Epson TM-T82XM User manual

EPSON OPOS ADK MANUAL
APPLICATION DEVELOPMENT
GUIDE
POSPrinter
(TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM
-T83IIIM)
Version 3.00 Apr. 2021

Notes
(1) Reproduction of any part of this documentation by any means is prohibited.
(2) The contents of this documentation are subject to change without notice.
(3) Comments and notification of any mistakes in this documentation are gratefully
accepted.
(4) This software cannot be used with other equipment that the specified.
(5) EPSON will not be responsible for any consequences resulting from the use of any
information in this documentation.
Trademarks
Microsoft®, Windows®, Windows Server®, Visual Basic® and Visual C++® are
trademarks or registered trademarks of Microsoft Corporation in the United States and/or
other countries.
QR Code is a registered trademark of Denso Wave Incorporated.
EPSON® and ESC/POS® are registered trademarks of Seiko Epson Corporation.
Other product and company names used herein are for identification purposes only and
may be trademarks or registered trademarks of their respective companies.
Copyright © 2019 Seiko Epson Corporation

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
iii
Contents
SECTION 1. INTRODUCTION .......................................................................................1
SECTION 2. DETAILS ON SETTINGS ..........................................................................2
2.1 References of Firmware Versions ..............................................................................2
2.2 Settings of DIP Switches ............................................................................................2
2.3 Port Information..........................................................................................................2
2.4 Device Settings ............................................................................................................3
2.4.1 Usable Device Specific Settings...........................................................................3
2.4.2 Multilingual font Setting ...........エラー! ブックマークが定義されていません。
SECTION 3. FUNCTION DETAILS................................................................................4
3.1 Property Set Values and Default Values...................................................................4
3.1.1 Capability Set Values...........................................................................................4
3.1.2 List Properties ......................................................................................................6
3.1.3 Width and Height Properties...............................................................................9
3.1.4 Common Property Strings .................................................................................10
3.1.5 PageMode Print Properties................................................................................10
3.2 Methods......................................................................................................................11
3.3 Escape Sequences......................................................................................................12
3.4 Printable Barcode Type ............................................................................................13
3.5 MAXI CODE Printing...............................................................................................14
3.5.1 Symbology Parameter ........................................................................................14
3.5.2 Printing Size .......................................................................................................14
3.5.3 Printing Position.................................................................................................14
3.5.4 Data Format........................................................................................................14
3.6 QR CODE Printing....................................................................................................16
3.6.1 QR CODE Printing.............................................................................................16
3.6.2 Printing Size .......................................................................................................16
3.6.3 Error Correction Level .......................................................................................16
3.6.4 Printing Position.................................................................................................16
3.7 GS1 Printing (two dimension)..................................................................................17
3.7.1 Symbology Parameter ........................................................................................17
3.7.2 Printing Size .......................................................................................................17
3.7.3 Printing Position.................................................................................................17
3.7.4 Data Format........................................................................................................17

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
iv
3.8 COMPOSITE Printing ..............................................................................................18
3.8.1 Symbology Parameter ........................................................................................18
3.8.2 Printing Size .......................................................................................................18
3.8.3 Printing Position.................................................................................................18
3.8.4 Data Format........................................................................................................19
3.9 Power Condition Reports..........................................................................................20
3.10 Synchronous Processing .........................................................................................20
3.11 Printing Positions....................................................................................................20
3.12 Electronic Logo Function (NVRAM) ......................................................................21
3.13 Printable bitmap types and sizes...........................................................................21
3.14 Maintenance Counter .............................................................................................22
3.15 Automatic Recovery Function ................................................................................22
3.16 Output without Flow Control on the USB/Ethernet Interfaces ..........................22
SECTION 4. WARNINGS ..............................................................................................23

