Epson FILMSCAN 200 User manual

IMPORTANT NOTICE
All rights reserved. No part of this publication
may be reproduced, stored in a retrieval system,
or transmitted in any form or by any means,
electronic, mechanical, photocopying, recording,
or otherwise, without the prior written
permission of SEIKO EPSON CORPORATION.
The information contained herein is designed
only for use with this EPSON scanner. EPSON is
not responsible for any use of this information as
applied to other scanners.
Neither SEIKO EPSON CORPORATION nor its
affiliates shall be liable to the purchaser of this
product or third parties for damages, losses,
costs, or expenses incurred by the purchaser or
third parties as a result of: accident, misuse, or
abuse of this product or unauthorized
modifications, repairs, or alterations to this
product, or (excluding the U.S.) failure to strictly
comply with SEIKO EPSON CORPORATION’s
operating and maintenance instructions.
SEIKO EPSON CORPORATION shall not be
liable for any damages or problems arising from
the use of any options or any consumable
products other than those designated as Original
EPSON Products or EPSON Approved Products
by SEIKO EPSON CORPORATION.
EPSON is a registered trademark of SEIKO
EPSON CORPORATION. Macintosh is a
registered trademark of Apple Computer, Inc.
Microsoft and Windows are registered
trademarks of Microsoft Corporation.
General Notice: Other product names used herein
are for identification purposes only and may be
trademarks of their respective owners. EPSON
disclaims any and all rights in those marks.
Copyright © 1997 by SEIKO EPSON
CORPORATION, Nagano, Japan.
DECLARATION OF CONFORMITY
According to ISO/IEC Guide 22 and EN 45014
Manufacturer: SEIKO EPSON CORPORATION
Address: 3-5, Owa 3-chome, Suwa-shi,
Nagano-ken 392 Japan
Representative: EPSON EUROPE B.V.
Address: Prof. J. H. Bavincklaan 5 1183
AT Amstelveen
The Netherlands
Declares that the Product:
Product Name: Film scanner
Model: G621A, G621B
Conforms to the following Directive(s) and
Norm(s):
Directive 89/336/EEC:
EN 55022 Class B
EN 61000-3-2
EN 61000-3-3
EN 50082-1
IEC 801-2
IEC 801-3
IEC 801-4
Directive 73/23/EEC:
EN60950
March, 1997
M. Hamamoto
President of EPSON EUROPE B.V.
A NOTE CONCERNING RESPONSIBLE USE
OF COPYRIGHTED MATERIALS
Like photocopiers, film scanners can be misused
by improper photographing of copyrighted
material. Unless you have the advice of a
knowledgeable attorney, be responsible and
respectful by not photographing published
material without the permission of the copyright
holder.
LOnion Ref. Guide
Rev.c
A5 size cover-2
02-07-97 DR, pass 1

Film Scanner
User’s Guide
Proof Sign-off:
Ishizaka _______
Fujimori _______
Grady _______ title page
F-R01
recylogo
®
R
Onion Ref. Guide
Rev.c
A5 size Front
02-07-97 DR, pass 1

Contents
Safety Instructions
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 0-1
For United Kingdom Users . . . . . . . . . . . . . . . . . . . . . 0-2
Warnings, Cautions, and Notes . . . . . . . . . . . . . . . . . . . 0-4
Chapter 1 Getting Started
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . 1-3
For Windows-based systems . . . . . . . . . . . . . . . . . . 1-3
For Macintosh-based systems . . . . . . . . . . . . . . . . . . 1-4
Unpacking the Scanner . . . . . . . . . . . . . . . . . . . . . . . 1-5
Choosing a Place for the Scanner . . . . . . . . . . . . . . . . . . 1-6
Getting to Know the Scanner . . . . . . . . . . . . . . . . . . . . 1-7
Chapter 2 Connecting EPSON FilmScan 200 to Your Computer
Connecting the Parallel Interface Model . . . . . . . . . . . . . . 2-2
Compatible operating systems . . . . . . . . . . . . . . . . . 2-2
Installing the parallel interface board . . . . . . . . . . . . . 2-2
Connecting the scanner to your PC . . . . . . . . . . . . . . 2-3
Connecting the SCSI Interface Model . . . . . . . . . . . . . . . 2-4
Compatible operating systems . . . . . . . . . . . . . . . . . 2-4
SCSI connections . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
Connecting the scanner to your computer or to another SCSI
device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Power-on sequence . . . . . . . . . . . . . . . . . . . . . . . 2-10
LOnion Ref. Guide
Rev.c
A5 size Front
02-07-97 DR, pass 1
ii

