Enviro Ascot User manual

SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
BY: SHERWOOD INDUSTRIES LTD
OWNER’S MANUAL
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
50-029
ASCOT
This appliance may be installed in an after-market
permanently located, manufactured (mobile)
home, where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certied kit is used.
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open
ame.
• Do not try to light any appliance.
• Do not touch any electrical switch or
use any phone in your building.
• Immediately call your gas supplier
from a neighbour’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
WARNING
If the information in this manual
is not followed exactly, a re or
explosion may result causing property
damage, personal injury or loss of
life. Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
ammable vapours and liquids in the
vicinity of this or any other appliance.
Massachusetts installations (Warning): This product must be installed by a licensed
plumber or gas tter when installed within the Commonwealth of Massachusetts.
Other Massachusetts code requirements: Flexible connector must not be longer than
36in., a shut off valve must be installed; only direct vent sealed combustion products
are approved for bedrooms/bathrooms. A carbon monoxide detector is required in all
rooms containing gas red direct vent appliances.

2
FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER,
PLEASE CAREFULLY READ THE FOLLOWING INFORMATION:
• All ENVIRO gas-red appliances must be installed
in accordance with their instructions. Carefully read all
the instructions in this manual rst. Consult the building
authority having jurisdiction to determine the need for
a permit prior to commencing the installation.
• NOTE: Failure to follow these instructions could
cause a malfunction of the replace, which could
result in death, serious bodily injury, and/or property
damage.
• Failure to follow these instructions may also void
your re insurance and/or warranty.
GENERAL
• Installation and repair should be done by a
qualied service person. The appliance should be
inspected before the rst use and, at least, annually
by a qualied service person. More frequent
cleaning may be required due to excessive lint from
carpeting, bedding material, etc. It is imperative the
control compartments, burners and circulating air
passageways of the appliance be kept clean.
• Due to high temperatures, the appliance should
be located out of high trafc areas and away from
furniture and draperies.
Children and adults should be alerted to the
hazards of high surface temperatures and
should stay away to avoid burn or clothing
ignition.
• Young children should be carefully supervised
when in the same room as the appliance.
• Clothing or other ammable materials should not
be placed on or near the appliance.
FOR YOUR SAFETY
• Installation and service must be performed by a
qualied installer, service agency or gas supplier.
• This installation must conform to local codes or, in
the absence of local codes, to the current CAN/CGA-
B149 installation code (Canada) or National Fuel Gas
Code ANSI Z223.1.2 (USA)
• To prevent injury, do not allow anyone who is
unfamiliar with the stove to operate it.
• To prevent injury, if the pilot or pilot and
burners have gone out on their own, open the
glass door and wait 5 minutes to air out before
attempting to re-light the stove.
• Always keep the area around these appliances
clear of combustible material, gasoline and other
ammable liquids and vapours.
• These appliances should not be used as a drying
rack for clothing or for hanging Christmas stockings/
decorations.
• Due to the paint curing on the stove, a faint odor
and slight smoking will likely be noticed when the
stove is rst used. Open a window until the smoking
stops.
Always connect this gas stove to a vent system and
vent to the outside of the building envelope. Never
vent to another room or inside the building. Make sure
the specied vent pipe is used, properly sized and of
adequate height to provide sufcient draft. Inspect
the venting system annually for blockage and signs of
deterioration.
WARNING: Failure to position the parts in accordance
with the diagrams in this booklet, or failure to use only
parts specically approved with this appliance, may
result in property damage or personal injury.
WARNING: Do not operate with the glass front
removed, cracked or broken. Replacement of the
glass should be done by a licensed or qualied service
person.
• Never use solid fuels such as wood, paper,
cardboard, coal, or any ammable liquids, etc., in this
appliance.
• Do not use this heater if any part has been under
water. Immediately call a qualied service technician
to inspect the heater and to replace any part of the
control or gas control systems that have been under
water.
• Do not abuse the glass by striking it or slamming
the door shut.
Safety Precautions

3
Safety Precautions....................................................................................................2
Table of Contents......................................................................................................3
Codes And Approvals.................................................................................................4
Specications...........................................................................................................5
Dimensions....................................................................................................5
Rating Label Location.....................................................................................5
Operating Instructions...............................................................................................6
Lighting Instructions.......................................................................................6
Pilot Light......................................................................................................7
Remote controls (Optional).............................................................................7
Blower Speed (Optional).................................................................................7
Normal Sounds During Operation....................................................................7
Maintenance And Service...........................................................................................8
Routine Maintenance......................................................................................8
Cleaning The Glass.........................................................................................8
Cleaning The Firebox......................................................................................8
Change Battery in Ignition Module...................................................................8
Replacing Glass..............................................................................................9
Glass Door Removal.......................................................................................9
Burner Removal.............................................................................................9
Fuel Conversion............................................................................................10
Initial Installation....................................................................................................12
Preparation For Installation...........................................................................12
Clearances to Combustibles...........................................................................12
Planning Your Installation.............................................................................13
Vent Termination Restrictions........................................................................14
Fireplace Horizontal Vent Kit 50-1235.............................................................15
Other Approved Vent Parts............................................................................16
Vent Restrictor Setting..................................................................................18
Horizontal Installation...................................................................................19
Vertical Installation.......................................................................................22
Freestanding Drafthood Adaptor - 50-841......................................................25
Hearth Mount Installation.............................................................................28
Gas Line Connection and Testing...................................................................29
Electrical Requirements.................................................................................30
Secondary Installation.............................................................................................31
Installation of Log Set and Embers................................................................31
Installation of Optional Blower.......................................................................33
Trouble Shooting.....................................................................................................34
Parts List................................................................................................................35
Parts Diagram.........................................................................................................38
Warranty................................................................................................................39
Installation Data Sheet............................................................................................40
Table of Contents

