Epson 7800p - PowerLite XGA LCD Projector User manual

Weighing just 12.1 lb, the EPSON PowerLite 7800p provides
remarkable power and an expansive feature set. This high-performance
portable boasts 3500 ANSI lumens, XGA resolution, and a 700:1
contrast ratio for brilliant image quality. In addition, state-of-the-art
EasyManagement™technology offers out-of-the-box networking
capabilities. IS personnel will appreciate its easy network monitoring,
maintenance and control.
A versatile performer, the EPSON PowerLite 7800p includes monitor out
capability, extraordinary video performance, and a preview function for
easy switching between sources. Bright enough for installation, and
light enough to carry, this model also offers vertical and horizontal
keystone correction, QuickCorner™image correction, and WallShot™
for color correction.
Convenient networking capability with
EasyManagement technology
• Built-in Ethernet port
• Projector monitoring, maintenance and control over the LAN
- Check power status, lamp hours, etc.
- Turn the projector on and off remotely
• Simple Network Management Protocol (SNMP)–for easy
network management
• Email notification via SMTP to alert issues related to temperature,
fan and lamp
Ultra bright 3500 lumens, weighs only 12.1 lb
• Remarkable brightness that’s great for classrooms or
conference rooms
Superior detail and razor-sharp contrast
• Three 1.0" EPSON high-aperture LCDs for evenly distributed
color across the screen
• XGA (1024 x 768) resolution for sharp, vivid detail
• 700:1 contrast ratio for blacker blacks and whiter whites
Easy installation, setup and operation
• Multiple lens options
• Image corrections tools for flexible setup and installation
- Keystone (40˚ vertical, 20˚ horizontal)
- QuickCorner for aligning images projected on a corner
- WallShot for color correction on a colored surface
• Short throw distance (5.25'/60") for placement closer to
the screen
• Preview function with seven convenient SnapWindows™
• Monitor out capability for simultaneous viewing on a monitor
and screen
• Easy-to-use remote control/control panel
- Manage the setup and installation process, picture-in-picture
capability, and more
- Operate multiple projectors simultaneously
• ASCII-based RS-232 communication
• Various inputs including D-Sub15, BNC, DVI, S-Video, and Video
• Low fan noise for undisturbed presentations
• Security function that protects your projector
• Start Here Kit gets first time users projecting in just minutes
Renowned EPSON service and support (free for the
duration of the warranty)
• Comprehensive two-year warranty
• 90-day bulb warranty for added dependability
• EPSON Road Service Program provides a replacement projector,
typically within 24 hours
• EPSON PrivateLineSM dedicated toll-free support line available
from 6 a.m. to 6 p.m. PST Monday – Friday
(Calls are answered live, typically in about a minute.)
• International warranty in over 45 countries
EPSON®
EPSON PowerLite®7800p
Portability with a twist
high
performance,
low profile
Front View
Back View
stylish metallic
silver finish
optional lenses/
zoom lens
WallShot
RJ-45 for
wired LAN
hard-wired
remote option
s-video
USB type B
RS-232
monitor
out
computer
DVI
BNC
composite video
full-featured
IR remote control

SM
EPSON PowerLite 7800p Specifications
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
Specifications and terms are subject to change without notice. EPSON is a registered trademark and EasyManagement, SnapWindows, WallShot and QuickCorner are trademarks of Seiko Epson Corporation.
