EPSON TERMINAL PRINTER
EPL-N2000
SERVICE MANUAL
EPSON
4006861

NOTICE
All right reserved. Reproduction of any part of this manual in any form wharsoever without SEIKO EPSON's express
written permission is forbidden.
The contents of this manual are subject to change without notice.
All efforts have been made to ensure the accuracy of the contents of this manual. However, should any errors be
detected, SEIKO EPSON would greatly appreciate being informed of them.
The above notwithstanding SEIKO EPSON can assume no responsibility for any errors in this manual or the consequences
thereof.
Epson is a resistoered trademark of Seiko Epson Corporation.
Generall Notice: Other product names used hererin are for identification purpose only and may be trademarks of their
respective companies.
Copyright 1996 by SEIKO EPSON CORPORATION
Nagano, Japan

PRECAUTIONS
Precautionary notations throughout the tect are categorized relative to1)personal injury, and2)
damage to equipment:
DANGER Singnals a precaution which, if ignored, could ressult in serious or fatal personal
injury, Great caution should be exercised in performing procedures preceded by
a DANGER headings.
WARNING Singnals a precaution which, if ignored, could result in damage to equipment.
The precautionary measures itemized below should always be observed when performing repair
/maintenance procedures.
DANGER
1. ALWAYS DISCONNECT THE PRODUCT FROM BOTH THE POWER SOURCE AND THE
HOST COMPUTER BEFORE PERFORMING ANY MAINTENANCE OR REPAIR PROCEDURE.
2. NO WORK SHOULD BE PERFORMED ON THE UNIT BY PERSONS UNFAMIAR WITH
BASIC SAFETY MEASURES AS DICTATED FOR ALL ELECTRONICS TECHNICIANS IN
THEIR LINE OF WORK
3. WHEN PERFORMING TESTING AS DISCATED WITHIN THIS MANUL, DO NOT CONNECT
THE UNIT TO A POWER SOURCE UNIT INSTRUCTED TO DO SO. WHEN THE POWER
SUPPLY CABLE MUST BE CONNECTED, USE EXTREME CAUTION IN WORKING ON
POWER SUPPLY AND OTHER ELECTRONIC COMPONENTS.
WARNING
1. REPAIRS ON EPSON PRODUCT SHOULD BE PERFORMED ONLY BY AN EPSON
CERTIFIED REPAIR TECHNICIAN.
2. MAKE CERTAIN THAT THE SOURCE VOLTAGE IS THE SAME AS THE RATED VOLTAGE,
LISTED ON THE SERIAL NUMBER/RATIG PLATE. IF THE EPSON PRODUCT HAS A
PRIMARY-AC RATING DIFERENT FORM THE AVAILABLE POWER SOURCE, DO NOT
CONNECTE IT TO THE POWER SOURCE.
3. ALWAYS VERIFY THAT THE EPSON PRODUCT HAS BEEN DISCONNECTED FROM THE
POWER SOURCE BEFORE REMOVING OR REPLACING PRINTED CIRCUIT BOARDS
AND/OR INDDMDUAL CHIPS.
4. IN ORDER TO PROTECT SENSITIVE m P CHIPS AND CIRCUITRY, USE STATIC
DISCHARGE EQUIPMENT, SUCH AS ANTI-STATIC WRIST STRAPS, WHEN ACCESSING
INTERNAL COMPONENTS.
5. REPLACE MALFUNCTIONING COMPONENTS ONLY WITH THOSE COMPONENTS
RECOMMENTED BY THE MAANUFACTURE; INTRODUCTION OF SECOND-SOURCE ICs
OR OTHER NONAPPROVED COMPONENTS MAY DAMAGE THE PRODUCT AND VOID
ANY APPLICABLE EPSON WARRANTY.