4
DIRECT VENT ONLY: This type is identied by the sufx DV. This appliance draws all of its air for
combustion from outside the dwelling, through a specially designed vent pipe system.
** TOP VENT DV ONLY** This appliance has been tested and approved for installations from 0 feet to
4500 feet (1372 m) above sea level.
In the USA: The appliance may be installed at higher altitudes. Please refer to your American Gas
Association guidelines which state: the sea level rated input of Gas Designed Appliances installed at
elevations above 2000 (610 m) feet is to be reduced 4% for each 1000 feet (305 m) above sea level.
Refer also to local authorities or codes which have jurisdiction in your area regarding the de-rate
guidelines.
In Canada: When the appliance is installed at elevations above 4500 feet (1372 m), the certied high
altitude rating shall be reduced at the rate of 4% for each additional 1000 feet (305 m).
• This appliance has been tested by INTERTEK (Warnock Hersey) and found to comply with the
established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows:
VENTED GAS FIREPLACE HEATER (ASCOT DV; NG/LPG)
TESTED TO: ANSI Z21.88a-2003/CSA 2.33a-2003 VENTED GAS FIREPLACE HEATERS
CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES
CSA P.4.1-02 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY
This ENVIRO ASCOT Fireplace:
• Has been certied for use with either natural or propane gases. (See rating label.)
• Is not for use with solid fuels.
Codes And Approvals
• Is approved for bedroom or bed sitting room. (IN CANADA: must be
installed with a listed wall thermostat. IN USA: see current ANSI Z223.1
for installation instructions.)
• Must be installed in accordance with local codes. If none exist, use current
installation code CAN/CGA B149 in Canada or ANSI Z223.1/NFPA 54 in the
USA.
• Must be properly connected to an approved venting system and not
connected to a chimney ue serving a separate solid-fuel burning
appliance.
IMPORTANT NOTICE (Regarding rst re up): When the unit is turned
on for the rst time, it should be turned onto high without the fan on for
the rst 4 hours. This will cure the paint, logs, gasket material and other
products used in the manufacturing process. It is advisable to open a
window or door, as the unit will start to smoke and can irritate some people.
After the unit has gone through the rst burn, turn the unit off including the
pilot, let the unit get cold then remove the glass door and clean it with a
good gas replace glass cleaner, available at your local ENVIRO dealer.

5
Specifications
DIMENSIONS:
 

 

 

 

 

 

 

 

 

Height: 24 1/16 inches (611 mm)
Width: 19 1/16 inches (484 mm)
Depth: 15  inches (397 mm)
Center of ue to ground without leveling legs:
18  inches (467 mm)
Center of ue to ground with leveling legs (approx.):
19 inches (483 mm)
Figure 1. Dimensions of the Ascot.
RATING LABEL LOCATION:
The Rating Label is located on a plate hang on the back left of the unit.

Operating Instructions
FOR YOUR SAFETY READ COMPLETELY BEFORE OPERATING.
LIGHTING INSTRUCTIONS:
6
CAUTION:Hot while operating. Do not touch. Keep children, clothing,
furnit ure, gasoline or other flammable vapors away.
FOR YOUR SAFETY: Do not operate this fireplace with the glass removed, cracked or broken.
Replacement of this glass should be done by a licensed or qualified person! This appliance needs fresh
air for safe operation and must be installed with provisions for combustion and ventilation air.
See installation and operating instructions manual. Keep burner and control compartment clean .
Improper installation, adjustment, alteration , service or maintenance can cause property
damage, personal injury, or loss of life. Refer to owners manual. Installation and service must be
performed by qualified installer, service agency or the g as supplier.
WARNING:
TO TURN OFF GAS TO APPLIANCE
1.
2.
Fli p burn er switch to “OFF”
Turn the gasco ntrol knob clockwise to th e “OF F”
po sition
3 . Turn off all electrical po wer to the ap pliance if service i sto
be performe d.
ACLIE -1
FOR YOUR SAFETY READ BEFORE OPERATING
WARNING: IF YOU DO NOT F OLLOW TH ESE IN STRUCTIO NS EXACTLY, A F IRE O R EXPLOSION M AY R ESULT CAU SING
PROP ERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
A)
B) BEFORE LIGHTING
WHAT TO DO IF YOU SMEL L GAS:
This appliance is e quippe d with a pilot, which mus tbe lit by
hand
smell all around the appliance area
f or gas
Do not try t o light any a pplian ce. Do not touch a ny electrical
switch:
Immediately call your gas sup plier f rom a neighbors p hone.
Follo w
b y following these instructions e xactly.
and n ext to the floor because some gas is heavi er
t han air and will se ttle on the floor.
do not use any phone in you r building.
the gas s upplie rs instr uctions.
If you cannot re ach y our gas supp lier, call the fire departm ent.
Use only y our ha nd to p ush in or tu rn the gas co ntrol knob,
Call a qual ified service techn ician. Force or
Do n ot use thisa pplian ce if any part has b een u nder water.
C)
D)
Neve r use tools. If the knob will not push in or turn by
hand , do n ot try to rep air it.
attempte d
repair may result in a fire or explosion.
Immediately call a qualified service technician to inspe ct
the a ppliance an d to replace any pa rt of t he con tr ol sy stem
and any ga s con trol which ha s been unde r water.
LIGHTING INSTRUCTIONS
1.
2.
3.
4.
5.
STOP! Read th e safe ty information above on th is labe l.
Turn off al l electrical power t o this applian ce.
Turn off t he gas contr ol knob clock wise to the off
position.
Open door. Wa it five (5) mi nutes to clear out any gas.
Cl ose do or.
If you do not smell gas go to the ne xt ste p
Fin d pilo t-locate d to th e righ t behin d the side log. Turn
the gas c ontrol
If y ou sme ll gas, includ ing ne ar the floor ,
ST OP! F ol low “ B” in the above safety inf ormation.
kn ob cou nter-clockwis e to “PILO T”.
Push the gas co ntrol in
ful ly and hold, Keep knob
depressed for a bout 30 seco nds after
pilot is lit. Release kno b. If p ilot goes out ,
rep eat st eps 4 t hrough 5.
: this gas valve ha s a lockout device, which will
n ot allow
stop and imme diately
I f the pilot does not stay lit after several tries, turn the gas
control
Turn the gas control k nob counter clockwise t o the
“ON”
Turn on the ele ctrical power to the unit.
WARNING
6.
7.
the pilot burner to be relit until the ther mocouple
h as cooled. If the knob does not po p up when released,
call yo ur service technician or gas
supplier.
knob to “OFF” and call your service technician or
g as supplier.
position. Flip the burner switch to
“ON” THEN TURN THE “HI/LOW” knob to the desired setting.
Figure 2. Lighting instruction label.

