Installation
mode
16
ON
OFF
6 ° -6 °
26 °
44 °
MANUFACTURER'S STATEMENT
OUTER DIMENSIONS AND PART NAMES
(1) Connector
(2) Mounting holes
(3) Operation indicator
(4) Depth angle adjustment screw
(5) Width adjustment screws
(6) Function key
(7) Dipswitches
(8) Detection window
(9) Area adjustment tool
Model
Cover color
Mounting height
Detection area
Detection method
Depth angle
adjustment
Power supply (*2 )
Power consumption
Operation indicator
Test input
Activation output
: PASAA2
: Black
: 2.0 (6'6") to 3.0m (9'10")
: See DETECTION AREA
: Active infrared reflection (*1 )
: 1st to 3rd rows / -6 to +6°
4th and 5th rows / +26 to +44°
: 12 to 24VAC ±10% (50 / 60 Hz)
12 to 30VDC ±10%
: < 2.5W (< 4VA at AC)
: See chart below
: Opto coupler
Voltage / 5 to 30VDC
Current / 6mA Max. (30VDC)
: When 3rd, 4th or 5th row detects.
Form A relay
50V 0.3A Max. (Resistance load)
Safety / Test output
Output hold time
Response time
Operating temperature
Operating humidity
IP rate
Category
Weight
Accessories
Performance level
: When 1st or 2nd row detects.
Opto coupler (NPN)
Voltage / 5 to 50VDC
Current / 100mA Max.
Dark current / 600nA Max.
(Resistance load)
: Approx. 0.5 sec.
: <0.3 sec.
: -20 to +55°C (-4 to 131°F)
: <80%
: IP54
: 2 (EN ISO 13849-1 : 2008)
: d (EN ISO 13849-1 : 2008)
: 320g (11.2oz )
: 1 Operation manual
2 Mounting screws
1 Mounting template
1 Area adjustment tool
1 Cable 3m (9'10")
(8 × 0.22mm² AWG24 ) (*3 )
The specifications herein are subject to change without prior notice due to improvements.
NOTE
*1 : The 1st and 2nd rows have presence detection function.
*2 : When using this sensor, the sensor has to be connected to a door system which has the SELV circuit.
*3 : Overcurrent protection with less than 2A.
It is required to check the operation manual if this symbol is shown on the product.
MANUFACTURER'S STATEMENT
WARNING Do not wash, disassemble, rebuild or repair the sensor, otherwise
it may cause electric shock or breakdown of the equipment.
Danger of electric shock.
WARNING
CAUTION
NOTE
Disregard of warning may cause the improper operation causing death or serious injury of
a person.
Special attention is required to the section of this symbol.
Disregard of caution may cause the improper operation causing injury of a person or damage to
objects.
NOTE
Read this operation manual carefully before use to ensure proper operation of this product.
Failure to read this operation manual may cause improper operation and may result in serious injury or
death of a person.The meanings of the symbols are as follows.
1. This product is a non-contact switch intended for header mount or wall mount for use on an automatic sliding door.
Do not use for any other applications.
2. When setting the sensor's detection area, make sure that there is no traffic around the installation site.
3. Before turning the power ON, check the wiring to prevent damage or malfunction of equipment connected to
the product.
4. Only use the product as specified in the operation manual provided.
5. Be sure to install and adjust the sensor in accordance with the local laws and standards of the country in which
the product is installed.
6. Before leaving the installation site make sure that the product is operating properly and instruct the building
owner/operator on proper operation of the door and the product.
7.The product settings can only be changed by an installer or service engineer. When changed, the
changed settings and the date shall be registered in the maintenance logbook accompanying the door.
[mm (inch)]
Operation indicator
The following conditions are not suitable for sensor installation.
-Fog or exhaust emission around the door.
-Wet floor.
-Vibrating header or mounting surface.
-Moving objects or objects that emit light near the detection area.
-Highly reflecting floor or highly reflecting objects around the door.
NOTE
Stand-by (Setting mode) Blinking Blue
Stand-by (Installation mode)
Stand-by (Operation mode) Green
Wrong dipswitch setting Red & Green blinking
Signal saturation Slow Green blinking
Sensor failure Fast Green blinking
Yellow
1st row detection Blinking Red
2nd row detection
3rd, 4th or 5th row detection Orange
Red
1sec. 1sec.
