Epson EB-1480Fi User manual

Installation Guide

About This Installation Guide
1
Contents of this Guide
This guide contains the following information.
Installing an ultra-short throw projector (EB-1480Fi) using the wall mount supplied
Installing the Touch Unit (ELPFT01)
Installing the Touch Unit using the touch unit bracket (ELPMB63)
Installing the Pen Stand
Equipment and mounts/brackets that are not included can be purchased as optional accessories.

Contents
2
About This Installation Guide
ContentsofthisGuide ................. 1
Introduction
UsingtheProductSafely ............... 4
Safetyindications .......................4
ExplanationofSymbols ................... 4
Package Contents . . ................... 5
Wallmount ............................ 5
MainMount ......................... 5
Accessories .......................... 6
TouchUnit(optional) ..................... 6
TouchUnitBracket(optional) ...............7
Penstand ............................. 8
NecessaryItems ......................... 8
InstallationWorkFlow ................ 9
Figures of Installation Dimensions . . . . 10
ConnectionFigure ................... 11
ConnectingMultipleProjectors ............. 11
Installing the Wall mount
Cautions on Installing the Wall Mount . 12
CautionsontheInstallation Location of
theWallMount ...................... 16
WallMountSpecifications ............ 18
Aboutreplacementinstallations ............18
Externaldimensions ..................... 19
Adjustmentrange ...................... 20
Verticalslide ........................ 20
Horizontalslide ...................... 20
Forward/backwardslide ................ 20
InstallingAccessories .................... 21
Installation Procedure for the Wall
Mount .............................. 22
InstallingtheBracket .................... 23
Determining the installation position
(projectiondistancetables) .............. 23
Removing the currently installed projector
andwallmount ...................... 32
Attaching the adjustment unit to the
projector ........................... 34
Attaching the setting plate to the wall plate . . 35
Attaching the adjustment unit to the setting
plate .............................. 40
Attachingperipheraldevices............41
Adjusting the position of the projected image . . 41
Preparationsbeforeadjusting ............ 42
AutoScreenAdjustment ................ 44
Performing mechanical adjustment using
theSettingPlateInstallationGuide........47
Adjusting using the projector menus . . . . . . . 51
Attachingthecovers ....................57
AttachingaSecurityCable ................59
Installing the pen stand
NotesonthePenStand ............... 60
PenStandSpecifications ............. 61
Externaldimensions ..................... 61
InstallingthePenStand .............. 62
Whensecuringwithmagnets..............62
Whensecuringwithscrews ................ 63
Adjusting the Interactive Pen
CalibratingtheInteractivePen ........ 65
ManualCalibration ...................... 65
AutoCalibration.......................67
Installing the Touch Unit
Notes on handling theTouchUnit ..... 69
ForCanadianUsers..................... 70
TouchUnitinstallationlocation ....... 71
NotesontheTouchUnitBracket ............ 72
NotesontheLaser ................... 73
Attachedlabels ........................ 73
Laserdiffusionport ..................... 73
TouchUnitSpecifications ............. 75
Externaldimensions ..................... 75
Touch Unit Bracket Specifications . . . . . 76
Externaldimensions ..................... 76

Contents
3
Adjustmentrange ...................... 77
When using an older model of Touch
Unit ................................ 78
InstallingtheTouchUnit ............. 79
Installingtheinfrareddeflectors ............79
InstallingtheTouchUnit .................. 80
When installing on the projection surface
without using the Touch Unit Bracket . . . . . . 80
When using the Touch Unit Bracket to install
outsideoftheprojectionsurface .......... 83
AttachingaSecurityCable ................ 88
TurningontheTouchUnit ................89
Adjusting the Angle of the Laser (Touch Unit
AutoSetup) ........................... 90
Whenautoadjustmentfails............. 95
Calibratingthetouchoperationposition......98
Setting the Projector
BatchSetupFunction ............... 101
SetupUsingaUSBflashdrive ............. 101
SavingsettingstotheUSBflashdrive..... 101
Copying saved settings to other projectors . 102
Setup by Connecting the Computer and
ProjectorwithaUSBCable ............... 103
Savingsettingstoacomputer ........... 103
Copying saved settings to other projectors . 104
WhenSetupFails ...................... 106
Appendix
ListofSafetySymbols ............... 107
GeneralNotice ..................... 110