2. Start the pilot by pressing the gas control knob and turning it to PILOT.
While holding the gas control knob in, press the piezo ignitor several
times until the pilot light starts. Hold the gas control knob in for thirty (30)
seconds. Check that the pilot has fully engulfed the thermocouple assembly
(see Figure 3).
3. Start the main burner by turning the gas control knob to ON and then turn
the rocker switch to ON. Check that all burner ports have ame.
4. Leak test all gas joints again.
 
Figure 3. Pilot ame.
REMOTE CONTROLS (OPTIONAL):
This replace can use an optional remote control or an optional cordless wall thermostat. If either of
these are to be used to control the replace for the majority of the time, leave the ON/OFF switch (on the
control panel) in the remote/thermostat position. Consult the instructions included with the remote/wall
thermostat for operation guidelines.
BLOWER SPEED (OPTIONAL):
The blower will come on only when the replace is up to temperature (approximately 20 minutes). The
speed of the fan can be changed by turning the fan control knob. To turn the blower off, turn the knob
COUNTER CLOCKWISE until it “clicks” off.
It is advisable not to operate the blower below 1/3 speed as it puts a strain on the windings of the blower
and running the blower at lower speeds could also cause premature fan failure.
NORMAL SOUNDS DURING OPERATION:
Table 1: Normal Sounds
Component Sound & Reason
Ascot Creaking when heating up or cooling down.
Burner Light pop or poof when turned off; this is more common with LP units.
Temperature Sensor Clinking when it senses to turn the blower on or off.
Pilot Flame Quiet whisper while the pilot ame in on.
Blower / Fan Air movement that increase and decreases with the speed of the blower. The
blower is pushing the heat from the replace into the room.
Gas Control Valve Dull click when turning on or off, this is the valve opening and closing.
7
Operating Instructions
For Your Safety, Read Safety Precautions And
Lighting Instructions Before Operating
PILOT LIGHT:
1. Turn off the gas to the replace. If not recently done, remove the glass and let the unit air out
for at least ve (5) minutes to clear out any gas. Turn on gas to the heater. Leak test all joints
with soapy water. NEVER USE AN OPEN FLAME FOR LEAK TESTING.

8
Maintenance And Service
ROUTINE MAINTENANCE:
At least once a year, run through the following procedures to ensure the system is clean and working
properly. Check the burner to see if all the ports are clear and clean. Check the pilot to make sure it is not
blocked by anything. The pilot ame should be blue with little or no yellow on the tips.
Warning: Clearances must be sufcient to allow access for maintenance and service
Warning: Failure to position the parts in accordance with this manual, or failure to use only parts
specically approved with this appliance may result in property damage or personal injury.
The venting system must be periodically examined; it is recommended the examination is done by a
qualied agency.
CLEANING THE GLASS:
When the replace has cooled, remove the face of the replace along with the glass. See MAINTENANCE
AND SERVICE - GLASS DOOR REMOVAL. Check the gasket material on the back of the glass, making sure that it
is attached and intact.
It will be necessary to clean the ceramic glass periodically. During a cold start up, condensation will
sometimes form on the glass. This is a normal condition with all replaces. However, this condensation
can allow dust and lint to cling to the glass surface. Initial paint curing of the appliance can leave a slight
lm behind the glass, a temporary problem. The glass will need cleaning initially after the rst 4 hours
of use and again about two (2) weeks after installation. Use a mild glass cleaner and a soft cloth;
abrasive cleaners will damage the glass and enamel surfaces. Depending on the amount of use,
the glass should require cleaning no more than two or three times a season. Do not clean the glass
when it is hot.
CLEANING THE FIREBOX:
Remove the logs carefully, as they are very fragile. Gently remove all the embers and rock wool and
place on a paper towel. Vacuum the bottom of the rebox thoroughly. Carefully clean any dust off the
logs and remove any lint from the burner and pilot. At this time, inspect the burner pan for cracking or
severe warping. If a problem is suspected, contact the dealer. Check the logs for deterioration or large
amounts of soot; a small amount on the bottom side of the logs is normal. Replace the logs and embers
as in the LOG SET AND EMBER INSTALLATION section. If new/more embers and rock wool are required, contact
your nearest ENVIRO dealer.
CHANGE BATTERY IN IGNITION MODULE:
Ignition Module
Figure 4. SIT Valve on Ascot.
If the unit does not spark when lighting, the battery in the
electronic ignition could need replacing.
The ignition module is located at the far left behind the valve
cover (see Figure 4). Remove the battery cover, located on the
left side of the module, and replace the AA battery.
Reinstall the battery cover and check for spark by depressing the
pilot knob located on the control panel.

