Epson PictureMate PM-401 User manual

Operation Guide

Contents
CopyrightandTrademarks..........4
Copyright................................4
Trademarks..............................4
AboutThisManual...................5
IntroductiontotheManuals..................5
MarksandSymbols.........................5
ImportantInstructions...............6
SafetyInstructions.........................6
InstructionsfortheACAdapter.............7
PrinterBasics........................8
PartNamesandFunctions...................8
ControlPanel............................10
Buttons...............................10
GuidetotheLCDScreen..................10
Menus.................................11
MenuOptions.........................12
PreparingtoPrint..................17
AvailablePaperandCapacities...............17
ListofPaperTypes........................18
PaperLoadingDirection....................19
PaperHandlingPrecautions.................19
UnusablePaper...........................20
SelectingPaperSettings.....................20
ChangingtheSettings....................20
PreventingMisprints.....................21
SupportedMemoryCards...................21
InsertingandRemovingaMemoryCard........22
Printing.............................23
Printing Photos by Selecting from a Memory
Card...................................23
PrintinginVariousLayouts..................26
DPOFPrinting...........................26
PrintingfromaDigitalCamera...............27
Printing from a Digital Camera Connected by
USBCable............................27
Printing from a Digital Camera Connected
Wirelessly.............................27
PrintingfromSmartDevices.................28
UsingEpsoniPrint......................28
UsingAirPrint.........................30
PrintingfromaComputer...................30
ReplacingInkCartridge............31
CheckingtheInkLevel.....................31
InkCartridgeCode........................31
InkCartridgeHandlingPrecautions............31
HandlingPrecautions....................31
InkConsumption.......................33
ReplacingInkCartridge....................34
Maintenance.......................38
CheckingandCleaningthePrintHead..........38
AligningthePrintHead....................38
CleaningthePaperPath....................39
SolvingProblems...................40
RemovingJammedPaper...................40
CheckingMessagesontheLCDScreen.........41
PowerandControlPanelProblems............42
PowerDoesNotTurnOn.................42
PowerDoesNotTurnOff.................42
LCDScreenGetsDark...................42
AutoPowerOnDoesNotWork............42
PaperDoesNotFeedCorrectly...............42
CannotSetupWi-Fi.......................42
PrintingaNetworkConnectionReport.......43
Messages and Solutions on the Network
ConnectionReport......................43
PrinterDoesNotPrint.....................43
CannotUseAirPrint.......................44
PrintoutProblems.........................44
Images or Photos are Printed in Unexpected
Colors.................................44
The Position, Size, or Margins of the Printout Are
Incorrect...............................44
PaperIsSmearedorScuffed.................45
PrintingIsTooSlow.......................45
PM-401 Operation Guide
Contents
2

OtherProblems..........................45
Slight Electric Shock when Touching the
Printer...............................45
CannotSavetheDatatoaMemoryDevice.....45
“?” Is Displayed on the Photo Selection Screen
....................................46
Moving and Transporting the Printer
.....................................47
Transporting............................47
TakingthePrinterwithYou.................47
WhereToGetHelp..................48
TechnicalSupportWebSite..................48
ContactingEpsonSupport...................48
BeforeContactingEpson..................48
HelpforUsersinHongKong..............48
Index
PM-401 Operation Guide
Contents
3

Copyright and Trademarks
Copyright
No part of this publication may be reproduced, stored in
a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written
permission of Seiko Epson Corporation. No patent
liability is assumed with respect to the use of the
information contained herein. Neither is any liability
assumed for damages resulting from the use of the
information herein. The information contained herein
is designed only for use with this Epson printer. Epson is
not responsible for any use of this information as
applied to other printers.
Neither Seiko Epson Corporation nor its affiliates shall
be liable to the purchaser of this product or third parties
for damages, losses, costs, or expenses incurred by the
purchaser or third parties as a result of accident, misuse,
or abuse of this product or unauthorized modifications,
repairs, or alterations to this product, or (excluding the
U.S.) failure to strictly comply with Seiko Epson
Corporation’s operating and maintenance instructions.
Seiko Epson Corporation and its affiliates shall not be
liable for any damages or problems arising from the use
of any options or any consumable products other than
those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any
damage resulting from electromagnetic interference
that occurs from the use of any interface cables other
than those designated as Epson Approved Products by
Seiko Epson Corporation.
© 2015 Seiko Epson Corporation. All rights reserved.
The contents of this manual and the specifications of
this product are subject to change without notice.
Trademarks
❏Apple, Mac OS, OS X, iPad, iPhone, iPod touch, and
iTunes are trademarks of Apple Inc., registered in
the U.S. and other countries.
❏AirPrint and the AirPrint logo are trademarks of
Apple Inc.
❏Android
™
is a trademarks of Google Inc.
❏General Notice: Other product names used herein
are for identification purposes only and may be
trademarks of their respective owners. Epson
disclaims any and all rights in those marks.
PM-401 Operation Guide
Copyright and Trademarks
4

