Epson Stylus color 600 User manual

EPSON
COLOR INK-JET PRINTER
EPSON Stylus Color 600
SERVICE MANUAL
SEIKO EPSON CORPORATION
4007367

NOTICE

All rights reserved. Reproduction of any part of this manual in any form whatsoever
without SEIKO EPSON’s express written permission is forbidden.

The contents of this manual are subjects to change without notice.

All efforts have been made to ensure the accuracy of the contents of this manual.
However, should any errors be detected, SEIKO EPSON would greatly appreciate
being informed of them.

The above notwithstanding SEIKO EPSON can assume no responsibility for any errors
in this manual or the consequences thereof.
EPSON is a registered trademark of SEIKO EPSON CORPORATION.
General Notice:
Other product names used herein are for identification purposes only and may be
trademarks or registered trademarks of their respective companies.
Copyright 1997 by SEIKO EPSON CORPORATION
Nagano, Japan

PRECAUTIONS
Precautionary notations throughout the text are categorized relative to 1) personal injury and 2)
damage to equipment.
WARNING
Signals a precaution which, if ignored, could result in serious or fatal personal injury.
Great caution should be exercised in performing procedures preceded by
WARNING Headings.
CAUTION
Signals a precaution which, if ignored, could result in damage to equipment.
The precautionary measures itemized below should always be observed when performing
repair/maintenance procedures.
WARNING
1. ALWAYS DISCONNECT THE PRODUCT FROM BOTH THE POWER SOURCE AND
PERIPHERAL DEVICES PERFORMING ANY MAINTENANCE OR REPAIR PROCEDURES.
2. NO WORK SHOULD BE PERFORMED ON THE UNIT BY PERSONS UNFAMILIAR WITH
BASIC SAFETY MEASURES AS DICTATED FOR ALL ELECTRONICS TECHNICIANS IN
THEIR LINE OF WORK.
3. WHEN PERFORMING TESTING AS DICTATED WITHIN THIS MANUAL. DO NOT
CONNECT THE UNIT TO A POWER SOURCE UNTIL INSTRUCTED TO DO SO. WHEN THE
POWER SUPPLY CABLE MUST BE CONNECTED, USE EXTREME CAUTION IN WORKING
ON POWER SUPPLY AND OTHER ELECTRONIC COMPONENTS.
CAUTION
1. REPAIRS ON EPSON PRODUCT SHOULD BE PERFORMED ONLY BY EPSON CERTIFIED
REPAIR TECHNICIAN.
2. MAKE CERTAIN THAT THE SOURCE VOLTAGE IS THE SAME AS THE RATED VOLTAGE,
LISTED ON THE SERIAL NUMBER/RATING PLATE. IF THE EPSON PRODUCT HAS A
PRIMARY AC RATING DIFFERENT FROM AVAILABLE POWER SOURCE, DO NOT
CONNECT IT TO THE POWER SOURCE.
3. ALWAYS VERIFY THAT THE EPSON PRODUCT HAS BEEN DISCONNECTED FROM THE
POWER SOURCE BEFORE REMOVING OR REPLACING PRINTED CIRCUIT BOARDS
AND/OR INDIVIDUAL CHIPS.
4. IN ORDER TO PROTECT SENSITIVE MICROPROCESSORS AND CIRCUITRY, USE
STATIC DISCHARGE EQUIPMENT, SUCH AS ANTI-STATIC WRIST STRAPS, WHEN
ACCESSING INTERNAL COMPONENTS.
5. REPLACE MALFUNCTIONING COMPONENTS ONLY WITH THOSE COMPONENTS BY
THE MANUFACTURE; INTRODUCTION OF SECOND-SOURCE ICs OR OTHER
NONAPPROVED COMPONENTS MAY DAMAGE THE PRODUCT AND VOID ANY
APPLICABLE EPSON WARRANTY.

