Epson 6100i - PowerLite XGA LCD Projector User manual

Ultra bright 3500 ANSI lumens for presentations in
any setting
• Brilliant presentations, whether the projector’s installed in a
lecture hall or transported from one classroom to the next
• Weighs just 15.4 lb
Superior image quality and performance
• Epson 3LCD technology for natural color and bright, vibrant images
• Solid state optical engine — works without a moving color wheel
• Accurate color registration — rainbow-free for crisp detailed
video and data images
• XGA (1024 x 768) resolution for vivid images with precision
color and detail
Installation features that make your life easier
• +/- 30˚ keystone correction and 1.6x optical zoom for greater
positioning flexibility without distortion
• Direct Power On and Off — power mounted projectors on and
off with one system switch
• Conveniently placed lamp and air filter access, designed for easy,
affordable changes, even when the projector is ceiling-mounted
• Sleek cable cover for unobtrusive installation applications
Easy setup and operation
• Closed captioning capabilities for the hearing impaired –
no external decoder box required
• High efficiency air filter and optional smoke filter — works with the
wind velocity sensor to alert you when the filter needs cleaning
• Dust resistant design to protect the optics
• Multi-screen color adjustment capabilities
• Innovative Instant Off™feature — just turn off the projector
and unplug it immediately
• On-screen keypad so there’s no need to toggle through the
entire alphabet
• Monitor out capability to display images on a monitor and
screen simultaneously
• Anchoring bar (underneath the projector) that accommodates
a security cable and helps deter theft
• High-altitude fan mode to quickly cool the projector, for
applicable locations
Local networking capabilities
• Easy network management with convenient monitoring and
control capabilities using EMP Monitor
- Displays and sorts projectors on the network
- Displays temperature levels, filter status, lamp status,
scheduling and more
• Convenient Web functionality with improved EasyManagement
– Makes it easy to verify projector status through a PC browser
– Allows you to restrict access or change certain settings
including A/V mute, power on/off and more
– Includes PJLink capabilities for simple setup with any system
• E-mail notification system — sends alerts to your PC, PDA or
mobile phone (up to three addresses at one time) SMTP
• SNMP plug-in available
Great audio and connectivity options
• 5 video inputs with individual audio for each — offers greater
flexibility when the projector is ceiling mounted
• Powerful 5W audio included
Outstanding Epson service and support
(two-year limited warranty)
• 90-day lamp warranty for added dependability
• Epson Road Service Program — provides a replacement projector,
typically within 1 business day
• Epson PrivateLine®dedicated toll-free support line available from
6 a.m. to 6 p.m. PST Monday – Friday
(Calls are answered live, typically in under a minute.)
• International warranty in over 45 countries
Epson PowerLite®6100i
The bright, closed captioning performer.
Front View zoom lens adjustable
foot
high performance,
low profile
full-featured
IR remote control
focus ring
RJ45
RS-232C
computer/component video
audio in
composite video
s-video
monitor out
audio out
audio in
Back View
audio in

Ultra bright 3500 ANSI lum
any setting
• Brilliant presentations, whether
lecture hall or transported from
• Weighs just 15.4 lb
Superior image quality and
• Epson 3LCD technology for nat
• Solid state optical engine — w
• Accurate color registration — r
video and data images
• XGA (1024 x 768) resolution fo
color and detail
Installation features that m
• +/- 30˚ keystone correction and
positioning flexibility without d
• Direct Power On and Off — po
off with one system switch
• Conveniently placed lamp and
affordable changes, even when
• Sleek cable cover for unobtrusi
Easy setup and operation
• Closed captioning capabilities f
no external decoder box requir
• High efficiency air filter and opt
wind velocity sensor to alert you
• Dust resistant design to protec
• Multi-screen color adjustment
• Innovative Instant Off™feature
and unplug it immediately
• On-screen keypad so there’s no
entire alphabet
• Monitor out capability to displa
screen simultaneously
• Anchoring bar (underneath the
a security cable and helps dete
• High-altitude fan mode to quic
applicable locations
