Epson L565 User manual

User's Guide
NPD5193-00 EN

Copyright
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of
Seiko Epson Corporation. No patent liability is assumed with respect to the use of the information contained
herein. Neither is any liability assumed for damages resulting from the use of the information herein. e
information contained herein is designed only for use with this Epson product. Epson is not responsible for any
use of this information as applied to other products.
Neither Seiko Epson Corporation nor its aliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by the purchaser or third parties as a result of accident, misuse, or
abuse of this product or unauthorized modications, repairs, or alterations to this product, or (excluding the U.S.)
failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
Seiko Epson Corporation and its aliates shall not be liable for any damages or problems arising from the use of
any options or any consumable products other than those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage resulting from electromagnetic interference that
occurs from the use of any interface cables other than those designated as Epson Approved Products by Seiko
Epson Corporation.
© 2014 Seiko Epson Corporation. All rights reserved.
e contents of this manual and the specications of this product are subject to change without notice.
User's Guide
Copyright
2

Trademarks
❏EPSON
®
is a registered trademark, and EPSON EXCEED YOUR VISION or EXCEED YOUR VISION is a
trademark of Seiko Epson Corporation.
❏PRINT Image Matching™ and the PRINT Image Matching logo are trademarks of Seiko Epson Corporation.
Copyright © 2001 Seiko Epson Corporation. All rights reserved.
❏EPSON Scan soware is based in part on the work of the Independent JPEG Group.
❏libti
Copyright © 1988-1997 Sam Leer
Copyright © 1991-1997 Silicon Graphics, Inc.
Permission to use, copy, modify, distribute, and sell this soware and its documentation for any purpose is
hereby granted without fee, provided that (i) the above copyright notices and this permission notice appear in
all copies of the soware and related documentation, and (ii) the names of Sam Leer and Silicon Graphics
may not be used in any advertising or publicity relating to the soware without the specic, prior written
permission of Sam Leer and Silicon Graphics.
THE SOFTWARE IS PROVIDED "AS-IS" AND WITHOUT WARRANTY OF ANY KIND, EXPRESS,
IMPLIED OR OTHERWISE, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL SAM LEFFLER OR SILICON GRAPHICS BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, INDIRECT OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR ANY DAMAGES
WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER OR NOT ADVISED
OF THE POSSIBILITY OF DAMAGE, AND ON ANY THEORY OF LIABILITY, ARISING OUT OF OR IN
CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.
❏Microso
®
, Windows
®
, and Windows Vista
®
are registered trademarks of Microso Corporation.
❏Apple, Macintosh, Mac OS, OS X, Bonjour, Safari, iPad, iPhone, iPod touch, and iTunes are trademarks of Apple
Inc., registered in the U.S. and other countries. AirPrint and the AirPrint logo are trademarks of Apple Inc.
❏Google Cloud Print™, Chrome™, Chrome OS™, and Android™ are trademarks of Google Inc.
❏Adobe, Adobe Reader, Acrobat, and Photoshop are trademarks of Adobe systems Incorporated, which may be
registered in certain jurisdictions.
❏Intel
®
is a registered trademark of Intel Corporation.
❏General Notice: Other product names used herein are for identication purposes only and may be trademarks
of their respective owners. Epson disclaims any and all rights in those marks.
User's Guide
Trademarks
3

