Epson EB-1460Ui User manual

Installation Guide

Using the Product Safely
1
Safety Instructions
For your safety, read all the instructionsin this guide before using this product. Incorrect handling that ignores
instructions in this guide could damage this product or could result in personal injury or property damage.
Keep this installation guide at hand for future reference.
Read the User'sGuide and SafetyInstructions for your projector and follow the instructions in these documents.
Safety indications
The documentation and this product use graphical symbols to show how to use this product safely.
The indications and their meaning are as follows. Make sure you understand them properly before reading
the guide.
Symbol Explanation
Warning This symbol indicates information that, if ignored, could possibly result in personal injury or
even death due to incorrect handling.
Caution This symbol indicates information that, if ignored, could possibly result in personal injury or
physical damage due to incorrect handling.
Explanation of Symbols
Symbols Explanation
Symbol indicating an action that must not be done
Symbol indicating an action that should be done
c
Symbol indicating related or useful information
Safety Precautions for Installation
Warning
The setting plate is exclusively for mounting the projector on a wall. If anything other than
a projector is mounted, the weight may result in damage.
If this product falls, it could cause death or personal injury.
The installation work (wall mounting) should be performed by specialists who have tech-
nical knowledge and ability. Incomplete or incorrect installation could cause the product
to fall and cause personal injury or property damage.
Follow the instructions in this guide when installing this product.
If the instructions are not followed, this product may fall, resulting in personal injury or an accident.

Using the Product Safely
2
Warning
Handle the power cord carefully.
Incorrect handling may cause fire or electric shock. Observe the following precautions when han-
dling:
•
Do not handle the power plug with wet hands.
•
Do not use a power cord that is damaged or modified.
•
Do not pull the power cord with too much force when routing the cable through the setting plate.
Do not install the setting plate in a place where it might be subjected to vibration or shock.
This could cause damage to the projector or mounting surface. If this product falls, it could cause
death or personal injury.
Install the setting plate so that it can sufficiently support the mass of the projector and
setting plate, and resist any horizontal vibration. Use M10 nuts and bolts.
Nuts and bolts smaller than M10 could cause the setting plate to fall. Epson acceptsno responsibility
for any damage or injury caused by lack of wall strength or inadequate installation.
The installation work should be performed by at least two qualified service personnel. If
you need to loosen any screws during installation, be careful not to drop this product.
If this product falls, it could cause death or personal injury.
When mounting this product on a wall, the wall requires enough strength to hold the
projector and the setting plate.
This product should be installed on a concrete wall. The maximum combined weight of the pro-
jector and the setting plate is approximately 16 kg (not including cables). Ensure the strength of
the wall before mounting this product on the wall. If the wall is not strong enough, reinforce the
wall before installation.
Inspect the setting plate on a regular basis to ensure there are no broken parts or loose
screws.
If any parts are damaged, stop using the setting plate immediately. If this product falls, it could
cause death or personal injury.
Do not disassemble or remodel this product.
There are numerous high-voltage sections inside the product that could cause a fire, electric shock,
or an accident.
Do not hang on this product or hang a heavy object on this product.
If this product falls, it could cause death or personal injury.
Do not use adhesives, lubricants, or oils to install or adjust the setting plate.
If you use adhesives to prevent the screws from loosening or things such as lubricants or oils on
the slide plate fixing part of the projector, the case may crack and cause the projector to fall,
resulting in personal injury or property damage.
Tighten all screws firmly after adjustment.
Otherwise, the product may fall and cause personal injury or property damage.
Never loosen the bolts and nuts after installation.
Confirm that the screws have not become loose on a regular basis. If you find any loose screws,
tighten them firmly. Otherwise, the product may falland cause personal injury or property damage.
Route the cables so that they are not interfered with the nuts and bolts.
Incorrect handling of the cables may cause fire or electric shock.

