ep R Series User manual

CPQD15/18N-RW21-Y CPQD20/25/30/35N-RW22-Y
CPQD20/25/30/35N-RW22A-Y CPQD20/25/30/35N-RW22B-Y
1.5-3.5T R Series of LPG Forklift
（USA IMPCO Combustion System）
（ITALY BRC Combustion System）
SERVICE MANUAL
&
PARTS LIST
E - P E q u i p m e n t
2008.03 1st EDITION

1
FOREWORD
Thanks for your purchasing EP forklift.
1.5-3.5T R Series LPG trucks use Japan Nissan gasoline engine. There are 4 types of combustion
system, respectively, BRC dual-fuel (Italy), BRC single-fuel (Italy), IMPCO dual-fuel(USA), and IMPCO
single-fuel(USA), in this manual, they are distinguished by Y0, Y1,Y2,Y3. Details are shown in table below.
1.5-1.8T R Series LPG forklift
Product Code
Configuration
Manuals Code
CPQD15/18N-RW21-Y
BRC dual-fuel(Italy)
CPQD15/18N-RW21-Y0
BRC single-fuel(Italy)
CPQD15/18N-RW21-Y1
IMPCO dual-fuel (USA)
CPQD15/18N-RW21-Y2
IMPCO single-fuel(USA)
CPQD15/18N-RW21-Y3
2-3.5T R Series LPG forklift
Product Code
Configuration
Manuals Code
CPQD20/25/30/35N-RW22-Y
BRC dual-fuel(Italy)
CPQD20/25/30/35N-RW22-Y0
BRC single-fuel(Italy)
CPQD20/25/30/35N-RW22-Y1
IMPCO dual-fuel (USA)
CPQD20/25/30/35N-RW22-Y2
IMPCO single-fuel(USA)
CPQD20/25/30/35N-RW22-Y3
CPQD20/25/30/35N-RW22A-Y
BRC dual-fuel(Italy)
CPQD20/25/30/35N-RW22A-Y0
BRC single-fuel(Italy)
CPQD20/25/30/35N-RW22A-Y1
IMPCO dual-fuel (USA)
CPQD20/25/30/35N-RW22A-Y2
IMPCO single-fuel(USA)
CPQD20/25/30/35N-RW22A-Y3
CPQD20/25/30/35N-RW22B-Y
BRC dual-fuel(Italy)
CPQD20/25/30/35N-RW22B-Y0
BRC single-fuel(Italy)
CPQD20/25/30/35N-RW22B-Y1
IMPCO dual-fuel (USA)
CPQD20/25/30/35N-RW22B-Y2
IMPCO single-fuel(USA)
CPQD20/25/30/35N-RW22B-Y3
This series of LPG forklift is an advanced model of R series forklift. A set of LPG fuel
system has been adopted，which makes it possible to take both petrol and LPG as fuel.
This service manual is about structure，principle，performance and characteristic of LPG
forklift and its fuel system ，as well as its operation and maintenance, OPERATION AND
MAINTENANCE MANUAL and SERVICE MANUAL of 1-3.5t R series are also concerned. All the
personnel in charge of operation ，maintenance and management should read all these three
manuals completely.
Owing to continuous update and improvement，there
is maybe something different between the explanations
in this manual and the forklift in your hand.
○
C2008.03 1st EDITION E - P E q u i p m e n t
.

2
Content
FOREWORD..................................................................................................................................................... 1
1 Parameter........................................................................................................................................................ 3
2 Operation.........................................................................................................................................................7
3. Fuel system parts catalog and maintenance manual......................................................................................8
4. Notice...........................................................................................................................................................46

3
1 Parameter
1.5~1.8t R series LPG forklift specification
Model
CPQD15N-RW21-Y
CPQD18N-RW21-Y
Combustion
system
configuration
USA IMPCO
Combustion system
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
ITALY BRC
Combustion system
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Rated capacity Kg
1500
1800
Load center mm
500
500
Max lift height mm
3000
3000
Free lift height mm
155
155
Max lift speed mm/s
500
500
Mast tilt range (F/R)
6°/12°
6°/12°
Max speed(Unload) Km/h
15
15
Min ground clearance mm
115
115
Turning radius (Out side) mm
1970
2000
Max gradeability %
20
20
Wheel base mm
1400
1400
Track（F/R）mm
890/900
890/900
Self weight Kg
2690
2880
Dimension
（L×W×T）（include forks）
3185×1080×2110
3222×1080×2110
Tires（F/R）
6.5-10-10PR/2
5.00-8-8PR/2
6.5-10-10PR/2
5.00-8-8PR/2
Voltage V/Capacity Ah
12/60/20h
12/60/20h
Gasoline
Engine
Model
NISSAN K21
Rated power/rpm
31.2 KW /2250rpm
Max torque/rpm
143.7Nm/1600 rpm
displacement cc
1980