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
1
Section 1. Introduction
This manual describes the method of use and related items, as well as machine-specific
precautions, when the EPSON TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III Series POS
Printers are used with the EPSON OPOS ADK program.
This manual applies to the following devices.
Device List
Serial
USB
Ethernet
TM-T82XM
TM-T82XMU
TM-T82XME
TM-T81IIIM
TM-T81IIIMU
TM-T81IIIME
TM-T82IIIL
TM-T82IIILU
TM-T82IIILE
TM-T83IIIM
TM-T83IIIMU
TM-T83IIIME
Before reading the manual, see the following explanation about the characteristic of the
TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III printers.
•TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III
Station: Receipt (Line Thermal 203 dpi X 203 dpi)
Compatibility mode
The compatibility mode for upward compatibility was added in OPOS Ver2.60.
For the details of the compatibility mode, please refer to “EPSON OPOS ADK MANUAL
APPLICATION DEVELOPMENT GUIDE Compatibility Mode”.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
2
Section 2. Details on Settings
This section describes connection configurations and how to make the settings for the
TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III Series printers.
2.1 References of Firmware Versions
Refer to the release notes (Relnote.txt/SupportedDevicesList.txt).
2.2 Settings of Memory Switches
Please check device specification sheet.
2.3 Port Information
1) Port information when serial port is used
The port information that can be set with the SetupPOS utility is as follows.
Item
Setting range
Baud rate [bps]
2400, 4800, 9600, 19200, 38400,57600,
115200
Bit length [bit]
8
Parity
NONE, ODD, EVEN
Stop bit [bit]
1
Handshake
DTR/DSR
The default settings are as shown in the following table.
Item
Setting range
Baud rate [bps]
38400
Bit length [bit]
8
Parity
NONE
Stop bit [bit]
1
Handshake
DTR/DSR
The baud rate setting of device is set using the Utility.
For details, please refer to the “Utility User's Manual”.
2) Port information when using USB port
Not applicable
3) Port information when using Ethernet port
Not applicable

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
3
2.4 Device Settings
The following explanation is about the settings for the
TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83III models.
2.4.1 Usable Device Specific Settings
For the TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM models, the following
device specific settings are settable by the SetupPOS utility. For the detail, please
refer to the corresponding part of the Section 2 of “EPSON OPOS ADK MANUAL
APPLICATION DEVELOPMENT GUIDE POSPrinter (TM Series)”
Tab
Settings
General
Disable panel buttons
Assume print complete when data output finishes
Homogenize Error Codes *1
Ignore firmware version check
Output complete timeout [s]
Paper
Paper Type
Paper Width [mm]: LineWidth [dot]: LineCharsList
Bitmap
TMFlogo...
NVRAM
Color Bitmap
Halftone: Method
Halftone: Brightness
Color: Primary
Status Log
ERROR
OFFLINE
Log file name (full path name)
Maximum file size [KB]
Default Value
Multilingual font
Printing Properties
Receipt Characters per Line
Receipt Line Spacing [dots]
CharacterSet [CodePage Number]
*1 The settings can be changed when using a connection other than serial.
2.4.2 Multilingual font Setting
The TM-T82XM/TM-T81IIIM/TM-T83IIIM supports the following font type.
•CHINA GB18030
•TAIWAN BIG-5 (TM-T82XM only)
•VIETNAMESE
•THAI 3 PASS
•THAI 1 PASS
The default font type is set to CHINA GB18030.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
4
Section 3. Function Details
This section describes the functions of the
TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM models in details. Supplementary
explanation of the parts not described in detail in the "UPOS" is also given here.
3.1 Property Set Values and Default Values
The following explanation is about the property set values and the default values.
3.1.1 Capability Set Values
The following values are the Capability set values.
Capability Name
Setting Value
CapTransaction
TRUE
CapCoverSensor
TRUE
CapConcurrentRecSlp
FALSE
CapConcurrentJrnSlp
FALSE
CapConcurrentJrnRec
FALSE
CapConcurrentPageMode
FALSE
CapCharacterSet
PTR_CCS_KANJI
*1
CapMapCharacterSet
FALSE
*2
CapJrnUnderline
FALSE
CapJrnNearEndSensor
FALSE
CapJrnItalic
FALSE
CapJrnEmptySensor
FALSE
CapJrnDwideDhigh
FALSE
CapJrnDwide
FALSE
CapJrnDhigh
FALSE
CapJrnColor
0
CapJrnCartridgeSensor
0
CapJrnBold
FALSE
CapJrn2Color
FALSE
CapJrnPresent
FALSE
CapRecPageMode
TRUE
CapRecRuledLine
FALSE
CapRecUnderline
TRUE
CapRecStamp
FALSE
CapRecRotate180
TRUE

