Epic Fitness STRENGTH Olympic Bench User manual

FLATBENCH
FLAT BENCH
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.jumpking.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.imagefitness.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.reebokhomefitness.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.healthrider.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.weiderfitness.com
new products, prizes,
fitness tips, and much more!
Visit our website at
www.freemotionfitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Model No. GZFW20211
Serial No.
Write the serial number in the
space above for future reference.
Serial Number Decal (End of Tube)
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guaran-
tee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
customer hot line will provide
immediate assistance, free of
charge.
CUSTOMER HOT LINE:
1-800-201-2109
Mon.–Fri., 8 a.m.–5 p.m. MST
OWNER’S MANUAL

TABLE OF CONTENTS
2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
WEIGHTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
WARRANTY TERMS AND CONDITIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover

3
1. Read all instructions in this manual before
using the strength bench. Use the strength
bench only as described in this manual.
2. It is the purchaser’s responsibility to ensure
that there is enough space around the
strength bench for the intended exercise. Do
not crowd the strength bench.
3. Using the three 9/16” anchor holes to pro-
vide maximum stability, the strength bench
must be anchored to the floor where required
or whenever possible.
4. It is the responsibility of the owner to ensure
that all users of the strength bench are ade-
quately informed of all precautions.
5. All users of the strength bench should be
instructed to report any injury or strength
bench irregularity to facility staff immediately.
6. Keep children under 12 and pets away from
the strength bench at all times.
7. Always wear athletic shoes for foot protec-
tion while exercising.
8. Make sure all parts are properly tightened
before each use of the strength bench.
Replace any worn parts immediately.
9. Do not lean on or rest your hands on the
strength bench when it is in use.
10. Use the strength bench only on a level sur-
face. Cover the floor beneath the strength
bench to protect the floor.
11. The strength bench is designed to support a
maximum user weight of 350 pounds, and a
maximum total weight of 950 pounds. Do not
use the bench with more than 600 pounds of
weight, including a barbell. Note: The
strength bench does not include a barbell or
weights.
12.
Always exercise with a partner. Your partner
should be ready to catch the barbell if you
cannot complete a repetition.
13. If you feel pain or dizziness at any time while
exercising, stop immediately and begin cool-
ing down.
WARNING: Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
WARNING: To reduce the risk of serious injury, read the following important precautions
before using the strength bench.
IMPORTANT PRECAUTIONS

ASSEMBLED DIMENSIONS:
Height: 51 in. / 130 cm
Width: 66 in. / 168 cm
Depth: 66 in. / 168 cm
4
Seat
Anchor Holes
Storage Bar
Rack
BEFORE YOU BEGIN
Thank you for selecting the EPIC STRENGTH™
OLYMPIC BENCH strength bench. The strength bench
is designed to help develop the major muscle groups of
the upper body. Whether your goal is to tone your body,
build dramatic muscle size and strength, or improve
your cardiovascular system, the strength bench will help
you to achieve the specific results you want.
For your benefit, read this manual carefully before
using the strength bench. If you have additional
questions, please call our Customer Service
Department toll-free at 1-800-201-2109, Monday
through Friday, 8 a.m. until 5 p.m. Mountain Time
(excluding holidays). To help us assist you, please
note the product model number and serial number
before calling. The model number is GZFW20211. The
serial number can be found on a decal attached to the
strength bench (see the front cover of this manual).
Before reading further, please review the drawing
below and familiarize yourself with the parts that are
labeled.

