Introduction
The EPSON®Stylus®COLOR IIs is an affordable, high-quality
ink jet printer. It can print up to 16 million colors at high
resolution to produce photo-quality color images. The printer
also produces realistic grayscale images, sharp text, and line
art. The printer’s ink jet technology allows it to operate quietly,
keeping your workspace peaceful.
The Stylus COLOR IIs is easy to install and use. You simply set
it up, connect it to your computer, and install the printer driver
software, as described in the Setup Guide. The printer has a
built-in parallel interface so you can connect it to any IBM®PC
or compatible computer.
Getting the Most Out of Your Printer
The printer supports a wide variety of settings that let you
improve print quality or speed up printing. You customize
these settings using the printer driver. Before using your
printer, read this section to learn more about the print options
available to you.
Also click on the ReadMe icon in the EPSON program group in
Microsoft®Windows® for the latest information.
Three Resolutions to Choose From
Resolution is a measure of the amount of detail that can be
represented. The higher the resolution, the more detailed and
realistic the image, and the longer it takes to print. For printed
images, resolution is measured in dots per inch (dpi).
Proof Sign-off:
Mary _______
Nancy _______
Moira _______
Cindy _______
R
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
Introduction 1

Your printer has three resolutions: 720 dpi, 360 dpi, and
180 dpi. Use 720 dpi for the best possible images. For
high-quality images in less time, use 360 dpi. When speed is
important and draft quality is good enough, use 180 dpi. For
guidelines on selecting the best resolution for your print jobs,
see Chapter 2.
Special Papers
The type of paper you use is very important. Although you get
good results with plain bond paper, you will get better results
by using coated papers because they do not absorb as much
ink.
To ensure the best possible quality, EPSON offers special
coated papers, glossy papers, and transparencies that are
formulated specifically for the inks used by the printer. You can
order these products from EPSON Accessories at [phone]
(U.S. sales only). In Canada, call (800) BUY-EPSON for sales
locations. For information about special papers and other
media, see Chapter 1.
Specially Formulated Ink
EPSON’s black and color ink cartridges are specially
formulated to work with EPSON paper and the driver to
deliver the best looking images. Always use genuine EPSON
ink cartridges and do not refill them. Other products may cause
damage not covered by EPSON’s warranty.
Automatic Printer Driver Settings
The printer driver includes an Automatic Document Type
option that sets various printer driver settings for you. When
you select this feature, the driver analyzes the elements on the
page to be printed and adjusts the driver settings so your
printed results are appropriate for each image type.
L
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
2 Introduction

MicroWeave for Superior Output
The printer’s MicroWeave feature is a special printing mode
you can use to enhance your printed output. When
MicroWeave is on, the printer selectively applies ink in an
intricate pattern to eliminate the possibility of banding (light,
horizontal lines which mar an image) that can sometimes occur
in normal mode.
High Speed Mode for Fast Printing
High Speed mode increases the print speed. When it is on, the
printer prints bidirectionally; that is, it prints a line from right
to left and the next line from left to right. When High Speed
mode is off, all lines are printed in the same direction.
Printing is faster with High Speed mode on. However, the
vertical alignment may not be as precise. For this reason, turn
off High Speed mode when you need to improve print quality.
Energy Star Compliance
As an Energy Star Partner, EPSON has determined
that this product meets the Energy Star guidelines
for energy efficiency.
The EPA estimates that if all desktop computers, printers, and
other peripheral devices met Energy Star standards, energy
cost savings would exceed $1 billion annually and carbon
dioxide emissions would be reduced by 20 million tons.
All of EPSON’s ink jet printers conform to Energy Star
standards.
R
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
Introduction 3

Energy-saving Tips
Here are a few tips you can use to be even more energy-wise:
❑If your monitor isn’t Energy Star compliant, turn it off
when you’re not using it.
❑Turn off your computer, printer, and monitor each day
when you are done using them.
❑Use the print preview option in your software so you can
catch errors before you print something.
❑If you have an electronic mail system available to you, send
E-mail rather than memos. Not only is this faster, but you’ll
save paper and storage space too.
How to Use This Manual
This manual explains how to use your printer once you have
set it up. First follow the instructions in the Setup Guide to
install your printer; then refer to this manual as needed for
operation and maintenance information.
Chapter 1, “Paper Handling,” explains how to select the right
paper or other media for your print job and how to load it in
your printer.
Chapter 2, “Controlling the Printer,” provides instructions for
managing the printer’s operation through the printer driver
software and the printer’s control panel. It also tells you how to
manage print jobs and access the Default Setting mode.
Chapter 3, “Maintenance,” gives instructions for cleaning the
print heads, replacing an ink cartridge, calibrating the printer,
cleaning the printer, and transporting it.
L
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
4 Introduction

