IR-700
Small cash register –
huge progress:
Epson IR-700
ArevolutionarygenerationofEpsonall-in-onecashregistersen-
tersthemarketwiththeEpsonIR-700.Atfirstglance,thenew
“cashregisterflagship”ischaracterisedbyitsstraightforwardde-
sign.Uponcloserinspection,itbecomesclearthatEpsonhassuc-
ceededincombining maximumbenefitwithminimalsize.Theergo-
nomiccashregistersystemfeaturesconvenient useof all functions
and options.Butnotonlythesophisticateddesign distinguishesthe
EpsonIR-700 fromitsestablishedpredecessorIR-320:IntelCel-
eronMand PentiumMprocessorsensurehigh performanceat
extremelylownoiseleveland powerconsumption. Inadditiontothe
brilliant12.1inchSVGAor15 inchXGAdisplayfeaturing atouch
screen,theincreasedflexibilityofthesystemvia anintegrated
CompactFlashslotand newwireless LANand peripheraloptions
facilitateeverydaywork.Theperformance,adaptabilityand reliabil-
ityofanoutstanding brand onafootprint of just 250 x340 mm: The
EpsonIR-700 providesconvenienceand efficiency inthecash
registeroperationofspecialtyretailersand resellers,grocerymar-
ketsand thehospitalitysegmentaswell aspointofinformation
stations.
Anything ispossible–outstanding cash
register!
Thefeaturessetstandards:therapidhigh-performanceoftheEp-
sonIR-700’sIntelPentiumM1.8GHzand IntelCeleronM1.3GHz
processorsisreflectedneitherinthenoiselevelnorpowercon-
sumption–onthecontrary.Onaverage,IntelPentiumMproces-
sorsconsumeless thanatenthof theenergyof acomparablePen-
tium4processor.Basedondaily24-hourcashregisteroperation,
thisresultsinannualsavingsof up toEUR200!
Thecashregistersystem’s15-inchTFTtouchscreenisextremely
brightand isalsosuitableforuseinlightrooms.Inadditionto
toughness withregardtosplashing,thespecially-treatedscreenis
alsofingerprintresistant. Thestandard“DualScreenFunction”
evenenablesoperationofafurtherscreen,forexampletodisplay
promotionstocustomersvia anadditionalapplication,generating
improvedsales.
TheintegratedEpsonTM-T88IIIXthermalprinterisbasedonthe
leading globalPoS-printerEpsonTM-T88III. Maintenance-free and
featuring “dropin”paperchanging,itensuresrapidprinting of
neatly-edgedreceiptsinusualEpsonquality!
Versatileineveryrespect
Thankstoitsmanifold easilyaccessibleinterfaces,theEpsonIR-
700 isextremelyflexible.Userscandeploypreciselytheperipher-
alsand storagemedia theywant. AsstandardPCcomponentsare
The compact high-end PoSsystemwith12“TFT,
receipt printer, 28 keypad, MSR, customerdis-
play.
The IR-700 indarkgreywith15“TFT and e.g. 60
POS-keyboard, MSRand customerdisplay.
Alooktothe manyinterfacesand HDDs
(opened rearcover)

© EPSONDeutschland GmbH, Retail Systems&Devices, Otto-Hahn-Strasse4, D-40670 Meerbusch,
Tel.: [phone], Fax: [phone], www.epson.de/rsd, [e-mail],
ISO14001: Zertifizierungsnummer80679, ISO9001: 2001 Zertifizierungsnummer80678.
VerwendeteHard-und Softwarenamen sind Handelsnamen und/oderMarken derjew. Hersteller.
Stand: 05.2006, Technische Änderungen und Liefermöglichkeiten vorbehalten.
IR-700
used,upgrading thesystemiseasy –theEpsonIR-700 isperfectly
equippedforthefuture.IncombinationwiththeRAIDcontroller,a
further3.5-inchharddriveensuresoutstanding reliabilityaswell as
automaticdatastorageand easy installation. Thissystemalsoputs
anend tocableclutteratPoS:Onesinglepowercableisrequired
fortheentirecashregistersystemand networkintegrationiseven
simplefornovicesthankstothenetworkinterfaceortheoptional
Epsonwireless LANcard.Furthermore,4rapidUSB 2.0and 4free
serialports,paralleland PS/2interfacesfulfilall requirementsre-
garding peripheralconnections.