PowerLite is a registered trademark, SizeWise is a trademark and EPSON Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are
trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2003 Epson America, Inc. CPD-15818 25K 4/03 WP Printed on Recycled Paper
Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 1.0 inches
Driving method EPSON Poly-silicon TFT Active Matrix
Pixel number 786,432 pixels x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9; 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual zoom/focus
F-number 1.7 to 2.3
f-number 28 to 37mm
Zoom ratio 1.0:1.35
Lamp
Type 250W UHE
Life (typical) 2000H (High Brightness)
Screen Width Ratio: (Distance/Width) 1.32 to 1.8:1
Screen Size (Projected Distance) 30" to 300" (2.6' to 36.1')
Keystone Correction Vertical: ±40 degrees, Horizontal: ±20 degrees
Auto Keystone Correction (Vertical only)
Brightness (typical) 3500 ANSI lumens, 2500 ANSI lumens (Low Brightness)
Contrast Ratio 700:1
Brightness Uniformity (typical) 90%
Color Reproduction 24 bit; 16.7 mil
Audio Output 5W Monaural
Operating Temperature 41ºF to 95ºF (5ºC to 35ºC)
Power Supply Voltage 100-120V/200-240V ±10%, 50/60Hz AC
Power Consumption 350W, 47W at sleep mode: Network ON
1.5W at sleep mode: Network OFF
Dimension (includes lens and feet) 12.8" x 16.5" x 5.4"
Dimension (excludes lens and feet) 12.8" x 16.5" x 4.6"
Weight 12.1 lb/5.5kg
Fan Noise 36db (High Brightness), 33db (Low Brightness)
Effective Scanning Frequency Range
Analog
Pixel Clock 13.5MHz to 230MHz
Horizontal 15KHz to 107KHz
Vertical 50Hz to 120Hz
Digital
Pixel Clock 25MHz to 135MHz
Horizontal 15KHz to 80KHz
Vertical 50Hz to 85Hz
Remote Control Features
Features Keystone, brightness, source selection, power,
PinP, preview, page up/page down,
color mode, volume, presets, e-zoom,
a/v mute, freeze, effects
Operating angle Right/Left ± 30 degrees
Upper/Lower ± 15 degrees
Operating distance 33 ft (10m)
RGB
Analog RGB I/O Digital RGB Input
Display performance
Native 1024 x 768 1024 x 768
Resize 1600 x 1200 1280 x 1024
1280 x 1024 800 x 600
800 x 600 640 x 480
640 x 480
Input terminal
Video Mini D-sub 15 pin x 1 DVI TypeD x1
5-BNC x 1
Audio Stereo mini jack Stereo mini jack
(for Mini D-sub),
RCA x 2 (for 5BNC)
RGB (cont.)
Analog RGB I/O
Output terminal
Video Mini D-sub 15pin
(monitor out) x1
Audio Stereo mini jack
Video I/O
Display performance NTSC: 560 line
PAL: 560 line
(Depends on observation of the
multi burst pattern)
Input signal NTSC/NTSC4.43/PAL/M-PAL/
N-PAL/PAL60/SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite video: RCA(Yellow) x 1
S-Video: Mini DIN
Component video: Mini D-sub 15pin
(in common with Analog RGB connector)
Video-RGB: Mini D-sub 15pin (in common
with Analog RGB connector)
Audio RCA(White/Red) x 2
Audio signal 500m Vrms/47Kohm
Control I/O
USB I/O USB connector series B x 1
(for mouse, keyboard)
Serial I/O Mini D-sub 9pin x 1
RS-232C
Network interface RJ45 x 1
Security Kensington®-style lock provision
Warranty
Two year limited warranty, 2-year international warranty, 90-day lamp
warranty, EPSON Road Service Program and EPSON PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cable, remote control, 2 AA batteries, computer cable, audio cable,
USB mouse cable, RCA Video Cable, RCA Audio Cable, CD-Rom (Windows-
based EasyManagement software, Start Here Kit.
Product/Accessory Part Numbers
EPSON PowerLite 7800p Projector V11H119020
Replacement lamp V13H010L22
Air filter set ELPAF01 V13H134A01
Middle throw zoom lens ELPLM03 V12H004M03
Long throw zoom lens ELPLL05 V12H004L05
Remote control cable set ELPKC28 V12H005C28
Ceiling mount ELPMB40
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Distribution amplifier ELPDA01
Digital video cable DVI to DVI, 3m ELPKC20
Digital video cable DVI to DFP, 3m ELPKC21
S-video cable ELPSV01
Mac adapter set ELPAP01
ATA shipping case ELPKS46
ATA molded hardshell case ELPKS48
50" portable screen ELPSC06
60" portable pop-up screen ELPSC07
80" portable pop-up screen ELPSC08
High resolution document imager ELPDC02
High resolution document camera V12H064020
Kensington security lock ELPSL01