Introduction
4
Using the Product Safely
For your safety, read all the instructionsin this guide before using this product. Incorrect handling that ignores
instructions in this guide could damage this product or could result in personal injury or property damage.
Keep this installation guide at hand for future reference.
Read the User'sGuide and Safety Instructions for your projector and follow the instructions in these documents.
Safety indications
The documentation and this product use graphical symbols to show how to use this product safely.
The indications and their meaning are as follows. Make sure you understand them properly before reading
the guide.
Symbol Explanation
Warning This symbol indicates information that, if ignored, could possibly result in personal injury or
even death due to incorrect handling.
Caution This symbol indicates information that, if ignored, could possibly result in personal injury or
physical damage due to incorrect handling.
Explanation of Symbols
Symbols Explanation
Symbol indicating an action that must not be done
Symbol indicating an action that should be done
c
Symbol indicating related or useful information

Introduction
5
Package Contents
Confirm that you have all necessary items before beginning installation.
c
If a wall mount has not been supplied with the projector, purchase the optional mount (ELPMB62). To
install the projector using the ELPMB62, see the Installation Guide for the EB-1485Fi on the following
website.
http://epson.sn/
The pen stand may not be included depending on the area of purchase.
Wall mount
Main Mount
c
For parts labeled with , use the parts of the old wall mount as they are.
Wall plate
Hexagonal axis
Wall plate cover
End cap
No. Part name
Adjustment unit
Setting plate

Introduction
6
Accessories
Part Name Application
Cable binding belt Secure excess cables after performing
wiring.
Safety wire set Connect to the wall mount and the
projector to prevent the projector from
falling. See the user's guide supplied
with the safety wire set for more details.
Hexagon wrench (for M4) -
Spanner (No. 13 for M6) -
M4 x 12 mm hexagon sock‐
et head cap bolt with wash‐
er/spring washer (x8)

Secure the adjustment unit to the pro‐
jector (x4)

Secure the adjustment unit to the set‐
ting plate (x4)
M6 x 20 mm hexagon
shoulder head bolt with
washer/spring washer (x1)
Secure the setting plate to the wall
plate.
M6 x 20 mm cross recessed
head shoulder screws with
plastic washers (x3)
Touch Unit (optional)
Part Name Application
Touch Unit -
Template sheet (for secur‐
ing the Touch Unit)
Attach this to the wall before attaching
the Touch Unit, and use it to drill nec‐
essary holes.
Touch Unit connection ca‐
ble (approx. 1.8m)
Connect the Touch Unit to the projec‐
tor.

Introduction
7
Part Name Application
Markers x2 Attach to the screen to adjust the angle
of the laser emitted by the Touch Unit.
c
When the finger touch op‐
erations do not work cor‐
rectly, you need to use the
markers again to re-cali‐
brate the angle of the laser.
Keep these in a safe place
after installing.
Tape for securing the mark‐
ers
(approx. 6 cm) x12
Secure the markers to the projection
surface.
Infrared deflectors
(approx. 28.5 cm) x8
Use these when there is a tray or frame
at the bottom of the projection surface.
This prevents malfunctions due to laser
reflections.
Spacers for screw holes x3 Attach them to the screw hole when
securing the Touch Unit with screws.
Label x4 Attach the label in the position of the
Touch Unit. These provide markers
when repositioning due to movement
that occurs during use.
Touch Unit Bracket (optional)
Use this when attaching the Touch Unit to outside of the projection surface.
Part Name Application
Touch Unit Bracket -
Template sheet (for Touch
Unit Bracket)
Attach this to the wall before attaching
the Touch Unit Bracket, and use it to
drill necessary holes.
M4 x 25mm hexagon socket
head cap bolts (x2)
Secure the Touch Unit to the Touch
Unit Bracket.
Hexagon wrench (for M4) -

Introduction
8
Pen stand
Part Name Application
Main unit -
Cover Attach to the front of the pen stand.
Spacers for screw holes x3 Attach them to the screw hole when
securing the pen stand with screws.
Necessary Items
As well as the items supplied, you also need to prepare the following screws and tools.
Applicable parts Necessary items
For the Touch Unit

M4 screws (to secure the Touch Unit: x2)
For the Touch Unit bracket

Anchor bolts or screws for the bracket (depending on what the
mounting surface is made of)

M4 anchor bolts (x4)

3.8 mm diameter wood screws with a length of 45 mm or more (x4)
For the pen stand

M4 x 20 mm screws (x2)

Introduction
9
Installation Work Flow
We recommend installing the projector and peripheral devices in the following order.
a
Mount projector on wall and adjust the projected image (sp.12)
b
Install the pen stand (sp.60)
c
Perform pen calibration (sp.65)
d
Install and adjust touch unit and perform finger touch calibration (sp.69)
c
When you want to use the installed Touch Unit (see the following image) as it is,
adjust the laser angle ( p.90).

Introduction
10
Figures of Installation Dimensions
When using the Touch Unit, install the projector so that there is a gap between the projected image and the
edges of the screen as shown in the following image.
5.7-50mm
20mm
100mm100mm
(20 - 50mm (21:9))
When you want to use the installed Touch Unit as it is, leave a gap of 25 to 100 mm between the bottom of
the touch unit and the top of the image. If there is not enough space, you need to reinstall the Touch Unit.