At250 x340 mm,thefootprintoftheEpsonIR-700 isextremely
compact. Thiscanevenbereducedto250 x260 mm thankstothe
kioskkitforpositioning thecashregistervertically.Thus,thecash
registersystemisalsoidealforthesmallestspaces.Furthermore,
itfeaturesa“minimalprofile“duetoitscompactdimensionsand
doesnotimpedeeyecontactwithcustomers. TheintegratedDM-D
customerdisplayproveninnumerabletimescanberetained.
Key criterion:reliability
ReliabilityisTHEkeycriterionofexcellentcashregistersystems–
ifthecashregisterisunstable,salesareatrisk.Thus,everycom-
ponentoftheEpsonIR-700 isextremelyrobustand durable.The
operating lifeofcomponentsiswell aboveaverageevenwhenin
use“around theclock”.Epson’scomprehensivemaintenancesoft-
warereducesfailuresand providesextensiveremotediagnosis
and backup functionsvia ISDN,internetorLAN.Thesystem’sser-
viceabilityisbeneficialincaseupgradeisrequired.Whethermoth-
erboard,harddrives,printersormonitors,all componentscanbe
accessedorexchangedrapidlyand easily. Timerequired: less than
5minutes.
On-siteservice intothebargain
Foranentireyear,on-siteserviceisincludedinthepurchaseprice
oftheIR-700 aswell astheothercashregistersystemsSRand
MR.Qualifiedtechniciansreplace,whereverpossible,anydefec-
tivecomponentsrightwherethecashregisterisinstalled,thus
ensuring quickresumptionofsmoothoperationatthecheck-out
and keeping turnoverlossestoaminimum.Forthosewishing
longer-lasting dependability,thereisalsotheoptionofextending
theon-siteservicetothree ormoreyears.
Branchsolutions
Meanwhile,therearealargenumberofsoftwareprogrammes,
whichhavebeendesignedforusewiththeIRand coverall impor-
tantbusiness needsfromgeneralmerchandising solutionsto
branchrelatedapplications.
Youcanfind thecompletesolution,whichismostsuitableforyour
business sectorinthe„EPSONSolutionpartner“table.
Upgrade memoryorinsert CompactFlashcard?
Noproblemwiththe easy accessiblemotherboard.
The verticalsettingkit (option)oncemorereduces
the footprint. The receipt ispresented tothe user.
The HDDsareeasy toreachan ensureprotection
of the important dataviaRAIDController.

© EPSONDeutschland GmbH, Retail Systems&Devices, Otto-Hahn-Strasse4, D-40670 Meerbusch,
Tel.: [phone], Fax: [phone], www.epson.de/rsd, [e-mail],
ISO14001: Zertifizierungsnummer80679, ISO9001: 2001 Zertifizierungsnummer80678.
VerwendeteHard-und Softwarenamen sind Handelsnamen und/oderMarken derjew. Hersteller.
Stand: 05.2006, Technische Änderungen und Liefermöglichkeiten vorbehalten.