4
2~3.5t R series LPG forklift specification
Model
CPQD20N –RW22-Y
CPQD25N- RW22-Y
CPQD30N –RW22-Y
CPQD35N –RW22-Y
Combustion
system
configuration
USA
IMPCO
Combusti
on system
Dual-Fuel
（Y2）
Single-Fuel (Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
ITALY
BRC
Combusti
on system
Dual-Fuel
（Y0）
Single-Fuel (Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Rated capacity Kg
2000
2500
3000
3500
Load center mm
500
500
500
500
Max lift height mm
3000
3000
3000
3000
Free lift height mm
140
140
155
155
Max lift speed mm/s
560
560
450
350
Mast tilt range F/R
6°/12°
6°/12°
6°/12°
6°/12°
Max speed(Unload)
Km/h
22
21.5
19.5
19.5
Min ground clearance
mm
105
105
130
130
Min Turning radius
(Out side) mm
mm
2175
2255
2375
2430
Gradeability (full
load) %
20
20
20
15
Wheel base mm
1650
1650
1760
1760
trace（F/R）mm
965/970
965/970
1005/975
1005/975
Self weight Kg
3440
3765
4255
4755
dimension（L×W×H）
（include forks）
3600×1155×2120
3675×1155×2120
3820×1225×
2150
3870×1225×
2150
tires（F/R）
7.00-12-12PR
6.00-9-10PR
7.00-12-12PR
6.00-9-10PR
28×9-15-12PR/2
6.50-10-10PR/2
28×9-15-12PR/2
6.50-10-10PR/2
Battery
Voltage V/Capacity Ah
12/60/20h
Gasoline
engine
Model
K25
Rated power/rpm
37.4KW /2300rpm
Max torque/rpm
176.5Nm/1600 rpm
Displacement cc
2472

5
Model
CPQD20N-RW22A-Y
CPQD25N-RW22A-Y
CPQD30N-RW22A-Y
CPQD35N-RW22A-Y
Combustion
system
configuration
USA
IMPCO
Combustion
system
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
ITALY
BRC
Combustion
system
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Dual-Fuel
（Y0）
Single-Fuel
(Y1)
Rated capacity Kg
2000
2500
3000
3500
Load center mm
500
500
500
500
Max lift height mm
3000
3000
3000
3000
Free lift height mm
150
150
155
155
Max lift speed mm/s
560
560
450
350
Mast tilt range F/R
6°/12°
6°/12°
6°/12°
6°/12°
Max speed(Unload)
Km/h
19.5
19.5
19.5
19.5
Min ground clearance
mm
105
105
130
130
Min turning
radium(outside) mm
2175
2235
2375
2415
Gradeability
(Full load) %
20
20
20
15
Wheel base mm
1650
1650
1760
1760
Trace（F/R）mm
965/970
965/970
1005/975
1005/975
Self weight Kg
3440
3765
4255
4555
Dimension
（L×W×H）
（include forks）
3600×1155×2120
3675×1155×2120
3820×1225×
2150
3870×1225×2150
Tires（F/R）
7.00-12-12PR
6.00-9-10PR
7.00-12-12PR
6.00-9-10PR
28×9-15-12PR/2
6.50-10-10PR/2
28×9-15-12PR/2
6.50-10-10PR/2
Battery
Voltage V/capacity Ah
12/60/20h
Gasoline
engine
Model
K25
Rated power/rpm
37.4KW /2300rpm
Max torque/rpm
176.5Nm/1600 rpm
Displacement
2472