SAFETY INFORMATION
This printer is a page printer which operates by means of a laser. There is no possibility of danger from
the laser, provided the printer is operated according to the instructions in this manual provided.
Since radiation emitted by the laser is completely confined within protective housings, the laser beam
cannot escape from the machine during any phase of user operation.
For United States Users;
[Laser Safety1
This printer is certified as aClass 1 Laser product under the U.S. Department of Health
and Human Services (DHHS) Radiation Performance Standard according to the Radia-
tion Control for Health and Safety Act of 1968. This means that the printer does not
produce hazardous laser radiation.
[CDRH Regulations]
The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug
Administration implemented regulations for laser products on August 2,1976. Compli-
ance is mandatory for products marketed in the United States. The label shown below
indicates compliance with the CDRH regulations and must be attached to laser products
marketed in the United States.
WARNING: Use of controls, adjustments or performance of procedures
other
1
than thosespecified inthis manual may result inhazardous radiationexposure.
[Internal Laser Radiation]
Maximum Radiation Power:
5.0 x 1o-4 (W)
Wave Length:
790 *2onm
This is aClass IIIb Laser Diode Assay that has an invisible laser beam. The print head
unit is NOT A FIELD SERVICE ITEM. Therefore, the print head unit should not be
opened under any circumstances.
For Other Countries Users;
WARNING: Use of controls, adjustments or performance of procedures other
than those specified in this manual may result in hazardous radiation exposure.
This is a semiconductor laser. The maximum power of the laser diode is 5.0 x
low4 Wandthewavelength is 790 + 20nm.
For Denmark Users;
ADVARS EL
Usynlig laserstrdling ved abning, nar sikkerhedsafbrydere er ude af funktion.
Undna udszttelse for strbling.
I Klasse 1laser nrodukt der onfvlder IEC825 sikkerheds kravene.

For Finland. Sweden Users:
"" VAROITUS
Laitteen kayttaminen muulla kuin t&a kayttoohjeessa mainitulla tavalla saat-
taa altistaa kayttajan turvallisuusluokan 1ylittavalle nakymattomalle la-
sersateiylle.
I VARNING
Om apparaten anvands pa annat satt %-I i denna bruksanvisning specificerats,
kan anvandaren utsattas for osynlig laserstrhlning, som over&rider gransen
for laser klass 1.
For Finland. Sweden Service PeoDle
VAROITUS
Avattaessa jasuojalukitus ohitettaessa olet alttiina nakymattomalle laser-
sateilylle. Ala katso sateeseen.
VARNING
Osynliglaserstralning nar denna de1 ar Bppnad och sparren ar urkopplad.
Betrakta eistralen.
For Norway Users;
ADVARSEL
Dersom apparatet brukes pa annen mate enn spesifisert i denne bruksan-
visning, kan brukeren utsettes forunsynlig laserstrdling som over&rider gren-
sen for laser klasse 1.
Dette er en halvleder laser. Maksimal effeckt til laserdiode er 5.0 x lo-" W og
bolgelengde er 790 + 20 nm.
Laser Safety Labels
[Label on rear printer case]
A laser safety labels is attached on the outside of the printer shown below.
For United State
This laser product conforms to the applicable
requirement of 21 CFR
Chapter I, subchapter J.
SEIKO EPSON CORP.
Hirooka Office
80 Hirooka, Shiojiri-shi, Nagano-ken,
Japan
MANUFACTURED:

For Europe
lASERKlASSE1NACHIEC825
CUBS1 LMERPRODUCTTOIEC825
WE1 UWR PR0DUKTI.H.T. IEC825
LUOKANl lAsERwlE
[Label inside printer]
The following laser safety label will be attached inside the printer as shown below.
For Denmark, Finland, Sweden, and Norway
I
CALITION - INVISIBLE LASER RADIATION WHEN OPEN
AVOID &X'GSURE TO SEAM
vORSlCHT- IJNSlCnTBARE
IASE-LUNG WENN
ASDECKUNG GEOFFNET NlCHl DEM SlRAHL
AUSSEIZEN
ADVAflSEL- USYNUG IASERSTliUNG N&l DEKSEL
iPNES UNNGA EKSPONERlNG FGR .STRhN 1
II
VAROL AVAlTAESSA
OLET ALTTIINA NhWMihN
blSEFt.SbElLYUT h.6. KATSO SbEESEEN
ADVARSEL USYNUG LASERStiNG VED hMNG
UNDGA UDS- E FOR Sl-&lNG
VARNING- OSVNIJG IASERSdLNlNG N&l DENNA DEL
AR 6WNAD SThLEN iR FARLIG
II

