Epson EB-955W Installation instructions

Epson EB-955W
The Affordable Solution for Corporate & Education
3 x Brighter Colours and reliable performance* – 3LCD, 3-Chip Technology.
Look for both high colour brightness and high white brightness
One measurement of brightness is not enough – look for both colour
brightness and white brightness. The Epson EB-955W has:
Colour Brightness: 3,000 lumens
White Brightness: 3,000 lumens
Premium quality and installation flexibility – WXGA resolution and a 1.6x
optical zoom for great images, wherever you choose to install the projector
Optional Wireless connection to your laptop and mobile device – connect
directly to your computer, smartphone or tablet, without wires (wireless
LAN not included)
Manage your projector and present remotely – easy network connectivity;
software included

Product Specifications
Epson EB-955W
CONNECTIVITY
Input: Video 1 x RCA (Yellow), 1 x S-Video, 2 x Component
(via D-sub 15-pin)
Input: Computer 2 x D-sub 15-Pin (RGB), 1 x USB 2.0 type B
Input: USB Memory Device 1 x USB 2.0 type A
Input: Digital 1 x HDMI
Input: Audio 1 x RCA (Red/White), 2 x Stereo mini jack
Input: Control 1 x USB 2.0 type B, RS232C
Input:EpsonUSBDocumentCamera 1 x USB 2.0 type B
Network I/O 1 x RJ45 (100Mbps)
Wireless Connectivity Optional (ELP-AP07)
Output: Video 1 x D-sub 15 pin (black moulding)
Output: Audio 1 x Stereo Mini Jack
Speaker Output 16W
ADVANCED FEATURES
EasyMP Network & Control Yes (with optional Wireless LAN Unit)
EasyMP Network Projection Yes (with optional Wireless LAN Unit)
PC Free Presentations Yes
USB Plug ‘n Play Yes
AV Mute Slide Yes
Instant Off Yes
Direct Power On/Off Yes
Security Kensington Lock,
Security cable hole
Password protect function
Colour Modes Dynamic, Presentation, Theatre, Photo, sRGB,
Blackboard, Whiteboard
GENERAL
Dimensions D x W x H 297 x 244 x 89 mm
Weight 2.7 kg
Lamp Warranty 12 months or 750 hours*
Projector Warranty 3 Years
Power Consumption: (Normal/Eco) Normal: 273W / Eco: 204W
Power Consumption: Standby 0.29W (communication off)
Noise Level Normal: 37dB / Eco: 29dB
PRODUCT NAME Epson EB-955W
PRODUCT CODE V11H582053
WHAT’S IN THE BOX
Power Cable, Remote Control + Batteries, User’s
Manual, 1.8m VGA Cable
TECHNOLOGY
Projection System Epson 3LCD, 3-chip technology
LCD Panel 0.59-inch without MLA (D7)
OPTICAL
Zoom 1 - 1.6 (Optical)
Screen Size 30" to 300" [0.84 to 8.4 m] (Zoom: Wide)
30" to 300" [1.36 to 13.9 m] (Zoom: Tele)
Projection Distance 60" screen 1.69 - 2.75 m
Throw Ratio 1.38 (Zoom: Wide), 2.24 (Zoom: Tele)
Projection Lens F Number 1.51-1.99
Projection Lens Focal Length 18.2 mm-29.2 mm
Focus Method Manual
Offset 10:00
Colour Light Output 3,000 Lumens
White Light Output 3,000 Lumens
Resolution WXGA
Native Aspect Ratio 16:10
Contrast Ratio 10,000:1
Lamp Hours Normal: 5,000 Hours / Eco: 6,000 Hours
Lamp Type 200 W UHE
Keystone Correction Vertical: -30 to +30 degrees
Horizontal: -30 to +30 degrees
*Whichever comes first