6
Model
CPQD20N-RW22B-Y
CPQD25N-RW22B-Y
CPQD30N-RW22B-Y
CPQD35N-RW22B-Y
Combustion
system
configuration
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Dual-Fuel
（Y2）
Single-Fuel
(Y3)
Rated capacity
Kg
2000
2500
3000
3500
Load center mm
500
500
500
500
Max lift height
mm
3000
3000
3000
3000
Free lift height
mm
150
150
155
155
Max lift speed
mm/s
560
560
450
350
Mast tilt range
F/R
6°/12°
6°/12°
6°/12°
6°/12°
Max
speed(Unload)
Km/h
21
21
20
20
Ground
clearance mm
105
105
130
130
Min turning
radium (outside)
mm
2175
2235
2375
2430
Gradeability
(full loade)%
20
20
20
15
Wheel base
mm
1650
1650
1760
1760
Trace（F/R）mm
965/970
965/970
1005/975
1005/975
Self weight
Kg
3440
3765
4255
4755
dimension（L×
W×H）
（include forks）
3600×1155×2120
3675×1155×2120
3820×1225×
2150
3870×1225×
2150
tires（F/R）
7.00-12-12PR
6.00-9-10PR
7.00-12-12PR
6.00-9-10PR
28×9-15-12PR/2
6.50-10-10PR/2
28×9-15-12PR/2
6.50-10-10PR/2
battery
Voltage V/Capacity Ah
12/60/20h
Gasoline
engine
Model
K25
Rated power/rpm
37.4KW /2300rpm
Max torque/rpm
176.5Nm/1600 rpm
Displacement cc
2472

7
2 Operation
LPG fuel system consists of LPG cylinder, petrol solenoid valve ，LPG solenoid valve with filter, LPG
vaporizer，adapter，LPG-petrol select switch and level indication. passing through the combination valve, the
high-pressured pipe, the filter，and the solenoid valve in sequence，enters the LPG vaporizer to vaporize，
then mix with air in certain proportion in the adapter, and combust in the engine cylinder to drive the forklift
truck to work
1. LPG filling & replacing
Replace the LPG cylinder when fuel in it is used up as following: shut off the outpouring valve，disconnect
the female body from the LPG cylinder，cover a dust cap on the valve tie-in （H2-63）, and get the LPG
cylinder away from the truck to a LPG filling station to refill the LPG. Fill LPG as following: Lay the LPG
cylinder flat, and set the charging limit valve upward(the level indication is exactly 60°to the horizontal
line), then screw off the dust cap on the charging valve，plug the filling connector, open the limit charging
valve to charge LPG till 80% rated volume of the container is full (the charging device is automatically
closed when 80% rated volume of the container is full)，take out the filling connector，screw down the dust
cap and the charging limit valve。Secondly，install the LPG cylinder to the truck by a certain angle (the
level indication is exactly 60°to the horizontal line)，connect the female body，open the outpouring valve，
check and eliminate it if there is any leak before starting the truck. Close the outpouring valve after every
task。
2. Operating the select switch
1．Switch to the GAS position，the fuel for the engine is LPG。
2．Switch to the PET position，the fuel for the engine is petrol。
3．Switch to the neutral position，neither is in use。
3. Starting up the engine
1．By petrol
Shut off LPG，switch on the petrol switch for several seconds，after petrol is flowing into the
floater room of the carburetor，turn the ignition key to start the motor-----the engine is started by petrol。
2．By LPG
a. Starting up when there is no petrol in the carburetor：If there is no petrol in the carburetor before
starting-up，you could start up the engine directly by LPG，that is，to shut off the petrol switch，but switch
on the LPG switch for several seconds，turn the ignition key to start the motor-----the engine is started by
LPG。
b. Starting up when there is petrol in the carburetor：It is some difficult to start up when there is
petrol in the carburetor，you should switch the select switch to the neutral position，start up the
engine by petrol。After petrol in the carburetor is used up and the engine is halted，switch on the
LPG switch，turn the ignition key to start the motor-----the engine is started.
4. Change fuel during the engine runs