Contents
Copyright
Trademarks
About This Manual
IntroductiontotheManuals...................7
MarksandSymbols.........................7
DescriptionsUsedinthisManual...............7
OperatingSystemReferences..................8
Important Instructions
SafetyInstructions..........................9
PrinterAdvisoriesandWarnings............... 9
Advisories and Warnings for Setting Up/
UsingthePrinter........................10
Advisories and Warnings for Using the
PrinterwithaWirelessConnection...........11
Advisories and Warnings for Using the LCD
Screen................................11
ProtectingYourPersonalInformation...........11
Printer Basics
PartNamesandFunctions...................12
ControlPanel............................ 14
ButtonsandLights.......................14
IconsDisplayedontheLCDScreen...........15
MenuOptions............................16
Copy Mode............................16
Scan Mode............................ 17
Fax Mode.............................17
Setup Mode............................18
Loading Paper
PaperHandlingPrecautions..................23
AvailablePaperandCapacities................24
ListofPaperTypes.......................24
LoadingPaperintheRearPaperFeed...........25
Placing Originals
AvailableOriginalsfortheADF............... 29
PlacingOriginalsontheADF.................29
Placing Originals on the Scanner Glass. . . . . . . . . . 30
Managing Contacts
RegisteringContacts....................... 32
RegisteringGroupedContacts................ 32
Registration and Backup of Contacts Using a
Computer...............................33
Printing
PrintingfromaComputer................... 34
PrintingBasics-Windows.................34
PrintingBasics-MacOSX.................35
Printing on 2-Sides (for Windows only). . . . . . . .37
PrintingSeveralPagesonOneSheet..........38
PrintingtoFitthePaperSize................39
Printing Multiple Files Together (for
WindowsOnly).........................40
Enlarged Printing and Making Posters (for
WindowsOnly).........................41
PrintingUsingAdvancedFeatures........... 47
Printing Photos Using Epson Easy Photo Print. . 49
PrintingfromSmartDevices................. 49
UsingEpsoniPrint.......................49
UsingAirPrint..........................51
CancelingPrinting.........................51
CancelingPrinting-PrinterButton...........51
CancelingPrinting-Windows.............. 51
CancelingPrinting-MacOSX..............52
Copying
Scanning
ScanningUsingtheControlPanel..............54
ScanningtotheCloud....................54
ScanningtoaComputer...................54
ScanningtoaComputer(WSD).............55
ScanningfromaComputer...................55
ScanningBasics.........................55
ScanningUsingAdvancedFeatures...........57
ScanningfromSmartDevices.................60
Faxing
SettingUpaFax...........................62
ConnectingtoaPhoneLine................62
MakingBasicFaxSettings................. 65
SendingFaxes............................67
User's Guide
Contents
4

BasicFaxSendingOperations...............67
VariousWaysofSendingFaxes..............69
ReceivingFaxes...........................70
SettingReceivingMode...................70
VariousWaysofReceivingFaxes.............71
SavingReceivedFaxes.................... 72
UsingOtherFaxingFeatures..................73
PrintingFaxReportandList................73
ReprintingReceivedFaxes...................73
Relling Ink
CheckingtheInkLevels.....................75
CheckingtheInkLevels-Windows...........75
CheckingtheInkLevels-MacOSX..........75
InkBottleCodes..........................76
InkBottleHandlingPrecautions...............76
RellingtheInkTanks......................77
Improving Print and Scan Quality
CheckingandCleaningthePrintHead..........81
Checking and Cleaning the Print Head -
ControlPanel.......................... 81
Checking and Cleaning the Print Head -
Windows..............................82
Checking and Cleaning the Print Head -
MacOSX.............................82
ReplacingInkinsidetheInkTubes.............83
Replacing Ink inside the Ink Tubes - Windows. . .83
Replacing Ink inside the Ink Tubes - Mac OS X. . 83
AligningthePrintHead.....................83
AligningthePrintHead-ControlPanel.......84
AligningthePrintHead-Windows...........84
AligningthePrintHead-MacOSX..........84
CleaningthePaperPath.....................85
CleaningtheADF......................... 85
CleaningtheScannerGlass...................87
Applications and Network Service
Information
EpsonConnectService......................89
Web Cong..............................89
Running Web Cong on a Web Browser. . . . . . . 89
RunningWebCongonWindows........... 90
RunningWebCongonMacOSX...........90
NecessaryApplications......................90
WindowsPrinterDriver...................90
MacOSXPrinterDriver.................. 92
EPSONScan(ScannerDriver)..............93
EpsonEventManager.....................93
PC-FAXDriver(FaxDriver)................94
FAXUtility............................ 94
EpsonEasyPhotoPrint...................95
E-WebPrint(forWindowsOnly)............95
EPSON Soware Updater. . . . . . . . . . . . . . . . . .95
EpsonNetCong........................96
UninstallingApplications....................96
UninstallingApplications-Windows......... 96
UninstallingApplications-MacOSX.........97
InstallingApplications......................97
UpdatingApplicationsandFirmware...........98
Solving Problems
CheckingthePrinterStatus.................. 99
CheckingMessagesontheLCDScreen........99
CheckingthePrinterStatus-Windows.......100
CheckingPrinterStatus-MacOSX.........100
RemovingJammedPaper...................100
Removing Jammed Paper from the Rear
PaperFeed............................101
Removing Jammed Paper from Inside the
Printer...............................101
RemovingJammedPaperfromtheADF......103
PaperDoesNotFeedCorrectly...............104
OriginalDoesNotFeedintheADF..........105
PowerandControlPanelProblems............105
PowerDoesNotTurnOn.................105
PowerDoesNotTurnO.................105
LCDScreenGetsDark...................105
PrinterDoesNotPrint.....................105
PrintoutProblems........................106
PrintQualityIsPoor.................... 106
CopyQualityIsPoor....................107
An Image of the Reverse Side of the Original
AppearsintheCopiedImage..............108
e Position, Size, or Margins of the Printout
AreIncorrect..........................108
PaperIsSmearedorScued...............108
Printed Characters Are Incorrect or Garbled. . . 109
ePrintedImageIsInverted..............109
e Printout Problem Could Not be Cleared. . . 109
OtherPrintingProblems................... 109
PrintingIsTooSlow.....................109
Printing Slows Down Dramatically During
ContinuousPrinting.....................110
CannotStartScanning.....................110
User's Guide
Contents
5