Local networking capabilit
• Easy network management wit
control capabilities using EMP
- Displays and sorts projectors
- Displays temperature levels, f
scheduling and more
Projection System Epson 3LCD technology
Projection Method Front/rear/ceiling mount
LCD
Driving method Epson Poly-silicon TFT Active Matrix
Pixel number 786,432 dots x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9)
Pixel arrangement Cross stripe
Projection Lens
Type Manual focus
F-number 1.75 - 2.42
Focal length 24 - 38.2 mm
Zoom ratio Optical zoom 1.6
Lamp
Type 230 W UHE
Life* 2500 H
(High Brightness), 3000 H (Low Brightness)
Screen Size (projected distance) 30" – 300" (2.7 – 48.2')
Keystone Correction Vertical: ±30 degrees
Brightness (high brightness mode) 3500 ANSI lumens
Contrast Ratio (high brightness, game mode) 500:1
Brightness Uniformity (typical) 90%
Color Reproduction 16.7 mil
Audio Output 5 W Monaural
Operating Temperature 32º – 104ºF (0º – 40ºC)
Power Supply Voltage 100-240 V ±10%, 50/60 Hz AC
Power Consumption 330 W, 10 W standby
Dimensions
Excludes lens and feet 13.4" x 18.3" x 5.7"
(with cable cover) 17.9" x 18.3" x 5.7"
Includes lens and feet 13.4" x 18.3" x 6.3"
(with cable cover) 17.9" x 18.3" x 6.3"
Weight 15.4 lb/7 kg
Fan Noise
High Brightness w/standard filter 39 db
(with an optional smoke filter) 43 db
Low Brightness w/standard filter 33 db
(with an optional smoke filter) 40 db
Effective Scanning Frequency Range
Pixel clock 13.5 MHz to 162 MHz
Horizontal 15 KHz to 99 KHz
Vertical 50 Hz to 120 Hz
Remote Control
Features Source selection, power, resize, color mode,
volume, e-zoom, A/V mute, freeze, menu,
page up and down, mouse functions, help, auto
Operating angle Right/left ± 30 degrees
Upper/lower ± 15 degrees
Operating distance 19.7 ft (6 m)
RGB
Analog RGB I/O
Display performance
Native 1024 x 768
Resize 640 x 480
800 x 600
1280 x 1024
Input terminal
Video Mini D-sub 15 pin x 2
Audio RCA x 2
Output terminal
Video Mini D-sub 15 pin (monitor out) x 1
Audio RCA x 1
Video I/O
Display performance NTSC: 560 line
PAL: 560 line
(depends on observation of the
multi burst pattern)
Input signal NTSC/NTSC4.43/PAL/M-PAL/
N-PAL/PAL60/SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite video: RCA x 1
S-Video: Mini DIN x 1
Component video: Mini D-sub 15 pin x 1
(in common with Analog RGB connector)
Video-RGB: Mini D-sub 15 pin (in common
with Analog RGB connector)
Audio RCA x 1 (in common with Analog RGB
Audio terminal)
Audio signal 500m Vrms/47 Kohm
Control I/O
I/O terminal I/O signal RS-232C x 1,
Network interface LAN (RJ45) x 1
Security Kensington-style lock provision
Warranty
Two-year limited warranty, 90-day lamp warranty, Epson Road Service
Program and Epson PrivateLine dedicated toll-free support
(U.S. and Canada only)
Contents
Power cable, computer cable, projector remote control, batteries, cable cover,
CD-ROM, Quick Setup Sheet, User's Manual, PrivateLine support card,
password protection sticker
Product/Accessory Part Numbers
Epson PowerLite 6100i projector V11H243020
Replacement lamp V13H010L37
High efficiency air filter (standard) V13H134A11
Smoke filter (optional) V13H134A12
Universal ceiling mount ELPMBUNI
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Adjustable ceiling channel (ceiling plate not included or required) ELPMBACC
Ceiling mount secure cable kit ELPMBSEC
Distribution amplifier ELPDA01
Component video cable ELPKC19
S-Video cable ELPSV01
50" portable screen (4:3 aspect ratio) ELPSC06
60" portable pop-up screen (4:3 aspect ratio) ELPSC07
80" portable pop-up screen (4:3 aspect ratio) ELPSC08
83.6" classroom style pull-down screen (4:3 aspect ratio) ELPSC09
Image Presentation Camera (ELPDC05) V12H162020
Kensington security lock ELPSL01
Support — The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
Epson PowerLite 6100i Specifications
Specifications and terms are subject to change without notice. Epson is a registered trademark and Exceed Your Vision and Instant Off are trademarks of Seiko Epson Corporation.
PowerLite and PrivateLine are registered trademarks and Epson Connection and Epson PresentersOnline are service marks of Epson America, Inc. All other product and brand names are
trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2006 Epson America, Inc. CPD-21903 7/06 10K
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Printed on Recycled Paper
* Lamp life results will vary depending upon mode selected, environmental conditions, and
usage. Lamp brightness decreases over time.