REPLACING GLASS:
The glass in the replace is a high temperature ceramic. If the glass is damaged in any way, a factory
replacement is required (see PARTS LIST - COMPONENTS). Wear gloves when handling damaged glass door
assembly to prevent personal injury. When the glass door assembly is being transported, it must be
wrapped in newsprint and tape and/or a strong plastic bag. Do not operate with the glass front removed,
cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or
qualied service person. The glass must be purchased from an ENVIRO dealer. No substitute
materials are allowed.
To Replace: Open door, and remove the glass carefully. Install the new piece of glass with the large bulb
in the gasket tape against the unit. Place the joint in the tape in a bottom corner. Close door.
GLASS DOOR REMOVAL:
Maintenance And Service
Figure 5. Removing inner glass door.
9
Turn unit off and wait until the appliance has cooled down.
Remove the cast iron top from the unit by lifting straight up. Lift
the two door handles located on either side of the door and lift
the glass door assembly straight up and out. Carefully open the
two doors and remove if necessary.
Ensure the door is properly fastened after cleaning before
attempting to re-light the appliance.
BURNER REMOVAL:
1. Remove the glass as shown in the MAINTENANCE AND SERVICE - GLASS DOOR REMOVAL.
2. Carefully remove the log set and ember material.
3. Remove the two (2) screws at the back of the re
box that hold the log support tray in place (see
Figure 6). Remove the support tray from the re
box
4. Remove the screw located on the right side of the
burner that holds the burner to the chassis inside
the re box. Remove the burner tray from the
rebox. Figure 6. Removing log support tray.

10
Maintenance And Service
FUEL CONVERSION:
Figure 7: Removing
valve cap.
a) Remove the main burner orice with a  inch deep socket.
b) Put a bead of pipe-thread sealant or approved Teon tape on the orice
threads before installing into the brass elbow.
c) Install the new orice(s) from the kit into the brass elbow.
6. Convert the pilot injector:
a) Pull the pilot hood straight up to access the pilot injector.
b) Using a 5/32” or 4 mm Allen key, remove the pilot injector.
c) Install the new pilot injector supplied with this conversion kit. Simply screw
the new injector inside the pilot hood using the Allen key,
d) Reinstall the hood by placing the hood on the assembly, line up the key
way, and snap into place.
TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY
Please read and understand these instructions before installing.
Warning: This conversion kit shall be installed by a qualied service agency in accordance
with the manufacturer’s instructions and all applicable codes and requirements of the
authority having jurisdiction. If the information in these instructions is not followed
exactly, a re, explosion or production of carbon monoxide may result causing property
damage, personal injury or loss of life. The qualied service agency is responsible for
the proper installation of this kit. The installation is not proper or complete until the
operation of the converted appliance is checked as specied in the manufacturer’s
instructions supplied with the kit.
Kit Parts List:
1 - Orice (NG - #48 DMS or LP - #57 DMS)
1 - Pilot Injector (NG 0.62 mm; LP 0.35 mm)
1 - Installation instruction sheet
1 - Conversion label
Carefully inspect all parts supplied with this conversion kit. If any parts have been damaged or are
missing, contact your dealer, distributor or courier company to have them replaced before starting this
installation.
Conversion Kit Installation:
1. Turn control knob on the gas valve to the “OFF” position and shut the gas supply off at the shut-off
valve upstream of the unit. CAUTION: The gas supply must be shut off prior to disconnecting the
electrical power and before proceeding with the conversion. Allow the valve and unit to cool down
to room temperature.
2. Remove the glass as shown in the MAINTENANCE AND SERVICE - GLASS DOOR REMOVAL.
3. Carefully remove the log set and ember material if they are installed.
4. Remove the burner as shown in the MAINTENANCE AND SERVICE - BURNER REMOVAL.
5. Convert the burner orice(s):