PREFACE
This manual describes functions, theory of electrical and mechanical operations, maintenance, and
repair of EPSON Stylus Color 600.
The instructions and procedures included herein are intended for the experience repair technician,
and attention should be given to die precautions on the preceding page. The Chapters are
organized as follows:
CHAPTER 1. GENERAL DESCRIPTION
Provides a general product overview, lists specifications, and illustrates the main components of the
printer.
CHAPTER 2. OPERATING PRINCIPLES
Describes the theory of printer operation.
CHAPTER 3. DISASSEMBLY AND ASSEMBLY
Includes a step-by-step guide for product disassembly and assembly.
CHAPTER 4. ADJUSTMENT
Includes a step-by-step guide for adjustment.
CHAPTER 5. TROUBLESHOOTING
Provides EPSON-approved techniques for troubleshooting.
CHAPTER 6. MAINTENANCE
Describes preventive maintenance techniques and lists lubricants and adhesives required to
service the equipment.
APPENDIX
Describes connector pin assignments, circuit diagrams, circuit board component layout and
exploded diagram.
The contents of this manual are subject to change without notice.

REVISION SHEET
Revision Issued Data Contents
Rev. A February 20,1997 First issue

TABLE OF CONTENTS
CHAPTER 1. GENERAL DESCRIPTION
CHAPTER 2. OPERATING PRINCIPLES
CHAPTER 3. DISASSEMBLY AND ASSEMBLY
CHAPTER 4. ADJUSTMENT
CHAPTER 5. TROUBLESHOOTING
CHAPTER 6. MAINTENANCE
APPENDIX

Chapter 1
Product Descriptions
1.1 Features....................................................................................................................1
1.2 Specifications..........................................................................................................2
1.2.1 Printing Specification................................................................................................................ 2
1.2.2 Paper Specification ................................................................................................................... 5
1.2.2.1 Cut Sheet...................................................................................................................... 5
1.2.2.2 Transparency Film / Glossy Paper............................................................................... 5
1.2.2.3 Envelope....................................................................................................................... 5
1.2.2.4 Index Card.................................................................................................................... 5
1.2.3 Adjust Lever Settings (PG adjust lever).................................................................................. 6
1.2.4 Printable Area ............................................................................................................................ 7
1.2.4.1 Cut Sheet...................................................................................................................... 7
1.2.4.2 Envelope....................................................................................................................... 8
1.2.5 Environmental Condition.......................................................................................................... 9
1.2.6 Ink Cartridge Specifications................................................................................................... 10
1.2.6.1 Black Ink Cartridge.....................................................................................................10
1.2.6.2 Color Ink Cartridge.....................................................................................................11
1.2.7 Physical Specification............................................................................................................. 12
1.2.8 Electric Specification .............................................................................................................. 13
1.2.9 Reliability.................................................................................................................................. 13
1.2.10 Safety Approvals ................................................................................................................... 13
1.2.11 Acoustic Noise....................................................................................................................... 13
1.2.12 CE Marking............................................................................................................................. 13
1.2.13 Printer Language and Emulation......................................................................................... 14
1.3 Interface..................................................................................................................16
1.3.1 Parallel Interface (Forward Channel)..................................................................................... 16
1.3.2 Parallel Interface (Reverse Channel)..................................................................................... 17
1.3.2.1 Prevention Hosts from Data Transfer Time-out......................................................... 19
1.3.3 Serial Interface......................................................................................................................... 20
1.4 Control Panel .........................................................................................................21
1.4.1 Indicators.................................................................................................................................. 21
1.4.2 Panel Functions....................................................................................................................... 22
1.4.3 Printer Condition and Panel Status....................................................................................... 23
1.5 Error Status............................................................................................................24
1.5.1 Ink Out ...................................................................................................................................... 24
1.5.2 Paper Out.................................................................................................................................. 24
1.5.3 Paper Jam................................................................................................................................. 24
1.5.4 No Ink-Cartridge Error............................................................................................................. 25
1.5.5 Maintenance Request.............................................................................................................. 25
1.5.6 Fatal Errors............................................................................................................................... 25
1.6 Printer Initialization ...............................................................................................26
1.6.1 Initialization Settings............................................................................................................... 26

