Where to Find Information
Setup Guide (this document)
Describes how to set up and use the scanner. Basic scanning
operations are covered. It also explains how to install and
configure the EPSON scanner software and the Automatic
Document Feeder, and includes information on how to calibrate
your system. The guide describes how to make basic software
settings, use the Start Button function, and scan images in a
networked environment.
Online Reference Guide
Provides basic information about scanning, detailed reference on
settings and functions of EPSON TWAIN HS and other EPSON
scanner utility software, troubleshooting tips, and customer
support information. Explanations about EPSONTWAIN HS also
apply to EPSON TWAIN HS Network. It also explains how to set
up the scanner server PC. To access the Online Reference Guide,
see “Getting Information from Online Reference Guide” on page
4-31 in this guide.
Information on EPSON TWAIN HS and EPSON TWAIN HS Network
(online help)
Provides you with detailed information on EPSON TWAIN HS
and EPSON TWAIN HS Network. To display the online help,
click the Help button in the dialog box of EPSON TWAIN HS or
EPSON TWAIN HS Network.
Information on ISIS driver
Refer to the respective documentation provided on the EPSON
Scanner Software CD-ROM.