11
Maintenance And Service
b) Insert a 5/32” or 4 mm Allen wrench into the
hexagonal key-way of the screw (see Figure 8),
rotate it counter-clockwise until it is free and
extract it.
c) Check that the screw is clean and if necessary
remove dirt.
d) Flip the screw (refer to Figure 9).
e) Using the Allen wrench as shown in Figure 8,
rotate the screw clockwise until a torque of 9 inch
lbs. WARNING! Do not over tighten the screw.
It is recommended that you grip the wrench by
the short side.
f) Verify that if the conversion is from NG to LPG,
the screw must be re-assembled with the red o-
ring visible (refer to Figure 10). If the conversion
is from LPG to NG, the red o-ring of the screw
must be not visible. Figure 9: Flip valve
screw.
Red o-ring
is not visible
Red o-ring
is visible
LPG Configuration
g) Re-attach the black protection
cap that was removed in step a
(Figure 7).
8. Reinstall the burner, brick panels,
log set, embers, and glass door.
Also refer to SECONDARY INSTALLATION
- INSTALLING LOG SET AND EMBERS. When
re-installing the burner, ensure that
the burner to pilot hood relationship Figure 10: O-ring on valve screw.
is similar to what is shown in Figure 11. On some units you will need to pay
special attention when installing the burner that the venturi adjustment rod
is properly installed into the venturi adjustment piece welded to the burner
venturi tube
9. Reconnect the main gas line if it was disconnected and open the shut-off valve
at the gas line to the unit.
10. Use a small brush to apply a warm soapy water solution to all gas connections
(use a half dish soap and half warm water). If a gas leak is present, bubbling
will occur. Gas leaks can be repaired by using an approved pipe thread sealant
or approved Teon tape. NEVER USE AN OPEN FLAME WHEN TESTING FOR
LEAKS.
Loosen
Tighten
Figure 8: Removing valve screw.
7. Convert the SIT gas valve:
a) Remove the black protection cap from the HI/LO knob by hand shown in Figure 7.
Figure 11. Ignitor
assembly beside the
burner.
11. Reconnect the electrical power to the unit.
12. Relight the main burner in both the “HI” and “LO” positions to verify proper burner ignition and
operation and proper ame appearance. Also refer to SECONDARY INSTALLATION - LOG SET AND EMBERS
INSTALLATION for a flame appearance picture.
13. MAKE SURE that the conversion label is installed on or close to the rating label to signify that the
unit has been converted to a different fuel type.

Initial Installation
QUALIFIED INSTALLERS ONLY
WARNING:
Operation of this heater when not connected to a properly installed and maintained venting system can
result in carbon monoxide (CO) poisoning and possible death.
PREPARATION FOR INSTALLATION:
• Remove the packaging from the appliance, and check to make sure there is no damage. If damage is
found, please report it to both the carrier and your dealer as soon as possible.
• Before beginning, carefully check the glass door and the log set
• Locate a position where the ue system of the stove can be properly installed without damaging the
integrity of the building; e.g. cutting a wall or ceiling joist.
• Check stove and ue system clearance requirements.
• Locate the stove where it can be accessed by a gas supply line.
• Locate the stove in a large and open room that is centrally located in the house. This will optimize heat
circulation and comfort.
• As the stove can be equipped with a convection fan, ensure that an electrical outlet is within 6 ft (1.8
m) of the stove.
• The ow of combustion and ventilation air must not be obstructed.
CLEARANCES TO COMBUSTIBLES:
A) Sidewall to unit 10 inches (254 mm)
B) Backwall to unit 2 inches (64 mm)
C) Corner to unit 2 inches (64 mm)
D) Ceiling bottom of unit 60 inches (1524 mm)
E) Floor 0 inches (0 mm)
Note: Must have hearth pad if installed on a
carpeted surface.
If this unit is installed in an alcove the alcove must meet
these minimum dimensions:
Width 48 inches (1219 mm)
Height 60 inches (1524 mm)
Maximum Depth 24 inches (610 mm)
CLEARANCES MUST BE SUFFICIENT TO ALLOW ACCESS FOR MAINTENANCE AND SERVICE.



 
 



 
 
Figure 12: Clearances to combustibles.
12

13
Initial Installation
QUALIFIED INSTALLERS ONLY
PLANNING YOUR INSTALLATION:
When planning your installation, it will be necessary to select the proper length of vent pipe for your
particular requirements. It is important to note when passing through a wall, the maximum allowable
wall thickness is 10 inches (25.4 cm), 1 inches (3.8 cm) clearance to combustibles must be maintained.
Select the amount of vertical rise desired for “vertical-to-horizontal” type installations. To determine
the length of vent pipe required for vertical installations, measure the distance from the appliance ue
outlet to the ceiling, the ceiling thickness, the vertical rise through the attic or second story, and allow
for sufcient vent height above the rooine. For two story applications, a re stop is required at each
oor level. If an offset is needed in the attic, additional pipe and elbows will be required. To connect the
venting system to the appliance ue outlet, a twist-lock adapter is built into the appliance at the factory.
Refer to INITIAL INSTALLATION - VENT CONFIGURATION AND RESTRICTOR SETTINGS for venting parameters.
Your total vent pipe length must be within the shaded area of Figure 36. If a 90° elbow is used in the
horizontal plane, 36” (91.4 cm) must be subtracted from the allowable horizontal run.
There are two (2) basic types of Direct Vent System installations. The two (2) types of installations are
shown below.
Vertical
Termination
Storm Collar
Flashing
Round Support
Box/Wall Thimble
Ceiling Firestop
Pipelength
Pipelength
Cathedral Ceiling
Support Box
Pipelength
Round Support
Box/Wall Thimble
Pipelength
Horizontal
Termination
90° Elbow
Figure 13: Common Horizontal Installation.
Figure 14: Common Vertical Installation.

