Important Information
Please read the following important information about your
projector.
Important Safety Information
Warning: N ever look into the projector lens when the lam p is
switched on as the bright light can dam age your eyes. N ever let
children look into the lens when it is on.
Warning: N ever open any covers on the projector except the
lamp and filter covers. Dangerous electrical voltages inside
the projector can cause severe injury. Except as specifically
directed in this Owner’s Manual, do not attempt to service
this product yourself. R efer all servicing to qualified service
personnel.
Warning: K eep the plastic bags for the projector, accessories
and optional parts out of the reach of children. Children
covering their heads with bags may result in death by
suffocation. Be particularly careful around small children.
Caution: When you replace the lamp, never touch the new
bulb with your bare hands. The invisible residue left by the oil
on your hands m ay be shorten the bulb life. Use a cloth or
gloves to handle the new bulb.

®
DATA/V IDEO PROJ ECTOR
Owner’s Manual
Downloaded from: http://www.usersmanualguide.com/

Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■ ■
■
iii
■ ■ ■ ■ ■ ■ ■ ■ ■
■
■
■
■
■
■
Contents
Contents iii
Introduction vii
Getting the Most Out of Your Projector ................................ ix
Optional Accessories...................................................................ix
About This Manual................................................................. x
Safety Instructions ................................................................. xi
Where to Get H elp .............................................................. xiii
World Wide Web site................................................................xiii
Transporting your projector...................................................... xiv
1 Installation 1
U npacking the Projector .........................................................2
Additional Components.............................................................. 3
Setting U p the Projector .........................................................4
Connecting to a Computer .....................................................6
Connecting to a PC Desktop Computer ..................................... 7
Connecting to a PC Laptop Computer ..................................... 10
Connecting to a Desktop Macintosh ......................................... 13
Connecting to a PowerBook..................................................... 17
Connecting to a Video Source ..............................................22
Connecting to an External Speaker or
PA System ............................................................................25
Downloaded from: http://www.usersmanualguide.com/

Contents
■ ■ ■ ■
iv
2 Using the Projector 27
Turning the Equipment O n and O ff .....................................29
Turning the Projector O n and O ff ............................................ 29
Focusing and Positioning the Screen Image ..........................31
Resize Button ........................................................................... 33
Controlling the Projector......................................................34
Using the Remote Control ....................................................... 35
Using the Operation Panel ....................................................... 38
Projector Status Indicators....................................................39
Operation Indicator.................................................................. 39
Lamp Indicator......................................................................... 39
Temperature Indicator.............................................................. 40
3 Using the Projector Menus 43
Accessing the Main Menu .....................................................44
Changing a Menu Setting .....................................................45
Menu Options......................................................................47
Video Menu (Image source = Computer) ................................. 47
Video Menu (Image source = Video) ........................................ 49
Audio Menu ............................................................................. 50
Effect Menu ............................................................................. 51
Setting Menu ........................................................................... 51
User's Logo Menu ................................................................... 52
Reset All Menu......................................................................... 54
Advanced Menu ....................................................................... 55
About Menu............................................................................. 56
4 Maintenance 57
Cleaning the Lens.................................................................58
Cleaning the Projector Case..................................................58
Cleaning the Air Filter ..........................................................59
Replacing the Lamp ..............................................................60
Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■ ■
■
v
5 Troubleshooting 63
Problems with the Projector..................................................64
Problems with the Image or Sound .......................................66
Technical Specifications 69
Supported Monitor Displays .................................................71
Computer In connector pin assignments ...............................73
Glossary 75
Index 77
World-Wide Warranty Terms 79
Downloaded from: http://www.usersmanualguide.com/

Contents
■ ■ ■ ■
vi
Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■ ■ ■ ■ ■ ■
■
■
■
■
■
■
■ ■ ■ ■ ■
■
vii
Introduction
Y our compact, lightweight EPSO N EMP-713/ 703/ 503
projector lets you project full-color images and video onto a
large screen for presentations. You can connect it
simultaneously to two image sources: one PC or Apple®
Macintosh® computer image source, plus one video source
such as a video tape deck, camcorder, or digital camera. You
can also connect audio for each image source.
Images are displayed in full color (16,670,000 colors) at a
XGA resolution of 1024 x 768 pixels (EMP-713/ 703) and
SVGA resolution of 800 x 600 pixels (EMP-503). Your
projector produces bright images that can be easily seen in
rooms light enough to take notes.
A totally new AVTSS™ (Automatic Video Tracking and
Synchronization Sensing, patent pending) provides automatic
set-up of image from a computer.
You control your projector through a hand-held remote
control unit, with menus being provided for image source
switching and image adjustment. The remote control can also
act as a wireless mouse to control mouse operations on your
computer screen during presentations.
Downloaded from: http://www.usersmanualguide.com/

Introduction
■ ■ ■ ■
viii
Your projector features the newest resizing technology D AR
(D igital Active Resizing) which supports VGA~U XGA
computer output (The EMP-503 does not support U XGA).
No matter what type of computer output is used, the result is
a full-size video image of outstanding clarity.
The video source can be NTSC, N TSC4.43, N TSC50, PAL
M-PAL, N-PAL, PAL60 or SECAM in composite video or S-
Video format. See Chapter 6 for details on supported
computers and video formats.
Downloaded from: http://www.usersmanualguide.com/