1.7 Main Components.................................................................................................27
1.7.1 Printer Mechanism...................................................................................................................27
1.7.2 C200 MAIN Board.....................................................................................................................28
1.7.3 C206 PSB/PSE Board...............................................................................................................29
1.7.4 C206 PNL Board.......................................................................................................................29

Chapter 1 Product Description
Rev. A 1-1
1.1 Features
EPSON Stylus Color 600 is designed for low price for that high performance. The major printer features
are;
 High color print quality
 1440(H) x 720(V) dpi printing
 Standard 4 color printing (CMY+Bk)
 Traditional and New Microwave control to eliminate banding
 Built-in auto sheet feeder
 Holds 100 cut-sheets (64g/‡u)
 Holds 10 envelopes
 Holds 10 transparency films
 Holds 65 special papers
 High-speed print
 200cps (at LQ/10CPI; No-Draft mode)
 By driving the printhead at frequency; 14.4KHz, printing speed is twice faster than Stylus Color.
 Compact size
 Non-operating : 429mm(W) x 275mm(D) x 168mm(H)
 Operating : 429mm(W) x 613mm(D) x 309mm(H)
 Weight : 5.2Kg (without cartridge)
 Acoustic noise
 Approximately 47dB(A)
 Two built-in standard I/F
 Bi-directional Parallel I/F (IEEE-1284 level 1 device)
 Serial I/F (Macintosh-compatible / up to 900Kbps)
The table below shows consumable for EPSON Stylus Color 600.
Item Code Remark
Black Ink Cartridge S020093 Color: Black
Color Ink Cartridge S020089 Color: Cyan/Magenta/Yellow
EPSON 360 dpi Ink Jet Paper S041025 Size: A4(200 sheets)
EPSON 360 dpi Ink Jet Paper S041059 Size: A4(100 sheets)
EPSON 360 dpi Ink Jet Paper S041060 Size: Letter(100 sheets)
Photo Quality Ink Jet Paper S041026 Size: A4(200 sheets)
Photo Quality Ink Jet Paper S041061 Size: A4(100 sheets)
Photo Quality Ink Jet Paper S041062 Size: Letter
Photo Quality Ink Jet Paper S041067 Size: Legal
Photo Quality Glossy Paper(New Release) S041126 Size: A4
Photo Quality Glossy Paper(New Release) S041124 Size: Letter
Photo Quality Glossy Film S041071 Size: A4
Photo Quality Glossy Film S041072 Size: Letter
Photo Quality Glossy Film S041107 Size: A6
Ink Jet Transparencies S041063 Size: A4
Ink Jet Transparencies S041064 Size: Letter
Photo Quality Ink Jet Card S041054 Size: A6
Photo Quality Ink Jet Card S041121 Size: 5 x 8 inches
Photo Quality Ink Jet Card S041122 Size: 10 x 8 inches
Photo Quality Self Adhesive Sheet S041106 Size: A4
Table 1-1 Available Consumable

EPSON Stylus Color 600
Rev. A
1-
2
1.2 Specifications
This section describes the product specifications for EPSON Stylus Color 600.
1.2.1 Printing Specification
 Print method
 On-demand color ink jet printing
 Nozzle configuration
 Black: 64 nozzles (32 nozzles x2 staggered / Nozzle pitch = 180dpi/vertical)
Color: 32 nozzles (per color (CMY) / Nozzle pitch = 90dpi/vertical)
 Print Direction
 Bi-directional printing with logical seeking for text and graphics
 Print Buffer: 32KBytes
 Print speed and Printable Columns
Character Pitch Printable
Column Draft Speed (CPS) LQ Speed (CPS)
10 CPI (Pica) 80 400 200
12 CPI (Elite) 96 480 240
15 CPI 120 600 300
17 CPI (Pica Condensed) 137 684 342
20 CPI (Elite Condensed) 160 800 400
Horizontal Resolution Printable
Area Available Dot CR Speed (IPS)
180 dpi 8.26 inch 1488 20
360 dpi 8.26 inch 2976 20
720 dpi 8.26 inch 5952 20
 Nozzle arrangement: See figure below.
Table 1-2 Print Speed (Text Mode)
Table 1-3 Print Speed (Raster Graphics Mode)
320/360" (22.5778mm)
144/360" (10.16mm)
32/360" (2.2578mm) 32/360" (2.2578mm)
180dpi
90dpi
Black Cyan Magenta Yellow
#2
#1
#3
#1 #1 #1
#63
#64
#32 #32 #32
*Viewed from the back of the head
Paper feed
direction
Figure 1-1. Nozzle Layout