Cannot Start Scanning when Using the
ControlPanel..........................111
ScannedImageProblems...................111
ScanQualityIsPoor.....................111
CharactersAreBlurred...................112
An Image of the Reverse Side of the Original
AppearsintheScannedImage............. 112
Moiré (Cross-Hatch) Patterns Appear in the
ScannedImage.........................112
Scanning Area or Direction Is Not Correct. . . . 112
e Scanned Image Problem Could Not be
Cleared..............................113
OtherScanningProblems...................113
umbnail Preview Does Not Work Properly. . .113
ScanningIsTooSlow....................113
Scanning Stops when Scanning to PDF/
Multi-TIFF........................... 114
Problems when Sending and Receiving Faxes. . . . .114
CannotSendorReceiveFaxes..............114
CannotSendFaxes......................115
Cannot Send Faxes to a Specic Recipient. . . . . 115
CannotSendFaxesataSpeciedTime....... 116
CannotReceiveFaxes....................116
MemoryFullErrorOccurs................116
SentFaxQualityIsPoor..................117
FaxesAreSentattheWrongSize............117
ReceivedFaxQualityIsPoor...............117
ReceivedFaxesAreNotPrinted............ 117
OtherFaxingProblems.....................118
Cannot Make Calls on the Connected
Telephone............................118
Answering Machine Cannot Answer Voice
Calls................................118
Sender's Fax Number Not Displayed on
ReceivedFaxesortheNumberIsWrong......118
OtherProblems..........................118
Slight Electric Shock when Touching the
Printer...............................118
OperationSoundsAreLoud...............118
e ADFDoesNotWork.................119
eDateandTimeAreIncorrect........... 119
Application Is Blocked by a Firewall (for
WindowsOnly)........................119
A Message Prompting You to Reset the Ink
LevelsisDisplayed......................119
Appendix
TechnicalSpecications....................120
PrinterSpecications....................120
ScannerSpecications...................120
InterfaceSpecications...................121
FaxSpecications.......................121
Wi-FiSpecications.....................121
EthernetSpecications...................122
SecurityProtocol.......................122
SupportedirdPartyServices.............122
Dimensions...........................123
ElectricalSpecications.................. 123
EnvironmentalSpecications..............123
SystemRequirements....................124
RegulatoryInformation....................124
StandardsandApprovals................. 124
RestrictionsonCopying..................125
Checking the Total Number of Pages Fed
rough thePrinter.......................126
Checking the Total Number of Pages Fed
roughthePrinter-ControlPanel.........126
Checking the Total Number of Pages Fed
rough thePrinter-Windows.............126
Checking the Total Number of Pages Fed
roughthePrinter-MacOSX............126
TransportingthePrinter....................126
WheretoGetHelp........................129
TechnicalSupportWebSite................129
ContactingEpsonSupport................129
User's Guide
Contents
6