Chapter 3 Setting Up the Scanner Software
Installing the Scanner Software in Your PC . . . . . . . . . . . 3-2
Preparing the scanner before installing EPSON TWAIN . 3-2
Installing the software in Windows 95 . . . . . . . . . . . . 3-3
Installing the software in Windows 3.1x or NT 3.5x . . . . 3-8
Installing the software in Windows NT 4.0 . . . . . . . . . 3-9
Installing the Scanner Software in Your Macintosh . . . . . . . 3-10
Calibrating Your Screen . . . . . . . . . . . . . . . . . . . . . . 3-12
Chapter 4 Scanning 35 mm Film Images
Understanding 35 mm Film . . . . . . . . . . . . . . . . . . . . 4-2
Supported film types . . . . . . . . . . . . . . . . . . . . . . 4-2
Base and emulsion sides . . . . . . . . . . . . . . . . . . . . 4-3
Loading 35 mm Negatives and Positives . . . . . . . . . . . . . 4-3
Loading 35 mm Slides . . . . . . . . . . . . . . . . . . . . . . . 4-7
Capturing Images Using EPSON TWAIN . . . . . . . . . . . . 4-9
Starting EPSON TWAIN . . . . . . . . . . . . . . . . . . . . 4-9
Saving the captured image file . . . . . . . . . . . . . . . . 4-19
Removing 35 mm Film From the Carrier . . . . . . . . . . . . . 4-20
Removing 35 mm strip film from the carrier . . . . . . . . . 4-20
Removing 35 mm slides from the carrier . . . . . . . . . . . 4-21
Chapter 5 Scanning Images From Your Film Cartridge
About the Advanced Photo System. . . . . . . . . . . . . . . 5-2
Understanding film cartridges . . . . . . . . . . . . . . . . 5-2
Cartridge handling precautions . . . . . . . . . . . . . . . . 5-3
Loading Cartridge Film . . . . . . . . . . . . . . . . . . . . . . . 5-5
Capturing Images Using EPSON TWAIN . . . . . . . . . . . . 5-8
Starting EPSON TWAIN . . . . . . . . . . . . . . . . . . . . 5-8
Scanning images . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Removing the Advanced Photo System film cartridge
holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-17
Saving the captured image file . . . . . . . . . . . . . . . . . 5-18
Taking the Film Cartridge Out of the Cartridge Holder . . . . 5-19
R
Onion Ref. Guide
Rev.c
A5 size Front
02-07-97 DR, pass 1
iii