8
a. Change from LPG to petrol:
Switch the select switch from GAS position to PET position directly, then the engine use the petrol as
fuel instead of LPG.
b. Change from petrol to LPG
Switch the select switch from the petrol position to the neutral position, when the petrol in the
Carburetor nearly finished, and the engine speed decline, then select the switch to the LPG position swiftly,
and the engine use the LPG as fuel.
5. If there is LPG leak during operation，shut off the LPG switch and the outpouring valve at once，check
every part and all connection to see if there is leak or loose，and get rid of it in time。Fuel by petrol before
malfunction is removed。
6. Choose 90# petrol or LPG special for vehicle as fuel for the truck。Otherwise it may affect the ignition
veracity and decline the motive performance。
7. If there is 10 minutes halt，you should shut off the LPG switch and the outpouring valve.
8. It is suitable to keep water in the radiator in the range 700C~850C during operation.
3. Fuel system parts catalog and maintenance manual
Explanation: The structure of CPQD15~18N-RW21-Y,CPQD20~35N-RW22-Y,CPQD20-35N-RW22A-Y,
CPQD20-35N-RW22B-Y LPG is the same as，CPQD15~18N-RW21（or CPQD15~18N-RW20）,
CPQD20~35N-RW22（or CPQD20~35N-RW11）,CPQD20-35N-RW22A（or CPQD20-35N-RW11A）,
CPQD20-35N-RW22B（or CPQD20-35N-RW11B）except the LPG fuel system.
1. IMPCO Fuel system
There are two kinds of IMPCO changing device
1)、LPG dual-fuel changing device-DFK8634A
2)、LPG single-fuel changing device-K8634A
There are three sections in Impco parts catalog and maintenance manual, they are list, illustration and
dismantle of main pars. For details, please see the reference content.
content
1．DFK8634A dual-fuel list
2．K8634A single list
3．Fuel system main parts’ illustration
4．Main part VFF3-2 valve dismantle process.
Main part COBRA-30177 Pressure reducer dismantle process
1. DFK8634A dual-fuel convert device list
Serial
Code
Name
Specification
Quantity
1
DK-01001
BRACKET-FUEL HOSE HOLDER
1
2
DK-01002
COUPLING-MALE TANK CONNECTION
1-1/4"F.ACME X 3/8" FNPT
1
1-2 Installed together
3
DK-01003
COUPLING-FEMALE TANK CONNECTION
1/4" FNPT X 1-1/4"M.ACME
1
4
DK-01004
CONVERSION FITTING
3/8" SAE FLARE X 1/4"NPT X45°
1
5
DK-01005
LPG HOSE ASSY
800mm
1
3-5 Installed together

9
6
DK-02001
BULKHEAD FITTING
1
7
DK-02002
HYDROSTATIC RELIEF VALVE
400PSI
1
8
DK-02003
LOCKWASHER
Star,7/8"
1
9
DK-02004
NUT
7/8"
1
10
DK-02005
BUCKHEAD OUTLET FITTING
3/8" SAE FLARE X 1/4"NPT X45°
1
11
DK-02006
PLASTIC CAP
1
12
DK-02007
BULKHEAD INLET FITTING
3/8" SAE FLARE X 1/4"NPT
1
6-12 installed together
13
DK-03001
GASOLINE SOLENOID VALVE
12V
1
14
DK-03002
SOLENOID INLET FITTING
1/4"SAE FLARE X 1/4"NPT X 90°
1
15
DK-03003
SOLENOID OUTLET FITTING
1/4"NPT X 1/8"NPT
1
16
DK-03004
CONVERSION FITTING
1/8" FPTX 1/8BSP X 90
1
13-15 installed together
17
DK-04001
Fuel change switch assemble
12V
1
18
DK-04002
AUXILIARY FUEL LINT
1000mm X 2- 3/8 SAE FLARE FITTING
1
19
DK-04003
FILTERLOCK INLET FITTING
3/8" SAE FLARE X 1/4"NPT
1
20
DK-04004
FILTERLOCK
VFF30-2
1
21
DK-04005
VACUUM FITTING
1/4" ID HOSE X 1/8"NPT X 90°
1
22
DK-04006
FILTERLOCK OUTLET FITTING
3/8" INV FL X 1/4"NPT X 90°
1
23
DK-04007
TUBE ASSY
1
24
DK-04008
LPG SOLENOID VALVEINLET FITTING
3/8" INV FL X 1/4"NPT X 90°
1
25
DK-04009
LPG SOLENOID VALVE
12V
1
26
DK-04010
LPG SOLENOID VALVE OUELET FITTING
1/4"FNPT X 1/4" NPT X 90°
1
27
DK-04011
REGULATOR INLET FITTING
1/4"NPT X 1/4"NPT
1
28
DK-04012
REGULATOR
COBRA,CB-30177
1
29
DK-04013
REGULATOR WATER OUTLET FITTING
3/8"NPT X 3/8" NPT X 90°
1
30
DK-04014
THERMOSTATE
1
31
DK-04015
THERMOSTATE WATER OUTLET FITTING
3/8" SAE FLARE X 3/8"NPT X 90°
1
32
DK-04016
WATER RETURN HOSE
10mm ID HOSE, 600mm
1
33
DK-04017
WATER HOSE CLAMP
10-18mm
2
34
DK-04018
REGULATOR LPG OUTLET FITTING
5/8" ID HOSE X 1/2" NPT X 90°
1
35
DK-04019
LPG INLET HOSE
5/8 ID" HOSE X 850mm
1
36
DK-04020
CLAMP
15-30mm
2
37
DK-04021
ASSY's BRACKET
1
38
DK-04022
BOLT
1/4"-20 X 3/4"
4
39
DK-04023
FLATWASHER
1/4"
4
40
DK-04024
LOCKWASHER
1/4"
4
41
DK-04025
REGULATOR WATER INLET FITTING
3/8"SAE FLARE X 3/8" NPT
1
42
DK-04026
WATER SUPPLY HOSE
10mm ID HOSE, 1000mm
1
18-41 installed together
43
DK-05001
MIXER
CA55-0258
1
44
DK-05002
CONVERSION FITTING
1/8" FNPT X 1/8 NPT X 90°
1