About This Manual
Introduction to the
Manuals
❏Operation Guide (paper manual)
This manual. Provides instructions on using the
printer, replacing ink cartridge, maintenance, and
solving problems.
❏Start Here (paper manual)
Provides you with information on setting up the
printer.
❏User’s Guide (digital manual)
Provides information on important instructions,
printer specifications, printing from a computer,
network settings, and solving problems when using
the printer on a network.
The latest version of the following manuals are available
from the Epson support website.
http://support.epson.net/
If you do not have a computer, you can download digital
manuals from a smart device such as a smartphone or
tablet.
Marks and Symbols
!
Caution:
Instructions that must be followed
carefully to avoid bodily injury.
c
Important:
Instructions that must be observed
to avoid damage to your
equipment.
Note:
Instructions containing useful tips
and restrictions on printer
operation.
&Indicates pages with related
information.
PM-401 Operation Guide
About This Manual
5

Important Instructions
Safety Instructions
Use only the AC adapter supplied with the product and do not use the adapter with any other
equipment. Use of any other adapter with this product or the use of the supplied AC adapter with
other equipment may result in fire or electric shock.
Be sure your AC power cord meets the relevant local safety standard.
Never disassemble, modify, or attempt to repair the AC adapter, plug, printer unit or options by
yourself, except as specifically explained in the product's guides.
Unplug the product and the AC adapter, and refer servicing to qualified service personnel under
the following conditions:
The AC adapter or plug is damaged; liquid has entered the product or the AC adapter; the product
or the AC adapter has been dropped or the casing damaged; the product or the AC adapter does
not operate normally or exhibits a distinct change in performance. Do not adjust controls that are
not covered by the operating instructions.
Place the product near a wall outlet where the plug can be easily unplugged.
Do not place or store the product or the AC adapter outdoors, near excessive dirt or dust, water,
heat sources, or in locations subject to shocks, vibrations, high temperature or humidity.
Take care not to spill liquid on the product and not to handle the product with wet hands.
Keep this product at least 22 cm away from cardiac pacemakers. Radio waves from this product
may adversely affect the operation of cardiac pacemakers.
If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands,
wash them thoroughly with soap and water. If the liquid crystal solution gets into your eyes, flush
them immediately with water. If discomfort or vision problems remain after a thorough flushing,
see a doctor immediately.
Keep ink cartridges out of the reach of children.
PM-401 Operation Guide
Important Instructions
6

Be careful when you handle used ink cartridges, as there may be some ink around the ink supply
port.
If ink gets on your skin, wash the area thoroughly with soap and water.
If ink gets into your eyes, flush them immediately with water.
If discomfort or vision problems continue after a thorough flushing, see a doctor immediately.
If ink gets into your mouth, see a doctor right away.
Instructions for the AC Adapter
❏The AC adapter cord should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place
objects on top of the cord and do not allow the AC adapter or the cord to be stepped on or run over. Be particularly
careful to keep the cord straight at the end.
❏Use only the type of power source indicated on the AC adapter's label, and always supply power directly from a
standard domestic electrical outlet with the AC adapter that meets the relevant local safety standards.
❏If you are not going to use the product for a long period, be sure to unplug the AC adapter from the electrical
outlet.
PM-401 Operation Guide
Important Instructions
7

Printer Basics
Part Names and Functions
A
Printer cover Close this cover to block dust when you are not using the printer.
B
Rear paper feed Loads paper.
C
Edge guide Feeds the paper straight into the printer. Slide to the edge of the paper.
D
Inner cover Open to replace ink cartridge or to remove jammed paper.
E
LCD screen Displays menus and messages. Raise the screen to use it.
F
DC inlet Connects the AC adapter's plug.
G
Micro USB port Connects a micro USB cable.
PM-401 Operation Guide
Printer Basics
8