Status Operation indicator color
SPECIFICATION
(9)
(1)
(5)
(4) (7)(6) (8)
(3)
(2)
Noise level : <70dBA
DETECTION AREA
Test conditions required by EN 16005
Floor : Grey paper
Detection object :
EN 16005 CA reference body
The actual detection area may become smaller depending on the ambient light, the color / material of
the object or the floor as well as the entry speed of the object.
The sensor may not be activated when the entering speed of the object or a person is slower than
50mm / sec. or faster than 1500mm / sec.
NOTE
The values above are those of the detection area when tested referring to the test conditions of EN 16005.
(The emitting area is as shown in Emitting area above.)
*: When installed at higher than 2.35m(7'8"), EN 16005 requirements are fulfilled only within the area width "I"
of 3m(9'10").
To comply with EN 16005, make sure that the detection area is within the values in the chart below.
EN 12978+A1:2009
EN 61496-3:2001 clause 4. 3. 5 and 5. 4. 7. 3
COMPLIED STANDARDS
1
3
2
CAUTION
Risk of getting caught.
Make sure to affix the mounting template as described in the above chart ,
otherwise it can be dangerous since there may be no detection area around
the threshold. Install the sensor as low as possible on the header.
WARNING
Danger of electric shock.
Do not use the sensor without the cover.
When using the cable knockout, install the sensor indoors or use the rain-cover
(Separately available) otherwise electric shock or breakdown of
the sensor may occur.
Before starting the procedure, make sure that the power is turned OFF.
When passing the cable through the hole, do not tear the shield.
otherwise it may cause electric shock or breakdown of the sensor.
To the connector
of the sensor
4
Power supply
12 to 24VAC±10% /12 to 30VDC±10%
Wire the cable to the door controller as shown below.
1.Plug the connector of the sensor.
2.Supply power to the sensor. Adjust the detection area and set the dipswitches. (See ADJUSTMENTS)
Place the housing cover.
If wiring is to be exposed, break the knockout.
}
H : Height from the floor to the bottom of the header
Y : Distance between the bottom of the header and the sensor
X : Distance between the door and the mounting surface
(The mounting height is "H + Y".)
WARNING
Danger of electric shock.
NOTE Make sure to connect the cable correctly to the door controller before turning the power ON.
When turning the power ON or after adjusting the settings, do not enter the detection area for more
than 10 seconds in order to enable the presence detection.
Do not touch the dipswitches before turning the power ON, otherwise an error occurs.
When changing the settings of dipswitch, see ADJUSTMENTS 3 Dipswitch settings.
1.White
2.Brown
3.Green
4.Yellow
5.Pink (+)
6.Blue (-)
7.Red (+)
8.Black (-)
Safety / Test output
Opto coupler(NPN) / Voltage: 5 to 50VDC
Activation output
Form A relay 50V 0.3A Max.
Test input
Opto coupler / Voltage: 5 to 30VDC
INSTALLATION
Detection area
1st row
2nd row
3rd row
4th row
5th row
: Emitting spots
: Detection Area
A
BCDEF
GG
HI
Motion / Presence
detection
Motion detection
: Emitting spots
(Can be eliminated)
Charts show the values in the following
depth angle adjustment settings ;
1st to 3rd rows : +6°
4th and 5th rows : +44°
[m(feet,inch)]
Emitting area
A
B
C
D
E
F
G
H
I (*)
X
1.35 (4' 5")
2.20 (7'2")
0.14 (6")
0.42 (1' 5")
0.82 (2' 8")
1.90 (6' 3")
1.33 (4' 4")
2.05 (6' 9")
2.78 (9' 2")
2.70 (8'10")
0.18 (7")
0.52 (1' 8")
1.00 (3' 3")
1.66 (5' 5")
2.34 (7' 8")
3.00 (9'10")
0.20 (8")
0.58 (1' 11")
1.10 (3' 7")
1.85 (6' 1")
2.60 (8' 6")
1.63 (5' 4")
2.51 (8' 3") 1.81 (5' 11") 2.79 (9' 2")
3.40 (11' 2") 3.79 (12' 5")
2.50 (8'2")
0.16 (6")
0.48 (1' 7")
0.93 (3' 1")
1.54 (5' 1")
2.17 (7' 1")
1.51 (4' 11")
2.32 (7' 7")
3.15 (10' 4")
1.23 (4' 1")
2.00 (6'6")
0.13 (5")
0.38 (1' 3")
0.74 (2' 5")
1.74 (5' 9")
1.06 (3' 6")
1.86 (6' 1")
2.52 (8' 3") 0.21 (8") 0.26 (10") 0.28 (11")0.24 (9")0.19 (8")
X is the distance between the 1st row and the mounting surface.