Chapter 1 Product Description
Rev. A 1-
3
 Paper Feeding Method
 Friction feed with built in ASF (Auto Sheet Feeder)
 Line Spacing
 1/6 inch or programmable at 1/360 inch
 Paper Path
 Top entry (from ASF) only
 Feeding Speed
 66.6 ms (at 1/6 inch line-feed)
 3.0 inch/sec (76.2 mm/sec / at continuous-feed)
 ASF Capacity
 Size :Index card to Legal
 Thickness *1 :Less than 8mm
 Paper capacity *2 :Normal cut sheets =100 sheets (64g/m2)
:Envelops =10
:Coated papers (360dpi) =65
:Coated papers (720dpi) =65
:Glossy papers *3 *4 =30
:Transparency films *4 =30
:Index cards *4 =30
Notes) *1: Total thickness of paper stack on the ASF.
*2: Those numbers above should be considered as reference. The actual paper accumulation
should be considered first.
*3: Only when the top margin is set for 30mm with A4/Letter size paper, otherwise only one sheet
can be set at a time.
*4: Specified paper must be set at the bottom of stack to ensure proper feeding operation:
 Normal paper =Glossy paper, Transparency film
 Card Board =Index card
(The one packed with the index card package)

EPSON Stylus Color 600
Rev. A
1-
4
 Control Code
 ESC/P2 and expanded raster graphics code
 EPSON Remote command
 Character Tables
Legal and 14 international character sets
 Standard version: 11 character tables (See Table 1-4 for details)
 NLSP version: 19 character tables (See Table 1-4 for details)
 Typeface *1
 Bit map LQ font: EPSON Roman (10/12/15 CPI, Proportional)
EPSON Sans Serif (10/12/15 CPI, Proportional)
EPSON Courier (10/12/15 CPI)
EPSON Prestige (10/12/15 CPI)
EPSON Script (10/12/15 CPI)
 Scaleable font: EPSON Roman (10.5 pt, 8 to 32 pt (every 2 pt))
EPSON Sans Serif (10.5 pt, 8 to 32 pt (every 2 pt))
EPSON Roman T (10.5 pt, 8 to 32 pt (every 2 pt))
EPSON Sans Serif H (10.5 pt, 8 to 32 pt))
Note) *1: Each typeface has four different font style; Normal, Bold, Italic and Bold-Italic.
Version Character Table Bit-map Font Scaleable Font
Common EPSON - ;
Roman
Sans Serif
Courier
Prestige
Script
EPSON - ;
Roman
Sans Serif
EPSON - ;
Roman T
Sans Serif H
Standard Italic
PC437 (US / Standard Europe)
PC850 (Multilingual)
PC860 (Portuguese)
PC861 (Icelandic)
PC863 (Canadian-French)
PC865 (Nordic)
BRASCII
Abicomp
Roman 8
ISO Latin 1
Supported Supported Supported
NLSP Italic
PC437 (US / Standard Europe)
PC850 (Multilingual)
Supported Supported Supported
PC437 Greek
PC852 (East Europe)
PC853 (Turkish)
PC855 (Cyrillic)
PC857 (Turkish)
PC866 (Russian)
PC869 (Greek)
MAZOWIA (Poland)
Code MJK (CSFR)
ISO 8859-7 (Latin/Greek)
ISO Latin 1T (Turkish)
Bulgaria (Bulgaria)
PC774
Estonia
ISO 8859-2 (ISO Latin 2)
PC866 LAT
Supported Supported Not
Supported
Table 1-4 Character Table and Typeface