Chapter 6 Getting to Know More About EPSON TWAIN
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Selecting a Destination Device and Media Size . . . . . . . . . . 6-3
Adding Destination settings . . . . . . . . . . . . . . . . . . . 6-3
Adding Media Size settings . . . . . . . . . . . . . . . . . . . 6-6
Adjusting the Quality of Scanned Images . . . . . . . . . . . . . 6-9
Modifying visual effects . . . . . . . . . . . . . . . . . . . . . 6-10
Configuring the scanning environment . . . . . . . . . . . . 6-13
Understanding Apple ColorSync. . . . . . . . . . . . . . . 6-16
Rotating an Image . . . . . . . . . . . . . . . . . . . . . . . . . . 6-17
Chapter 7 Troubleshooting
Diagnosing a Problem . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Error indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
Testing the operation of the scanner . . . . . . . . . . . . . . 7-3
Problems and Solutions . . . . . . . . . . . . . . . . . . . . . . . 7-5
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Film carrier and optional cartridge holder . . . . . . . . . . 7-7
EPSON TWAIN operation . . . . . . . . . . . . . . . . . . . 7-8
Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-14
Winding film in the film cartridge holder . . . . . . . . . . . 7-20
Appendix
Maintenance and Transportation . . . . . . . . . . . . . . . . . . A-2
Cleaning the scanner . . . . . . . . . . . . . . . . . . . . . . A-2
Transporting the scanner . . . . . . . . . . . . . . . . . . . . A-3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Mechanical . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
Environmental . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
Safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . A-6
Interface Specifications . . . . . . . . . . . . . . . . . . . . . . . . A-7
Parallel interface . . . . . . . . . . . . . . . . . . . . . . . . . A-7
SCSI interface . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
LOnion Ref. Guide
Rev.c
A5 size Front
02-07-97 DR, pass 1
iv

Initialization Methods . . . . . . . . . . . . . . . . . . . . . . . A-8
Contacting Customer Support . . . . . . . . . . . . . . . . . . . A-9
For United Kingdom and the Republic of Ireland users . . A-9
For Australian users . . . . . . . . . . . . . . . . . . . . . . . A-11
For Singapore users . . . . . . . . . . . . . . . . . . . . . . A-13
For Hong Kong users . . . . . . . . . . . . . . . . . . . . . . A-13
For Philippines users . . . . . . . . . . . . . . . . . . . . . . A-14
Glossary
Index
R
Onion Ref. Guide
Rev.c
A5 size Front
02-07-97 DR, pass 1
v

LOnion Ref. Guide
Rev.c
A5 size Front
02-07-97 DR, pass 1
vi

Safety Instructions
Important Safety Instructions
Read all of these instructions and save them for later reference.
Follow all warnings and instructions marked on the scanner.
❑Unplug the scanner before cleaning. Clean with a damp
cloth only. Do not spill liquid on the scanner.
❑Do not place the scanner on an unstable surface or near a
radiator or heat source.
❑Do not block or cover the scanner’s openings. Do not insert
objects into the openings, except as described in this
manual.
❑Use only the type of power source indicated on the
scanner’s label.
❑Connect all equipment to properly grounded power
outlets. Avoid using outlets on the same circuit as
photocopiers or air control systems that regularly switch
on and off.
❑Do not use a damaged or frayed power cord.
❑If you use an extension cord with the scanner, make sure
the total ampere rating of all devices plugged into the
extension cord does not exceed the cord’s ampere rating.
Also, make sure the total ampere rating of all devices
plugged into the wall outlet does not exceed the wall
outlet’s ampere rating.
❑Except as specifically explained in this user’s guide, do
not attempt to service the scanner yourself.
Proof Sign-off:
Ishizaka _______
Fujimori _______
Grady _______ R
Onion Ref. Guide
Rev.c
A5 size Introduction
02-07-97 DR, pass 1
Safety Instructions 1

❑Unplug the scanner and refer servicing to qualified service
personnel under the following conditions:
If the power cord or plug is damaged; if liquid has entered
the scanner; if the scanner has been dropped or the cabinet
damaged; if the scanner does not operate normally or
exhibits a distinct change in performance. Adjust only those
controls that are covered by the operating instructions.
❑If you plan to use the scanner in Germany, observe the
following:
To provide adequate short-circuit protection and over-current
protection for this scanner, the building installation must be
protected by a 16 Amp circuit breaker.
Bei Anschluß des Scanners an die Stromversorgung muß
sichergestellt werden, daß die Gebäudeinstallation mit
einem 16 A-Überstromschalter abgesichert ist.
For United Kingdom Users
Use of options
Epson (UK) Limited shall not be liable against any damages or
problems arising from the use of any options other than those
designated as Original EPSON Products or EPSON Approved
Products by Epson (UK) Limited.
LOnion Ref. Guide
Rev.c
A5 size Introduction
02-07-97 DR, pass 1
2 Safety Instructions