H
Ink cartridge holder Install the ink cartridge. Ink is ejected from the print head nozzles underneath.
I
Memory card slot Insert a memory card. Remove the cap if it is inserted.
J
External interface USB port Connects an external storage device or a PictBridge capable device.
K
Power light - Power on: The light turns on.
- Printer off: The light turns off.
Unplug the power cord when the power light is off.
L
Output tray Holds the ejected paper. Raise the stopper at the edge of the tray when printing.
PM-401 Operation Guide
Printer Basics
9

Control Panel
Buttons
A
Power Turns the printer on or off.
B
Home Displays the home screen.
C
Arrows Use the udlrbuttons to select a photo, menu, and setting.
D
+/- Selects the number of pages to print.
E
Stop Stops the current operation.
F
Back Returns to the previous screen.
G
OK Press to open the selected menu or to proceed to the next screen.
H
Start Starts an operation such as printing.
Guide to the LCD Screen
Menus and messages are displayed on the LCD screen. Select a menu or setting by pressing the udlrbuttons.
To learn the meaning of the icons, select Help from the home screen, and then select Icon List.
PM-401 Operation Guide
Printer Basics
10

A
Icons that show the printer status are displayed.
B
When land rare displayed, you can scroll right or left.
C
Available buttons are displayed. In this example, you can proceed to the next screen by pressing the OK button.
D
The name of the screen displayed.
E
When uand dare displayed, you can scroll up or down.
Menus
Check this along with the detailed explanations on menu options. Some menus are not displayed depending on the
combination of selected options.
&“Menu Options” on page 12
Mode Menus
Print Photos View and Print Photos
Photo Layout Sheet
Setup Ink Level
Maintenance
Printer Setup
Network Settings
Epson Connect Services
Google Cloud Print Services
External Device Setup
Restore Default Settings
PM-401 Operation Guide
Printer Basics
11

Mode Menus
Help How To...
Ink Cartridge
Troubleshooting
Icon List
Wi-Fi Setup Select this mode to access the menus for network setup or for checking the
network settings.
&“Wi-Fi Setup Mode” on page 16
Menu Options
You can set the following menus on the control panel.
Some menus are not displayed depending on the combination of selected options.
Print Photos Mode
Menu Settings and Explanations
View and Print Photos You can print photos on the memory card by selecting them on the LCD screen.
Photo Layout Sheet You can print your photos in various layouts, such as printing multiple photos on a
sheet of photo paper.
20-up: The serial number or date is printed below each photo.
P.I.F. is displayed if you have a P.I.F. frame on your memory card.
Menu Options for Print Photos
To view the following menus, press the dbutton on the screen when photos are displayed.
Menu Settings and Explanations
Browse Browse by Date Displays the photos on the memory card sorted by date. Select a date
to display all photos saved on that date.
Cancel Browse Cancels sorting photos and displays all the photos.
Select Photos Select All Photos Select all the photos on the memory card and set the number of prints.
Cancel Photo Selection Returns the number of copies of all photos to 0 (zero).
PM-401 Operation Guide
Printer Basics
12

Menu Settings and Explanations
Display Options 1-up Displays one photo on a screen. Information on settings, such as
number of copies, is also displayed.
1-up without Information Displays one photo on a screen. Information on settings, such as
number of copies, is not displayed.
9-up Displays nine photos on a screen.
Print Settings Paper Size Select the paper size you loaded.
Paper Type Select the paper type you loaded.
Borderless Prints without margins around the edges. The image is enlarged a little
to remove borders from the edges of the paper.
Quality Select the print quality. Selecting Best provides higher quality print-
ing, but the printing speed may be slower.
Expansion With borderless printing, the image is enlarged a little to remove
borders from the edges of the paper. Select how much to enlarge the
image.
Date Select a date format to print photos with a date. The date is not printed
for some layouts or if date information is not included in the photo
data.
The date is printed automatically when selecting 20-up.The date used
is the date the photo was taken or the date you saved the photo data.
Fit Frame Trims your photo. This may not be available for panorama photos. The
photo is always trimmed in Borderless, Upper 1/2, or Lower 1/2
printing.
On Crops the top and bottom or left and
right of the image.
Off Creates margins on the left and right or
top and bottom of the image.
Photo Adjustments Enhance Select one of the image adjustment options.
PhotoEnhance: Produces sharper images and more vivid colors by
automatically adjusting the contrast, saturation, and brightness of the
original image data.
P.I.M.: Adjusts the image based on the printing information provided
by a digital camera compatible with PRINT Image Matching.
Scene Detection Available when selecting PhotoEnhance as the Enhance setting. Im-
proves the image quality for photos of people, landscapes, and night
scenes.
Fix Red-Eye Fixes red-eye in photos. Corrections are not applied to the original file,
only to the printouts. Depending on the type of photo, parts of the
image other than the eyes may be corrected.
Sharpness Enhances or defocuses the outline of the image.
Filter Prints in sepia or monochrome.
Crop/Zoom Enlarges a part of the photo to be printed.
PM-401 Operation Guide
Printer Basics
13