Introduction
11
Connection Figure
Connecting Multiple Projectors
If interactive pen operations interfere with projectors that have been installed nearby, connect the projectors
by using the optional remote control cable set (ELPKC28).
You can reduce the interference caused by the interactive pen by setting Installation of Projectors > Sync
of Projectors to Wired from the Pen/Touch menu after connecting.

Installing the Wall mount
12
Cautions on Installing the Wall Mount
Warning
The Wall mount is exclusively for mounting the projector on a wall. If anything other than
a projector is mounted, the weight may result in damage.
If this product falls, it could cause death or personal injury.
The installation work (wall mounting) should be performed by specialists who have tech‐
nical knowledge and ability. Incomplete or incorrect installation could cause the product
to fall and cause personal injury or property damage.
Follow the steps in this guide to install the Wall mount, and be sure to use the bolts and
screws specified in this guide.
If the instructions are not followed, this product may fall, resulting in personal injury or an accident.
Handle the power cord carefully.
Incorrect handling may cause fire or electric shock. Observe the following precautions when han‐
dling:

Do not handle the power plug with wet hands.

Do not use a power cord that is damaged or modified.

Do not pull the power cord with too much force when routing the cable through the setting plate.
Do not install the setting plate in a place where it might be subjected to vibration or shock.
This could cause damage to the projector or mounting surface. If this product falls, it could cause
death or personal injury.
When installing on a wall, install so that it can sufficiently support the mass of the projector
and the Wall mount and resist any horizontal vibration. Use M10 or 3/8 inch x 60 mm nuts
and bolts.
Nuts and bolts smaller than M10 or 3/8 inch x 60 mm could cause the setting plate to fall. Epson
accepts no responsibility for any damage or injury caused by lack of wall strength or inadequate
installation.
The installation work should be performed by at least two qualified service personnel. If
you need to loosen any screws during installation, be careful not to drop this product.
If this product falls, it could cause death or personal injury.
When installing this product on a wall, the wall requires enough strength to hold the pro‐
jector and the Wall mount.
This product should be installed on a concrete wall.
The maximum combined weight of the projector and the Wall mount is approximately 18.7kg (not
including cables).
Ensure the strength of the wall before mounting this product on the wall. If the wall is not strong
enough, reinforce the wall before installation.
When installing the EB-1480Fi on a wall, use the wall mount supplied or the ELPMB62.
If you use a mount not specified in this manual, the projector cannot be installed correctly and the
projector may fall or the installation surface may be damaged.

Installing the Wall mount
13
Warning
Inspect the setting plate on a regular basis to ensure there are no broken parts or loose
screws.
If any parts are damaged, stop using the setting plate immediately. If this product falls, it could
cause death or personal injury.
Do not disassemble or remodel this product.
There are numerous high-voltage sections inside the product that could cause a fire, electric shock,
or an accident.
Do not hang on this product. Do not hang heavy objects on this product.
If this product falls, it could cause death or personal injury.
Do not use adhesives, lubricants, or oils to install or adjust the Wall mount.
If you use adhesives to prevent the screws from loosening or things such as lubricants or oils on
the slide plate fixing part of the projector, the case may crack and cause the projector to fall,
resulting in personal injury or property damage.
Tighten all screws firmly after adjustment.
Otherwise, the product may fall and cause personal injury or property damage.
Never loosen the bolts and nuts after installation.
Confirm that the screws have not become loose on a regular basis. If you find any loose screws,
tighten them firmly. Otherwise, the product may falland cause personal injury or property damage.
Route the cables so that they are not interfered with the nuts and bolts.
Incorrect handling of the cables may cause fire or electric shock.
When turning on the projector, do not look into the projection lens.
This could cause damage to eyesight due to the powerful light emitted. Take particular care when
there are children present. When turning on the projector at a distance using the remote control,
make sure there is no one looking into the projection lens.
When using the projector, do not place any objects or put your hand near the projection
lens.
This area is dangerous as it reaches a high temperature due to the concentrated projection light.
Do not use the projector in a location subject to combustible or explosive gas.
High temperatures within the projector may cause ignition and a fire to occur.
Only a specialist should remove or reinstall the projector, including for maintenance and
repairs.
See the projector's User's Guide for instructions on maintenance and repairs.
If any abnormalities occur with this product, immediately disconnect the cables from the
product, and then contact your local dealer or the nearest Epson service call center.
Continuing to use the product in an abnormal condition could cause a fire, electric shock, or visual
impairment.

