EX7220 WXGA 3LCD Projector
1
The wireless, widescreen projector
with proven performance.
3x Brighter Colors
1, and reliable performance — 3LCD, 3-chip technology
One measurement of brightness is not enough — look for both high color brightness and high
white brightness. The EX7220 has:
Color Brightness — 3000 lumens
2
White Brightness — 3000 lumens
2
Larger-than-life, widescreen images — high-definition WXGA (1280 x 800) resolution and 16:10
aspect ratio; ideal for HD content
Wireless connection to your laptop and mobile device — connect directly to your computer,
smartphone or tablet, without wires (wireless LAN module included)
Audio/video with just one cable — all-digital HDMI™connection
Simple Setup Suite — Epson offers a host of innovative features that ensure flexible placement
and quick setup in any room

EX7220 WXGA 3LCD Projector
The best-selling projectors in the world.
Built with image quality and reliability in mind, Epson projectors enhance communication and
inspire collaboration, while offering a low total cost of ownership. From ultra portable projectors
designed for educational settings to boardroom-ready business projectors, Epson has a model
that’s perfect for you.
The wireless, widescreen projector with proven performance.
The EX7220 makes it easy to present compelling, larger-than-life presentations from virtually any device. Offering 3x Brighter
Colors1than competitive models, Epson®3LCD projectors ensure bright, vivid images. With 3000 lumens of color brightness
and 3000 lumens of white brightness2, the EX7220 features the ultimate in widescreen HD performance. Plus, it offers a fast
wireless connection to your laptop, smartphone and tablet. Thanks to HDMI connectivity, it delivers digital video and audio
with just one cable. And, Epson’s Simple Setup Suite enables easy setup in nearly any venue. It’s the perfect solution for
professionals like you whose presentations demand proven performance.
3x Brighter Colors with Epson
1
Brilliant image quality requires high color
brightness (color light output), and Epson 3LCD
projectors have 3x Brighter Colors than leading
competitive projectors
1.
One brightness measurement (lumens) is not
enough. A projector’s specification needs to
show both high color brightness and high white
brightness. If color brightness is lower than
white brightness, images may be dark, dull and
lose detail. If not provided, be sure to ask for a
projector’s color brightness specification.
COLOR
BRIGHTNESS2
LUMENS
3000
WHITE
BRIGHTNESS2
LUMENS
3000
COLOR
BRIGHTNESS2
LUMENS
3000
WHITE
BRIGHTNESS2
LUMENS
3000
1
1
Energy-efficient long-life lamp
• Deliversmorelumensperwattandlastsupto
6000 hours
5
• Epsonlampsmaximizeyourpresentationtime,while
minimizingyourcosts
3LCD — The #1 projection
technology in the world
• All3LCDprojectorshavebothhigh
color brightness and high white
brightness
• All3LCDprojectorshave3chips
• 25%lowerpowerconsumption
for lower energy costs
3
• 20yearsofroad-testedreliability
Actual photographs of projected images from an identical signal source. Price,
resolution and white brightness are similar for both projectors (Epson 3LCD and
1-chip DLP competitor). Both projectors are set to their brightest mode.
High color brightness and high white brightness
EPSON
Color brightness signicantly lower than white brightness
COMPETITOR
Wireless connection
(wireless LAN module included)
Convenient wireless features built in:
• Connectwirelesslytoacomputerorlaptop
(direct peer-to-peer connection)
• Connectwirelesslytoanetwork
• Makeapresentationormonitor/controlyourprojector
over the wireless network

Additional Features/Benefits
• PC-freeslideshows— via a USB thumb drive
• The ultimate in portability — compact, lightweight
design; carrying case included for easy transfer to and from
the ofce
• Filters to protect your investment — with easy side
access for hassle-free maintenance
• Remote control and batteries included — for easy
access to multiple functions
The more the pixels, the better the
image quality
Resolution denes the level of detail and depth you’ll see in a
projected image. It’s measured as the number of pixels wide
by the number of pixels high.
