EPSON EMP-505Specifications
Model
EMP-505
Projection SystemRGB Liquid Crystal Shutter Projection
System
Projection Method
Front / Rear / Ceiling Mount
SpecificationofMain Parts
LCD
Size
Driving Method
Pixel Number
Native Resolution
Aspect Ratio
Pixel Arrangement
Projection Lens
Type
F-number
Focal Length
Zoom Ratio
Lens cover
Lamp Type
Optical System
0.9 inches (x3)
Poly-Silicon TFTActiveMatrix
480000 dots
(800 x 600)x3
SVGA
4:3
Stripes
Manual : zoom / focus / retractable
2.0 to 2.2
35 to 42 mm
1.2
It’s attached bythe string
150WUHE
Dichroic Mirror Separation & PrismCombine
Method
Screen Size
(Projected Distance) 26to 300 inch (1.0 to 13.8m)
Keystone Correction Ratio
10 : 0 Fix
Brightness1100 ANSI
Lumens
ContrastRatio
400:1
Brightness Uniformity
85%
Color Reproductivity
Full Color(1,677 Million Colors)
Sound Output 1W Monaural
EffectiveScanning FrequencyRange
PixelClock
Horizontal
Vertical
13.5Mhzto 160Mhz
15KHz to 92KHz
50Hz to 85Hz
Adjustment Function
Projector / Remote Control
Tilt Angle
Keystone correction
Keystone / Brightness / Contrast/ Tint /
Soundetc.
0 to 15 Degrees
-15 to 0 to 15 Degrees
Analog RGB I/O
Display Performance
Native
Resize
Input Signal
Signal Type
Video Signal
800 x600 dots
1280x1024 / 1024x768 /640x480 dots
Separate Signal
Analog

Sync Signal
Audio Signal
Input Terminal
Video
Audio
Output Signal
Audio Signal
Output terminal
Audio (Plug-in, Then Speaker - Off)
Separation / Composite / Sync. on green
500m Vrms / 47Ω
Mini D-sub 15 pin
Stereo Mini Jack
0 - 500 VRMS / 600Ω
Stereo Mini Jack
(Common Video Audio Output)
Video I/O
Display Performance
Input Signal
Video Standard
Video Signal
Audio Signal
Input Terminal
Video
Audio
Output Signal
Audio Signal
Output Terminal
Audio
600 TV Line
NTSC / NTSC4.43 / NTSC 50 / PAL / M-PAL /
N-PAL / PAL60 / SECAM
Composite Video / S-video / Component
Video / Video RGB
500m Vrms / 47kΩ
RCA x1 / S-video x 1 / Mini D-sub
RCAx2
0 – 500m Vrms / 600Ω
Stereo Mini Jack (Common Analog RGB Audio
Output)
(Plug-in, Then Speaker-Off)
Control I/O
I/O Terminal
Mouse / Serial I/O
Mouse compatibility
Din 9 pin x 1 / USB type B x 1
PS/2, ADB, USB
Operating Temperature 5°C to 35°C (4°to 95°F)
Power Supply Voltage 100-120V / 200-240V AC ±10%, 50 / 60Hz
AC
Power Consumption 100/120V 1.9A 50/60Hz / 200-240V 1A 50/60
Hz
Dimension
Exclude Projection Lens & Feet
Maximum Dimensions
267 (W) x 72 (H) x 213 (D) mm
267 (W) x 87 (H) x 213 (D) mm
Weight 6.0lbs / 2.7kg
Fan Noise 42db

Accessories Power cable (2.7m),
Computer Cable (1.8m : Mini D-Sub 15pin
(Male),
Video/Audio Cable (1.8m),
White, Red, Yellow : RCA (Male) to RCA
(Male),
Remote Control,
Communication Cable Set (PS/2 Mouse cable,
USB Mouse Cable),
Battery (AA x 2),
User’s Manual,
Soft Cover,
Quick Reference Card
EasyMP
(Applicable to EMP-505 and EMP-715 only)
Interface
PCMCIA
Supported Device
Accessories
Type I/II x 1
Compact Flash / Smart Media / Memory Stick /
3.3 Volts type ATA Flash Card / 5 Volts Type
ATA Flash Card / Micro Drive
SlideMaker CD-Rom / PCMCIA Adapter /
8MB Compact Flash Memory with Demo data /
Dummy PCMCIA Card / PCMCIA Slot Cover