Chapter 1 Product Description
Rev. A 1-
5
1.2.2 Paper Specification
This section describes the types of paper that can be used in this printer.
1.2.2.1 Cut Sheet
[Size] :A4 [Width 210mm (8.3”) x Length 297mm (11.7”)]
:Letter [Width 216mm (8.5”) x Length 279mm (11.0”)]
:B5 [Width 182mm (7.2”) x Length 257mm (10.1”)]
:Legal [Width 216mm (8.5”) x Length 356mm (14.0”)]
:Half Letter [Width 139.7mm (5.5”) x Length 215.9mm (8.5”)]
:Exclusive [Width 190.5mm (7.5”) x Length 254mm (10”)]
[Thickness] :0.08mm (0.003”) - 0.11mm (0.004”)
[Weight] :64g/m2(17Ib.) - 90g/m2(24Ib.)
[Quality] :Exclusive paper, Bond paper, PPC
1.2.2.2 Transparency Film / Glossy Paper
[Size] :A4 [Width 210mm (8.3”) x Length 297mm (11.7”)]
:Letter [Width 216mm (8.5”) x Length 279mm (11.0”)]
:A6 [Width 105mm (4.1”) x Length 148mm (5.8”)]
[Thickness] :0.13mm (0.005”) - 0.15mm (0.006”)
:0.17mm (0.007”) - 0.18mm (0.007”) for glossy paper
Note) Transparency printing is only available at normal temperature.
1.2.2.3 Envelope
[Size] : No.10 [Width 241mm (9 1/2”) x Length 104.8mm (4 1/8”)]
: DL [Width 220mm (8.7”) x Length 110mm (4.3”)]
: C6 [Width 162mm (6.4”) x Length 114mm (4.5”)]
[Thickness] : 0.16mm (0.006”) - 0.43mm (0.017”)
[Weight] : 45g/m2 (12Ib.) - 75g/m2 (20Ib.)
[Quality] : Bond paper, Plain paper, Air mail
Note) 1. Envelop printing is only available at normal temperature.
2. Keep the longer side of the envelope horizontally at setting.
1.2.2.4 Index Card
[Size] :A6 Index card [Width 105mm (4.1”) x Length 148mm (5.8”)]
:5x8” Index card [Width 127mm (5.0”) x Length 203mm (8.0”)]
:10x8” Index card [Width 127mm (5.0”) x Length 203mm (8.0”)]
[Thickness] :Less than 0.23mm(0.0091”)
[Weight] :188g/m2
Note) 1. No curled, wrinkled, scuffing or torn paper be used.
2. Set the lever to the proper position according to the paper type you print. (Refer to section
1.2.3 for details)
3. Printing should be performed at room temperature in spite of the paper types.

EPSON Stylus Color 600
Rev. A
1-
6
1.2.3 Adjust Lever Settings (PG adjust lever)
The adjust lever located on the right side (blue knob) under the printer cover needs to be set to the proper
position according to the paper you print (Refer to the table below). Also, if there is any dirt caused by
friction on the wavy or wrinkled paper, this can be prevented by changing the lever position to rear position
(marked with “+”) in spite of paper types.
Paper Lever position PG adjustment value
Normal paper,
Coated paper
Transparency film
Label
Front 0 mm (1.1mm between head and platen)
Envelopes Rear 0.9 mm (2.0mm between head and platen)
Table 1-5. Adjust Lever Settings
Front (Mark "0") Rear (Mark "
+ ")
CR Guide Shaft
Bush
Level adjustment lever
Figure 1-2. Adjust Lever Settings