For Finland. Sweden Users:
"" VAROITUS
Laitteen kayttaminen muulla kuin " kayttoohjeessa mainitulla tavalla saat-
taa altistaa kayttajan turvallisuusluokan 1ylittavalle nakymattomalle la-
sersateiylle.
I VARNING
Om apparaten anvands pa annat satt %-I i denna bruksanvisning specificerats,
kan anvandaren utsattas for osynlig laserstrhlning, som over&rider gransen
for laser klass 1.
For Finland. Sweden Service PeoDle
VAROITUS
Avattaessa jasuojalukitus ohitettaessa olet alttiina nakymattomalle laser-
sateilylle. Ala katso sateeseen.
VARNING
Osynliglaserstralning nar denna de1 ar Bppnad och sparren ar urkopplad.
Betrakta eistralen.
For Norway Users;
ADVARSEL
Dersom apparatet brukes pa annen mate enn spesifisert i denne bruksan-
visning, kan brukeren utsettes forunsynlig laserstrdling som over&rider gren-
sen for laser klasse 1.
Dette er en halvleder laser. Maksimal effeckt til laserdiode er 5.0 x lo-" W og
bolgelengde er 790 + 20 nm.
Laser Safety Labels
[Label on rear printer case]
A laser safety labels is attached on the outside of the printer shown below.
For United State
This laser product conforms to the applicable
requirement of 21 CFR
Chapter I, subchapter J.
SEIKO EPSON CORP.
Hirooka Office
80 Hirooka, Shiojiri-shi, Nagano-ken,
Japan
MANUFACTURED:

REVISION SHEET
Revision
Rev. A
Issued Date
November 17, 1996
Revision Page
1st issued

TABLE OF CONTENTS
CHAPTER 1.
CHAPTER 2.
CHAPTER 3.
CHAPTER 4.
CHAPTER 5.
CHAPTER 6.
APPENDIX
GENERAL DESCRIPTION
OPERATION PRINCIPLES
DISASSEMBLY AND ASSEMBLY
ADJUSTMENTS
TROUBLESHOOTING
MAINTENANCE

Chapter 1 Product Description
Table of Contents
1.1 FEATURES 1-1
1.2 SPECIFICATIONS 1-4
1.2.1 Basic Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.2.2 Electric Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
1.2.3 Specifications for Reliability and Durability. . . . . . . . . . . . . . . . . . . . . . . . 1-8
1.2.4 Environmental Conditions for Operation (Including Consumables). . . . . 1-9
1.2.5 Environmental Conditions for Storage and Transportation . . . . . . . . . . 1-10
1.2.6 Specifications for the ImagingCartridge . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
1.2.7 Applicable Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
1.2.8 Physical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
1.2.9 Process Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
1.2.10 Controller Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.2.11 Software Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
1.2.12 Font Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
1.3 INTERFACE SPECIFICATIONS 1-17
1.3.1 Parallel Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
1.3.1.1 Parallel Interface B Type Specifications . . . . . . . . . . . . . . . . . . . 1-17
1.3.1.2 Parallel Interface C Type Specifications . . . . . . . . . . . . . . . . . . . 1-22
1.3.1.3 Network Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23
1.3.2 Serial Interface Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
1.3.3 Optional LocalTalk Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-26
1.4 OPERATING INSTRUCTIONS 1-27
1.4.1 Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-27
1.4.2 Panel Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-29
1.4.3 Service Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1.4.3.1 Hexadecimal Dump Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1.4.3.2 EEPROM Initialize Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1.4.3.3 Formatting Flash Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1.4.3.4 Page Counter Clearance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1.4.3.5 Flash ROM Updating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-36
1.4.4 Display of Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-37
1.4.4.1 Status Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-37
1.4.4.2 Error Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-38
1.4.4.3 Warning Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-46
1.4.4.4 Message at Power On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-49
1.4.4.5 Service Call Error Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-49
1.4.5 Printer Sharing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-50
1.4.5.1 Port Fixed Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-50
1.4.5.2 Auto Sense Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-50
1.4.6 Controller RAM Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-51
1.4.7 EJL (EPSON Job Control Language) . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-51
1.4.8 BiRITech (BI Resolution Improvement Technology). . . . . . . . . . . . . . . . 1-51
1.4.9 PGI (Photo and Graphics Improvement). . . . . . . . . . . . . . . . . . . . . . . . . 1-52
1.4.10 Toner Saver Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-52
1.4.11 Precaution for Power Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-52