Getting the Most Out of Your Projector
■ ■ ■ ■ ■
■
ix
Getting the Most Out of Your Projector
Your projector comes with a full set of features that enable
you to control the settings for the image display, video and
audio. To get the most out of your projector, read this section
for a quick summary of the important features.
Optional Accessories
To enhance your use of the projector, EPSON provides the
following optional accessories:
•Image Presentation Camera ELPDC01
•Image Presentation Camera (XGA) ELPDC02
•Image Presentation Camera (PAL/ NTSC) ELPDC03
•Computer Cable ELPKC02
•VGA-H D 15 PC Cable (3.0m) ELPKC09
•VGA-H D 15 Extension Computer Cable
(20m) ELPKC10
•Soft Carrying Case (for PC) ELPKS16
•Soft Carrying Case ELPKS24
•Spare Lamp ELPLP14
•Portable Screen (50" ) ELPSC06
•60" Screen ELPSC07
•80" Screen ELPSC08
•Celling Mount (Silver)* ELPMB09
You can purchase these accessories from your dealer.
* A special technique is necessary to suspend the projector from the ceiling.
Please consult with your dealer if you are planing to suspend the projector from
the ceiling when you use it.
Downloaded from: http://www.usersmanualguide.com/

Introduction
■ ■ ■ ■
x
About This Manual
Chapter 1, “Installation”, gives step-by-step instructions on
how to set up the projector and connect it to your computer,
video source, or other external speaker or PA system. Read
the installation procedures that apply to your configuration.
Chapter 2, “U sing the Projector”, describes how to switch
the projector on/ off and control simple projector settings
using the remote control or the operation panel.
Chapter 3, “U sing the Menus”, describes how to use the
menus to adjust the color and image settings, change the
display of the projected image, and modify audio settings.
Chapter 4, “Maintenance”, describes how to clean your
projector and perform limited maintenance.
Chapter 5, “Troubleshooting”, describes how to interpret
your projector’s indicator lights and gives helpful information
for avoiding errors, optimizing image quality and solving
problems.
Chapter 6, “Technical Specifications,”lists the technical
specifications for your projector.
A Glossary and Index are provided at the end of the manual.
Downloaded from: http://www.usersmanualguide.com/

Safety Instructions
■ ■ ■ ■ ■
■
xi
Safety Instructions
Follow these safety instructions when setting up and using the
projector:
1. Do not place the projector on an unstable cart, stand, or
table.
2. Do not use the projector near water or sources of heat.
3. U se attachments only as recommended.
4. U se the type of power source indicated on the projector.
If you are not sure of the power available, consult your
dealer or local electricity company.
5. Place the projector near a wall outlet where the plug can
be easily unplugged.
6. Insert the projector’s three-pin grounding-type plug into
a properly grounded outlet. If you have a two-prong
outlet, contact an electrician to replace it. Do not handle
the plug with wet hands.
7. Take the following precautions when handling the plug.
Failure to comply with these precautions could result in
sparks or fire.
•Do not insert the plug into an outlet with dust present.
•Insert the plug firmly into the outlet.
8. Do not overload wall outlets, extension cords or integral
convenience receptacles. This can cause fire or electric
shock.
9. Do not place the projector where the cord can be stepped
on. It may result in fraying or damage to the plug.
10. U nplug the projector from the wall outlet before cleaning.
U se a damp cloth for cleaning. Do not use liquid or
aerosol cleaners.
Downloaded from: http://www.usersmanualguide.com/

Introduction
■ ■ ■ ■
xii
11. D o not block the slots and openings in the projector case.
They provide ventilation and prevent the projector from
overheating. Do not place the projector on a sofa, rug or
other soft surface, or in a closed-in cabinet unless proper
ventilation is provided.
12. N ever push objects of any kind through cabinet slots.
Never spill liquid of any kind into the projector.
13. Except as specifically explained in this U ser’s Guide, do
not attempt to service this product yourself. Refer all
servicing to qualified service personnel. O pening or
removing covers may expose you to dangerous voltages
and other hazards.
14. U nplug the projector during thunder storms or when it
will not be used for extended periods.
15. D o not place the projector and remote control on top of
heat-producing equipment or in a heated place, such as a
car.
16. U nplug the projector from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
•When the power cord or plug is damaged or frayed
•If liquid has been spilled into the projector, or it has
been exposed to rain or water
•If it does not operate normally when you follow the
operating instructions, or if it exhibits a distinct change
in performance, indicating a need for service
•If it has been dropped or the housing has been damaged
17. When you use the projector in other countries except from
where you purchased it, use the correct power cable
suitable for that country.
Downloaded from: http://www.usersmanualguide.com/