Chapter 4, “Troubleshooting,” contains troubleshooting
guidelines for any print quality or printer operation problems
you may have.
Appendix A, “Technical Specifications,” contains the
specifications for the Stylus COLOR IIs printer.
Appendix B, “Commands and Character Tables,” lists the
ESC/P 2emulation commands supported by the printer and
shows the printer’s built-in character tables.
A Glossary and Index are included at the end of the manual.
Where to Get Help
If you purchased your printer in the United States or Canada
and you need technical assistance, you can call an EPSON
Color Specialist at [phone].
EPSON also provides customer support and service through a
network of Authorized EPSON Customer Care Centers and
provides the following services when you dial [phone]:
❑EPSON technical information library fax service
❑Product literature on current and new products
❑Assistance in locating your nearest Authorized EPSON
Reseller or Customer Care Center
❑Technical information on the installation, configuration,
and operation of EPSON products
❑Customer relations.
You can purchase ink cartridges, paper, parts, printed manuals,
and accessories for EPSON products from EPSON Accessories
at [phone] (U.S. sales only). In Canada, call
(800) BUY-EPSON.
R
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
Introduction 5

If you purchased your printer outside the United States or
Canada, contact your EPSON dealer or the marketing location
nearest you for customer support and service.
If you need help with any software program you are using,
see the documentation for that program for technical support
information.
Electronic Support Services
If you have a modem, the fastest way to access helpful tips,
specifications, drivers, application notes, and bulletins for
EPSON products is through the online services below.
World Wide Web
If you are connected to the Internet and have a Web browser,
you can access EPSON’s World Wide Web site at
http://www.epson.com. EPSON’s home page links users to
What’s New, EPSON Products, EPSON Connection,
SM Corporate
Info and EPSON Contacts. Link to the EPSON Connection for
the latest drivers and FAQs (Frequently Asked Questions) and
the EPSON Chat area. To get in touch with EPSON around the
world, EPSON Contacts includes Contact Information for local
EPSON subsidiaries.
EPSON Bulletin Board Service
You can call the EPSON Bulletin Board Service (BBS) at
[phone]. No membership is required. Make sure your
communications software is set to 8 data bits with 1 stop bit,
no parity bit, and a modem speed of 28.8 Kbps or less. See the
documentation that came with your communications software
for more information.
L
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
6 Introduction

CompuServe online support
CompuServe®members can call the Epson America Forum
on CompuServe. If you are already a member, simply type
GO EPSON at the menu prompt to reach the Forum.
If you are not currently a member, you are eligible for a free
introductory membership as an owner of an EPSON product.
This membership entitles you to:
❑An introductory credit on CompuServe
❑Your own user ID and password
❑A complimentary subscription to CompuServe Magazine,
CompuServe’s monthly publication.
To take advantage of this offer, call [phone] in the United
States and Canada and ask for representative #529. In other
countries, call the following U.S. telephone number:
[phone], or your local CompuServe access number.
Important Safety Instructions
Before using your printer, read the following safety
instructions to make sure you use the printer safely and
effectively.
❑Turn off and unplug the printer before cleaning. Clean with
a damp cloth only. Do not spill liquid on the printer.
❑Do not place the printer on an unstable surface or near a
radiator or heating vent.
❑Do not block or cover the openings in the printer’s cabinet
or insert objects through the slots.
❑Use only the type of power source indicated on the
printer’s label.
R
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
Introduction 7

❑Connect all equipment to properly grounded power
outlets. Avoid using outlets on the same circuit as
photocopiers or air control systems that regularly switch
on and off.
❑Do not let the power cord become damaged or frayed.
❑If you use an extension cord with the printer, make sure the
total ampere rating of the devices plugged into the
extension cord does not exceed the cord’s ampere rating.
Also, make sure the total of all devices plugged into the
wall outlet does not exceed 15 amperes.
❑Except as specifically explained in the User’s Guide, do not
attempt to service the printer yourself.
❑Unplug the printer and refer servicing to qualified service
personnel under the following conditions:
If the power cord or plug is damaged; if liquid has entered
the printer; if the printer has been dropped or the cabinet
damaged; if the printer does not operate normally or
exhibits a distinct change in performance. Adjust only those
controls that are covered by the operating instructions.
L
Hudson User’s Guide
A5 size Introduction
10-28-95 DR, pass 2-Rev1
8 Introduction

Chapter 1
Paper Handling
Proof Sign-off:
Mary _______
Nancy _______
Moira _______
Cindy _______
Choosing Paper and Other Media . . . . . . . . . . . . . . . . . 1-2
Setting the Paper Thickness and Adjustment Levers . . . . . . 1-3
Paper Thickness Lever . . . . . . . . . . . . . . . . . . . . . 1-3
Thickness Adjustment Lever . . . . . . . . . . . . . . . . . . 1-4
Loading Plain Paper . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Feeding Paper One Sheet at a Time . . . . . . . . . . . . . . . . 1-8
Loading Special Papers and Other Media . . . . . . . . . . . . 1-9
Loading Special Papers and Transparencies . . . . . . . . 1-10
Loading Envelopes . . . . . . . . . . . . . . . . . . . . . . . 1-13
1
R
Hudson User’s Guide
A5 size Chapter 1
10-28-95 DR, pass 2-Rev1
Paper Handling 1-1