A
C
G
I
2.20 (7'2")2.00 (6'6") 0.24 (10")
1.10 (3' 7")
2.54 (8' 4")
0.23 (9")
1.02 (3' 4")
2.41 (7' 11")
The values above are when the sensitivity is set to "Middle" and speed of detection object is 50mm / sec..
Maximum mounting distance (Y)
X
H
Y
Sensor
Door
Header
Floor
X2.00 (6' 6") 2.30 (7' 6") 2.50 (8' 2") 2.80 (9' 2")
0No limit
0.05 (2") 0.20 (7") 0.20 (7") 0.20 (7")
0.10 (4") 0.20 (7") 0.20 (7") 0.20 (7") 0.20 (7")
0.15 (6") 0.13 (5”) 0.15 (5”) 0.19 (7") 0.20 (7")
0.20 (8") -0.12 (4”) 0.14 (5”) 0.15 (5”)
0.25 (10") 0.12 (4”)
0.30 (12") - -
H
0.20 (7")
---
- 0.11 (4")
[m (feet,inch)]
Machinery Directive 2006/42/EC
Notified Body: TÜV SÜD Product Service GmbH, Daimlerstraße 40 60314 Frankfurt Germany
3.00 (9'10")
0
0
0
0
0
-
1. Affix the mounting template at the desired mounting position.
2. Drill two mounting holes of ø3.4mm (ø1/8”).
3. To pass the cable through the header, drill a wiring hole of ø8mm (ø5/16”).
4. Remove the mounting template.
5. Remove the housing cover. Fix the sensor to the mounting surface with the two mounting screws.
(When setting the detection area close to the door, mount the sensor according to the chart below.)
EN ISO 13849-1:2008 EN ISO 13849-2:2008
EN 16005:2012
EMC Directive 2004/108/EC
0
1
1
3A/3B
1
8
41
0
To the control panel
Ditec PASAA2
IP1965
All manuals and user guides at all-guides.com
all-guides.com

Mounting height [ m (feet,inch) ]
2.0 (6' 6") 2.2 (7' 2") 2.5 (8' 2") 3.0 (9' 10")
2
1
ADJUSTMENTS
When using more than two sensors close to each other, set the different
frequency for each sensor by dipswitches 5 and 6.
3-3.Setting the frequency
3-5.Setting the immunity
Red
4th and 5th rows
Area depth angle adjustment
1st to 3rd rows
C
Area adjustment tool
AB
Area width adjustment
Blue
Use the area adjustment tool (B) as shown above to
change the area depth angle for the 4th and 5th rows.
Depth angle adjustment screw
for the 1st to 3rd rows
Depth angle adjustment screw
for the 4th and 5th rows
Use the area adjustment tool (A) as shown above to
change the area depth angle for the 1st to 3rd rows.
1-2.Simultaneous adjustment
1-1.Independent adjustment
For the simultaneous adjustment of the 1st to 5th rows, use the adjustment tool (C).
When adjusting the width adjustment screws, make sure to turn until it clicks otherwise the proper operation may not
be obtained.
cannot be eliminated separately, neither can .
Depth angle
adjustment screw
Shallow Deep
4th and 5th rows1st to 3rd rows
Width adjustment
screws (Right)
Width adjustment
screws (Left)
Dipswitch settings
Refer to the chart below for the suitable sensitivity to your installation environment.
3-1.Setting the sensitivity
3-2.Setting the presence detection timer
The 1st and 2nd rows have the presence detection function.
To comply with EN 16005, set the timer to " 30sec." or more.
To enable the presence detection, do not enter the detection area for 10 seconds after setting the timer.