10
45
DK-05003
CRANKCASE VENTILATION HOSE FITTING
1/2" HOSE X 1/8 NPT
1
46
DK-05004
CRANKCASE VENTILATION HOSE
1/2" ID HOSE X 400mm
1
47
DK-05005
VACUUM SIGNAL HOSE
1/4" ID HOSE X 60mm
1
48
DK-05006
MIXER LPG INLET FITTING
5/8" ID HOSE X 3/8 NPT X 90°
1
49
DK-05007
VACUUM FITTING
1/4" ID HOSE X 1/4"-28
1
50
50
DK-06001
NYLON STRAP
8
51
DK-06002
GASOLINE FUEL GAUGE DECAL
1
52
DK-06003
FUEL CHANGOVERIN STRUCTION DECAL
1
53
DK-06004
REFUELING INSTRUCTION DECAL
1
54
DK-06005
SAFETY MAINTENANCE
1
55
DK-06006
PLASETIC CAP
1/2" ID CAP
1
2. K8634A Single-fuel switch device parts list
Serial
Code
Name
Specification
Quantity
1
DK-01001
BRACKET-FUEL HOSE HOLDER
1
2
DK-01002
COUPLING-MALE TANK CONNECTION
1-1/4"F.ACME X 3/8" FNPT
1
1-2 installed together
3
DK-01003
COUPLING-FEMALE TANK CONNECTION
1/4" FNPT X 1-1/4"M.ACME
1
4
DK-01004
CONVERSION FITTING
3/8" SAE FLARE X 1/4"NPT X45°
1
5
DK-01005
LPG HOSE ASSY
800mm
1
3-5 installed together
6
DK-02001
BULKHEAD FITTING
1
7
DK-02002
HYDROSTATIC RELIEF VALVE
400PSI
1
8
DK-02003
LOCKWASHER
Star,7/8"
1
9
DK-02004
NUT
7/8"
1
10
DK-02005
BUCKHEAD OUTLET FITTING
3/8" SAE FLARE X 1/4"NPT X45°
1
11
DK-02006
PLASTIC CAP
1
12
DK-02007
BULKHEAD INLET FITTING
3/8" SAE FLARE X 1/4"NPT
1
6-12 installed together
13
DK-04002
AUXILIARY FUEL LINT
1000mm X 2- 3/8 SAE FLARE FITTING
1
14
DK-04003
FILTERLOCK INLET FITTING
3/8" SAE FLARE X 1/4"NPT
1
15
DK-04004
FILTERLOCK
VFF30-2
1
16
DK-04005
VACUUM FITTING
1/4" ID HOSE X 1/8"NPT X 90°
1
17
DK-04006
FILTERLOCK OUTLET FITTING
3/8" INV FL X 1/4"NPT X 90°
1
18
SK-04007
TUBE ASSY
1
19
DK-04011
REGULATOR INLET FITTING
1/4"NPT X 1/4"NPT
1
20
DK-04012
REGULATOR
COBRA,CB-30177
1
21
DK-04013
REGULATOR WATER OUTLET FITTING
3/8"NPT X 3/8" NPT X 90°
1
22
DK-04014
THERMOSTATE
1
23
DK-04015
THERMOSTATE WATEROUTLET FITTING
3/8" SAE FLARE X 3/8"NPT X 90°
1