A
A
DE
LB
C
F
B
B
B
JMK
G
H
I
Openable
Fixed
Closed
Openable Fixed
Closed
Termination Cap Air Supply Inlet Gas Meter
G
G
Restriction Zone
(Termination not allowed)
N
O
1 In accordance with the current CSA B149, Natural Gas and Propane Installation Code.
2 In accordance with the current ANSI Z223.1 NFPA 54, National Fuel Gas Code.
* These numbers are only estimates. Clearance in accordance with installation codes and the requirements of the gas supplier.
t A vent shall not terminate directly above a side walk or paved driveway that is located between two single family dwellings and it serves both dwellings.
+ Permitted only if verandah, porch, deck, or balcony is fully open on a minimum of two sides beneath the oor.
NOTE: Venting terminals shall not be recessed into walls or siding.
Figure 15. Vent Termination Restrictions, refer to Table 2.
Initial Installation
QUALIFIED INSTALLERS ONLY
VENT TERMINATION RESTRICTIONS:
Letter Canadian Installation 1US Installation2Description
A 12 in (30 cm) Clearance above grade, verandah, porch, deck, or balcony.
B 12 in (30 cm) 9 in (23 cm) Clearance from window or door that may be opened.
C 12 in (30 cm)* Clearance from permanently closed window (to prevent
condensation).
D 24 in (60 cm)* Vertical clearance to ventilated soft located above the
terminal, within a horizontal distance of 2 ft (60 cm) from
center line of terminal.
E 18 in (45 cm)* Clearance to unventilated soft.
F 12 in (30 cm)* Clearance to outside corner.
G 12 in (30 cm)* Clearance to inside corner.
H 3 ft (91 cm) within a height of
15 ft (4.5 m) above the meter/
regulator assembly
3 ft (91 cm) within a height of
15 ft (4.5 m) above the meter/
regulator assembly*
Clearance to each side of center line extended above
meter/regulator assembly.
I 3 ft (91 cm) 3 ft (91 cm)* Radial clearance around service regulator vent outlet.
J 12 in (30 cm) 9 in (23 cm) Clearance to non-mechanical air supply inlet to building, or
the combustion air inlet to any other appliance.
K 6 ft (1.83 m) 3 ft (91 cm) above if within 10
ft (3 m) horizontally
Clearance to mechanical air supply inlet.
L 7 ft (2.13 m)t 7 ft (2.13 m)*t Clearance above paved sidewalk or paved driveway located
on public property.
M 12 in / 30 cm+12 in / 30 cm*+Clearance under verandah, porch, deck, or balcony.
N 12 in (30 cm)* Clearance horizontally to any surface (such as an exterior
wall) for vertical terminations.
O 12 in (30 cm) Clearance above roof line for vertical terminations.
Table 2: Vent termination clearances, refer to Figure 15.
14

15
Initial Installation
QUALIFIED INSTALLERS ONLY


Figure 16: Wire Spacers.
it to the inner wall frame using four (4) 1” wood screws. If a wall is
greater than 8” (203mm) in depth, the clearance above the ex must be
4” (111mm)
6. Apply a bead of Mill-Pac Black sealant to the new Ø4” (10 cm) by 5” (12.5
cm) provided ue collar adaptor. Press the ue collar into the ue outlet of
the replace so that the Mill-Pac seals the ue collar to the ue outlet.
7. Stretch both the Ø4” (10 cm) ex vent and the Ø6” (16.25 cm) ex intake
liner to the length needed to ensure the ex can be easily connected to the
Figure 17: Wire Spacer in Place.
vent terminal.
8. Slide the Ø6” (16.25 cm) ex intake liner
over the ex vent. Install four (4) wire
spacers around the ex pipe. Ensure the
wire spacers are positioned at either end of
the pipes, and at each end of any elbows in
the liners (refer to Figure 16 and 17).
9. Install the ex pipe assembly through
the wall thimble, ensure that this portion
of pipe slides through the outside wall
far enough to connect onto the vent
termination cap.
KIT COMPONENTS:
Qnty Description Qnty Description
1 Horizontal direct vent termination cap 4 Wire spacers
1 Flue collar adapter 1 4 oz tube Mill-Pac Sealant
1 Wall thimble 1 4 oz tube RTV silicone
1 5’ (190 cm) length of Ø4” (10 cm) double walled ex pipe 12 9/16” tech screws
1 5’ (190 cm) length of Ø6” (16.8 cm) double walled ex pipe 8 1” wood screws
Please ensure that all components are supplied with this kit. If components are missing or have
been damaged, contact your dealer, distributor, or courier company. Do not attempt the installation if
components are missing or damaged.
INSTALLATION INSTRUCTIONS:
1. Plan your installation and clearances to combustibles. Decide on a location for the unit that will meet
the clearances noted in the venting section, and any or all local code requirements.
2. Set the appliance in the desired location. Determine if any wall studs, electrical wiring, or plumbing
pipes are in the way of the venting system as it passes through the exterior wall. The replace location
should be adjusted if obstructions are found in the wall.
3. Project a line from the center point of the ue outlet upward and outward to the desired ue outlet
location on the exterior wall. Using this center point, scribe a 10” (25.4 cm) hole or square on the wall.
Cut the hole from the interior through the exterior wall surfaces.
4. Frame the hole as shown in Figure 22.
5. Trim the wall thimble to match the wall thickness as necessary. Install the wall thimble and secure
Please read and understand these instructions before installing. Failure to follow
these instructions carefully could cause property damage or personal injury.
FIREPLACE HORIZONTAL VENT KIT 50-1235:

Flue Pipe Adaptor
Wall Framing
Wall Thimble
Fire Stop
Exhaust 4" Flex Pipe
Combusion Air 6 5/8" Flex Pipe
Wire Spacers
Horizontal Vent Termination
Initial Installation
QUALIFIED INSTALLERS ONLY
Figure 18: Installation of Fireplace Horizontal Vent Kit.
10. Apply a bead of Mill-Pac Black sealant to
the top section of the Ø4” (10 cm) by 5”
(12.5 cm) ue collar adaptor previously
installed into the replace ue outlet.
Slide the Ø4” (10 cm) ex vent over
the ue collar and secure with three (3)
sheet metal screws evenly spaced.
11. Place a bead of high temperature
silicone on the intake collar of the
replace, slide the Ø6” (16.25 cm)
ex intake liner over the collar, secure
the ex liner with three (3) sheet metal
screws evenly spaced.
12. On the outside of the exterior wall,
apply a bead of Mill-Pac Black sealant
to the Ø4” (10 cm) pipe of the vent
terminal. Slide the ex liner onto the
vent terminal and secure with three (3)
sheet metal screws evenly spaced.
13. Place a bead of high temperature
silicone on the intake collar of the vent
terminal, slide the Ø6” (16.25 cm)
ex intake liner over the collar, secure
the ex liner with three (3) sheet metal
screws evenly spaced.
14. Attach the vent terminal to the outside of the house using four (4) wood screws provided.
15. Light the appliance and ensure proper operation.
OTHER APPROVED VENT PARTS:
Table 3: Approved Vent Manufacturers
Manufacturer Trade Name Nominal Sizes
American Metal Products AmeriVent Direct 4” - 6 5/8”
Security Chimneys International LTD Secure Vent 4” - 6 5/8”
Selkirk Metalbestos Direct-Temp 4” - 6 5/8”
Simpson Dura-Vent Direct Vent GS 4” - 6 5/8”
The Ascot replace has been tested and certied for use with AMERICAN METAL PRODUCTS “AMERIVENT
DIRECT”, SIMPSON DURAVENT TYPE GS PIPE FOR GAS STOVES. SECURITY CHIMNEY’S “SECURE VENT
DIRECT VENT SYSTEM” and SELKIRK “DIRECT-TEMP VENT SYSTEM” kits are available for horizontal and
vertical venting. When using Simpson Duravent, it is recommended that, before installation, a bead of
RTV High Temperature Silicone should be applied to each outer vent joint, and Mil-Pac to each inner
joint. When planning an installation, it will be necessary to select the proper length of vent pipe for the
particular requirements.
WARNING: Do not mix parts from different vent manufacturers’ systems.
16

EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a Direct Vent GS
starting collar in conjunction with Secure Vent, Direct-Temp, and Ameri Vent Direct venting systems. Use
of these systems with the Direct Vent GS starting collar is deemed acceptable and does not affect the
Intertek WH listing of the appliance.
Table 4: Vent part numbers (Must state if galvanized or black wanted, PART NUMBERS).
Direct Vent GS Direct-Temp Secure Vent Ameri Vent Direct Description
908 4DT-6 SV4L6 6” pipe length
4D7 7” pipe length
907 4DT-9 9” pipe length
906 4DT-12 SV4L12 4D12 12” pipe length
904 4DT-24 SV4L24 4D2 24” pipe length
903 4DT-36 SV4L36 4D3 36” pipe length
902 4DT-48 SV4L48 4D4 48” pipe length
945 4DT-EL45 SV4EBR45 4D45B 45° elbow, black
990 4DT-EL90 SV4EBR90 4D90B 90° elbow, black
950 4DT-VS SV4VS Vinyl siding standoff/sheild
942 4DT-WT SV4RSN 4DWT Wall thimble
953 4DT-SC SV4FC 4DSC Storm collar
963 4DT-FS SV4BF 4DFSP Fire stop
988 4DT-WS/B SV4BM 4DWS Wall strap/support/band
970 4DT-HKA SV0SHK 4DHTK1 Horizontal termination kit (SD: Basic Kit,
SEL: Kit A, SC: Standard Kit)
911 11” to 14 ” pipe, adjustable
4DT-AJ 4D12A 4” to 10” pipe , adjustable
SV4LA12 1” to 12” pipe , adjustable
943 4DT-AF6 4DF Flashing, 0/12 to 6/12 roof pitch
943S 4DT-AF12 4DF12 Flashing, 7/12 to 12/12 roof pitch
SV4FA Flashing, 1/12 to 7/12 roof pitch
SV4FB Flashing, 8/12 to 12/12 roof pitch
943F SV4F Flat ashing
980 4DT-VC SV4CGV 4DVC Vertical termination
991 4DT-HVC High wind vertical termination
984 4DT-HC SV4CHC 4DHC Horizontal square termination
985 4DT-HHC High wind horizontal termination
978 4DT-VKC SV0FAK 4DVTK Vertical termination kit
971 4DT-HKB SV0SHK2 4DHTK2 Horizontal termination kit
(SD: Kit A, SEL: Kit B, SC: Kit)
Initial Installation
QUALIFIED INSTALLERS ONLY
17

18
Initial Installation
VENT RESTRICTOR SETTING:
To access restrictor plate, look at the left hand rear corner of the unit. There is a small rectangular hole
in the air jacket. Loosen the ” hex head bolt and adjust to the correct setting. Slide the hex bolt to the
next setting and retighten the bolt to ensure the plate does not move
1
2
3
4
5
1
2
3
4
5
 
 
 
 
15’ (4.57m)
10’ (3.05m)
5’ (1.52m)
2’ (0.62m)
2’ (0.62m)
18”
(0.46m)
1
2
3
4
5
Vent Restrictor Settings
Refer to Figure 20 to determine were the vent restrictor should be
set for proper operation.
The numbers in the chart represent the actual vent restrictor
settings. Although the numbers do not appear on the unit use this
guide to follow.
Ensure that the setscrew is retightened and the unit is checked for
proper operation. Figure 20. Possible Vent Congurations.
Figure 19. Vent Restrictor Settings.
Wait for the unit to warm up to operating temperature to ensure a proper and clean burning unit.
NOTE: The total length of the vent pipes can not exceed 15 feet (4.6 m). Any combination of rise and
run can be used as long as it lays within the shaded area.

