Epson EMP-713 User manual

Printed on October 2001
EMP-503
EMP-713
Multimedia Projector
The Perfect Team for the Perfect Presentation
Better Presentations with EPSON
All other product names and other company names herein are for identification purpose only and maybe the trademarks or
registered trademarks of their respective owners. EPSON disclaims any and all rights in those marks. Specifications are subject
to change without notice.
INDIA
EPSON India Pvt Ltd
Tel: [phone] Fax: [phone]
www.epson.co.in
INDONESIA
PT EPSON Indonesia
Tel: [phone] Fax : [phone]
MALAYSIA
EPSON Trading (M) Sdn Bhd
Tel: [phone] Fax: [phone]
www.epson.com.my
PHILIPPINES
EPSON Philippines Corporation
Tel: [phone] Fax: [phone]
www.epson.com.ph
SINGAPORE
EPSON Singapore Pte Ltd.
Tel: [phone] Fax: [phone]
www.epson.com.sg
THAILAND / INDO-CHINA
EPSON (Thailand) Co., Ltd
Tel: [phone] Fax: [phone]
www.epson.co.th
CONNECTOR PANEL
OPTION AND PERIPHERAL
DEALER’SSTAMP:
• Replacement Lamp
ELPLP14
Part no: V13H010L14
• Soft Carrying Case
ELPKS16 Projector/
PC Bag
Part no: V12H001K16
• ELPKS24
Projector Bag
Part no: V12H001K24
SPECIFICATIONS of EMP-713
Model EMP-713
Part Number V11H057052
Projection System RGB Liquid Crystal Shutter Projection System
Projection Method Front / Rear / Ceiling Mount
Specification Of Main Parts
LCD
Size 0.9 inches with MLA (x3)
Driving Method Poly-Silicon TFT Active Matrix
Pixel Number 786,432 Dots (1024x768)x3
Native Resolution XGA
Aspect Ratio 4:3
Pixel Arrangement Stripes
Projection Lens
Type Manual: Zoom /Focus /Retractable
F-number 2.0 - 2.2
Focal Length 35 - 42mm
Zoom Ratio 1.2
Lens cover It’s attached by the string
Lamp
Type 150W UHE
Optical System Dichroic Mirror Separation & Prism Combine Method
Screen Size ( Projected Distance ) 26 to 300inch (1.0 to 13.8m)
Keystone Correction Ratio 10: 0 Fix
Brightness 1200 ANSI lumens
Contrast 400:1
Brightness Uniformity 85%
Color Reproductivity Full Color (1677 Million Colors)
Sound Output 1W Monoaural
Effective Scanning Frequency Range
Pixel Clock 13.5Mhz to 162Mhz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 96Hz
Adjustment Function
Projector / Remote Control Keystone / Brightness / Contrast / Tint / Sound Etc.
Tilt Angle 0 to15 Degrees
Keystone -15 to 0 to 15 degrees
Analog RGB I/0
Display Performance
Native 1024 x 768 dots
Resize:EMP-713 1600x1200/1280x1024/800x600/640x480 dots
Input
Signal Type Separate Signal
Video Signal Analog
Sync. Signal Separation / Composite /sync. on green
Audio Signal 500Vrms / 47Ω
Input Terminal
Video Mini D-sub 15 pin
Audio Stereo Mini Jack
Output Signal
Audio Signal 0- 500 VRMS / 600Ω
Output Terminal
Audio Stereo Mini Jack (Common Video Audio Output)
(Plug-in, Then Speaker - Off )
Video I/0
Display Performance NTSC: 550 Line PAL: 550 Line
Input Signal
Video Standard NTSC/NTSC4.43/NTSC 50/PAL/M-PAL/N-PAL/PAL60/SECAM
Video Signal Composite Video/S-Video/Video RGB
Audio Signal
Input Terminal
Video RCA x 1 / S- Video x 1 / Mini D-Sub 15 pin
Audio RCA x 2
Output Signal
Audio Signal 0 - 500 M Vrms / 600Ω
Output Terminal
Audio Stereo Mini Jack ( Common Ananlog RGB Audio Output )
( Plug-in, Then Speaker-Off )
Control I/O
I/O Terminal
Mouse / Serial IO Din 9 Pin x 1 / USB type B x1
Mouse Compatibility PS / 2, ADB, USB
Operating Temperature 5°C To 35°( 41°TO 95°F )
Power Supply Voltage 100-120V /200-240 ±10%, 50 / 60Hz AC
Power Consumption 100-120V 1.9A 50 / 60Hz / 200-240V 1A 50 / 60Hz
Dimension
Exclude Projection Lens & Feet 267 ( W ) x 72 (H ) x 213 ( D ) mm
Maximum Dimensions 267 ( W ) x 87 ( H ) x 213 ( D ) mm
Weight 5.8lbs/2.6kg
Fan Noise 42db
Accessories Power Cable (2.7m), Computer Cable (1.8m: Mini D-Sub, 15 Pin (Male), Video/
Audio Cable (1.8m): White, Red,Yellow: RCA (Male) to RCA (Male), Remote
Control, Communication, Cable Set (PS/2 Mouse Cable, USB Mouse Cable),
Battery (AA x 2), User’s Manual, Soft Cover.