1.5 MAIN COMPONENTS 1-53
1.5.1 C207 MAIN Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-54
1.5.2 PWB-A Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-55
1.5.3 PWB-E Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-55
1.5.4 PWB-F Board Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-56
1.5.5 Paper Takeup Roller Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-56
1.5.6 Registration Roller Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-57
1.5.7 Transfer Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-57
1.5.8 Print Head Unit (Optical Unit) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-58
1.5.9 Fusing Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-58
1.5.10 Drive Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-59
1.5.11 ImagingCartridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-59
1.5.12 Cassette Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-60
List of Figures
Figure 1-1. Exterior View of the EPL-N2000 . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Figure 1-2. Printable Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Figure 1-3. Space Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Figure 1-4. Timing Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-17
Figure 1-5. Operation Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-27
Figure 1-6. Interface Port Fixed Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-50
Figure 1-7. Interface Auto Sense Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-50
Figure 1-8. BiRITech Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-51
Figure 1-9. Toner Saver Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-52
Figure 1-10 Main Component Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-53
Figure 1-11. C207 MAIN Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-54
Figure 1-12. PWB-A Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-55
Figure 1-13. PWB-E Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-55
Figure 1-14. PWB-F Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-56
Figure 1-15. Paper Takeup Roller Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-56
Figure 1-16. Registration Roller Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-57
Figure 1-17. Transfer Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-57
Figure 1-18. Print Head Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-58
Figure 1-19. Fusing Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-58
Figure 1-20. Drive Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-59
Figure 1-21. ImagingCartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-59
Figure 1-22. Cassette Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-60

List of Tables
Table 1-1. Options and Consumables for EPL-N2000. . . . . . . . . . . . . . . . . . . . 1-2
Table 1-2. Paper Feed Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Table 1-3. Available Paper Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Table 1-4. Paper Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Table 1-5. Usability of Special Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Table 1-6. Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Table 1-7. Paper Feed Reliability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Table 1-8. Paper Skew. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Table 1-9. Environmental Conditions for Storage . . . . . . . . . . . . . . . . . . . . . . 1-10
Table 1-10. Environmental Conditions for Storage and Transportation. . . . . . . 1-11
Table 1-11. Differences between LJ4-GL/2 Mode and GL-like Mode . . . . . . . . 1-14
Table 1-12. Built-in Fonts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-15
Table 1-13. Timing in Compatibility Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Table 1-14. Pin Assignments for Parallel B Type I/F . . . . . . . . . . . . . . . . . . . . . 1-18
Table 1-15. Pin Assignments for Parallel C Type I/F . . . . . . . . . . . . . . . . . . . . . 1-22
Table 1-16. Pin Assignments for RJ-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23
Table 1-17. Serial Interface Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
Table 1-18. LocalTalk Interface Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . 1-26
Table 1-19. SelecType Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-30
Table 1-20. Status Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-37
Table 1-21. Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-38
Table 1-22. Warning Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-46
Table 1-23. Messages at Power On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-49
Table 1-24. Service Call Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-49
Table 1-25. Toner Saver Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-52

1.1 FEATURES
The EPSONEPL-N2000 is a non-impact page printer that combines a semi-conductor laser with
electrophotographic technology. The main features are:
❏Paper feed up to 1150 sheets
(for A4 or letter-size paper): Standard: 150 sheets for MP (multipurpose) tray 500 sheets for standard lower paper cassette
Optional: 500 sheets for 500-sheet lower paper cassette unit
❏ High print speed: 20 ppm in single-sided print mode for A4 or letter-size
paper
❏Integrated imaging cartridge: Provides long cartridge life (10,000 sheets) and easy user
maintenance.
❏Optional duplex print
❏Ozone Printing process creates no ozone gas
❏High capacity output tray: Face-down exit tray holds up to 500 sheets
❏2 optional paper cassettes for the
lower paper cassettes unit: 500-sheet cassette for A4 or letter-size paper 250-sheet universal cassette (available for up to A3-size
paper)
❏Power saving mode: Conforms to Energy Star program
Figure 1-1. Exterior View of the EPL-N2000
Rev. A 1-1