About This Manual
Introduction to the Manuals
e latest versions of the following manuals are available from the Epson support website.
http://www.epson.eu/Support (Europe)
http://support.epson.net/ (outside Europe)
❏Start Here (paper manual)
Provides you with information on setting up the printer, installing the soware, using the printer, solving
problems, and so on.
❏User's Guide (PDF manual)
is manual. Provides overall information and instructions on using the printer, and on solving problems.
❏Network Guide (digital manual)
Provides information on network settings and solving problems when using the printer on a network.
As well as the manuals above, see the help included in the various Epson soware applications.
Marks and Symbols
!
Caution:
Instructions that must be followed carefully to avoid bodily injury.
c
Important:
Instructions that must be observed to avoid damage to your equipment.
Note:
Provides complementary and reference information.
& Related Information
Links to related sections.
Descriptions Used in this Manual
❏Screenshots of the printer driver and the EPSON Scan (scanner driver) screens are from Windows 8.1 or Mac
OS X v10.9.x. e content displayed on the screens varies depending on the model and situation.
❏Illustrations of the printer used in this manual are examples only. Although there may be slight dierences
depending on the model, the method of operation is the same.
❏Some of the menu items on the LCD screen vary depending on the model and settings.
User's Guide
About This Manual
7

Operating System References
Windows
In this manual, terms such as "Windows 8.1", "Windows 8", "Windows 7", "Windows Vista", "Windows XP",
"Windows Server 2012 R2", "Windows Server 2012", "Windows Server 2008 R2", "Windows Server 2008", "Windows
Server 2003 R2", and "Windows Server 2003" refer to the following operating systems. Additionally, "Windows" is
used to refer to all versions.
❏Microso® Windows® 8.1 operating system
❏Microso® Windows® 8 operating system
❏Microso® Windows® 7 operating system
❏Microso® Windows Vista® operating system
❏Microso® Windows® XP operating system
❏Microso® Windows® XP Professional x64 Edition operating system
❏Microso® Windows Server® 2012 R2 operating system
❏Microso® Windows Server® 2012 operating system
❏Microso® Windows Server® 2008 R2 operating system
❏Microso® Windows Server® 2008 operating system
❏Microso® Windows Server® 2003 R2 operating system
❏Microso® Windows Server® 2003 operating system
Mac OS X
In this manual, "Mac OS X v10.9.x" refers to "OS X Mavericks" and "Mac OS X v10.8.x" refers to "OS X Mountain
Lion". Additionally, "Mac OS X" is used to refer to "Mac OS X v10.9.x", "Mac OS X v10.8.x", "Mac OS X v10.7.x"
and "Mac OS X v10.6.8".
User's Guide
About This Manual
8