Setup Mode
Menu Settings and Explanations
Ink Level Displays the approximate level of the ink cartridge.
When an ! icon is displayed, the ink cartridge is running low. When a X mark is displayed, the ink
cartridge is expended.
Maintenance Nozzle Check Prints a pattern to check if the print head nozzles are clogged.
Head Cleaning Cleans clogged nozzles in the print head.
Print Head Alignment Adjusts the print head to improve print quality.
Ink Cartridge Replacement Use this feature to replace the ink cartridge before the ink is expended.
Paper Guide Cleaning Use this feature to feed paper for cleaning.
Printer Setup Paper Source Setting Paper Setup Select the paper size and paper type
you loaded.
Paper Setting Alert Warns you when the paper settings do
not match the paper you loaded.
Paper Configuration Automatically displays the paper
settings screen when paper is loaded.
AirPrint is not available when disabled.
Stickers Adjusts the printing position of a photo sticker by moving up, down,
left, or right to fit.
Sound Turns on or off the beeps that sound when operating the buttons or
when an error occurs, and changes the volume.
Auto Power On Turns on the printer automatically when it receives a print job over a
USB connection or a network connection. Enabling Auto Power On
increases power consumption slightly in standby status when com-
pared to turning the printer off completely. The default setting is
disabled.
Power Off Timer Turns the printer off automatically when a specified time has passed
and no operations have been performed. You can adjust the time
before power management is applied.
Sleep Timer Select the time period before the printer enters sleep mode (energy
saving mode) when no operations are performed. The LCD screen
turns black when the set time passes.
Language Select the display language.
PM-401 Operation Guide
Printer Basics
14

Menu Settings and Explanations
Network Settings Network Status Press the lor rbutton to check the status of the network connection,
Epson Connect connection, and so on.
Wi-Fi Setup Wi-Fi Setup Wizard Select an SSID, enter a password, and
then connect the printer to a wireless
(Wi-Fi) network.
Push Button Setup (WPS) Connect the printer to a wireless
network by using the WPS button on
your wireless router.
PIN Code Setup (WPS) In the wireless router utility, enter the
PIN code displayed on the printer's
screen and connect the printer to a
wireless (Wi-Fi) network.
Wi-Fi Auto Connect Easily connect the printer to a wireless
(Wi-Fi) network using a computer
connected to the wireless router. By
simply following the on-screen
instructions on the computer, you can
make the network settings without
entering an SSID or security key.
Disable Wi-Fi Disables the connection by turning the
Wi-Fi off without deleting the network
information. To enable the
connection, set up the wireless (Wi-Fi)
network again.
Wi-Fi Direct Setup Connects the printer to a wireless
(Wi-Fi) network without a wireless
router.
Manual Network Setup Changes the network settings, such as the printer name or TCP/IP.
Connection Check Checks the status of the network connection and prints the network
connection check report. If there are any problems with the connec-
tion, see the check report to solve the problem. See the User's Guide
(digital manual) for more details.
Epson Connect
Services
You can suspend or resume the Epson Connect or Google Could Print service, or cancel using the
services (restore the default settings). See the following for details.
https://www.epsonconnect.com/
Google Cloud Print
Services
External Device Setup Change the print settings to print directly from an external device such as a digital camera or mobile
phone.
Restore Default
Settings
Resets the selected settings to their defaults.
Help Mode
See the Help for information on using the printer or when printouts are unsatisfactory.
PM-401 Operation Guide
Printer Basics
15

Wi-Fi Setup Mode
See the User's Guide (digital manual) to make the following settings.
Select this mode to access the menus for network setup or for checking the network settings as described below. You
can also access the network menus from the Setup mode.
❏When the printer is not connected to a network
Select an icon of your desired connection method, and press the OK button on the next screen to display the
network setup menus. To setup the printer for use on a network using the menus, see the User’s Guide.
❏When the printer is connected to a network
Select See Connection Details to display the setting information such as the printer's IP address. Select Details to
display the menus for check the status.
PM-401 Operation Guide
Printer Basics
16