Read this chapter for information about choosing the best
paper and other media for your printing needs and for
instructions on loading them.
Choosing Paper and Other Media
You can use most plain bond paper with your printer and
achieve good results. Coated papers give you better results
because they reduce the amount of ink that is absorbed.
However, if the coated paper does not absorb enough ink, the
ink can smear.
To ensure the best results, EPSON provides special papers and
transparencies that are formulated for the inks used in EPSON
ink jet printers. These papers include the following:
❑EPSON special coated paper for 360 dpi. Use this paper for
best results when printing at 360 dpi.
❑EPSON special coated paper for 720 dpi. Use this paper for
best results when printing at 720 dpi. Five sample sheets
are included with the printer.
❑EPSON high-quality glossy paper. Use this paper with
720 dpi to produce camera-ready composites. When
printing on glossy paper, use only EPSON high-quality
glossy paper.
❑EPSON transparency film. When printing transparencies,
use only EPSON transparencies. For best results, use
transparencies within six months of opening the package.
Do not select 720 dpi when printing transparencies.
To order EPSON papers and transparencies, contact your
dealer or call EPSON Accessories at [phone] (U.S. only).
In Canada, call (800) BUY-EPSON for sales locations.
L
Hudson User’s Guide
A5 size Chapter 1
10-28-95 DR, pass 2-Rev1
1-2 Paper Handling

Use the following part numbers when ordering:
Paper Size Part Number
Special coated paper for
720 dpi Letter (8.5 x 11 inches) Legal (8.5 x 14 inches) S041062 S041048
Special coated paper for
360 dpi Letter (8.5 x 11 inches) S041060
High-quality glossy paper Letter (8.5 x 11 inches) S041072
Transparency film Letter (8.5 x 11 inches) S041064
Setting the Paper Thickness and Adjustment Levers
Before you start printing, you should check the paper thickness
and adjustment levers to make sure they are set correctly for
the type of paper or other media you are loading.
cCaution:
Before you change the lever settings, make sure there is no
paper in the paper path and that printing is paused. To do this,
press the Pause button or turn off the printer.
Paper Thickness Lever
The paper thickness lever on the right side of the sheet feeder
has two settings: plain paper and thick paper. Set the lever to
the position that best suits the paper or other media you plan
to use, as shown in the following table and illustration.
Paper type Paper thickness lever position
Standard paper Plain paper
Transparency film Plain paper
Envelopes or labels Thick paper
Manually fed paper Thick paper
R
Hudson User’s Guide
A5 size Chapter 1
10-28-95 DR, pass 2-Rev1
Paper Handling 1-3

Thickness Adjustment Lever
You need to change the position of the thickness adjustment
lever when you print on thick paper, such as envelopes, or if
your documents smear, as shown in the following table.
Paper type Thickness adjustment lever position
Standard paper 0
Transparency film 0
Envelopes or labels +
Previously smeared documents +
plain paper
setting
thick paper
setting
2-1t
L
Hudson User’s Guide
A5 size Chapter 1
10-28-95 DR, pass 2-Rev1
1-4 Paper Handling

To access the lever, open the printer cover; the lever is in the
left back corner, as shown below.
If a document is smeared, set the thickness adjustment lever to
the + position (regardless of the paper type) and print it again.
If your document still smears, press the Alt and Load/Eject
buttons on the printer’s control panel to enable the non-smear
printing mode. See “Using the Printer’s Control Panel” in
Chapter 2 for more information.
2-2t
R
Hudson User’s Guide
A5 size Chapter 1
10-28-95 DR, pass 2-Rev1
Paper Handling 1-5

Loading Plain Paper
This section explains how to load plain bond paper in the
printer. For instructions on loading coated or glossy paper,
envelopes, and transparencies, or on feeding paper one sheet at
a time, see page 1-8.
You can load up to 100 sheets of plain paper in the sheet feeder.
Be sure to load it with the printable surface facing up. The
printable surface is marked with an arrow on most plain paper
packaging.
Note:
You can use these instructions for printing on labels; however, be sure
to set the paper thickness lever to the thick paper position and the
thickness adjustment lever to the + position. Also make sure no labels
are curled or peeling away from the backing when you load them.
1. Slide out the output tray located at the bottom of the printer;
then pull out the extension.
HW 16t
L
Hudson User’s Guide
A5 size Chapter 1
10-28-95 DR, pass 2-Rev1
1-6 Paper Handling