When adjusting the 1st row close to the door,
follow 3-9 Installation mode for the easier adjustment.
Special attention to the setting is required when the door is used often by the elderly or children.
Please adjust the sensitivity and the presence detection timer according to your risk assessment.
For example
Floor condition
Low reflection Middle Middle High S-High -Carpet
-Dark color floor
Middle reflection Low Middle Middle -Concrete
High reflection Low Low Middle High -Tile
-Marble
S-High
When the above procedures (1-3) are not followed, an error (Red & Green blinking) occurs.
Make sure to use the sensor only in the" Operation mode".
The sensor does not operate properly in the "Setting mode".
Follow these steps to change the settings of dipswitches.
1.Change the function key from the "Operation mode" to the "Setting mode".
During the "Setting mode", the operation indicator is blinking Blue
(only when stand-by status) and the door remains open.
2.Change the dipswitch settings.
3.When the setting is finished, change the function key back to the "Operation mode".
Function key
Operation mode
Setting mode
Set the depth rows with dipswitches 7 and 8.
3-4.Setting the row adjustment
When "2rows" are selected, the activation output
is disabled.
Make sure that the detection area does not overlap with the door / header, and there is no highly reflecting
object near the detection area otherwise ghosting / signal saturation may occur.
NOTE
NOTE
NOTE
NOTE
NOTE
NOTE
INFRARED FINDER
Detection area
Detection area
1. Turn the depth angle adjustment screw to the right (Deep) to place the detection area most away from the door.
2. Set INFRARED FINDER sensitivity to "H" (High) and place it on the floor as shown below.
Area depth adjustment with INFRARED FINDER (Separately available)
REFERENCE
3. Turn the depth angle adjustment screw to the left (Shallow) until the emitting area is placed at the position where
INFRARED FINDER is in the low detection status (Slow Red blinking).
Set dipswitch 9 to ON when the sensor operates by itself (Ghosting).
3
9
9
ONOFF
65
Setting1
65
Setting2
65
Setting3
65
Setting4
21
Low
21
Middle
21
High
21
S-High
43
30sec.
43
60sec.
43
180sec.
43
87
5rows
87
4rows
87
3rows
87
2rows
NOTE When dipswitch 9 is set to ON ,the actual detection area may become smaller.
Shallow Deep
ShallowDeep
[m]
0
1.0
2.0
3.0
2.0
3.0
[m]
1.0
0
1.0
2.0
2.0
3.0
1.0
0
1.0
2.0
ShallowDeep
[m]
[m]
2.0
3.0
0
1.0
2.0
3.0
2.0
3.0
Front view
[m]
0
2.0
3.0 0
2.0 1.0 2.0
1.0
1 2 3 45 6 7 89 10 11 12
Narrow
Wide
Eliminated
Eliminated Eliminated Eliminated Narrow
Wide
Eliminated
Eliminated Eliminated Eliminated
1 2 3 10 11 12
1 2 3 10 11 12 1 2 3 10 11 12
3-6.Setting the self monitoring
10
10
DisableEnable
When the door remains open and the LED indicator shows fast or slow green
blinking, please refer to the TROUBLESHOOTING.
If the door still remains open, set dipswitch 10 to "Disable".
To comply with EN 16005 dipswitch 10 must be set to "Enable".
NOTE
Contact your installer or service engineer.
Sensor failure
Wrong wiring or connection failure Check the wires and connector.
Wrong wiring or connection failure Check the wires and connector.
Door operation Operation
indicator Possible cause Possible countermeasures
None Wrong power supply voltage Set to the stated voltage.
Wrong wiring or connection failure
Fast
Green
blinking
Signal saturation (1st or 2nd row)
Dirty detection window Wipe the detection window with a damp cloth.
(Do not use any cleaner or solvent.)
Sensitivity is too low. Set the sensitivity higher.(*)
The detection area overlaps with
the door / header. Adjust the detection area to "Deep" (Outside).
Door opens
when no one
is in the
detection area.
(Ghosting)
Unstable
Door remains
open Sudden change in the detection area. Check ADJUSTMENTS 3-1 & 3-2.(*)
If the problem still persists, hard-reset the
sensor.(Turn the power OFF and ON again.)
Slow
Green
blinking
Check the wires and connector.