For more information on Epson’s environmental
programs, go to eco.epson.com
• RoHScompliant
• Recyclableproduct
8
• EpsonAmerica,Inc.isa
SmartWay
SM Transport Partner 9
Eco Features
Simple Setup Suite from Epson
Epson projectors offer a host of innovative features that ensure
flexible placement and fast, easy setup.
Easy image adjustments — Position your projector
almost anywhere and still get a correctly proportioned image
withautoverticalcorrectionandEasy-slidehorizontal
image correction.
USB Plug ‘n Play instant setup — Use the included
USB cable to instantly project content. View your
projected presentation on the screen and your
computer simultaneously.
Convenient lens control—Optimizetheimagesize
whether your projector is close to the screen or far away
withthezoomlens.
HDMI connectivity — Get both audio and brilliant HD
video content with just one cable. The EX7220 is
compatible with the latest laptops, Blu-ray Disc®and
media players.
Quick, convenient control — The EX7220 includes:
• InstantOff®— quickly power down the projector,
pack up and go
• SleepMode(A/VMute)—pauseyourpresentation
without turning the projector off
• DirectPowerOff/On—controlyourprojectorwiththe
flip of a switch
SVGA (800 x 600)
Meets basic projection needs
XGA (1024 x 768)
Ensures sharper detail
1.5x more
resolution than SVGA
2x more
resolution than SVGA
WXGA (1280 x 800)
Offers high definition and is ideal for
widescreen (16:10) displays
Travel light and present from your tablet
or smartphone
Display and control content from your iOS®or Android™6mobile
device with the free Epson iProjection™ App and any nearby
wireless Epson projector
7.
• Controlyourpresentationwithjustatouchofthescreen
• AdvancethroughPowerPoint®or Apple®Keynote®
presentations
• ZoominandoutofPDF,Excel®and Word documents
• Projectwebpagesandviewbrilliant,high-qualityimages

EX7220 WXGA 3LCD Projector
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada Limited
185 Renfrew Drive, Markham, Ontario L3R 6G3
www.epson.com
www.epson.ca
1 Compared to leading 1-chip DLP business and education projectors based on NPD data, July 2011 through June 2012. Color brightness (color light output) measured in accordance with IDMS 15.4.
Color brightness will vary depending on usage conditions.
2 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured
in accordance with ISO 21118.
3 Data source: ProjectorCentral.com Jan. 2013. Average of 1128 shipping models for which the manufacturers provided lumens and total power data, all resolutions and brightness levels. Energy efficiency
was measured as wattage per lumen. It was measured for both 3LCD and 1-chip projectors in each of five brightness segments. 3LCD projectors averaged less required electricity per lumen in each of the
five segments.
4 Leading 3LCD and 1-chip DLP business and education projectors selected according to NPD data as of July 2013. Independent U.S. research conducted by Radius Research (July 2013); results confirmed
at a 99% confidence level.
5 ECO Mode is up to 6000 hours. Normal Mode is up to 5000 hours. Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
6 Android does not currently support Microsoft®Office and Keynote for Mac files.
7 Check your owner’s manual to determine if a separate wireless LAN module must be purchased separately to enable wireless connection on your Epson projector. Epson projectors can be networked either
through the Ethernet port on the projector (check model specifications for availability) or via a wireless connection.Not all Epson projectors are able to be networked. Availability varies depending on model.
8 See our website for convenient and reasonable recycling options at www.epson.com/recycle
9 SmartWay is an innovative partnership of the U.S. Environmental Protection Agency that reduces greenhouse gases and other air pollutants and improves fuel efficiency.