Safety information
wWarning: This appliance must be earthed. Refer to rating plate
for voltage and check that the appliance voltage corresponds to
the supply voltage.
Important: The wires in the mains lead fitted to this appliance
are coloured in accordance with the following code:
Green and yellow — Earth
Blue — Neutral
Brown — Live
If you have to fit a plug:
As the colours of the mains lead of this appliance may not
match coloured markings used to identify the terminals in a
plug, please proceed as follows:
The green and yellow wire must be connected to the terminal
in the plug which is marked with the letter E or the Earth
symbol (
G
).
The blue wire must be connected to the terminal in the plug
marked with the letter N.
The brown wire must be connected to the terminal in the plug
marked with the letter L.
If damage occurs to the plug, replace the cord set or consult a
qualified electrician.
Replace fuses only with a fuse of the correct size and rating.
R
Onion Ref. Guide
Rev.c
A5 size Introduction
02-07-97 DR, pass 1
Safety Instructions 3

Chapter 1
Getting Started
Proof Sign-off:
Ishizaka _______
Fujimori _______
Grady _______
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . 1-3
For Windows-based systems . . . . . . . . . . . . . . . . . . 1-3
For Macintosh-based systems . . . . . . . . . . . . . . . . . 1-4
Unpacking the Scanner . . . . . . . . . . . . . . . . . . . . . . . 1-5
Choosing a Place for the Scanner . . . . . . . . . . . . . . . . . 1-6
Getting to Know the Scanner . . . . . . . . . . . . . . . . . . . 1-7
1
R
Onion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
Getting Started 1-1

Features
The EPSON FilmScan 200 offers the following features:
❑Parallel model-built-in bidirectional interface, compatible
with Microsoft® Windows®95 and 3.1x.
SCSI model-built-in SCSI interface, compatible with
Microsoft Windows 95, 3.1x, NT®3.5x/4.0, and Apple®
Macintosh®systems.
❑Full color or grayscale (varying shades of gray, from black
to white) scanning. You can scan full color (16 million
colors), 256 color, or grayscale images from 35 mm
negatives and positives.
❑You can scan 35 mm negatives and positives, as well as
mounted 35 mm slides. In addition, you can scan Advanced
Photo Systemimages using the optional cartridge holder.
❑Compact size. It has a smaller and narrower foot print than
most scanners.
❑EPSON TWAIN lets you take full advantage of your
scanner’s advanced features; you can change the captured
color images for output device, modify visual effects
(exposure, gamma, and sharpness setting), and control
the captured image resolution from 50 to 4800 dpi.
LOnion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
1-2 Getting Started

System Requirements
For Windows-based systems
❑IBM®compatible PC with a 486 or Pentium processor
❑Microsoft Windows 95 or Windows 3.1x, for the parallel
interface model
Microsoft Windows 95, Windows 3.1x, or NT 3.5x or later
for the SCSI interface model
❑To use the parallel interface model, a bidirectional parallel
interface board must be installed in your computer.
Because some interface boards may not be fully compatible
with your EPSON FilmScan 200, the EPSON bidirectional
parallel interface board packed with your scanner is
recommended.
To use the SCSI interface model, a SCSI interface board
must be installed in your computer.
❑At least 16MB of RAM (32MB recommended)
❑VGA, Super VGA, or better display adapter and color
monitor 640 ×480 screen resolution (800 ×600 or higher
recommended), and 256-color (65,000-color or higher
recommended)
Note:
When sanning, the required amount of free hard disk space is twice
the size of the image data file.
1
R
Onion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
Getting Started 1-3