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
5
CapRecRight90
TRUE
CapRecPapercut
TRUE
CapRecNearEndSensor
FALSE
CapRecMarkFeed
0
CapRecLeft90
TRUE
CapRecItalic
FALSE
CapRecEmptySensor
TRUE
CapRecDwideDhigh
TRUE
CapRecDwide
TRUE
CapRecDhigh
TRUE
CapRecColor
PTR_COLOR_PRIMARY
CapRecCartridgeSensor
0
CapRecBold
TRUE
CapRecBitmap
TRUE
CapRecBarCode
TRUE
CapRec2Color
FALSE
CapRecPresent
TRUE
CapSlpUnderline
FALSE
CapSlpRotate180
FALSE
CapSlpRight90
FALSE
CapSlpNearEndSensor
FALSE
CapSlpLeft90
FALSE
CapSlpItalic
FALSE
CapSlpEmptySensor
FALSE
CapSlpDwideDhigh
FALSE
CapSlpDwide
FALSE
CapSlpDhigh
FALSE
CapSlpColor
0
CapSlpCartridgeSensor
0
CapSlpBothSidesPrint
FALSE
CapSlpBold
FALSE
CapSlpBitmap
FALSE
CapSlpBarCode
FALSE
CapSlp2Color
FALSE
CapSlpFullslip
FALSE
CapSlpPresent
FALSE
CapSlpPageMode
FALSE
CapSlpRuledLine
FALSE
*1 If Thai 3 Pass character model or VIETNAMESE character model,
“PTR_CCS_UNICODE” is set.
*2 If Thai 3 Pass character model or VIETNAMESE character model, “TRUE” is set.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
6
3.1.2 List Properties
The List Properties are explained in the following.
TM-T82XM:
List Property
Settings
CharacterSetList (Simplified Chinese)
”120, 121, 126, 130, 131, 150, 151, 152, 153, 154, 155,
255, 437, 720, 737, 775, 850, 851, 852, 853, 855, 857,
858, 860, 861, 862, 863, 864, 865, 866, 869, 936, 998,
999, 1098, 1125, 1250, 1251, 1252, 1253, 1254, 1255,
1256, 1257, 1258”
(Traditional Chinese)
”120, 121, 126, 130, 131, 150, 151, 152, 153, 154, 155,
255, 437, 720, 737, 775, 850, 851, 852, 853, 855, 857,
858, 860, 861, 862, 863, 864, 865, 866, 869, 950, 998,
999, 1098, 1125, 1250, 1251, 1252, 1253, 1254, 1255,
1256, 1257, 1258”
(Thai1 Pass)
“437, 874”
(Thai3 Pass and Vietnamese)
“120,121,126,130,131,437,997
*1
”
JrnLineCharsList
“”
RecLineCharsList 79.5mm: (Font A) “48”
(Font B) “64”
57.5mm: (Font A) “35”
(Font B) “46”
SlpLineCharsList
“”
RecBarCodeRotationList
“0, R90, L90, 180”
RecBitmapRotationList
”0, R90, L90, 180”
SlpBarCodeRotationList
“”
SlpBitmapRotationList
“”
FontTypefaceList
“”
*1 All characters loaded in the device are allocated to Unicode for printing. However, the
BinaryConversion property should be set to "OPOS_BC_NONE" when printing with
Unicode.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
7
TM-T81IIIM:
List Property
Settings
CharacterSetList
(Simplified Chinese)
”255,437,850,852,858,860,863,865,866,936,998,999,12
52”
(Thai1 Pass)
“437, 874”
(Thai3 Pass and Vietnamese)
“120,121,126,130,131,437,997
*1
”
JrnLineCharsList
“”
RecLineCharsList 79.5mm: (Font A) “48”
(Font B) “64”
57.5mm: (Font A) “35”
(Font B) “46”
SlpLineCharsList
“”
RecBarCodeRotationList
“0, R90, L90, 180”
RecBitmapRotationList
”0, R90, L90, 180”
SlpBarCodeRotationList
“”
SlpBitmapRotationList
“”
FontTypefaceList
“”
*1 All characters loaded in the device are allocated to Unicode for printing. However, the
BinaryConversion property should be set to "OPOS_BC_NONE" when printing with
Unicode.
TM-T82IIIL:
List Property
Settings
CharacterSetList ”120, 121, 126, 130, 131, 150, 151, 152, 153, 154, 155,
255, 437, 720, 737, 775, 850, 851, 852, 853, 855, 857,
858, 860, 861, 862, 863, 864, 865, 866, 869, 997*1,
998, 999, 1098, 1125, 1250, 1251, 1252, 1253, 1254,
1255, 1256, 1257, 1258”
JrnLineCharsList
“”
RecLineCharsList
(Font A) : “48”
(Font B) : “64”
SlpLineCharsList
“”
RecBarCodeRotationList
“0, R90, L90, 180”
RecBitmapRotationList
”0, R90, L90, 180”
SlpBarCodeRotationList
“”
SlpBitmapRotationList
“”
FontTypefaceList
“”
*1 All characters loaded in the device are allocated to Unicode for printing. However, the
BinaryConversion property should be set to "OPOS_BC_NONE" when printing with
Unicode.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
8
TM-T83IIIM:
List Property
Settings
CharacterSetList
(Simplified Chinese)
”120, 121, 126, 130, 131, 150, 151, 152, 153, 154, 155,
255, 437, 720, 737, 775, 850, 851, 852, 853, 855, 857,
858, 860, 861, 862, 863, 864, 865, 866, 869, 936, 998,
999, 1098, 1125, 1250, 1251, 1252, 1253, 1254, 1255,
1256, 1257, 1258”
(Thai1 Pass)
“437, 874”
(Thai3 Pass and Vietnamese)
“120,121,126,130,131,437,997
*1
”
JrnLineCharsList
“”
RecLineCharsList
(Font A) : “48”
(Font B) : “64”
SlpLineCharsList
“”
RecBarCodeRotationList
“0, R90, L90, 180”
RecBitmapRotationList
”0, R90, L90, 180”
SlpBarCodeRotationList
“”
SlpBitmapRotationList
“”
FontTypefaceList
“”
*1 All characters loaded in the device are allocated to Unicode for printing. However, the
BinaryConversion property should be set to "OPOS_BC_NONE" when printing with
Unicode.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
9
3.1.3 Width and Height Properties