Installing the Wall mount
14
Warning
Laser warning labels have been attached to the inside and outside of the projector.
Internal
External
Do not look into the laser beam emitted from the projection lens while projecting. (Based on IEC/
EN60825-1:2014)
For North/South America
This projector is a Class 2 laser product that complies with the IEC/EN60825-1:2007 international
standard for lasers.
Complies with FDA performance standards for laser products except for deviations pursuant to
Laser Notice No. 50, dated June 24, 2007.

Installing the Wall mount
15
Warning
Never open any cases on the projector.
Electrical voltages inside the projector can cause severe injury.
Do not look directly into the projector’s light source.
Possibly hazardous optical radiation emitted from this product. Eye injury may result.
Caution
Do not install this product in a location where the operating temperature for your projector
model may be exceeded.
Such an environment may damage the projector.
Install this product in a place free from excessive dust and humidity to prevent the lens or
optical components from becoming dirty.
Do not use excessive force when adjusting this product.
This product may break, resulting in personal injury.
This projector is a Class 1 laser product that complies with the IEC/EN60825-1: 2014
international standard for lasers.
Do not disassemble the projector when disposing of it.
Dispose according to your local or national laws and regulations.

Installing the Wall mount
16
Cautions on the Installation Location of the
Wall Mount
Warning
Do not install in a location subject to oily smoke or smoke for events.
If oils and so on stick to the slide plate fixing part of the projector, the case may crack and cause
the projector to fall, resulting in personal injury or property damage.
Caution
Do not install the projector or the screen in a location subject to direct sunlight.
If the projector or the screen are subject to direct sunlight, the interactive function may not operate
correctly.
Carry out power supply wiring work at the installation location of the projector in advance.
Install the projector away from other electric devices such as fluorescent lights or air con‐
ditioners.
Some types of fluorescent lights could interfere with the remote control or the pen.
When installing the projector, make sure there is a gap between the wall and the projector's
air exhaust and intake vents as shown in the following image.
When installing two or more projectors in parallel, make sure the temperature of the sur‐
rounding environment is less than 35°C.
If the environment is too hot, the projector may overheat and the power may turn off without
warning.

Installing the Wall mount
17
Caution
When installing two or more projectors in parallel, leave a gap of at least 1,200 mm between
the projectors.
1200mm
If you cannot secure a gap of approx. 1,200 mm, install a partition to block the heat vented from
the projector's air exhaust vent.
The partitions should be larger than the exhaust vent (approx. 20 mm in all directions), and installed
approximately 400 mm from the exhaust vent and 200 mm from the intake vents.
400mm 200mm
Install and adjust the projector at a room temperature that is close to the actual intended
usage environment.
If the temperature changes, the position of the image may shift or the accuracy of the pen may
decline.
Install the projector so that it is tilted at an angle of no more than +3 degrees or -3 degrees
vertically and horizontally in relation to the screen.
When using interactive functions, install the projector so that the projected image is within
reach.
We recommend using stick-on screens or board screens.

Installing the Wall mount
18
Wall Mount Specifications
Item Specification
Wall mount mass (setting plate, hexagonal axis, adjustment unit, wall plate,
wall plate cover, end cap)
Approx. 8.8 kg
(With setting plate and adjust‐
ment unit only: Approx. 5.4 kg)
Maximum load capacity Approx. 15.0 kg
About replacement installations
When replacing an installed projector with EB-1480Fi and you want to project images in the same position,
check if the following conditions are met.
The installed projector is one of the following:
BrightLink 485Wi
BrightLink 475Wi
BrightLink 480i
PowerLite 485W
PowerLite 475W
PowerLite 470
PowerLite 480
EB-485Wi
EB-485Wi+
EB-485Wie
EB-475Wi
EB-475Wi+
EB-475Wie
EB-485W
EB-485We
EB-475W
EB-475We
EB-470
EB-480
EB-480e
EB-480i
EB-470i
BrightLink 595Wi
BrightLink 595Wi+
BrightLink 585Wi
BrightLink 585Wi+
BrightLink 575Wi
BrightLink 575Wi+
PowerLite 585W
PowerLite 575W
PowerLite 580
PowerLite 570
EB-595Wi
EB-595Wie
EB-585Wi
EB-575Wi
EB-575Wie
EB-585W
EB-585We
EB-575W
EB-575We
EB-580
EB-580e
EB-570
If it is installed on a wall, the installation mount is one of the following:
ELPMB28
ELPMB43
Projecting at a size of 65 inches or more

Installing the Wall mount
19
External dimensions
70.6
233 75
375 472.8-174.8
229
160.8
223.5
376
458
547.6
LENSCENTER
30.5
162
26
12
20
5.2
125.9
2xM4
4xM4
208.5 74
117
11225