Remove highly reflecting objects from the
detection area. Or lower the sensitivity.(*)
Or change the area depth angle for 1st to 3rd rows.
Wrong setting of dipswitch
Red &
Green
blinking
Door does not
open when a
person enters
the detection
area.
Unstable Wrong detection area positioning Check ADJUSTMENTS 1 , 2 & 3.(*)
Sensitivity is too low. Set the sensitivity higher.(*)
Short presence detection timer Set the presence detection timer longer.(*)
Door remains
closed.
Proper
Proper
Wrong setting of dipswitches. Check ADJUSTMENTS 3-6 ,3-7 & 3-8.(*)
Dirty detection window Wipe the detection window with a damp cloth.
(Do not use any cleaner or solvent.)
Wrong setting of function key Set to the"Operation mode".
3-7.Setting the test input, safety / test output and test input delay time
3-9.Installation mode
Set dipswitch 16 to ON when adjusting the 1st row close to the door.
When the setting is finished, set to OFF.
During the installation mode, only the 1st row remains, and the operation indicator glows Yellow.
Check the operation in the operation mode according to the chart below.
1. Always keep the detection window clean. If dirty, wipe the window with a damp cloth.(Do not use any cleaner / solvent.)
2. Do not wash the sensor with water.
3. Do not disassemble, rebuild or repair the sensor yourself, otherwise electric shock may occur.
4. When the operation indicator blinks Green, contact your installer or service engineer.
5. Always contact your installer or service engineer when changing the settings.
6. Do not paint the detection window.
WARNING
1. When turning the power ON, always walk-test the detection area to ensure the proper operation.
2. Do not place any objects that move or emit light in the detection area. (e.g. Plant, illumination, etc.)
NOTE
3-8.Setting the activation output
Set dipswitch 14 to "N.O." (Normally Open) or "N.C." (Normally Closed) .
NOTE If the function key is set back to the "Operation mode" while the installation mode is still ON, an error occurs.
*: The test input delay time is the time period between the test input and safety / test output.
Test input
(from door controller)
Safety / Test output
(to door controller)
High
Test inputDetection
(*)Test input delay time (=t2)
Test input and Safety / Test output timing chart
12
Low
12
High
11
Low
11
CHECKING
INFORM BUILDING OWNER / OPERATOR OF THE FOLLOWING ITEMS
14
14
N.C.N.O.
16
16
ONOFF
TROUBLESHOOTING
1. Set the function key to the "Setting mode".
2. Change the dipswitch 16 setting (ON OFF or
OFF ON OFF).
3. Set the function key back to "Operation mode".
Blinking Blue
Set dipswitches 11 to 13 according to the door controller.
Proper
operation
Others Set the immunity to ON.(*)
Adjust the detection area to "Deep" (Outside).
Waterdrops on the detection window Use the rain-cover (Separately available).
Or install in a place keeping the waterdrops off.
The detection area overlaps
with that of another sensor.
Detection area overlaps with door /
header.
Check ADJUSTMENTS 3-3.(*)
Objects that move or
emit light in the detection area.
Remove the objects.
Sensitivity is too high. Set the sensitivity lower.(*)
Installation mode is set to ON.Set installation mode to OFF.(*)
Yellow
t1(>t2)
t2
* Before changing these settings, set the function key to the "Setting mode". When finished, set back to the
"Operation mode".
Remove highly reflecting objects from the
detection area. Or lower the sensitivity.(*)
Or change the area depth angle.
Signal saturation (3rd, 4th or 5th row)Slow
Green
blinking
13
13
20msec.10msec.
Status
Green
Motion
detection active
Red Blinking Red
Entry Outside of
detection
area
Outside of
detection
area
Entry into
3rd to 5th row Entry into
2nd row Entry into
1st row
Orange
Stand-by
Green
Stand-by
Operation indicator
Motion / Presence
detection active
Power OFF
-
None
Activation
output
Safety
/ Test
output
ON OFF ONOFF
OFF ON OFFOFF
High
11
Low
11
N.O.
14
N.C.
14
t2
Entrematic Group AB
Lodjursgatan, 10
SE-261 22 Landskrona - SWEDEN
www.ditecentrematic.com
All manuals and user guides at all-guides.com