Table 1-1 lists the consumables and optional units available for the EPL-N2000.
Table 1-1. Options and Consumables for EPL-N2000
Option Part # Requirements
ROM SIMM
(EpsonScript Level 2 PostScript ROM
SIMM)
C83226* Minimum RAM size: 2MB
1MB RAM SIMM ---
2MB RAM SIMM ---
4MB RAM SIMM ---
8MB RAM SIMM ---
16MB RAM SIMM ---
32MB RAM SIMM ---
NLSP Bitmap 2 Font ROM for LGC*1--- Available only in Europe
NLSP Bitmap 2 Font ROM for HA ---
NLSP Bitmap 2 Font ROM for OCR ---
LocalTalk/Serial Module C82334* Cannot be used with AppleTalk I/F of Type
B I/F Board
Interface Cable (2 m, 6.6’) C83602*
C836031 (See Note 2)
C836041 See Notes 2 and 3)
C836051 (See Note 2)
C836061 (See Notes 2 and 3)
C83615* (See Note 4)
Interface Cable (0.4 m, 1.3’) C836141 (See Note 5)
Notes:
1. Can be used in HP (GL/2) and ESC/P 2 modes.
2. Can be used only when 32KB serial interface is used.
3. Can be used in combination with interface cable C836141 with the serial interface mode for the
LocalTalk /Serial Module.
4. Can be used when RS-232C I/F is selected for serial interface mode and LocalTalk/Serial Module.
5. Can be used with the serial interface mode for LocalTalk/Serial Module.
6. The asterisk is a substitution for the last digit of the product number, which varies by country:
1: For EAI
2: For areas other than EAI
Product Description EPL-N2000 Service Manual
1-2 Rev. A

Table 1-1. Options and Consumables for EPL-N2000 (Continued)
Option Part # Description
Type B Interface Board C82307* 32KB Serial I/F (RS-422)
C82310* 32KB Parallel Interface
C82312* AppleTalk Interface
C82314* Coax Interface
C82315* Twinax Interface
C82313* GPIB Interface or IEEE-1284
C82324* NetWare
C82328* Fax
Imaging Cartridge S051035
250 Sheet Paper Cassette A3 Universal C81269*
500 Sheet Paper Cassette A4 C81264*
500 Sheet Paper Tray LT C81265*
250 Sheet Paper Tray A3 Universal C81270*
500 Sheet Paper Tray A4 C81266*
500 sheet Paper Tray LT C81267*
duplex Unit C81268*
*The asterisk is a substitution for the last digit of the product number, which varies by
country:
1: for EAI
2: for the areas other than EAI
EPL-N2000 Service Manual Product Description
Rev. A 1-3