11
24
DK-04016
WATER RETURN HOSE
10mm ID HOSE, 600mm
1
25
DK-04017
WATER HOSE CLAMP
10-18mm
2
26
DK-04018
REGULATOR LPG OUTLET FITTING
5/8" ID HOSE X 1/2" NPT X 90°
1
27
DK-04019
LPG INLET HOSE
5/8" ID HOSE X 850mm
1
28
DK-04020
CLAMP
14-27mm
2
29
SK-04021
ASSY's BRACKET
1
30
DK-04022
BOLT
1/4"-20 X 3/4"
4
31
DK-04023
FLATWASHER
1/4"
4
32
DK-04024
LOCKWASHER
1/4"
4
33
DK-04025
REGULATOR WATER INLET FITTING
3/8"SAE FLARE X 3/8" NPT
1
34
SK-04026
WATER SUPPLY HOSE
10mm ID HOSE, 600mm
1
14-34 installed together
35
SK-05001
MIXER
I172
1
36
SK-05002
IDLE ADJUSTMENT SCREW
1
37
SK-05003
MIXER LPG INLET FITTING
5/8" ID HOSE X 3/8 NPT X 90°
1
38
SK-05004
VACUUM FITTING
1/4" ID HOSE X 1/4"-28
1
39
DK-05005
VACUUM SIGNAL HOSE
1/4" ID HOSE X 600mm
1
40
SK-05006
GASKET
1
41
SK-05007
throttle lever bracket
1
42
SK-05008
conversion flange
1
43
SK-05009
return spring
1
44
SK-05010
DASHPOT
1
45
SK-05011
CABLE BRACKET
1
35-45 installed together
46
DK-06001
NYLON STRAP
8
47
SK-06003
IDLE ADJUSTMENT HOSE
4mm ID X 300mm
1
48
DK-06004
REFUELING INSTRUCTION DECAL
1
49
DK-06005
SAFETY MAINTENANCE
1

12
3. Combustion system main parts illustration
CONNECTION
LINE
ITEM
PART No
NAME
1
DK-01001
BRACKET-FUEL
HOSE HOLDER
2
DK-01002
COUPLING-MALE
TANK
CONNECTION
3
DK-01003
COUPLING-FEMALE
TANK
CONNECTION
4
DK-01004
CONVERSION
FITTING
5
DK-01005
LPG HOSE ASSY
BULKHEAD
ITEM
PART No
NAME
6
DK-02001
BULKHEAD
FITTING
7
DK-02002
HYDROSTATIC
RELIEF VALVE
8
DK-02003
LOCKWASHER
9
DK-02004
NUT
10
DK-02005
BUCKHEAD
OUTLET FITTING
11
DK-02006
PLASTIC CAP
12
DK-02007
BULKHEAD
INLET FITTING
DFK8634A DUAL-FUEL
GASOLINE
SOLENOID
VALVE
ITEM
PART No
NAME
13
DK-03001
GASOLINE
SOLENOID
VALVE
14
DK-03002
SOLENOID
INLET FITTING
15
DK-03003
SOLENOID
OUTLET FITTING

13
16
DK-03004
CONVERSION
FITTING
DFK8634A DUAL-FUEL FILTERLOCK-REGULATOR
ASSY
ITEM
PART No
NAME
ITEM
PART No
NAME
18
DK-04002
AUXILIARY FUEL LINT
31
DK-04015
THERMOSTATE WATER
OUTLET FITTING
19
DK-04003
FILTERLOCK INLET FITTING
32
DK-04016
WATER RETURN HOSE
20
DK-04004
FILTERLOCK
33
DK-04017
WATER HOSE CLAMP
21
DK-04005
VACUUM FITTING
34
DK-04018
REGULATOR LPG OUTLET
FITTING
22
DK-04006
FILTERLOCK OUTLET FITTING
35
DK-04019
LPG INLET HOSE
23
DK-04007
TUBE ASSY
36
DK-04020
CLAMP
24
DK-04008
LPGSOLENOIDVALVEINLET
FITTING
37
DK-04021
ASSY's BRACKET