Initial Installation
QUALIFIED INSTALLERS ONLY
HORIZONTAL INSTALLATION:
STEP 1. Set the appliance in the desired location. Check to determine if wall studs or roof rafters are
in the way when the venting system is attached. If this is the case, you may want to adjust the
location of the appliance.
STEP 2. Direct vent pipe and ttings are designed with special twist-lock connections. Assemble the
desired combination of black pipe and elbows to the appliance adapter with pipe seams oriented
towards the wall or oor, as much out of view as possible.
Sealant
Female
Locking
Lugs
Male
Locking
Lugs
Figure 21: Twist-Lock Connection
Woodscrews
Wall Thimble
Strap
Sheet metal
screws
Fold strap
here
11/4"
(3.2cm)
Figure 23: Installing Decorative Wall Thimble.
10"
(254mm)
10"
(254mm)
Figure 22: Wall Framing Hole for
Horizontal Installation.
19
Place a bead of Mil-Pac on the
outer edge of the inner exhaust
pipe (non-ared end). Place a bead
of high temperature silicone on
the male edge of the outer pipe.
Push the pipe sections completely
together, then twist-lock one
section clockwise approximately 
turn, until the two sections are fully
locked. The female locking lugs will
not be visible from the outside, on
black pipe. They may be located by
examining the inside of the female
ends as shown in Figure 21.
Notes:
(1) Twist-lock procedure: four (4) indentations, located on the female end of the pipes and ttings, are
designed to slide straight onto the male ends of adjacent pipes and ttings, by orienting the four pipe
indentations so they match and slide into the four entry slots on the male end.
(2) Horizontal runs of vent pipe must be supported every three (3) feet. Wall straps are available for this
purpose, also when running horizontal pipe minimum clearances to combustibles must be maintained;
2” (5.1 cm) at top, 1” (3.8 cm) at sides, 1” (3.8 cm) at bottom.

the cap assembly. It is important that the
vent pipe extend into the vent cap a sufcient
distance with a minimum of 1” (3.2 cm)
overlap. Secure the connection between the
vent cap pipe and the vent cap by attaching
the two sheet metal straps extending from
the vent cap assembly into the outer wall of
the vent pipe. Use the two sheet metal screws
provided to connect the straps to the vent
pipe. Bend any remaining portion of the sheet
metal straps back towards the vent cap, so the
decorative wall thimble will conceal it (see left
image in Figure 23).
STEP 7. Slide the decorative wall thimble up to the wall
surface and attach with the screws provided.
Apply decorative brass or chrome trim if
desired (see right image in Figure 23).
NOTES:
(1) The four wood screws provided should be replaced
with the appropriate fasteners for stucco, brick,
concrete, or other types of siding.
(2) For buildings with vinyl siding, a vinyl siding
standoff, should be installed between the vent cap
and the exterior wall (see Figure 24). Attach the
vinyl siding standoff to the horizontal termination.
The vinyl siding standoff prevents excessive heat
from possibly melting the vinyl siding material.
Note that the horizontal vent termination bolts onto
the at portion of the vinyl siding standoff (shaded
area in Figure 24), so that an air space will exist
between the wall and the vent termination.
Initial Installation
QUALIFIED INSTALLERS ONLY
Wood screws (x4)
Cut vinyl siding
away to fit standoff
Bolt (x4)
required
Nut (x4)
required
Wood
screw (x4)
Figure 24: Installing Vent Cap with Vinyl Siding
Stand-Off.
Figure 25: Installing Horizontal Vent Termination.
STEP 3. With the pipe attached to the stove in the correct location, mark the wall for a 10” (25.4 cm) x
10” (25.4 cm) square hole (refer to Figure 22). The center of the square hole should match the
center line of the horizontal pipe. Cut and frame the 10” (25.4 cm) x 10” (25.4 cm) hole in the
exterior wall where the vent will be terminated. Refer to Figure 15. If the wall being penetrated
is constructed of non-combustible material i.e. masonry or concrete, a 7 inches (17.8 cm) hole
is acceptable.
STEP 4. Position the horizontal vent termination in the center of the 10” (25.4 cm) x 10” (25.4 cm)
hole, and attach to the exterior wall with the four screws provided. Before attaching the vent
termination to the exterior wall, run a bead of non-hardening mastic around the edges, so as to
make a seal between the termination and the wall. The arrow on the vent termination should be
pointing up, insure that the proper clearances to combustible materials are maintained.
STEP 5. Before connecting the horizontal run of the vent pipe to the vent termination, slide the black
decorative wall thimble cover over the vent pipe.
STEP 6. Slide the appliance and vent assembly towards the wall, carefully inserting the vent pipe into
20