Important Instructions
Safety Instructions
Read and follow these instructions to ensure safe use of this printer. Make sure you keep this manual for future
reference. Also, be sure to follow all warnings and instructions marked on the printer.
❏Use only the power cord supplied with the printer and do not use the cord with any other equipment. Use of
other cords with this printer or the use of the supplied power cord with other equipment may result in re or
electric shock.
❏Be sure your AC power cord meets the relevant local safety standard.
❏Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, scanner unit, or options by
yourself, except as specically explained in the printer's manuals.
❏Unplug the printer and refer servicing to qualied service personnel under the following conditions:
e power cord or plug is damaged; liquid has entered the printer; the printer has been dropped or the casing
damaged; the printer does not operate normally or exhibits a distinct change in performance. Do not adjust
controls that are not covered by the operating instructions.
❏Place the printer near a wall outlet where the plug can be easily unplugged.
❏Do not place or store the printer outdoors, near excessive dirt or dust, water, heat sources, or in locations
subject to shocks, vibrations, high temperature or humidity.
❏Take care not to spill liquid on the printer and not to handle the printer with wet hands.
❏Keep the printer at least 22 cm away from cardiac pacemakers. Radio waves from this printer may adversely
aect the operation of cardiac pacemakers.
❏If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands, wash them
thoroughly with soap and water. If the liquid crystal solution gets into your eyes, ush them immediately with
water. If discomfort or vision problems remain aer a thorough ushing, see a doctor immediately.
❏Avoid using a telephone during an electrical storm. ere may be a remote risk of electric shock from lightning.
❏Do not use a telephone to report a gas leak in the vicinity of the leak.
❏Be careful not to touch any ink when you handle the ink tanks, ink tank caps, and opened ink bottles or ink
bottle caps.
❏If ink gets on your skin, wash the area thoroughly with soap and water.
❏If ink gets into your eyes, ush them immediately with water. If discomfort or vision problems continue aer
a thorough ushing, see a doctor immediately.
❏If ink gets into your mouth, see a doctor right away.
❏Do not tilt or shake an ink bottle aer removing its seal; this can cause leakage.
❏Keep ink bottles and the ink tank unit out of the reach of children. Do not allow children to drink from or
handle the ink bottles and ink bottle cap.
Printer Advisories and Warnings
Read and follow these instructions to avoid damaging the printer or your property. Make sure you keep this
manual for future reference.
User's Guide
Important Instructions
9

Advisories and Warnings for Setting Up/Using the Printer
❏Do not block or cover the vents and openings in the printer.
❏Use only the type of power source indicated on the printer's label.
❏Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and o.
❏Avoid electrical outlets controlled by wall switches or automatic timers.
❏Keep the entire computer system away from potential sources of electromagnetic interference, such as
loudspeakers or the base units of cordless telephones.
❏e power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place
objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over.
Be particularly careful to keep all the power-supply cords straight at the ends and the points where they enter
and leave the transformer.
❏If you use an extension cord with the printer, make sure that the total ampere rating of the devices plugged into
the extension cord does not exceed the cord's ampere rating. Also, make sure that the total ampere rating of all
devices plugged into the wall outlet does not exceed the wall outlet's ampere rating.
❏If you plan to use the printer in Germany, the building installation must be protected by a 10 or 16 amp circuit
breaker to provide adequate short-circuit protection and over-current protection for the printer.
❏When connecting the printer to a computer or other device with a cable, ensure the correct orientation of the
connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation
may damage both devices connected by the cable.
❏Place the printer on a at, stable surface that extends beyond the base of the printer in all directions. e printer
will not operate properly if it is tilted at an angle.
❏When storing or transporting the printer, avoid tilting it, placing it vertically, or turning it upside down;
otherwise ink may leak.
❏Allow space above the printer so that you can fully raise the document cover.
❏Leave enough space in front of the printer for the paper to be fully ejected.
❏Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct
sunlight, strong light, or heat sources.
❏Do not insert objects through the slots in the printer.
❏Do not put your hand inside the printer during printing.
❏Do not touch the white at cable and ink tubes inside the printer.
❏Do not use aerosol products that contain ammable gases inside or around the printer. Doing so may cause re.
❏Do not move the print head by hand; otherwise, you may damage the printer.
❏Be careful not to trap your ngers when closing the scanner unit.
❏Do not press too hard on the scanner glass when placing the originals.
❏Do not continue printing when the ink level is below the lower line on the ink tank. Continued use of the
printer when the ink level is below the lower line could damage the printer. Epson recommends lling all ink
tanks to the upper line when the printer is not operating to reset the ink levels.
❏Always turn the printer o using the
P button. Do not unplug the printer or turn o the power at the outlet
until the
P light stops ashing.
❏Before transporting the printer, make sure that the print head is in the home (far right) position.
❏If you are not going to use the printer for a long period, be sure to unplug the power cord from the electrical
outlet.
User's Guide
Important Instructions
10