14
25
DK-04009
LPG SOLENOID VALVE
38
DK-04022
BOLT
26
DK-04010
LPGSOLENOIDVALVEOUELET
FITTING
39
DK-04023
FLATWASHER
27
DK-04011
REGULATOR INLET FITTING
40
DK-04024
LOCKWASHER
28
DK-04012
REGULATOR
41
DK-04025
REGULATOR WATER INLET
FITTING
29
DK-04013
REGULATORWATEROUTLET
FITTING
42
DK-04026
WATER SUPPLY HOSE
30
DK-04014
THERMOSTATE
DFK8634A DUAL-FUEL
CARBURETOR ASSY
ITEM
PART No
NAME
43
DK-05001
MIXER
44
DK-05002
CONVERSION
FITTING
45
DK-05003
CRANKCASE
VENTILATION
HOSE FITTING
46
DK-05004
CRANKCASE
VENTILATION
HOSE
47
DK-05005
VACUUM
SIGNAL HOSE
48
DK-05006
MIXER LPG
INLET FITTING
49
DK-05007
VACUUM
FITTING
K8634A SINGL-FUEL
FILTERLOCK-REGULATOR ASSY

15
K8634A SINGLE-FUEL FILTERLOCK-REGULATOR ASSY
13
DK-04002
AUXILIARY FUEL LINT
24
DK-04016
WATER RETURN HOSE
14
DK-04003
FILTERLOCK INLET FITTING
25
DK-04017
WATER HOSE CLAMP
15
DK-04004
FILTERLOCK
26
DK-04018
REGULATOR LPG OUTLET
FITTING
16
DK-04005
VACUUM FITTING
27
DK-04019
LPG INLET HOSE
17
DK-04006
FILTERLOCK OUTLET FITTING
28
DK-04020
CLAMP
18
SK-04007
TUBE ASSY
29
DK-04021
ASSY's BRACKET
19
DK-04011
REGULATOR INLET FITTING
30
SK-04022
BOLT
20
DK-04012
REGULATOR
32
DK-04024
LOCKWASHER
21
DK-04013
REGULATORWATEROUTLET
FITTING
33
DK-04025
REGULATOR WATER INLET
FITTING
22
DK-04014
THERMOSTATE
34
SK-04026
WATER SUPPLY HOSE
23
DK-04015
THERMOSTATEWATEROUTLET
FITTING

16
K8634A SINGLE-FUEL
CARBURETOR
ITEM
PART No
NAME
35
SK-05001
MIXER
36
SK-05002
IDLE
ADJUSTMENT
SCREW
37
SK-05003
MIXER LPG
INLET FITTING
38
SK-05004
VACUUM
FITTING
39
DK-05005
VACUUM
SIGNAL HOSE
40
SK-05006
GASKET
41
SK-05007
THROTTLE
LEVER
BRACKET
42
SK-05008
CONVERSION
FLANGE
43
SK-05009
RETURN
SPRING
44
SK-05010
DASHPOT
45
SK-05011
CABLE
BRACKET
OTHERS
ITEM
PART No
NAME
46
DK-06001
NYLON STRAP
47
SK-06002
IDLE
ADJUSTMENT
HOSE
48
DK-06003
REFUELING
INSTRUCTION
DECAL
49
DK-06004
SAFETY
MAINTENANCE

17
4. VFF30-2 Filterlock disassembly and assembly flow
I
Do not use the TELFON screw thread instead of NPT type, where the fuel pass through.
II
Use suds inspect all joints, fuel tank and covers.
III
Using the correct bolt to ensure the safety of lock valve, longer bolt may lead to serious damage.
G1-89
gasket
AF1-10
filter
S7-3
screen
BD1-26
diaphragm
BD1-27
diaphragm
BD1-27-5
diaphragm
S1-59
Screw（2）
S1-100
Screw（2）
S4-18
valve seat
S3-116
O-ring
P1-15
valve operating pin
W1-42
retaining washer
PP-1-4-116
Installation guide
H1-14236
holder
P1-14235
Installation pin
2
Remove 10 screws from cover which has the
words "Fuel In" cast into it.

18
3
Remove the cover and the gasket
4
4
Remove the filter and screen
5
Remove screw holding spring in p

19
6
Remove the valve spring
7
Remove valve seat
8
Remove valve operating pin