1.2 SPECIFICATIONS
This section provides statistical data for the EPL-N2000.
1.2.1 Basic Specifications
❏Type Desktop page printer
❏Printing method Laser beam scanning and dry electrophotographic process
❏Resolution 600 dpi
❏Printing speed Single-sided print: 20.0 ppm*1, 11.0 ppm*2
Duplex print: 12.0 ppm*1, 6 .0 ppm*2
❏First print time Single-sided print: 16.0 seconds*1, 18.0 seconds*2
Duplex print: 26.0 seconds*1, 36.0 seconds*2
❏Warm-up time 100 V, 200 V: Less than 70 seconds
(at rated current and 23oC (68oF) temperature)
❏Paper supplies See Table 1-2.
*1: Using A4 or letter-size paper in landscape orientation in the direction of the paper path.
*2: Using A3 paper in portrait orientation in the direction paper of the paper path.
Table 1-2. Paper Feed Sources
Paper Supply Paper Size*1Capacity Usage Thickness
(Ream Weight)
MP Tray Universal
A3+, A3, B4, F4, A4 (L)
B5 (L), l-B5 (L), A5 (L),
Ledger, Legal, GLG,
Letter (L), GLT (L),
Executive (L), HLT (L)
200 *2
Standard: 60 to 135 g /m2
(16 to 36 lb)
Thick paper: 90 to 157 g/m2
(24 to 42 lb)
Special Labels,
papers: transparencies
Envelopes
Monarch, C10, DL, C5,
C6 *110 Standard paper
60 to 105 g/m2(16 to 28 lb)
Standard lower
cassette unit A4/letter
cassette
GLG, LGL, B
A3, B4, LTR (L)
A4 (L), B5 (L),
A5 (L) *1250 *2Standard paper
60 to 90 g/m2(16 to 24 lb)
Optional lower
cassette unit*
3
A4/letter
cassette A4 (L), LTR (L), *1500 *2Standard paper
60 to 90 g/m2(16 to 24 lb)
A3 universal
cassette
A3, B4, F4, A4 (L)
B5 (L), l-B5 (L), A5 (L),
Ledger, Legal, GLG,
Letter (L), GLT (L),
Executive (L), HLT (L)
250
*1: (L) indicates landscape orientation; all others are portrait orientation
*2: With 75 g/m2(20 lb) paper.
*3: The A4/letter cassette and A3 universal cassette are available for both the standard and
optional cassette units.
Product Description EPL-N2000 Service Manual
1-4 Rev. A

❏Paper sizes See Table 1-3.
Front tray Width: 92 mm to 330.2 mm (3.26" to 13")
Length: 140 mm to 483 mm (5.5" to 19")
Table 1-3. Available Paper Sizes
Paper Type Size
Width X Length
MP Tray Cassette Duplex*2
Universal Universal A4/Letter
A3+ 328 X 453 mm P*1—— P
A3 297 X 420 mm PP— P
B4 257 X 364 mm PP— P
F4 210 x 330 mm PP— P
A4 210 X 297 mm L*1LLL
B5*3182 x 257 mm LL—L
l-B5*3176 X 250 mm LL—L
A5 148 x 210 mm LL—L
Ledger 11" X 17" PP— P
Legal 8.5 X 14" PP— P
GLG 8.5" X 13" PP— P
Letter 8.5" X 11" LLL L
GLT 8" X 10.5" LL—L
Executive 7.25" X 10.5" LL—L
HLT 5.5" X 8.5" LL—L
Monarch 3 7/8" X7 1/2" P—— —
C-10 4 1/8"x9 1/2" P—— —
DL 110 X 220 mm P—— —
C5 162 X 229 mm P—— —
C6 114 X 162 mm P—— —
*1: P: Portrait orientation
L: Landscape orientation
*2: Only standard-size paper can be used for duplex printing.
*3: The printer identifies B5 with l-B5 paper.
EPL-N2000 Service Manual Product Description
Rev. A 1-5

❏Paper types Normal paper: 60 to 90 g/m2(16 to 24 lb)
Recycled paper: 60 to 90 g/m2 (16 to 24 lb)
Special paper: Transparencies (OHP), letterhead, envelopes, labels,
thick paper (91 to 157 g/m2, 24 to 42 lb)
Specific paper: A3+ 328 mm ×453 mm, 75 to 80 g/m2(20 to 21 lb)
Table 1-4. Paper Types
U.S. Europe
Normal
Paper
Recommended
Paper Minolta Bond 20 lb. (Nekoosa) Copy paper 70 Copy paper 80
(Neusiedler)
Standard Paper Xerox 4024 DP 20 lb —
Recycled Paper Ardor Recycled Xerox/Bond
20 lb (Nekoosa) RCC80 (Steinbeis)
Special
Paper
Letterhead Four Star 403C 20 lb, Parchment Deed 13C 20 lb
Neenah Bond 20 lb, Gilbert 20 lb
Transparency
(OHP) 3M PP2500
Table 1-5. Usability of Special Papers
Feeding
Source Standard Paper Normal Paper Special Papers — OHP, Envelopes, Labels
MP tray RF R P
Lower paper cassette RF R N
Universal cassette
(250 sheets) RF R N
A4, letter cassette
(500 sheets) RF R N
Duplex unit RF R N
RF:Reliable feeding and good image quality.
R: Reliable feeding and good image quality, but limited to paper generally available.
P: Possible, but limited to paper generally available.
N: Not supported.
❏Paper feed alignment direction: Center alignment for all sizes
❏Paper ejection: Face-down only
❏Output tray capacity: 500 sheets (75 g/m2, 20 lb paper)
Product Description EPL-N2000 Service Manual
1-6 Rev. A