1. Attach the Left Arm (2) to the Base (1) with two
1/2” Washers (12) and two 1/2” x 1” Bolts (9).
Attach the Right Arm (14) in the same manner.
2. Identify the Right and Left Uprights (3 [not
shown], 13). Note: The racks are offset toward
the outside of the Upright.
Attach the Left Upright (13) to the Left Arm (2)
with four 1/2” x 3 1/2” Button Head Bolts (15). Do
not tighten the Bolts yet.
Attach the Right Upright (not shown) to the
Right Arm (not shown) in the same manner.
Make sure that the racks are aligned and tight-
en the eight 1/2” x 3 1/2” Button Head Bolts
(15).
5
Before beginning assembly, carefully read the
following information and instructions:
•Assembly requires two people.
•Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
•Tighten all parts as you assemble them, unless
instructed to do otherwise.
•As you assemble the strength bench, make sure
all parts are oriented as shown in the drawings.
The following tools (not included) are required
for assembly:
• One adjustable wrench
• One Allen wrench
Assembly will be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
Make Things Easier for Yourself
Everything in this manual is designed to ensure
that the strength bench can be assembled suc-
cessfully by most people. Setting aside plenty of
time will help assembly go smoothly.
ASSEMBLY
1
1
2
12
9
14
2
2
13
Rack
15

6
3. Attach the Seat (4) to the Base (1) with two 3/8” x
4” Bolts (8). 3
5. Attach a Long Weight Bar (6) to the Left Upright
(13) with a 1/2” x 1 1/4” Button Head Bolt (11).
Attach a Long Weight Bar (6) to the Right
Upright (not shown) in the same manner.
6. Slide four Bumper Rings (7) on a Long Weight
Bar (6). Slide a Bumper Ring onto a Short Weight
Bar (5).
Repeat with the other Weight Bars (not
shown).
7. Make sure that all parts have been properly
tightened.
4. Attach a Short Weight Bar (5) to the Left Upright
(13) with a 1/2” x 3” Bolt (10).
Attach a Short Weight Bar (5) to the Right
Upright (not shown) in the same manner.
4
1
8
8
413
5
13
6
11
6
6
7
7
7
5
10
5

This section explains how to use the strength bench for storing weights. Make sure all parts are properly tight-
ened each time the strength bench is used. Replace any worn parts immediately.
7
Rack
Rack
Long
Storage
Bar
25-lb.
weights
45- and 35-lb.
weights
5- and 10-lb.
weights
Long
Storage
Bar
Short
Storage
Bar
Short
Storage
Bar
WEIGHTS
STORING WEIGHTS
Store unused weights on the storage bars. Note: The
diagram shows the suggested locations for storing
weights.
WARNING: Each long storage bar
can hold up to 150 pounds. Each short storage
bar can hold up to 225 pounds. Do not place
more than a total of 600 pounds, including the
barbell (not included), on the racks and stor-
age bars. Always place an equal amount of
weight on each side of your barbell.

