Epson PowerLite 81p User manual

Projection System Epson original LCD technology
Projection Method Front/rear/ceiling mount
LCD
Size 0.7”
Driving method Epson High Temperature Poly-Silicon TFT
Pixel number 786,432 dots x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom / focus
F-number 1.70 – 1.87
f-number 21.3 – 25.6mm
Zoom ratio 1.0:1.2
Lamp
Type 200W UHE
Life* 2000H (High Brightness), 3000H (Low Brightness)
Screen Width Ratio (Distance/width) 1.44 to 1.76:1
Screen Size (Projected distance) 30” to 300” (2.9’ to 35.4’)
Keystone Correction Vertical: +/-15° Auto Keystone Correction
Brightness (Typical) 2000 ANSI lumens (High Brightness)
1500 ANSI lumens (Low Brightness)
Contrast Ratio (High brightness) 400:1
Brightness Uniformity (Typical) 85%
Color Reproduction 24 bit; 16.7ml
Audio Output 5W Monaural
Operating Temperature 41°F to 95°F (5°C to 35°C)
Power Supply Voltage 100-240VAC +/-10%, 50/60Hz
Power Consumption 280W/5W at sleep mode
Dimensions 10.7” x 13.8” x 4.3”
Weight 8.9lb/4.0kg
Fan Noise 36db (High Brightness),
30db (Low Brightness)
Effective Scanning Frequency Range
Pixel clock 13.5MHz to 230MHz
Horizontal 15KHz to 107KHz
Vertical 50Hz to 120Hz
Remote Control
Features: Source selection, power, page up/page down,
color mode, volume, e-zoom, a/v mute, freeze,
resize, menu, help, pointer
Operating Angle: Right/Left +/- 30 degrees
Upper/Lower +/- 15 degrees
Operating Distance: 20 ft (6m)
RGB
Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1600 x 1200, 1280 x 1024, 800 x 600,
640 x 480
Input terminal
Video Mini D-sub 15 pin x 2
Audio Stereo mini jack x 2
Output terminal
Video Mini D-sub 15pin (monitor out)
Audio Stereo mini-jack
Video I/O
Display performance NTSC: 560 lines
PAL: 560 lines
(Depends on observation of the multi
burst pattern)
Input signal NTSC, NTSC4.43, PAL, M-PAL, N-PAL,
PAL60, SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite Video: RCA (Yellow) x 1;
S-Video: Mini DIN;
Component Video: Mini D-sub 15pin
(in common with Analog RGB connector);
Video-RGB: Mini D-sub 15pin (in common
with Analog RGB connector)
Audio Stereo mini jack x 2
Audio signal 500m Vrms/47Kohm
Control I/O
I/O terminal USB connector series B x 1
(for mouse, keyboard)
Serial: Mini D-sub 9 pin x 1, RS-232C
Security Kensington®-style lock provision
Supplied Accessories
Power cable, remote control with battery, computer cable, audio adapter
cable, USB A/USB B cable, Start Here Kit, soft carrying case
Warranty
Two-year limited warranty, 2-year international warranty, 90-day lamp
warranty, Epson Road Service Program and Epson PrivateLine dedicated
toll-free support (U.S. and Canada only)
Product/Accessory Part Numbers
Epson PowerLite 81p projector V11H157020
Replacement lamp V13H010L30
Air filter set V13H134A06
Samsonite wheeled soft case ELPKS35
ATA molded hardshell case ELPKS51
Ceiling mount ELPMB36
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Security bracket/cabling for gyro lock mounts ELPMBSEC
Adjustable ceiling channel ELPMBACC
Component video cable ELPKC19
S-Video cable ELPSV01
Distribution amplifier ELPDA01
Mac adapter set ELPAP01
50” portable screen ELPSC06
60” portable pop-up screen ELPSC07
80” portable pop-up screen ELPSC08
83.6” hanging pull-down screen ELPSC09
Kensington security lock ELPSL01
High-Resolution Document Imager (ELPDC05) V12H162020
High-Resolution Document Camera (ELPDC04) V12H064020
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
EPSON®
Offering sharp, accurate detail with remarkable XGA
resolution, plus a host of high-performance features, the Epson
PowerLite 81p is ideal for virtually any presentation. Its flexible
connectivity and powerful 5 watt audio make this projector perfect for
any classroom or board room.
Epson high-aperture LCDs work with its brilliant 2000 ANSI lumens to
deliver accurate color, superior color saturation and remarkable image
quality in any setting. And, with four input connections, plus automatic
source selection, setup and operation couldn’t be easier! Just plug it in,
and you’re presenting within seconds.
With whisper-quiet operation, unbeatable reliability and a convenient
carrying case, the Epson PowerLite 81p ensures quality presentations
that really make the grade.
Ultra bright 2000 ANSI lumens for presentations
in any setting
• Works great in large conference rooms and classrooms
Superior image quality and performance
• Three Epson high-aperture LCDs for greater color depth and
color accuracy
• XGA (1024 x 768) resolution for vibrant images with precision
color and detail
Easy setup and operation
• Color-coded cables make setup a breeze
• Audible power-on and -off beeps respond to user commands
• Quick start-up time avoids presentation delays and reduces
presentation jitters
• Source search function automatically displays the connected input
source(s) and switches instantly between various sources
• +/-15º digital keystone correction automatically engages without
manual adjustments
• Optical zoom lens for flexible placement and positioning
• Monitor out capability to display images on a monitor and
screen simultaneously
• Password-protected security features, plus operation lock prevent
against unauthorized use
• Full-featured remote control, including mouse emulation functions
and an electronic pointer for complete presentation control
• Soft carrying case included
Great audio and connectivity
• Powerful 5W audio so there’s no additional audio expense
• Audio out (audio follow-through)
• No costly expansion modules needed; two computer and two
video inputs with dedicated audio for each
• Third-party network monitor and control management
capabilities via the RS232C port
State-of-the-art video performance
• Two video inputs for composite, component (optional cable
required), and S-video compatibility
• HDTV-ready; supports 480i, 480p, 720p, and 1080i formats
Quiet and unobtrusive
• Whisper-quiet operation (36db/30db) ensures the presentation is
the center of attention
• Cooling fan located in front for a comfortable viewing experience
• Lamp and air filter access on top of the projector for easy
changes, even when the projector is ceiling mounted
Outstanding Epson service and support
(free for the duration of the two-year warranty)
• 90-day lamp warranty for added dependability
• Epson Road Service program provides a replacement projector,
typically within 24 hours
• Epson PrivateLineSM dedicated toll-free support line available from
6 a.m. to 6 p.m. PST Monday – Friday
(Calls are answered live, typically in about a minute.)
• International warranty in over 45 countries, exclusively from Epson
SM
Epson PowerLite 81p Specifications
Epson PowerLite®81p
A bright XGA performer that truly makes the grade.
Printed on Recycled Paper
Specifications and terms are subject to change without notice. Epson is a registered trademark of Seiko Epson Corporation. PowerLite is a registered trademark, and Epson Connection, PrivateLine and Presenters
Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks.
© Copyright 2004 Epson America, Inc. CPD-18017 15K 4/04 WP
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Front View
zoom lens
USB type B
computer 2/component video 2
Back View RS-232C
audio 1
high
performance,
low profile
*Lamp life results will vary depending upon mode selected, environmental conditions, and usage.
computer 1/component video 1
monitor out
audio 2
audio
audio out
s-video
full-featured
IR remote control
audio