The width and height properties are described below.
Property
Settings
Default
Value
Maximum
value [dot]
Minimum
value [dot]
RecLineSpacing
30
127
24 *1
JrnLineSpacing
X
X
X
SlpLineSpacing
X
X
X
SlpLineHeight [dot]
X
RecLineHeight [dot]
(Font A) 24
(Font B) 17
JrnLineHeight [dot]
X
SlpLineWidth [dot]
X
RecLineWidth [dot]
(79.5mm) 576
(57.5mm) 420
*3
JrnLineWidth [dot]
X
RecSidewaysMaxLines *2
(79.5mm) 19
(57.5mm) 14
*3
RecSidewaysMaxChars
(Font A) 138
(Font B) 184
RecLinesToPaperCut
4 *4
SlpSidewaysMaxLines
X
SlpSidewaysMaxChars
X
SlpMaxLines
X
X: No settings
*1 When Font A is selected. In the case of a line thermal station, the Line Spacing setting is
identical with the height of the characters which means that it can be set at up to 17
when Font B is selected.
*2 It can be changed by the settings of the RecLineSpacing or the RecLineHeight.
*3 Only TM-T81IIIM/ TM-T82XM are supported.
*4It can be changed by the settings of the RecLineSpacing or the character height.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
10
3.1.4 Common Property Strings
The Device information properties are described below.
I/F
DeviceName
DeviceDescription
S
TM-T82XM
EPSON TM-T82XM POS Printer
TM-T81IIIM
EPSON TM-T81IIIM POS Printer
TM-T82IIIL
EPSON TM-T82IIIL POS Printer
TM-T83IIIM
EPSON TM-T83IIIM POS Printer
U
TM-T82XMU
EPSON TM-T82XMU POS Printer
TM-T81IIIMU
EPSON TM-T81IIIMU POS Printer
TM-T82IIILU
EPSON TM-T82IIILU POS Printer
TM-T83IIIMU
EPSON TM-T83IIIMU POS Printer
E
TM-T82XME
EPSON TM-T82XME POS Printer
TM-T81IIIME
EPSON TM-T81IIIME POS Printer
TM-T82IIILE
EPSON TM-T82IIILE POS Printer
TM-T83IIIME
EPSON TM-T83IIIME POS Printer
I/F indicate the connected interface.
S: Serial
U: USB
E: Ethernet
3.1.5 PageMode Print Properties
The Device information properties are described below.
Property Station *2
Journal
Receipt
Slip
PageModeArea
-
(79.5mm) “576”, “1662”
(57.5mm) “420”, “1662”
*3
-
PageModeDescriptor *1
-
BM/BC/BMR/BCR
-
*1 Following setting values are used for the PageModeDescriptor property.
BM: Bitmap printing is available.
BC: Barcode printing is available.
BMR: Rotated printing of bitmap is available.
BCR: Rotated printing of barcode is available.
*2 If the Station’s CapRecPageMode property value is FALSE, the PageModeArea
property shall have” ” and the PageModeDescriptor property shall have ”0” respectively
as a setting value.
*3Only TM-T81IIIM/ TM-T82XM are supported.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
11
3.2 Methods
The following explanation is about supported/unsupported Methods, and the
detailed information.
Method
Supported/Unsupported
Compatibility with the
PageMode printing
PrintNormal
O
O
PrintTwoNormal
X
X
PrintImmediate
O
O*1
PrintBarCode
O
O*2
PrintBitmap
O
O*3
PrintMemoryBitmap
O
O*3
CutPaper
O
(1~100: Cutting with one point
of the bottom left corner uncut)
X
MarkFeed
X
X
ChangePrintSide
X
X
ValidateData
O
O
TransactionPrint
O
O
SetLogo
O
O
SetBitmap
O
O
RotatePrint
O
X
EndRemoval
X
X
BeginRemoval
X
X
EndInsertion
X
X
BeginInsertion
X
X
ClearPrintArea
O
O
PageModePrint
O
O
DrawRuledLine
X
X
O: Supported
X : Unsupported
*1 If the specified Station is ready to print, the printing data shall not be stored in the
PageMode printing buffer but, instead, go straight to printing. If the Station is not ready
to print, an error is returned.
*2 If other than “LEFT” is specified for the printing position of barcode, the printing shall be
done, regardless of the PageModeHorizontalPosition property setting, based on the
PageModePrintArea property setting in the horizontal direction.
*3 If other than “LEFT” is specified for the printing position of bitmap, the printing shall be
done, regardless of the PageModeHorizontalPosition property setting, based on the
PageModePrintArea property setting in the horizontal direction.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
12
3.3 Escape Sequences
The following figure is about supported/unsupported Escape Sequences.
Escape Sequence Supported/Unsupported
Compatibility with the
PageMode printing
#P
0~100
X
#fP
0~100
X
#sP
X
X
sL
X
X
#B
O
O
tL
O
O
bL
O
O
[*]#R
O
O
#lF
0~9999
O
#uF Base Pitch [inch]
0~ equiv. 50 cm
O
#rF Maximum [inch]
X
X
[*]#E
0~65535
X
#fT
X
X
bC
O
O
#uC
1~2
O
[!]iC
X
X
#rC
1
O
[!]rvC
O
O
#sC
X
X
#fC
X
X
tbC
X
X
[!]tbC
X
X
[!]tpC
X
X
1C
O
O
2C
O
O
3C
O
O
4C
O
O
#hC
1~8
O
#vC
1~8
O
cA
O
O *1
rA
O
O *1
lA
O
O
[!][#]stC
O
O
*#dL
X
X
N
O
O
O : Supported
X : Unsupported
Numbers: Settable range
*1 Regardless of the PageModeHorizontalPosition property setting, center or right adjust
what is to be printed based on the PageModePrintArea property setting in the horizontal
direction.

