SM
high
performance,
low profile
Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 0.7 inches
Driving Method EPSON Poly-Silicon TFT Active Matrix
Pixel Number 786,432 dots (1024 x 768) x 3
Native Resolution XGA
Aspect Ratio 4:3 (supports 16:9, 5:4)
Pixel Arrangement Stripe
Projection Lens
Type Manual focus
F-number 1.5
f-number 26.3mm
Zoom ratio Digital (1.0-1.2); lens at max size,
zoom reduces up to 83%
Lamp
Type 150W UHE
Life (typical) 1500H
(Approx. 5 years, based on
6 hours/week x 50 weeks/year)
Screen Width Ratio: (distance/width) 1.77 to 2.13:1
Screen Size (projected distance) 28" to 300" (1.0m to 11.0m)
Keystone Correction ±15 degrees
Brightness (typical) 700 ANSI lumens
Contrast Ratio 400:1
Brightness Uniformity (typical) 88%
Color Reproduction 24 bit; 16.7 mil
Sound Output 1W monoaural
Operating Temperature 41ºF to 95ºF (5ºC to 35ºC)
Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC
Power Consumption 230W/8.6W @ stand by mode
Dimension 9.1"D x 11.9"W x 3.9"H
Weight 6.8 lbs/3.1 kg
Fan Noise 42db
Effective Scanning Frequency Range
Pixel Clock 13.5MHz to 162MHz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 85Hz
Remote Control Features
Keystone, special effects, source selection, power, e-zoom, right/left mouse,
click, volume
RGB Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1280 x 768
800 x 600
640 x 480
Input terminal
Video Mini D-sub 15pin
Audio Stereo mini jack (RGB)
RCA x2 (YUV)
Output terminal
Audio Stereo mini jack
(common video audio output)
(plug in, then speaker off)
Video I/O
Display performance 750 TV Line
Input signal NTSC/NTSC4.43/
PAL/M-PAL/N-PAL/PAL60/SECAM
Input terminal
Video RCA x 1; S-video x 1
Audio RCA x 2
Output signal 0 - 500 Vrms/600 ohm
Output terminal Stereo mini jack
(Common analog RGB audio output)
(Plug in, then speaker off)
Control I/O
Mouse/Serial I/O
I/O terminal Din 9pin x 1/USB type B x 1
Mouse compatibility PS/2, ADB, USB
Security Kensington-style lock provision
Warranty
Standard two year limited warranty, international warranty, 90-day lamp
warranty, EPSON Road Service Program and EPSON PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cable, remote control, 2 AA batteries, computer cable HD15/HD15
video/audio cable, PS/2 mouse cable, USB mouse cable, Start Here kit,
standard carrying case
Product/Accessory Part Numbers
EPSON PowerLite 70c Projector EMP-70
Replacement lamp ELPLP13
ATA shipping case ELPKS37
ATA molded hard shell shipping case ELPKS36
Samsonite wheeled soft case ELPKS35
Laptop/projector carrying case ELPKS13
Ceiling mount ELPMB35
Component video cable ELPKC19
Mac adapter set ELPAP01
Presentation Audio System ELPPAS1
Wireless microphone system ELPCVS1
50" portable screen ELPSC06
60" insta-theatre screen ELPSC07
80" insta-theatre screen ELPSC08
Kensington security lock ELPSL01
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
If you're looking for an exceptional value, the 6.8 lb
EPSON PowerLite 70c offers superior image quality and a
comprehensive feature set–all at a price that's sure to please. With
700 lumens and native XGA resolution, it's designed to meet all your
presentation needs, delivering both powerand portability without
sacrificing performance.
Youalready know Epsonfor our world class image quality printers.
And, you've probably used our innovative LCD technology in cell
phones, PDAs, and camcorders. Whatyou might not know is that we
are also the world leader inLCD projector technology. Our three-LCD
designproduces superior color saturation across the screen, while
ensuring cool operation, even after many hours of use.
Built with a variety of user-friendly features, the EPSON PowerLite 70c
gives you the flexibility toconductany presentation with confidence
and ease. Its simple 4-buttoncontrol panel is ideal for both novice users
and seasoned professionals, andincludes a context-sensitive help
feature. Use its 15° digital keystone correction to correct the angle,
aspect ratio and shape of projectedimages. A digital zoom lens and
full-featured remote control are also included in this powerful,yet
economical, superportable projector.
700 lumens; weighs just 6.8 lb
• Incredible brightness from a travel-friendly,
ultraportable projector
Superior detail and razor-sharp contrast
•Three EPSON 0.7" high aperture LCDs for rich color saturation
across the screen
• 150W UHE lamp
•400:1 contrast ratio for blacker blacks and whiter whites
•XGA (1024 x 768) resolution for sharp, vivid detail
State-of-the-art video performance
•Digital comb filter for extraordinary video clarity,
reduced noise and improved contrast
• Component video input capability
(optional cable required)
• HDTV-ready, supports 480i, 480p, 720p,
and 1080i formats (optional cable required)
Easy installation, setup and operation
•Start Here Kit gets first time users projecting in just minutes
• 15° digital keystone correction ensures distortion-free images
• Simplified 4-button control panel
•EPSON SizeWiseTM resizing technology supports virtually any
computer (Mac or PC) up to SXGA (1280 x 1024)
•Easy-to-use remote control with right/left mouse emulation,
a pointer, and three special effects (the stamp, horizontal bar,
and marker)
•USB mouse with hot swap capability
•Digital zoom: scaling range of 100% to 83%
• Standard carrying case included
•Cable lock feature for security conscious environments
Renowned EPSON service and support
• Comprehensive 2-year warranty
•90-day bulb warranty for added dependability
•EPSON PrivateLineSM dedicated toll-free support line available
from 6 a.m. to 6 p.m. PST Monday - Friday. This program is free
for the duration of the warranty
•EPSON Road Service Program provides a replacement projector,
typically within 24 hours. This program is free for the duration
of the warranty
•International warranty in over 45 countries, offered exclusively
by EPSON
CYAN
MAGENTA
YELLOW
BLACK
PANTONE 519 CV
PANTONE 5483 CV
EPSONPowerLite70cSpecifications
EPSONPowerLite®70c
A brilliantvalueinultraportableprojectors
Specifications and terms are subject to change without notice. EPSON is a registered trademark of SeikoEpson Corporation. PowerLite is a registered trademark, SizeWise is a trademark and Epson Connection,
PrivateLine and Presenters Online are service marks of Epson America, Inc. All other productand brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all
rights in these marks. © Copyright 2001 Epson America, Inc. CPD-11614 50K 2/01 LG Printed on Recycled Paper
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
EPSON®
full-featured
IR remote control
stylish metallic
silver finish
Front View
Back View
HD 15 computer
input
audio in and out
mouse ports
s-video
composite video
audio L/R