Advisories and Warnings for Using the Printer with a Wireless
Connection
❏Radio waves from this printer may negatively aect the operation of medical electronic equipment, causing
them to malfunction. When using this printer inside medical facilities or near medical equipment, follow
directions from the authorized personnel representing the medical facilities, and follow all posted warnings and
directions on the medical equipment.
❏Radio waves from this printer may negatively aect the operation of automatically controlled devices such as
automatic doors or re alarms, and could lead to accidents due to malfunction. When using this printer near
automatically controlled devices, follow all posted warnings and directions on these devices.
Advisories and Warnings for Using the LCD Screen
❏e LCD screen may contain a few small bright or dark spots, and because of its features it may have an uneven
brightness. ese are normal and do not indicate that it is damaged in any way.
❏Only use a dry, so cloth for cleaning. Do not use liquid or chemical cleaners.
❏e exterior cover of the LCD screen could break if it receives a heavy impact. Contact your dealer if the
screen's surface chips or cracks, and do not touch or attempt to remove the broken pieces.
Protecting Your Personal Information
When you give the printer to someone else or dispose of it, erase all the personal information stored in the printer's
memory by selecting Setup > Restore Default Settings > Clear All Data and Settings on the control panel.
User's Guide
Important Instructions
11

Printer Basics
Part Names and Functions
A ADF (Automatic Document Feeder) cover Open when removing jammed originals in the ADF.
B ADF input tray Feeds originals automatically.
C ADF edge guide Feeds originals straight into the printer. Slide to the
edges of the originals.
D ADF output tray Holds originals ejected from the ADF.
A Edge guide Feeds the paper straight into the printer. Slide to the
edges of the paper.
User's Guide
Printer Basics
12

B Rear paper feed Loads paper.
C Paper support Supports loaded paper.
D Feeder guard Prevents foreign substance from entering the printer.
Usually keep this guard closed.
E Output tray Holds the ejected paper.
A Document cover Blocks external light while scanning.
B Scanner glass Place the originals.
C Control panel Operates the printer.
A Scanner unit Scans placed originals. Open when removing jammed
paper inside the printer.
B Ink tube Supplies ink to the print head.
User's Guide
Printer Basics
13

C Ink tank unit Contains the ink tanks.
D Ink reservoir tanks (Ink tanks) Supplies ink to the ink tubes.
E Print head Fires ink.
A AC inlet Connects the power cord.
B USB port Connects a USB cable.
C LINE port Connects a phone line.
D EXT. port Connects external phone devices.
E LAN port Connects a LAN cable.
Control Panel
Buttons and Lights
A Turns the printer on or o.
Unplug the power cord when the power light is o.
B Displays the home screen.
User's Guide
Printer Basics
14

C Enter the last dialed number or enter a pause when entering a fax number.
D Stops the current operation.
E - Displays menus and messages.
Fl
, u , r , d , OK Press l , u , r , and d to select menus. Press OK to conrm your selection or run the selected
feature.
G Returns to the previous screen.
H 0 - 9
,
Enters numbers, characters, and symbols.
I Opens the contacts list.
J Starts printing, copying, scanning, and faxing in black and white.
K Starts printing, copying, scanning, and faxing in color.
Icons Displayed on the LCD Screen
e following icons are displayed on the LCD screen depending on the printer's status.
Turns on when originals are placed in the ADF.
Turns on when the wired (Ethernet) network is disabled and an Ethernet cable is not
connected.
Turns on while the printer is connected to a wired (Ethernet) network.
Turns on while the printer is not connected to a wireless (Wi-Fi) network.
Turns on while the printer is connected to a wireless (Wi-Fi) network. The number of
bars indicates the signal strength of the connection. The more bars there are, the
stronger the connection.
Indicates a problem with the printer's wireless (Wi-Fi) network connection, or that the
printer is searching for a wireless (Wi-Fi) network connection.
Indicates that the printer is connected to a network in Ad Hoc mode.
Indicates that Simple AP mode and Wi-Fi Direct mode are disabled.
Indicates that the printer is connected to a network in Wi-Fi Direct mode.
Indicates that Simple AP mode is enabled.
Turns on when Eco Mode is enabled.
User's Guide
Printer Basics
15