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
13
3.4 Printable Barcode Type
The TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM printers allow the following
barcode types.
•Code 128
•Code 128 Parsed
•Code 93
•Codabar
•ITF
•Code 39
•JAN 13 (EAN 13)
•JAN 8 (EAN 8)
•UPC-E
•UPC-A
•PDF417
•QRCODE
•MAXI CODE
•GS1-Data
•GS1-Data Expanded
•GS1-128
•GS1-Data Truncated
•GS1-Data Limited
•GS1-Data Stacked
•GS1-Data Stacked Omnidirectional
•GS1-Data Expanded Stacked
•Composite

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
14
3.5 MAXI CODE Printing
3.5.1 Symbology Parameter
When printing MAXI CODE, set the Symbology parameter to one of the following
values.
PTR_BCS_MAXICODE : Print using MAXI mode 2.
PTR_BCS_OTHER + 0 : Print using MAXI mode 3.
PTR_BCS_OTHER + 1 : Print using MAXI mode 4 or 5. The mode is set to
4 or 5 automatically depending on the length of the
Data parameter. (If the data is long, then the
data correction level is lowered for printing.)
PTR_BCS_OTHER + 2 : Print using MAXI mode 6.
3.5.2 Printing Size
Because the size of MAXI CODE is fixed, printing is done at a fixed size that is
unaffected by the Width and Height parameters. An error occurs only when the
Width and Height parameters fall below zero. If the two-dimensional barcode
cannot fit into the print area (depending on the paper width, layout settings, etc.)
then OPOS_E_ILLEGAL is returned and at this moment ResultCodeExtended
becomes zero.
3.5.3 Printing Position
Like the one-dimensional barcode, the print position of the two dimensional
barcode is the specified position.
3.5.4 Data Format
3.5.4.1 Mode 2
In the case of mode 2, because the format of header + primary message +
secondary message is fixed, data for the Data parameter must follow this format.
The header part contains the following data, which can be omitted.
"[)> RS 01 GS yy" (In hexadecimal: 0x5B 0x29 0x3E 0x1E 0x30 0x31 0x1D 0x..
0x..)
yy is '0' to '9' (0x30 to 0x39)
The primary message part contains the following data.
"Postal Code" GS "ISO Country Code" GS "Service Class Code" GS
Field
Length (byte)
Type
Postal Code
1 to 9
Number (0x30 to 0x39)
ISO Country Code
1 to 3
Number (0x30 to 0x39)
Service Class Code
1 to 3
Number (0x30 to 0x39)
For the secondary message, you can freely specify any data from 0x01 to 0xFF,
and the data can be omitted. Since the length of the encoded data is not known,
the data length cannot be correctly verified. For this reason, if the printer
determines, after examining the original data length, that the data can more or
less be printed, it tries to print the data; if the length is more than that, then an
error occurs. (For the secondary message, an error occurs if the data length is
more than 70 bytes.)