Where to Get Help
■ ■ ■ ■ ■
■
xiii
Where to Get Help
If you are having trouble setting up or running your
projector, first see Chapter 5, “Troubleshooting”. If you
cannot resolve the problem, contact the appropriate
representative listed in the section entitled “World -Wide
Warranty Terms”at the end of this manual.
Before you call, please have the following information ready:
•Product name
•Product serial number
•Computer configuration
•Description of the problem
World Wide Web site
If you connect to the Internet and have a Web browser, you
can access to EPSON’s World Wide Web site at http:/ / www.
epson. com. EPSO N’s home page provides you What’s New,
EPSO N Products, EPSO N Connection, Corporate Info and
EPSO N Contacts. Link to the EPSO N Connection for the
latest drivers and FAQ ’s (Frequently Asked Q uestions) and
the EPSO N Chart area. To get in touch with EPSO N around
the world, EPSO N Contacts includes Contact Information
for local EPSO N subsidiaries.
Downloaded from: http://www.usersmanualguide.com/

Introduction
■ ■ ■ ■
xiv
Transporting your projector
The projector contains many glass parts and precision parts. If
you need to transport it, please follow these packing
guidelines to prevent damaging the projector:
•When shipping the projector for repairs, use the original
packaging material.
If you don’t have the original packaging, use equivalent
materials, placing plenty of cushioning around the
projector.
•When transporting the projector for business use, first put
the projector in a hard carrying case, then pack it in a firm
box, using cushioning around the case.
♦Note: EPSON shall not be liable for any dam ages incurred
during transportation.
Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■
■ ■ ■ ■ ■
■
1
1
Installation
This chapter describes how to unpack and set up your
projector, and connect it to other equipment. The projector
must be connected to a computer or a video source such as a
video tape deck, camcorder, digital camera or laser disc player
before it can project any images.
You may also want to set up the projector for one or more of
the following:
•Connect the mouse cable to use the remote control as a
wireless mouse.
•Provide audio for one or both image sources. The audio
source can be the computer, video source, or another
device such as a stereo.
•Connect to an external speaker or PA system to amplify the
audio.
Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■
2
Unpacking the Projector
When you unpack the projector, make sure you have all these
components:
•Projector
•Remote control
•2 AA batteries
•Power cord
•Computer cable
•Audio/ Video cable (A/ V cable)
•PS/ 2 mouse cable
•U SB mouse cable
•O wner’s manual
•Softcase
Depending on the configuration of your equipment, you may
not need all these components.
Save all packaging materials in case you need to ship the
projector in the future. It should be transported in its original
packaging or the equivalent.
Downloaded from: http://www.usersmanualguide.com/

Unpacking the Projector
■ ■ ■ ■ ■
■
3
Additional Components
Depending on how you plan to use the projector, you may
need these additional components:
•To receive an S-Video signal, you need an S-Video cable.
(O ne is usually provided with your video device.) A
separate cable is required for each video source.
•To connect the projector to a Macintosh PowerBook, you
need a video-out cable.
(O ne is provided by/ or can be purchased from Apple for all
new PowerBooks that have video-out capability.) If your
PowerBook does not include one, see your Macintosh
dealer.
•To connect the mouse cable to your computer, you may
require a special connector, cable, or other components.
You can obtain these items from your computer dealer. If
your computer doesn’t have a mouse connector, you
cannot use the mouse cable.
♦Note: Y ou can connect a K ensington MicroSaver® anti-theft
device in the hole on the projector’s right side. Contact your
computer dealer.
Downloaded from: http://www.usersmanualguide.com/

■ ■ ■ ■
4
Setting Up the Projector
1. Place the projector on a sturdy, level surface within five
feet of the computer or video source.
♦Caution: Do not hold the projector by the lens. This can damage
the lens.
2. Place the projector at a correct distance from the screen.
The distance between the projector and the screen
determines the actual image size. U se the general
guidelines below to determine the correct distance.
3. Turn the projector so that the lens is at right angles to the
screen. If the projector is not angled correctly, the screen
image will be crooked.
4. Connect one end of the power cable to the projector’s
power connector. Connect the other end to an earthed
electrical socket.
The projector should be in sleep mode, indicated by an
orange power indicator.
♦Warning: N ever look into the lens when the projector is on.
There is a risk that the projector might come on suddenly even
though it is not in use. The light from the lam p can dam age your
eyes. It is especially im portant that children should not be
allowed to look into the lens.
Screen size Horizontal distance from projector to screen
300 inches (610x460cm) 450.7 inches (11.5m) ~ 546.3 inches (13.8m)
200 inches (410x300cm) 299.5 inches (7.7m) ~ 363.3 inches (9.2m)
150 inches (305x228cm) 223.9 inches (5.7m) ~ 271.7 inches (6.9m)
100 inches (200x150cm) 148.3 inches (3.8m) ~ 180.2 inches (4.5m)
80 inches (160x120cm) 118.1 inches (3.0m) ~ 143.6 inches (3.6m)
60 inches (120x90cm) 87.8 inches (2.3m) ~ 107.0 inches (2.7m)
40 inches (81x61cm) 57.6 inches (1.5m) ~ 70.4 inches (1.7m)
30 inches (61x46cm) 42.5 inches (1.1m) ~ 52.1 inches (1.3m)
26 inches (53x40cm) — ~ 44.7 inches (1.1m)
Downloaded from: http://www.usersmanualguide.com/