Specifications and terms are subject to change without notice. EPSON and Instant Off are registered trademarks, EPSON Exceed Your Vision is a registered logomark and Better Products for a Better Future
and Epson iProjection are trademarks of Seiko Epson Corporation. PrivateLine is a registered trademark, Duet is a trademark and Epson Connection is a service mark of Epson America, Inc. Android is a
trademark of Google Inc. Mac is trademark of Apple Inc., registered in the U.S. and other countries. Wi-Fi is a registered trademark of the Wi-Fi Alliance. SmartWay is a service mark of the U.S. Environmental
Protection Agency. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2014 Epson
America, Inc. CPD-40425R2 1/14
EX7220 WXGA 3LCD Projector
Product Name Product Code UPC
EX7220 (U.S.) V11H550020 0 10343 90859 8
EX7220 (Canada) V11H550020-F 0 10343 90850 5
Genuine Epson Lamp V13H010L78 0 10343 90969 4
Replacement Air Filter V13H134A32 0 10343 88586 8
Specifications
Projection System
3LCD, 3-chip technology
Projection Method
Front/rear/ceiling mount
Driving Method
Poly-silicon TFT Active Matrix
Pixel Number
1,024,000 dots (1280 x 800) x 3
Color Brightness
2
Color Light Output: 3000 lumens
White Brightness
2
White Light Output: 3000 lumens
Aspect Ratio
16:10
Native Resolution
1280 x 800 (WXGA)
Resize Support
640 x 480 (VGA), 1024 x 768 (XGA),
1152 x 864 (SXGA), 1440 x 900 (WSXGA),
1400 x 1050 (SXGA+)
Lamp Type
200 W UHE
Lamp Life
5
Up to 6000 hours (ECO Mode)
Up to 5000 hours (Normal Mode)
Throw Ratio Range
1.30 – 1.56
Size (projected distance)
33" – 318" (0.9 – 9.0 m)
Keystone Correction Auto
Vertical: ± 30 degrees
Keystone Correction Manual
Horizontal ± 30 degrees
USB Plug ‘n Play
Projects audio and video
PC and Mac
®compatible
Contrast Ratio
Up to 10,000:1
Color Reproduction
Up to 1 billion colors
Projection Lens
Type
Manual zoom/Manual focus
F-number
1.58 – 1.72
Focal Length
16.9 – 20.28 mm
Zoom Ratio
Digital zoom 1.0 – 1.2
Other
Display Performance
NTSC: 480 lines
PAL: 560 lines
(Depends on observation of the
multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAM
Interfaces
HDMI x1
Computer/component video: D-sub 15 pin x 1
S-video: Mini DIN x 1
Composite video: RCA (Yellow) x 1
Audio in: RCA x 1 (White/Red)
USB connector Type A x 1: Wi-Fi®, PC-free USB
and DC-06 document camera
USB connector Type B x 1: USB Plug ‘n Play
Speaker
2 W (mono)
Other (continued)
Operating Temperature
41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz
Power Consumption
283 W (Normal Mode)
207 W (ECO Mode)
Fan Noise
37 dB (Normal Mode)
29 dB (ECO Mode)
Security
Kensington®-style lock provision
Password protect function
Dimensions (W x D x H)
Including feet: 11.6" x 9.0" x 3.1"
Excluding feet: 11.6" x 9.0" x 3.0"
Weight: 5.29 lb
Remote Control
Features
Source search selection, power, volume,
e-zoom, A/V mute, freeze, menu, page up and
down, help, auto, mouse functions
Operating Angle
Right/left: ± 30 degrees
Upper/lower: ± 15 degrees
Operating Distance
19 ft (6 m)
Support
The Epson Connection
SM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Service Programs
One-year projector limited warranty, Epson Road
Service program, PrivateLine®dedicated toll-
free support and 90-day limited lamp warranty
What’s In The Box
EX7220 projector, power cable, computer cable
(VGA), USB cable, soft carrying case, projector
remote control, batteries, user manual CD, Quick
Setup Sheet, wireless LAN module
Accessory Part Numbers
Universal projector ceiling mount ELPMBPJF
Component to VGA video cable ELPKC19
Soft shoulder case for projector
and laptop ELPKS16B
Duet™ screen ELPSC80
ES1000 screen V12H002S4Y
ES3000 screen V12H002S3Y
Epson DC-06 USB document
camera ELPDC06
Kensington security lock ELPSL01
Wireless LAN module ELPAP07
Computer/Component Video
Power
Composite Video
Audio
HDMI
S-video
USB-B
USB-A
