Epson EB-G6050W
Powerful projectors with uncompromising image
quality and reliability for large venues
3 x Brighter Colours* and reliable performance – 3LCD, 3-Chip Technology.
Look for both high colour brightness and high white brightness
Edge Blending – Combine multiple individual images to create one seamless
giant image
2 x Digital connections – Digital quality and flexibility
360° Installation – Install on any plane, from horizontal to vertical and
everything in between
Arc and Point Correction – Fine tune image geometry to perfection
Passive 3D – For stacked 3D applications using polarized passive glasses
Six optional Lenses with Lens Shift – For complete flexibility and easy exchange

Product Specifications
Epson EB-G6050W
CONNECTIVITY
Input: Video 1 x RCA (Yellow), 1 x S-Video, 1 x 5BNC
Input: Computer 1 x D-sub 15-Pin (RGB)
Input: Digital 1 x HDMI, 1 x DisplayPort
Input: Audio 3 x Stereo mini-jack, 1 x RCA (Red/White), 1 x HDMI,
1 x DisplayPort
Input: Control 1 x RS232c, 1 x Stereo mini-jack (Remote)
Input: Network I/O 1 x RJ45, 1 x USB Type A (for optional Wireless LAN unit)
Wireless Connectivity Optional
Output: Video 1 x Monitor Out (via D-sub 15-pin)
Output: Audio 1 x Stereo mini jack
Speaker Output 10W
ADVANCED FEATURES
EasyMP Network & Control Yes
EasyMP Network Projection Yes
Split Screen Yes
Edge Blending Yes
Arc Correction Yes
360 Degrees Projection Yes
Instant Off Yes
Direct Power On/Off Yes
Security Kensington®-style lock provision
Padlock and Security cable hole
Password protect function
Wireless LAN Lock
Lens Lock
Colour Modes Photo, Presentation, Theatre Dynamic, sRGB,
Multi-Projection, DICOM SIM, 3D Presentation,
3D Theatre, 3D Dynamic, 3D Multi-Projection
GENERAL
Dimensions D x W x H (excl feet) 505 x 405.5 x 171 mm
Weight 9.7kg (Including Standard Lens. Excluding Cable Cover)
Lamp Warranty 1 Year or 750 Hours**
Projector Warranty 3 Years
Power Consumption: Lamp on 477 W
Power Consumption: Standby 0.41 W
Noise Level Normal/Eco: 37/31 dB
PRODUCT NAME Epson EB-G6050W
PRODUCT CODE V11H511053
WHAT’S IN THE BOX
EB-G6050W Projector, 3m Power Cable, 1.8m
Computer Cable, Remote Control, 2 x AA Batteries,
Lens Lock Screw, HDMI Cable Clamp, Cable Cover,
Manual, Projection Software CDROM
TECHNOLOGY
Projection System RGB liquid crystal shutter projection system
LCD Panel 0.76-inch wide panel with MLA (D8, C2 Fine)
OPTICAL
Zoom 1 - 1.8 (Optical)
Screen Size 50"to 300"[1.35m to 8.36m] (Zoom: Wide)
50"to 300"[2.47m to 15.01m] (Zoom: Tele)
Projection Distance 100"screen 2.75m - 4.98m
Throw Ratio 1.26 (Zoom:Wide), 2.30 (Zoom:Tele)
Projection Lens F Number 1.65-2.55
Projection Lens Focal Length 21.28mm - 37.94mm
Focus Method Manual
Colour Light Output 5,500 Lumens
White Light Output 5,500 Lumens
Resolution WXGA
Native Aspect Ratio 16:10
Contrast Ratio 5,000:1
Lamp Hours 3,000 hours (Power Consumption: Normal (5)
4,000 hours (Power Consumption: ECO)
Lamp Type 380 W UHE
Keystone Correction Vertical: -30 to +30 degrees
Horizontal: -30 to +30 degrees
Lens Shift Vertical: -67% to +67%
Horizontal: -30% to +30%
Tilt Angle -1.50 to 10 degrees
* Compared to leading 1-chip DLP business and education projectors based on NPD data, July 2011
through June 2012. Colour brightness (colour light output) measured in accordance with IDMS 15.4.
Colour brightness will vary depending on usage conditions.
** Whichever comes first. For more information visit www.epson.com.au/warranty
Epson is the registered trademark of Seiko Epson Corporation. All other names and company names used herein are for identification purpose only and may
be the trademarks or registered trademarks of their respective owners. Epson disclaims any and all rights in those marks. All print samples shown herein are
simulations. Specifications are subject to change without notice.
