairs
OneDellWayPS4‐30
RoundRock,Texas78682USA
512‐338‐4400
Industry Canada, Class A
ThisClassAdigitalapparatuscomplieswithCanadianICES‐003.
Notice:TheIndustryCanadaregulationsprovidethatchangesormodificationsnot
expresslyapprovedbyDellInc.couldvoidyourauthoritytooperatethisequipment.
CetappareilnumériquedelaclasseAestconformeàlanormeNMB‐003duCanada.
Avis:Danslecadredesréglementationsd’IndustryCanada,vosdroitsd’utilisation
decetéquipementpeuventêtreannuléssideschangementsoumodificationsnon
expressémentapprouvésparDellInc.ysontapportés.
CE Notice
Thisproducthasbeendeterminedtobeincompliancewith2006/95/EC(LowVoltage
Directive),2004/108/EC(EMCDirective),andamendmentsoftheEuropeanUnion.
Ver sionsofthisproductmayhaveintegratedmodulesoradd‐incardssupporting
wirelessandtelecommunicationsoperations.Thesewirelessandtelecommunications
peripheralshavebeenassessedascompliantinthisproductand,whenpresent,arein
compliancewith1999/5/EC(R&TTEDirective,forRadioandTelecommunications
Interfaces).
European Union, Class A
War ning:ThisisaClassAproduct.Inadomesticenvironmentthisproductmay
causeradiofrequencyinterferenceinwhichcasetheusermayberequiredtotake
adequatemeasures.
A“DeclarationofConformity”inaccordancewiththeprecedingdirectivesand
standardshasbeenmadeandisonfileatDellInc.ProductsEuropeBV,Limerick,
Ireland.
VCCI Notice
ThisisaclassAproductbasedonthestandardoftheVol untaryControlCouncilfor
InterferencebyInformationTechnologyEquipment(VCCI).Ifthisequipmentisused
inadomesticenvironment,radiodisturbancemayarise.Whensuchtroubleoccurs,
theusermayberequiredtotakecorrectiveactions.
BSMI EMC Statement — Taiwan
ThisisaclassAproduct.Inadomesticenvironmentthisproductmaycauseradio
interferenceinwhichcasetheusermayberequiredtotakeadequatemeasures.
Hazardous Substances
ThisproductcomplieswiththerequirementsofEuropeanDirective,2002/95/EC,
RestrictionofHazardousSubstances(RoHS)inElectricalandElectronicEquipment.
European Waste Electrical and Electronic Equipment (WEEE) Notice
InaccordancewithDirective2002/96/ECoftheEuropeanParliamentonwaste
electricalandelectronicequipment(WEEE):
1. Thesymbolaboveindicatesthatseparatecollectionofelectricalandelectronic
equipmentisrequiredandthatthisproductwasplacedontheEuropeanmarket
afterAugust13,2005,thedateofenforcementforDirective2002/96/EC.
2. Whenthisproducthasreachedtheendofitsserviceablelife,itcannotbedisposed
ofasunsortedmunicipalwaste.Itmustbecollectedandtreatedseparately.
3. IthasbeendeterminedbytheEuropeanParliamentthattherearepotential
negativeeffectsontheenvironmentandhumanhealthasaresultofthepresence
ofhazardoussubstancesinelectricalandelectronicequipment.
4. Itistheusers’responsibilitytoutilizetheavailablecollectionsystemtoensure
WEEEisproperlytreated.
Forinformationabouttheavailablecollectionsystem,pleasegoto
www.enterasys.com/services/support/ orcontactEnterasysCustomerSupportat
35361705586(Ireland).
Declaration of Conformity
A“DeclarationofConformity”inaccordancewiththeprecedingdirectivesand
standardshasbeenmadeandisonfileatDellInc.ProductsEuropeBV,Limerick,
Ireland.
ѻક䇈ᯢк䰘ӊ
Supplement to Product Instructions
᳝↦᳝ᆇ⠽䋼៪ܗ㋴(Hazardous Substance)
䚼ӊৡ⿄
(Parts) 䪙
3E
∲
+J
䬝
&G
݁Ӌ䫀
&U
໮⒈㘨㣃
3%%
໮⒈Ѡ㣃䝮
3%'(
䞥ሲ䚼ӊ
(Metal Parts) hƻƻhƻƻ
⬉䏃῵ഫ
(Circuit Modules) hƻƻhƻƻ
⬉㓚ঞ⬉㓚㒘ӊ
(Cables & Cable Assemblies) hƻƻhƻƻ
ล᭭㘮ড়⠽䚼ӊ
(Plastic and Polymeric parts) ƻƻƻƻƻh
⬉䏃ᓔ݇
(Circuit Breakers) ƻƻhhƻƻ

ƻ˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼೼䆹䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ৿䞣ഛ೼ SJ/T 11363-2006 󰵼ޚ㾘ᅮⱘ䰤䞣㽕∖ҹϟDŽ
Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is
below the relevant threshold of the SJ/T 11363-2006 standard.
h˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ೼䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ёⱘ৿䞣䍙ߎSJ/T 11363-2006 󰵼ޚ㾘ᅮⱘ䰤䞣㽕∖DŽ
Indicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T 11363-2006 standard.

ᇍ䫔ଂП᮹ⱘ᠔ଂѻકᴀ㸼ᰒ⼎
߃߯կᑨ䫒ⱘ⬉ᄤֵᙃѻકৃ㛑ࣙ৿䖭ѯ⠽䋼DŽ⊼ᛣ೼᠔ଂѻકЁৃ㛑Ӯгৃ㛑ϡӮ৿᳝᠔᳝᠔߫ⱘ䚼ӊDŽ
This table shows where these substances may be found in the supply chain of Enterasys’ electronic
information products, as of the date of sale of the enclosed product. Note that some of the component types
listed above may or may not be a part of the enclosed product.

50
ℸ⦃ֱՓ⫼ᳳ䰤া䗖⫼Ѣѻકᰃ೼ѻક᠟ݠЁ᠔㾘ᅮⱘᴵӊϟᎹ԰
The Environmentally Friendly Use Period (EFUP) for all enclosed products and their parts
are per the symbol shown here, unless otherwise marked. Certain parts may have a
different EFUP (for example, battery modules) and so are marked to reflect such. The
Environmentally Friendly Use Period is valid only when the product is operated under the
conditions defined in the product manual.
䰸䴲঺໪⡍߿ⱘ󰵼⊼ℸ󰵼ᖫЎ䩜ᇍ᠔⍝ঞѻકⱘ⦃ֱՓ⫼ᳳ󰵼ᖫᶤѯ䳊䚼ӊӮ
᳝ϔϾϡৠⱘ⦃ֱՓ⫼ᳳ՟བ⬉∴ܗ῵ഫ䌈೼݊ѻકϞ
Enterasys®Wireless
Controller C5110
Quick Reference
P/N 9034514-01