8
MAINTENANCE
It is important for safe and trouble-free operation of your EPIC STRENGTH™strength equipment to perform rou-
tine preventative maintenance on a regular basis. Make sure that all parts are properly tightened each time the
strength bench is used. Replace any worn parts immediately. The strength bench can be cleaned with a damp cloth
and a mild, non-abrasive detergent. Do not use solvents.
Note: Instruct all personnel to perform equipment inspection and maintenance requirements. Personnel must
record and report any accident. Contact FreeMotion Fitness Customer Service at 1-800-201-2109 with any
questions or concerns.
Use only original EPIC STRENGTH parts for repair or replacement to maintain your bench’s warranty.
FreeMotion Fitness recommends the following procedures:
SCHEDULED MAINTENANCE
DAILY
1. Upholstery—General cleaning:
• Wipe using a soft cloth dampened with a light
solution of household dish detergent and warm
water.
• If necessary, use a soft bristle brush with the
cleaning solution.
• Always remove the cleaning solution using a
cloth dampened with clean water. Rinse often.
2. Upholstery—Difficult stains:
• Spray the stain with a non-abrasive household
cleaner such as FORMULA 409®cleaner,
SIMPLE GREEN®, or a similar product.
• Rub the area gently and let it sit for a few min-
utes.
• Rinse thoroughly using a clean, water-damp-
ened cloth.
• Repeat if necessary using a soft bristle brush.
Optional method for difficult stains:
• Rub the area gently using a soft cloth damp-
ened with rubbing alcohol.
• Rinse thoroughly using a water-dampened cloth
to remove alcohol residue.
CAUTION: When using any cleaning product, try
it first in an inconspicuous place to ensure there
is no damage to the material. Follow directions
and adhere to the safety precautions of the manu-
facturer of each cleaning agent used. FreeMotion
Fitness and its vendors cannot be held liable for
damage or injuries resulting from the use or mis-
use of cleaning products.
3. Frames:
• Wipe with a light solution of mild soap and warm
water. Rinse and dry thoroughly.
Important: Do not use abrasive cleaners
because they may scratch the equipment. Strong
cleansers and abrasives will damage decals. Use
caution around decals. Do not use solvents such
as lacquer thinner, kerosene, gasoline, or similar
liquids.
WEEKLY
1. Hardware:
• Check all nuts and bolts. Tighten them as
required.
CUSHION ATTACHMENT
Important: All EPIC STRENGTH cushions are fabri-
cated using dense plywood with tee-nuts installed for
bolting to the machine framework. Because these tee-
nuts are held by the plywood, they will not withstand
the torque that standard nuts and bolts will. Therefore,
when tightening the cushion bolts, turn them only until
they are snug and the cushion does not move or feel
loose. Overtightening may strip the tee-nuts from the
plywood and make it impossible to remove the cush-
ion in the future.

Note: “#” indicates a non-illustrated part. Specifications are subject to change without notice. See the back cover
of the owner’s manual for information about ordering replacement parts.
Key No. Qty. Description Key No. Qty. Description
1 1 Base
2 1 Left Arm
3 1 Right Upright
41 Seat
5 2 Short Weight Bar
6 2 Long Weight Bar
7 10 Bumper Ring
8 2 3/8” x 4” Bolt
9 4 1/2” x 1” Bolt
10 2 1/2” x 3” Bolt
11 2 1/2” x 1 1/4” Button Head Bolt
12 4 1/2” Washer
13 1 Left Upright
14 1 Right Arm
15 8 1/2” x 3 1/2” Button Head Bolt
# 1 Owner’s Manual
PART LIST/EXPLODED DRAWING—Model No. GZFW20211 R0204A
10
11
13
5
7
5
7
9
1
2
4
8
89
12
12
3
6
6
7
7
7
7
10
11
15
14
15
9