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
15
3.5.4.2 Mode 3
In the case of mode 3, except for the format of the primary message, it is same as
mode 2. The primary message of mode 3 has the following type of data.
"Postal Code" GS "ISO Country Code" GS "Service Class Code" GS
Field
Length (byte)
Type
Postal Code
1 to 6
Number (0x30 to 0x39)
A-Z space "#$%&'()*+,-./
ISO Country Code
1 to 3
Number (0x30 to 0x39)
Service Class Code
1 to 3
Number (0x30 to 0x39)
3.5.4.3 Modes 4 and 5
0x01 to 0xFF can be specified to the Data parameter, and there is no restriction
on the format. Since the length of the encoded data is not known, the data length
cannot be correctly verified. For this reason, if the printer determines, after
examining the original data length, that the data can more or less be printed, it
tries to print the data; if the length is more than that, then an error occurs. (An
error occurs if Data is zero byte or more than 80 bytes.)
Mode 4 differs from mode 5 in the error correction level. As much as possible,
OPOS uses the higher error correction level. Therefore, if the data amount is
small (less than 50 bytes), OPOS uses mode 5 (the one with a higher error
correction level).
3.5.4.4 Mode 6
0x01 to 0xFF can be specified to the Data parameter, and there is no restriction
on the format. Since the length of the encoded data is not known, the data length
cannot be correctly verified. For this reason, if the printer determines, after
examining the original data length, that the data can be printed, it tries to print the
data; if the length is more than that, then an error occurs. (An error occurs if Data
is zero byte or more than 80 bytes.)

Version 3.00 Apr. 2021
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-T82XM/TM-T81IIIM/TM-T82IIIL/TM-T83IIIM)
16
3.6 QR CODE Printing
3.6.1 QR CODE Printing
When printing QR CODE, set the Symbology parameter to one of the following
values.
PTR_BCS_QRCODE: Print using QR CODE model 2.
PTR_BCS_OTHER + 3: Print using QR CODE model 1 (old specification, used
for maintaining compatibility).
PTR_BCS_OTHER + 4: Print using QR CODE model 2.
3.6.2 Printing Size
Because the width and length of QR CODE are the same, printing is done to the
inner part at a size closest to it by using the value specified by the Width
parameter. Therefore, the height of print is not affected by the Height parameter.
If the Height parameter is less than 0, an error occurs.
The print size is determined by the version of QR and the size of the module.
Because the version of QR is determined by the data length and type, you can
use the size of the module to adjust the print size. If the two-dimensional
barcode cannot fit into the print area (depending on the paper width, layout
settings, etc.) then OPOS_E_ILLEGAL is returned and at this moment
ResultCodeExtended becomes zero.
For QR, it differs from other two-dimensional barcodes; if the encoded data result
is not known, then the print width cannot be obtained. If the print width cannot be
obtained, the page mode range for 90-degree rotated printing cannot be specified.
Therefore, within OPOS it calculates the number of code words of the encoded
data. Because of this reason, data amount can be correctly verified.
3.6.3 Error Correction Level
Error correction level is fixed at 7%.
3.6.4 Printing Position
Like the one-dimensional barcode, the print position of the two dimensional
barcode is the specified position.