Chapter 1 Product Description
Rev. A 1-
7
1.2.4 Printable Area
1.2.4.1 Cut Sheet
Following tables show printable areas at Character mode and Raster Graphics mode.
Paper size PW
(Paper width)
(typ.)
PL
(Paper
Length)
(typ.)
LM
(Left margin)
(min.)
RM
(Right
margin)
(min.)
TM
(Top margin)
(min.)
BM
(Bottom
margin)
(min.)
A4 210mm(8.3”) 297mm(11.7”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Letter 216mm(8.5”) 279mm(11.0”) 3mm(0.12”) 9mm(0.35”) 3mm(0.12”) 14mm(0.54”)
B5 182mm(7.2”) 257mm(10.1”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Legal 216mm(8.5”) 356mm(14.0”) 3mm(0.12”) 9mm(0.35”) 3mm(0.12”) 14mm(0.54”)
Statement 139.7mm(5.5”) 215.9mm(8.5”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Executive 190.5mm(7.5”) 254mm(10”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Paper size PW
(Paper width)
(typ.)
PL
(Paper
Length)
(typ.)
LM
Left margin)
(min.)
RM
(Right
margin)
(min.)
TM
(Top margin)
(min.)
BM
(Bottom
margin)
(min.)
A4 210mm(8.3”) 297mm(11.7”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Letter 216mm(8.5”) 279mm(11.0”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
B5 182mm(7.2”) 257mm(10.1”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Legal 216mm(8.5”) 356mm(14.0”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Statement 139.7mm(5.5”) 215.9mm(8.5”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Executive 190.5mm(7.5”) 254mm(10”) 3mm(0.12”) 3mm(0.12”) 3mm(0.12”) 14mm(0.54”)
Table 1-6. Character Table
Table 1-7. Raster Graphics Mode
PW
LM RM
TM
BM
PL
Printable Area
Figure 1-3. Printing Area for Cut Sheet

EPSON Stylus Color 600
Rev. A
1-
8
1.2.4.2 Envelope
The table and figure below show the printable area for envelopes.
Paper Size LM
(Left Margin)
(min.)
RM
(Right Margin)
(min.)
TM
(Top Margin)
(min.)
BM
(Bottom Margin)
(min.)
#10 3mm (0.12”) 28mm (1.10”) 3mm (0.12”) 14mm (0.55”)
DL 3mm (0.12”) 7mm (0.28”) 3mm (0.12”) 14mm (0.55”)
C6 3mm (0.12”) 3mm (0.12”) 3mm (0.12”) 14mm (0.55”)
Table 1-8. Envelope
LM RM
TM
BM
Printable area
Figure 1-4. Printing Area for Envelope

Chapter 1 Product Description
Rev. A 1-
9
1.2.5 Environmental Condition
 Temperature
 Operating :10 - 35°C (Refer to the figure below for condition)
 Non-operating :-20 - 60°C (with shipment container)
Note) Storage should be within one month at 40°C and 120 hours at 60°C.
 Humidity
 Operating :20% - 80% RH
(without condensation. Refer to the figure below for condition)
 Non-operating :5% - 85% RH
(without condensation and with shipment container)
 Resistance to shock
 Operating :1G, within 1 ms (X,Y,Z directions)
 Non-operating :2G, within 2 ms (X,Y,Z directions/with shipment container)
 Resistance to vibration
 Operating :0.15G, 10•`55Hz (X,Y,Z directions)
 Non-operating :0.50G, 10•`55Hz (X,Y,Z directions/with shipment container)
Note) 1. During non-operating, make sure that the head is capped.
2. During the transport, make sure that the head is capped and ink cartridge is installed to the
printer.
3. If the head is not capped at the power-off state, turn the power on with the ink cartridge
installed and turn off the power after confirming that the head is correctly capped.
4. Ink will be frozen under -4°C environment, however it will be useable after placing it more than
3 hours at 25°C.
Humidity
(% RH)
°C
(°F)
80%
55%
20%
10°C
(50°F)
27°C
(80°F)
35°C
(95°F)
Guaranteed range
Figure 1-5. Temperature/Humidity of Range