WARRANTY TERMS AND CONDITIONS
10
Limited Warranty on Commercial Equipment
FreeMotion Fitness, Inc. warrants that all new equipment will be free of manufacturing defects in workman-
ship and materials, becoming effective at the date of original installation. Parts repaired or replaced under
the terms of this warranty will be warranted for the remainder of the original warranty period only. Labor
must be performed at a FreeMotion Fitness commercial service facility or by a FreeMotion Fitness author-
ized commercial service provider.
Terms and Conditions of Coverage
1. Warranty applies only while:
(A) it remains in the possession of the original purchaser and proof of purchase is demonstrated,
(B) it has not been subject to accident, misuse, abuse, improper service, or modification, and
(C) claims are made within the warranty period.
2. All coverage is provided by specific Product according to the guidelines listed below.
3. If the Product or any covered part must be returned to a service facility for repairs, We, FreeMotion
Fitness, Inc., will pay all transportation and insurance charges for the first year. We must approve trans-
portation and insurance previous to shipping. You are responsible for transportation and insurance
charges during the remaining years.
4. We will ship to you any new or rebuilt replacement part or component, or, at our option, replace the
Product. Such replacement parts are warranted for the remaining portion of the original warranty period.
5. This warranty does not cover damage or equipment failure caused by failure to provide reasonable and
necessary maintenance as outlined in the owner’s manual. Any failures or damage caused by unautho-
rized service, misuse, accident, negligence, improper assembly or installation, debris resulting from any
destruction activities in the Product’s environment, rust or corrosion as a result of the Product’s location,
alterations or modifications without written authorization, or by failure on your part to use, operate, and
maintain the Product as set in your owner’s manual will void this warranty.All terms of this warranty
are void if this Product is moved beyond the continental borders of the United States of America
(excluding Alaska, Hawaii, and Canada) and are then subject to the terms provided by that coun-
try’s local authorized FreeMotion Fitness representative.
6. During the labor period, FreeMotion Fitness, Inc. compensates Servicers for warranty trips within their
normal service area to repair Product at the consumer’s location. You may be charged a trip charge out-
side the service area.
7. FreeMotion Fitness, Inc. Limited Warranty service may be obtained by contacting Customer Care at
1-800-201-2109.
8. Product limited warranty is void when Product is installed in a country other than where sold.
Limited warranty does not apply to:
1. Repairs performed on Product with missing, altered, or defaced serial numbers.
2. Service calls to correct installation of the Product or instruct owners on how to use the Product.
3. Repair pick-up, delivery, or freight charges other than specified above.
4. Any labor costs incurred beyond the applicable labor warranty period.
Limited Warranty
Parts are warranted to be free from defects in materials and workmanship for the duration of the warranty
period as described below. Labor is warranted for one year except for upholstery and grips.
• 10 years: Structural frame
• 3 years: Bearings, guide rods, pulleys, cams, weight stacks
• 1 year: Cables
• 120 days: Upholstery, grips, selector pins, knobs, decals

11
Your Responsibility
Retain proof of purchase; use, operate, and maintain the Product as specified in the Owner’s Manual; noti-
fy Customer Care of any defect within 10 days after discovery of the defect; if instructed, return any defec-
tive part for replacement, or, if necessary, the entire Product for repair.
Owner’s Manual
It is very important that you read the Manual before operating the Product. Remember to perform the peri-
odic maintenance requirements specified in the Manual to assure proper operation and your continued sat-
isfaction.
Receipt of Parts and Service
Simply call Customer Care toll-free at 1-800-201-2109, Monday through Friday from 8 a.m. to 5 p.m.
Mountain Time, and give your name, address, and the serial number of your Product. A representative will
tell you how to get a replacement part, or, if necessary, arrange for service where your Product is located
or advise you on how and where to ship the Product for service.
Before Shipping:
1. Obtain a Return Authorization Number (RA#) from Customer Care.
2. Securely pack your Product.
3. Write the RA# on the outside of the carton.
4. Insure the Product.
5. Include a letter explaining the defect or problem and a copy of your proof of purchase if you believe the
service is covered by warranty.
Exclusive Warranty
FreeMotion Fitness, Inc. is not responsible or liable for indirect, special, or consequential damages arising
out of, or in connection with, the use or performance of the Product or damages with respect to any eco-
nomic loss, loss of property, loss of revenues or profits, loss of enjoyment or use, costs of removal or
installation, or other consequential damages of whatsoever nature. Some states do not allow the exclusion
or limitation of incidental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth
herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly, the above
limitation may not apply to you.
Unauthorized Changes to Warranty
No one is authorized to change, modify, or extend the terms of this limited warranty.
State Laws
This warranty gives you specific legal rights and you may have other rights which vary from state to state.

Part No. GZ7252 R0204A Printed in USA © 2004 ICON Health & Fitness, Inc.
To order replacement parts, simply call our Customer Service Department toll-free at 1-800-201-2109, Monday
through Friday, 8 a.m. until 5 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre-
pared to give the following information:
• The MODEL NUMBER of the product (GZFW20211)
• The NAME of the product (EPIC STRENGTH™ OLYMPIC BENCH strength bench)
• The SERIAL NUMBER of the product (see the front cover of this manual)
• The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST and EXPLODED DRAWING on
page 9 of this manual)
ORDERING REPLACEMENT PARTS