Menu Options
Copy Mode
Note:
❏Available menus vary depending on the layout you selected.
❏Press the OK button to display hidden setting menus.
Menu Settings and Explanations
Number of copies Enter the number of copies.
Layout With Border Copies with a border around the edges.
2-up Copies multiple page originals onto one sheet.
When placing originals in the ADF, insert them into the feeder from the top or
left edge.
Load vertical originals as shown below, and select Portrait from Document
Orientation.
Load horizontal originals as shown below, and select Landscape from
Document Orientation.
ID Card Scans both sides of an ID card and copies onto one side of A4 size paper.
Document Size Select the size of your original.
Zoom Enlarges or reduces the original.
Select Auto Fit Page to t to the paper size of the selected paper source.
Document
Orientation
Select the orientation of your original.
Quality Select the type of your original.
Draft: Provides faster printing, but the printouts may be faint.
Best: Provides higher quality printing, but the printing speed may be slower.
Density Set the density of your copies.
Layout Order Select the copy layout for multiple pages when you have selected 2-up as the Layout setting.
User's Guide
Printer Basics
16

Scan Mode
Cloud
Menu Settings and Explanations
Destination Select a destination that has been registered in the Epson Connect Server.
Settings Format Select the format in which to save the scanned image.
Scan Area Select the scan area.
Auto Cropping: Crops the white space around the text or image when
scanning.
Max Area: Scans at the maximum scan area of the scanner glass or the ADF.
Document Type Select the type of your original.
Density Select the contrast of the scanned image.
Document
Orientation
Select the orientation of your original.
Computer
Menu Settings and Explanations
Select Computer From the list of computers connected using USB or over the network, select the computer you want
to save the scanned image to.
Settings Format Select the format in which to save the scanned image.
Computer (WSD)
is menu has no setting item.
Fax Mode
Select Fax on the home screen, and then press the OK button.
Menu Settings and Explanations
Resolution Select the resolution of the outgoing fax.
Select Photo for originals that contain both text and photo images.
Density Set the density of the outgoing fax.
Direct Send See the page that describes this feature for more details.
Transmission
Report
Prints a transmission report automatically after you send a fax. Select Print on Error to print a report
only when an error occurs.
Send Fax Later See the pages that describes these features for more details.
Polling Receive
Reprint Faxes Prints received faxes temporarily stored in the printer's memory from the latest one.
User's Guide
Printer Basics
17

Menu Settings and Explanations
Fax Report Fax Settings List Prints the current fax settings.
Fax Log Displays or prints a history of sent and received fax jobs. You can set to print
this report automatically using the following menu.
Setup-Fax Settings-Output Settings--Fax Log Auto Print
Last Transmission Prints a report for the previous fax that was sent or received through polling.
Protocol Trace Prints a detailed report for the previous fax that was sent or received.
Related Information
&“Sending Many Pages of a Monochrome Document (Direct Send)” on page 69
&“Sending Faxes at a Specied Time (Send Fax Later)” on page 69
&“Receiving Faxes by Polling (Polling Receive)” on page 72
Setup Mode
Menu Settings and Explanations
Maintenance Print Head Nozzle
Check
Prints a pattern to check if the print head nozzles are clogged.
Print Head Cleaning Cleans clogged nozzles in the print head.
Reset Ink Levels Select this feature to reset the ink levels before you rell the ink tanks.
Print Head
Alignment
Adjusts the print head to improve print quality.
Perform this feature if your printouts look blurry or text and lines are
misaligned.
Paper Guide
Cleaning
Perform this feature to clean the roller inside the printer when the printout
are smeared or scued.
Paper Setup Select the paper size and paper type you loaded in the paper source.
Print Status Sheet Conguration Status
Sheet
Prints an information sheet showing the current printer status and
settings.
Printer Settings Paper Source
Settings
A4/Letter Switching Enable this feature so that error messages are not
displayed even when the paper size setting for
the print job and the paper loaded in the paper
source do not match. This feature is only available
when the paper size is set to A4 or Letter.
Error Notice Displays an error message when the paper size or
type settings in Paper Setup and the print
settings do not match.
PC Connection via
USB
Enables the printer which is connected to the computer over a USB
connection. If this feature is disabled, the computer does not recognize
printers with a USB connection.
User's Guide
Printer Basics
18