EPSON Stylus Color 600
Rev. A
1-1
0
1.2.6 Ink Cartridge Specifications
1.2.6.1 Black Ink Cartridge
Item Specifications
Type Black Ink Cartridge(Code: S020093)
Color Black
Print capacity 540 pages / A4 (ISO/IE10561 Letter Pattern at 360 dpi)
Validity 2 years (sealed in package) / 6months(out of package)
Environmental
conditions
 Temperature
 Storage :-20 - 40°C (within a month at 40°C)
 Packing storage :-30 - 40°C (within a month at 40°C)
 Transit :-30 - 60°C (within 120 hours at 60°C and within a
month at 40••)
 Humidity
 5% - 85% (without condensation)
 Resistance to vibration
 Sealed in package :5 - 55Hz
 Acceleration :Less than 29.4m/s (3G)
 Direction :X, Y, Z direction
 Time :1 hour
 Drop
 Sealed in package:
 Dropping height :Less than 0.80m
 Direction :Drop the package facing the bottom, sides and one
edge down.
 Out of package:
 Dropping height :Less than 1.50m
 Frequency :Once
Dimension 19.8mm(W) x 52.7(D) x 38.5mm(H)
Weight  Total ink cartridge :54g
 Total ink :16.4•}0.5g (Amount in the ink cartridge)
 Consumable ink :More than 12.1g(Useable ink quantity until ink ends)
Note) 1. Ink cartridge can not re-fill, only ink cartridge is prepared for article of consumable.
2. Do not use the ink cartridge which is passed away the ink life.
3. Ink will be frozen under -4••environment, however it will be usual after placing it more than 3
hours at room temperature.
Table 1-9. Black Ink Cartridge Specifications
18.3
38.5
51.2
19.8
52.7
Figure 1-6. Ink Cartridge (Black)

Chapter 1 Product Description
Rev. A 1-11
1.2.6.2 Color Ink Cartridge
Item Specifications
Type Color Ink Cartridge(Code: S020089)
Color Magenta/Cyan/Yellow
Print capacity 300 pages / A4 (360 dpi, 5% duty each color)
Validity 2 years (sealed in package) / 6months(out of package)
Environmental
conditions
 Temperature
 Storage :-20•• - 40•• (within a month at 40••)
 Packing storage :-30•• - 40•• (within a month at 40••)
 Transit :-30•• - 60•• (within 120 hours at 60••and within a
month at 40••)
 Humidity
 5% - 85% (without condensation)
 Resistance to vibration
 Sealed in package :5 - 55Hz
 Acceleration :Less than 29.4m/s (3G)
 Direction :X, Y, Z direction
 Time :1 hour
 Drop
 Sealed in package :
 Dropping height :Less than 0.80m
 Direction :Drop the package facing the bottom, sides and one
edge down.
 Out of package:
 Dropping height :Less than 1.50m
 Frequency :Once
Dimension 42.9mm(W) x 52.7(D) x 38.5mm(H)
Weight  Total ink cartridge :68g
 Total ink :13.3•}0.5g (Amount in the ink cartridge)
 Consumable ink :More than 10.1g/each color (Useable ink quantity until
ink ends)
Note) 1. Ink cartridge can not re-fill, only ink cartridge is prepared for article of consumable.
2. Do not use the ink cartridge which is passed away the ink life.
3. Ink will be frozen under -4••environment, however it will be usual after placing it more than 3
hours at room temperature.
Table 1-10. Color Ink Cartridge Specification
41.4
38.5
51.2
43.2
42.9
52.7
Figure 1-7. Ink Cartridge (Color)

EPSON Stylus Color 600
Rev. A
1-1
2
1.2.7 Physical Specification
[Dimension] :429mm(W) x 234mm(D) x 162mm(H)
:429mm(W) x 695mm(D) x 309mm(H) with extended stacker and paper support.
[Weight] :5.2Kg
695mm (Max)
429mm
309mm
Figure 1-8. Dimension