Using the Product Safely
3
Warning
When turning on the projector, do not look into the projection window.
This could cause damage to eyesight due to the powerful light emitted. Take particular care when
there are children present. When turning on the projector at a distance using the remote control,
make sure there is no one looking into the projection window.
When using the projector, do not place any objects or put your hand near the projection
window.
This area is dangerous as it reaches a high temperature due to the concentrated projection light.
Do not cover the projector's air intake vent or air exhaust vent. If either of the vents are
covered, the internal temperature could rise and cause a fire.
Avoid locations subject to high temperatures, such as close to heaters, and leave a gap of at least
50 cm between the wall and the air exhaust vent.
Do not use the projector in a location subject to combustible or explosive gas.
The projector may catch fire because of the high temperature of the lamp inside the projector.
If any abnormalities occur with this product, immediately disconnect the cables from the
product, and then contact your local dealer or the nearest Epson service call center.
Continuing to use the product in an abnormal condition could cause a fire, electric shock, or visual
impairment.
Caution
Do not install this product in a location where the operating temperature for your projector
model may be exceeded.
Such an environment may damage the projector.
Install this product in a place free from excessive dust and humidity to prevent the lens or
optical components from becoming dirty.
Do not use excessive force when adjusting this product.
This product may break, resulting in personal injury.
Notes on handling the Touch Unit (EB-1460Ui/EB-1450Ui only)
Warning
Do not disassemble or remodel the Touch Unit.
The Touch Unit contains a high power laser product that could cause a fire, electric shock, or an
accident.
Only connect the Touch Unit to the EB-1460Ui/EB-1450Ui. Do not connect it to any other
projectors or devices.
The device could malfunction, or laser light that is higher than normal intensity could be emitted.
Do not go near the Touch Unit if you are using medical equipment such as a pace maker.
Furthermore, when using the Touch Unit, make sure there is no one using medical equip-
ment such as a pace maker, in the surrounding area.
A powerful magnet within the unit generates electromagnetic interference which may cause med-
ical equipment to malfunction.

Using the Product Safely
4
Caution
Do not go near the Touch Unit with magnetic storage media such as magnetic cards, or
precision electronic devices such as computers, digital watches, or mobile phones.
A powerful magnet within the unit could corrupt data or cause a malfunction.
About This Installation Guide
This guide describes how to mount the ultra short-throw projector EB-1460Ui/EB-1450Ui/EB-1440Ui on a wall.
It also describes how to install the Touch Unit (EB-1460Ui/EB-1450Ui only), Control Pad, and Pen Stand after
mounting on a wall.

Using the Product Safely
5
Choosing an Installation Location
Projector installation location
•Carry out power supply wiring work for the installation location of the setting plate in advance.
•Install the projector away from other electric devices such as fluorescent lights or air conditioners. Some kinds of
fluorescent lights could interfere with the remote control of the projector.
•When installing the projector, make sure there is a gap of at least 50 cm from the wall to the projector's air exhaust
and intake vents on the left and right.
•When installing two or more projectors in parallel, make sure the temperature of the surrounding environment is
less than 35°C.
If the environment is too hot, the projector may overheat and the power may turn off without warning. When using
the projector in an environment of 35°C or more, install a partition to block the heat vented from the projector's air
exhaust vent. Make sure the partition is slightly larger than the exhaust vent (approx. 2 cm wider and taller), and then
install the partition 10 to 30 cm from the exhaust vent.
•It is recommended to keep connection cable length less than 20 meters to reduce external noise.
•We recommend using stick-on screens or board screens.
•Install the projector so that it is tilted at an angle of no more than ±3° vertically and horizontally in relation to the screen.
•When using the interactive function (Easy Interactive Function), install so that the projected image is within reach.
•Do not install the projector or the screen in a location subject to direct sunlight. If the projector or the screen are
subject to direct sunlight, the interactive function may not operate correctly.

Using the Product Safely
6
Touch Unit installation location (EB-1460Ui/EB-1450Ui only)
•When using the Touch Unit, install the projector using one of the following methods. The Touch Unit cannot be used
if another installation method is used.
•Mount the projector on a wall or suspend it from a ceiling and project images from in front of the screen.
•Install vertically on a table and project from the front of the desk. (When installing vertically on a table, you need
the optional Interactive Table Mount (ELPMB29).)
•Before installing the Touch Unit, make sure that the installation surface is not warped or distorted, and that any
unevenness on the screen surface is less than 5 mm.
•When installing the Touch Unit on a whiteboard, secure the Touch Unit with magnets or screws.
•When installing the Touch Unit outside the whiteboard, you need the supplied Touch Unit Bracket.

Using the Product Safely
7
•If the distance from the wall to the surface of the screen (f) is more than 51 mm, you cannot install the Touch Unit
outside the whiteboard.
•If there is a frame around the screen, make sure that the thickness of the top of the frame (e) is less than 3 mm. If
the thickness of the top of the screen exceeds 3 mm, the Touch Unit will not operate correctly.