❏Printable area: See Figure 1-2.
Note: For A3+ paper (E X F) : 297 × 420 mm ( 12.12 X 17.14 ")
The maximum printable area with good image quality (E X F) :
323 × 443 mm (12.72 × 17.44").
Printable area can vary, depending on the emulation.
1.2.2 Electrical Specifications
Table 1-6. Electrical Specifications
Printer Version 100 V Version 120 V Version 200 V Series
Rated Voltage 90 V to 110 V
(100 V ±10 %)108 V to 132 V (120 V ± 10 %)207 V to 253 (230 V ±10 %)
Rated Frequency
Range 50 /60 Hz ±3 Hz
Power Consumption Less than 790 W
Less than 45 W (in energy-saver mode)
Current Consumption Less than 8 A
( at rated voltage) Less than 7 A ( at rated voltage) Less than 5 A ( at rated voltage)
Printable Area
4 mm
4 mm 4 mm
4 mm
AB
Paper transprt Direction
C
D
E
F
Figure 1-2. Printable Area
EPL-N2000 Service Manual Product Description
Rev. A 1-7

1.2.3 Specifications for Reliability, Durability, and Maintenance
❏MPBF* (mean prints between failures): over 60,000 sheets or 3,000 hours
* MPBF indicates an average number of pages printed before occurrence of problem requiring
replacement or service.
Table 1-7. Paper Feed Reliability
MP tray Cassette*1Duplex
Jam rate *21/ 2000 or less 1/ 2000 or less 1/ 1000 or less
Feed failure 1/ 2000 or less 1/ 2000 or less 1/2000 or less
Multiple paper feeds 1/ 500 or less 1/ 500 or less 1/500
Leading edge bent 1/ 1000
for 1C or more *3 1/ 1000
for 1C or more *3 1/500 or less
Paper wrinkle 1/ 1000 or less 1/ 1000 or less 1/500 or less
*1: A4/letter cassette and universal cassette from the lower paper cassette units.
*2: Multiple paper feeds excluded.
*3: Disregarding a sheet bent less than 1C. (1C = 1 corner bent by 1 mm or less)
Note: Statistics above only apply to newly unpacked paper.
❏Print Position (Refer to Figure 1-2.)
Single-sided print:
Main scan direction: Standard position (C) ± 2.0 mm
Sub scan direction: Standard position (A) ± 2.5 mm
Duplex print:
Main scan direction: Standard position (C) ±3.0 mm
Sub scan direction: Standard position (A) ±2.5 mm
❏Paper curl height: ±30 mm or less
❏MTTR (mean time to repair): 30 minutes or less
❏Printer operating life: 5 years or 360,000 sheets,
whichever comes first.
❏Acoustic noise: 38 db(A), standby
53 db(A), operation
❏Ozone density: Less than 0.02 ppm (Blue Angel standard conformance)
❏Toxicity: No toxicity exists in OPC, toner, or plastic materials
❏Skew See Table 1-8.
Table 1-8. Paper Skew
Direction A4 (Landscape) A3
Single-sided print C-D*1
A-B*2±1.5 mm
±2.0 mm ±3.0 mm ±2.0 mm
Duplex print C-D
A-Bæ 2.5 mm ±3.0 mm ±4.5 mm ±3.0 mm
*1: Main scan direction *2: Sub scan direction (See Figure 1-2.)
Product Description EPL-N2000 Service Manual
1-8 Rev. A