IR-700
Features ofIR-700 Yourbenefit
All-in-oneconcept Nocableknotsat PoS, protectionof inadvertent disconnection
Compact design, minimizedfootprint Minimalfootprint (25 x34 cm)savesspaceonthecounter, that
canbeusedforadditionalrevenue
Modularstructure, manyoptions TheIRcanbeindividuallycustomised, all componentsarespe-
ciallybuilt toworkwitheachother
Userfriendlyand futureorientedstyl-
ishdesign Goodlooking formanyyears, smart appearanceforthecustom- ers, easy toclean
2coloursavailable Youcanselect: coolwhiteordarkgrey
Integratedhigh-resolutionTFTtouch
screen Brilliant, largedisplayof graphics, text and photos. Verysensible and easy totouch
Programmableanadjustableuser-
interface Colourcoding and largeon-screenbuttonsminimiselearning- curvesand maximiseease-of-use, Photosand symbolscanbe
shownaswell, especiallyuseful foroftenchanging staff
Easy handling bytouchof thefinger Quickerintroductionof personnel, easy toclean
Protectedagainst fingerprints Fingerprintsdonot disturbthecleargraphics
High-end PC-technologywithIntel
Pentium“M”and Celeron“M”CPU Strong and approved; basedonindustrystandards; long term availability, worldwidesupport
Advantagesof „M“CPU ComparedtodesktopCPUsat similarclockratedoubleperform-
ance; producesless heat; needsless fanpower(=less noise);
muchless powerconsumptionsavesup to200,-€peryear
Dual-displaycontrollerintegrated Enabletorun 2applicationssimultaneously; promotionscanbe
shownonsecond displaytoincreasebusiness
BasedonstandardPCtechnology Openstandardarchitectureforasaveinvestment
IntegratedEthernet card
(10Base-T, 100Base-TX) Easy toconnect tonetworks, Wake-on-LAN-functionallowsto boot thesystembynetwork
PoweredUSB card(Option) Savesthepowersuppliesof externalperipheralslikescannersor
credit cardterminals
ExternalUSB 2.0CD-ROMorfloppy
drive(option) Update, installationormaintenanceon-sitebecomesaChildsplay
Uptotwo3,5“HDDswithRAIDcon-
trolleronboard Perfect forpermanent datamirroring; high securitylevelensures ongoing business transactions
HDDsarelockable(option) High securityleveltoprevent dataloss and unauthoriseduseof
thesystem, noaccess toconfidentialdata
CompactFlashinterfaceplacedon
themotherboard Bootablevia CompactFlashalsowithout anyHDD; CF-memoryis moredurablethanHDDs
WorldwideprovedthermalPoS-
printerwithaeasy paperhandling is
integrated
Easy touseand reliable, avoidswaiting timeforyourcustomers
incaseof paperend, high printing performance
Integratedsound function Sound filesorspokenremarksfortrainingsand presentationscan
beused
Manyintegratedinterfaceslike4se-
rialand 4xUSB 2.0free Flexibilityand upgradeabilitythrough openPC-architecturesaves theinvestment; bootablevia USB and CompactFlash
2internalPCI ports Easy upgradewithISDNorotherPCI cards
Strong integratedpowersupply Onlyonepowerconnectionforthecompletesystem
Integrated3-trackMSR(option) Best ergonomicposition, easy tousee.g. forECcards
Cablecover Nocableknots, protectionof inadvertent disconnection

© EPSONDeutschland GmbH, Retail Systems&Devices, Otto-Hahn-Strasse4, D-40670 Meerbusch,
Tel.: [phone], Fax: [phone], www.epson.de/rsd, [e-mail],
ISO14001: Zertifizierungsnummer80679, ISO9001: 2001 Zertifizierungsnummer80678.
VerwendeteHard-und Softwarenamen sind Handelsnamen und/oderMarken derjew. Hersteller.
Stand: 05.2006, Technische Änderungen und Liefermöglichkeiten vorbehalten.
IR-700
Programming toolsfree of charge Savestimeand moneyforapplicationdevelopment
Remotemaintenanceand diagnostic
toolsfree of charge Saveson-siteservicecost; updatescanbeeasilydoneperre- motevia LANortheInternet
Extremelyservicefriendly, onlyfew
screws Reducedservice-and maintenancecosts, quickand easy adapta- tionof thesystem
Free programmable60 PoS-keyboard
with2integratedUSB portsand man-
agerkeylock(option)
Forapplicationsthat requireakeyboard; additionalperipherals
canbeconnectedtokeyboard; high securitylevelthrough man-
agerkeylock
Free programmable28 PoS-keyboard
attachedtoLCD (option) Combinescomfortabletouch-input and quicknumericdatainput
Extremelyrobust construction
("Heavy Duty") Reliableand sturdy; alsoforuseintough environment likefast foodrestaurantsorDIY- gardenmarkets
1yearOn-site-serviceincluded;
3-yearOn-site-serviceasoption Ensuresongoing business at thePOSincaseof defect; for3yearsand alsoonweekends
Affordablepricescheme Specificconfigurationsarepossibletocoverindividualneeds,
quickROI („ReturnonInvestment“)
AnEpsonproduct Theperformanceof astrong partner, long availability; worldwide
experience, serviceand support

© EPSONDeutschland GmbH, Retail Systems&Devices, Otto-Hahn-Strasse4, D-40670 Meerbusch,
Tel.: [phone], Fax: [phone], www.epson.de/rsd, [e-mail],
ISO14001: Zertifizierungsnummer80679, ISO9001: 2001 Zertifizierungsnummer80678.