Preparing to Print
Available Paper and Capacities
Epson recommends using genuine Epson paper to ensure high-quality printouts.
Genuine Epson Paper
Media Name Size Loading
Capacity
(Sheets)
Borderless
Printing
Manual
2-Sided
Printing
Epson Ultra Glossy Photo Paper 10 ×15 cm (4 ×6 in.) 20
*1
✓-
Epson Premium Glossy Photo Paper 10 ×15 cm (4 ×6 in.)
13 ×18 cm (5 ×7 in.)
20
*1
✓-
Epson Premium Semigloss Photo Paper 10 ×15 cm (4 ×6 in.) 20
*1
✓-
Epson Photo Paper Glossy 10 ×15 cm (4 ×6 in.)
13 ×18 cm (5 ×7 in.)
20
*1
✓-
*1Load one sheet of paper at a time if the printouts are scuffed or if there are uneven colors.
Note:
The availability of paper varies by location. For the latest information on paper available in your area, contact Epson
support.
Commercially Available Paper
Media Name Size Loading
Capacity
(Sheets)
Borderless
Printing
Manual
2-Sided
Printing
Plain paper A5
*1
, A6
*2
Up to the
line
indicated by
the triangle
symbol on
the edge
guide.
-✓
*3
User Defined
*2
1- ✓
Envelope
*2
Envelope #10, Envelope
DL, Envelope C6
1- -
*1Due to the printer's mechanism, printouts have 10 mm margins around the edges.
*2Only printing from computer is available.
*3For manual 2-sided printing, you can load up to 20 sheets for paper with one side already printed.
PM-401 Operation Guide
Preparing to Print
17

c
Important:
You can use paper that's 0.05 to 0.6 mm thick. However, depending on the solidity or transparency of the paper, paper
that is this thick may not be fed or printed correctly.
List of Paper Types
To obtain optimum printing results, select the paper type that suits the paper.
Media Name Media Type
Control Panel Printer Driver, Smart Device
*1
Epson Ultra Glossy Photo Paper
*2
Ultra Glossy Epson Ultra Glossy
Epson Premium Glossy Photo Paper
*2
Prem. Glossy Epson Premium Glossy
Epson Premium Semigloss Photo Paper
*2
Prem. Semigloss Epson Premium Semigloss
Epson Photo Paper Glossy
*2
Glossy Photo Paper Glossy
Plain paper
*2
plain papers plain papers
Envelope Envelope Envelope
*1For smart devices, these media types can be selected when printing using Epson iPrint.
*2These paper types are compatible with Exif Print and PRINT Image Matching when printing from the printer driver. For more
details, see the documentation provided with the Exif Print or PRINT Image Matching compatible digital camera.
PM-401 Operation Guide
Preparing to Print
18

Paper Loading Direction
Load paper vertically along the left side of the rear paper
feed with the printable side facing up. If you load
horizontally, printing is not performed correctly.
Pre-punched paper
❏Load one sheet of pre-punched paper at a time. Do
not load paper with binding holes at the top or the
bottom.
❏Adjust the print position of your file to avoid
printing over the holes.
Envelopes
Load the envelopes with the flap closed and facing to the
left.
Paper Handling
Precautions
❏Read the instruction sheets supplied with the paper.
❏Fan and align the edges of the paper before loading.
Do not fan or curl photo paper. Doing so may
damage the printable side.
❏To print both sides of the paper, dry completely,
flatten one side, and then print the other side.
❏If the paper is curled, flatten it or curl it slightly in
the opposite direction before loading. Printing on
curled paper may cause paper jams and smears on
the printout.
PM-401 Operation Guide
Preparing to Print
19

❏If card sized paper is curled, flatten it with the
printable side facing up, and then load it with the
printable side facing up.
❏Fan and align the edges of the envelopes before
loading. When the stacked envelopes are puffed up
with air, press them down to flatten them before
loading.
Unusable Paper
Do not use the following paper. Using paper in these
conditions may cause paper jams and smears on the
printout, or incorrect printing.
❏Paper that is wavy, torn, cut, folded, damp, too
thick, too thin, paper that has stickers stuck to it or
that has partially printed characters.
❏Envelopes that are curled or folded.
❏Envelopes with adhesive surfaces on the flaps or
window envelopes.
❏Envelopes that are too thin.
Selecting Paper Settings
When paper is loaded in the rear paper feed, the paper
size and paper type settings screen is displayed. Check
the current settings, and if they do not match the paper
you loaded, change the settings.
Changing the Settings
A
Select Change and press the OK button.
B
Select the paper size.
PM-401 Operation Guide
Preparing to Print
20