Menu Settings and Explanations
Common Settings Sound Adjust the volume and select the type of audio.
Sleep Timer Select the time period before the printer enters sleep mode (energy saving
mode) when no operations are performed.
The LCD screen turns black when the set time passes.
Power O Timer You can adjust the time before power management is applied. Any
increase will aect the product’s energy eciency. Please consider the
environment before making any change.
LCD Contrast Adjust the contrast of the LCD screen.
Date/Time Settings Date/Time Enter the current date and time.
Daylight Saving Time Select the summer time setting that applies to
your area.
Time Dierence Enter the time dierence between your local time
and UTC (Coordinated Universal Time).
Country/Region Select the country or region.
Language Select the display language.
Scroll Speed Select the scroll speed of the LCD screen.
Network Settings Network Status Displays or prints the network settings and connection status.
Wi-Fi Setup Wi-Fi Setup Wizard See the Network Guide for more details.
Push Button Setup
(WPS)
PIN Code Setup
(WPS)
Wi-Fi Auto Connect
Disable Wi-Fi You may be able to resolve network problems by
disabling the Wi-Fi settings or making the Wi-Fi
settings again. See the Network Guide for more
details.
Wi-Fi Direct Setup See the Network Guide for more details.
Connection Check Checks the status of the network connection and prints the network
connection check report. If there are any problems with the connection,
see the check report to solve the problem.
Advanced Setup See the Network Guide for more details.
Epson Connect
Services
You can suspend or resume the Epson Connect or Google Could Print service, or cancel using the
services (restore the default settings).
See the Epson Connect portal website for more details.
https://www.epsonconnect.com/
http://www.epsonconnect.eu (Europe only)
Google Cloud Print
Services
Fax Settings See the list of menus in Fax Settings.
User's Guide
Printer Basics
19

Menu Settings and Explanations
Universal Print
Settings
These print settings are applied when you print using an external device without using the printer
driver.
Top Oset Adjust the top or left margin of the paper.
Left Oset
Skip Blank Page Skips blank pages in the print data automatically.
Eco Mode Sleep Timer Select the time period before the printer enters sleep mode (energy saving
mode) when no operations are performed.
The LCD screen turns black when the set time passes.
When this setting is disabled, the setting made in Common Settings is
applied.
Restore Default
Settings
Resets the selected settings to their defaults.
Related Information
&“Copy Mode” on page 16
&“Scan Mode” on page 17
&“Fax Settings” on page 20
Fax Settings
Select Setup > Fax Settings from the home screen.
Menu Settings and Explanations
User Default
Settings
The settings made in this menu become your default settings for sending faxes. For details on the
setting items, see the list of menus in Fax mode.
Receive Settings Receive Mode Select the receive mode.
DRD If you have subscribed to a distinctive ring service from your telephone
company, select the ring pattern to be used for incoming faxes (or select On).
Rings to Answer Select the number of rings that must occur before the printer automatically
receives a fax. Select "0" (zero) if you want to receive faxes with no ringing.
Remote Receive When you answer an incoming fax call on a phone connected to the printer,
you can start receiving the fax by entering the code using the phone.
User's Guide
Printer Basics
20