VerwendeteHard-und Softwarenamen sind Handelsnamen und/oderMarken derjew. Hersteller.
Stand: 05.2006, Technische Änderungen und Liefermöglichkeiten vorbehalten.
IR-700
Technical dataEpson IR-700
CPU IntelCeleron®M1.3GHzor
IntelPentium®M1.8GHz(FSB: 400 MHz)
Memory 2x184 PinDDR SDRAMDIMM, max1GB
Drives •CompactFlashinterfaceonboard(bootable)
•1HDD 3,5“or2HDDs3,5"(serialATA)
•Floppydriveexternal(option)
•USB 2.0CD-ROMorCD-RWexternal(option)
Extensions 2xPCI (alsofor3,3Volt)
Interfaces •4serialfree, with+5Vor+12V
•2PS/2
•1forcashdrawer
•1parallel(ECP, EPP)
•4USB 2.0high-speed, 2of thembootable
•1forext. CRT/LCD
•124VforTM-printer
•1Ethernet 10Base-T/100 Base-TX, wake-on-LAN
•1Microphonein, line-out
•1powerin
Video Video controllerwithdual-display-function
15”: 1024 ×768, 260,000 colours(up to16 Mio.)
12,1”: 800 ×600, 260,000 colours(up to16 Mio.)
Touch screen LCD 15,0“(38 cm)TFT(XGA)resistiveor
12,1“(30,7cm)TFT(SVGA)resistive
Standard features •Powerswitchonfront side
•Mainreset switchonfront side
•TM-printerreset switchonfront side
•integratedpowersupply100-240 V
•integratedadjustablespeaker
OS Windows2000 professionalSp4/ WindowsXP professionalSp2
DimensionsWxDxHmm 250 mm ×340 mm ×254 mm
(mainunit without LCD, including cablecover)
Weight approx. 6,4kg(without HDD)
Colour Epsoncoolwhite(ECW)orEpsondarkgrey(EDG)
Options •3-trackMSRISO
•ThermalprinterTM-T88IIIX
•PrinterTrayforotherTM-printers
•Dummy-Cover(if printerisnot integrated)
•IntegratedcustomerdisplayDM-D
•PoleextensionforDM-D
•Kioskkit forverticalsetting
•2nd HDD 3,5“(RAID)
•EpsonPoweredUSB-card(PCI)
•Epsonprogrammable28 keyunit
•Epsonprogrammable60 keyboard
•ExternalEpsonTM-printer
•ExternalCD-ROMorfloppydrive
•3yearsOn-site-service

© EPSONDeutschland GmbH, Retail Systems&Devices, Otto-Hahn-Strasse4, D-40670 Meerbusch,
Tel.: [phone], Fax: [phone], www.epson.de/rsd, [e-mail],
ISO14001: Zertifizierungsnummer80679, ISO9001: 2001 Zertifizierungsnummer80678.
VerwendeteHard-und Softwarenamen sind Handelsnamen und/oderMarken derjew. Hersteller.
Stand: 05.2006, Technische Änderungen und Liefermöglichkeiten vorbehalten.
IR-700
Included Accessories •DriverCD-ROM
•Maintenanceand diagnosticsoftware
•Usermanual
•Cablecover
•1yearon-siteservice