For Macintosh-based systems
❑68000 series or Power PC processor
❑System 7.1 or later
❑At least 16MB of RAM (32MB recommended)
At least 3MB of available memory for scanning 35 mm film,
and 6MB of available memory for scanning the Advanced
Photo System cartridge film.
❑Color monitor, 640 ×480 screen resolution (832 ×624 or
higher recommended), and 256-color (32,000-color or
higher recommended)
Note:
When scanning, the required amount of free hard disk space is twice
the size of the image data file.
LOnion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
1-4 Getting Started

Unpacking the Scanner
Make sure you have all the parts shown below.
In some locations, the power cord comes attached to the scanner. The shape of
the AC plug varies by country; be sure the plug included is the right shape for your
location.
35 mm negative and positive carrier
scanner
35 mm slide carrier
CD-ROM and/or floppy disks (media
type and quantity vary depending
on where you purchase the scanner).
new
Bidirectional parallel interface board
(parallel interface model only).
B80818✽
!interfa
power cord
cord
Note:
❑A SCSI interface board and/or SCSI
cable may be included with the SCSI
interface model depending on where
you purchased the scanner.
❑A parallel interface cable may be
included with the parallel interface
model depending on where you
purchased the scanner.
1
R
Onion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
Getting Started 1-5

Remove all protective materials packed with your scanner
before you set it up and turn on the power. Save all packaging
and protective materials in case you need to transport the
scanner later.
Choosing a Place for the Scanner
Follow the guidelines listed below when selecting a location for
your scanner:
❑Place the scanner on a flat, stable surface. The scanner will
not operate properly if it is tilted or at an angle.
❑Place the scanner close enough to the computer for the
interface cable to reach it easily.
❑Allow some space behind the scanner for the cables, and
make sure to place the scanner where you can easily
unplug the power cord. Also allow sufficient space in front
of and behind the scanner so that the film carrier can move
fully forward and backward while scanning the images.
❑Keep the scanner away from high temperatures and
humidity. Also avoid using or storing the scanner in places
subject to rapid changes of temperature and humidity.
❑Keep the scanner away from direct sunlight and strong
light sources.
❑Avoid places subject to shocks and vibrations.
06-n
LOnion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
1-6 Getting Started

Getting to Know the Scanner
After you unpack your scanner, take a few minutes to learn
about its features, as shown below.
Front
READY light
On when the scanner is ready to scan. Flashes
to indicate that an error has occurred. See
“Error indicators” in Chapter 7 for more
information.
OPERATE button
Turns on or off
the scanner.
Carrier slot and scanner door
Insert a 35 mm film carrier or
the optional cartridge holder
into this slot. Do not insert
other objects. Button
Press this button and push down the scanner
door before inserting the optional cartridge
holder into the scanner. Be sure to push down
the scanner door again to close the door.
OPERATE light
On when the scanner is
turned on.
RESET button
Restarts the scanner.
09test
ERROR light
Flashing or on
if an error occurs.
1
R
Onion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
Getting Started 1-7

Back
Parallel interface model
SCSI interface model
Ground connector
Connect the ground wire
here if your interface cable
has one.
AC inlet
Connect the power
cord here.
Parallel interface connector
Connect the parallel interface
cable here.
03
Terminator switch
Use this to turn the SCSI
terminator on or off.
SCSI ID rotary dial
Set the SCSI ID here.
50-pin SCSI connector
Connect the 50-pin end of
a SCSI cable here.
25-pin SCSI connector
Connect the 25-pin end of
a SCSI cable here.
Ground connector
Connect the ground wire
here if your interface
cable has one.
AC inlet
Connect the power
cord here.
02
LOnion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
1-8 Getting Started

Film carrier
Cartridge holder (option)
For 35 mm negatives
or positives
04
For 35 mm slides
05
For Advanced Photo System
cartridge film
Code: B81309✽
24
1
R
Onion Ref. Guide
Rev.c
A5 size Chapter 1
02-07-97 DR, pass 0
Getting Started 1-9
